Monitor your containers with the Elastic Stack

Containers as well as orchestration systems like Kubernetes are quickly gaining popularity as the prefered tools for deploying and running microservices. While being easier to deploy and isolate, containerized applications are creating new challenges for the logging and monitoring systems.

One popular solution for logging and monitoring is the Elastic Stack composed of Elasticsearch, Logstash, Kibana, and Beats. This talk shows you how to use the Elastic Stack, and in particular the Beats lightweight shippers, to collect logs and metrics from your containers.

The session includes details about how to:
fetch the logs of the containers with Filebeat
collect container metrics with Metricbeat
monitor the network traffic exchanged between containers with Packetbeat
automatically discover metadata from Docker containers
visualize the collected data with predefined Kibana dashboards
scaling Logstash deployments

Transcript

2. Monitor your containers with the Elastic Stack Monica Sarbu
3. 3 Monica Sarbu Team lead, Beats team monica@elastic.co @monicasarbu
4. Monitor your containers with the Elastic Stack
5. @monicasarbu Elastic Stack 5
6. Beats are lightweight shippers that collect and ship all kinds of operational data to Elasticsearch
7. @monicasarbu Multiple data types, one place 7 •Docker metrics •flows •MySQL logs •diskIO •HTTP transactions •MySQL transactions •Redis metrics •Apache logs •Redis logs •CPU % •Docker metrics •Docker logs •memory % •filesystem •Redis transactions •flows
8. @monicasarbu Central point for your distributed infrastructure 8
9. @monicasarbu The Beats 9 30+ other community Beats shipping
10. Filebeat 10
11. • Tails log files, without parsing them • “At least once” guarantees, handles backpressure • Extra powers: • Multiline • JSON logs • Filtering 11 Filebeat
12. @monicasarbu Parse log lines with Ingest Node 12 I N G E S T
13. @monicasarbu Parse log lines with Logstash 13 I N G E S T
14. Filebeat Back pressure handling 14
15. @monicasarbu Why back-pressure is key? 15
16. @monicasarbu Synchronous sending 16 batch of messages ack stream of log lines read read acked registry file
17. • Filebeat adapts its speed automatically to as much as the next stage can process • But: be aware when benchmarking 17 This means..
18. • Filebeat patiently waits • Log lines are not lost • It doesn’t allocate memory, it doesn’t buffer things on disk 18 When the next stage is down..
19. Filebeat Collect container logs 19
20. @monicasarbu Docker logging drivers 20 https://docs.docker.com/engine/admin/logging/overview/
21. @monicasarbu Centralize Docker logs: option 1/522 • Use the Docker gelf driver and the Logstash-gelf-input • Pros: • No shipper to install, send directly to Logstash • Cons: • UDP based, no delivery guarantees, no congestion control 21
22. @monicasarbu Centralize Docker logs: option 2/522 • Use the Docker JSON driver, use Filebeat with the JSON support • Pros: • Simple (default driver) • Easy to add container metadata (name, labels, etc.) • `docker logs` works • Cons: • JSON driver can slow down Docker 22
23. @monicasarbu Centralize Docker logs: option 3/522 • Use the Docker syslog driver, and a local syslog server, then Filebeat for shipping • Pros: • Good control over the path where the files are written, rotation strategies, etc. • Cons: • you need to manage the syslog server • metadata is serialized as string, needs to be de- serialized again (opportunity for mistakes) • multiline is difficult because data from containers can be mixed 23
24. @monicasarbu Centralize Docker logs: option 4/522 • Use the Docker journald driver then Filebeat for shipping • Pros: • journald is often already available • convenient support for metadata • `docker logs` works • Cons: • Filebeat doesn’t yet support journald (a Journalbeat exists, however) 24
25. @monicasarbu Centralize Docker logs: option 5/522 • Mount a volume and have your app write logs into the volume • Pros: • If your app can rotate it’s own logs, it’s very easy to setup • Scales well • Cons: • Difficult to pass metadata 25
26. @monicasarbu Centralize Docker logs: conclusion • json driver, syslog driver, and shared volume are pretty good options today • journald driver might be better options in the future 26
27. Metricbeat 27 new in 5.0
28. @monicasarbu One Metricbeat module for each service 28 + Add your own
29. @monicasarbu Metricbeat system module 29 CPU Mem diskIO filesystem processes load network cores
30. Metricbeat Collect container metrics 30
31. @monicasarbu Querying the Docker API • Dedicated Docker module • Has access to container names and labels • Easy to setup • Offers: • CPU and memory • Docker container information • network (in/out bytes, dropped) • diskIO (reads/writes) • status of containers (# of stopped, running, etc) 31 in progress
32. @monicasarbu Reading cgroup data from /proc/ • Doesn’t require access to the Docker API (can be a security issue) • Works for any container runtime (Docker, rkt, runC, LXD, etc.) • Part of the system module • Automatically enhances process data with cgroup information • Cannot get the container name and labels 32
33. @monicasarbu Run as a container 33 App1 App2 App3 Host
34. 34 Elasticsearch as time series DB
35. #velo @monicasarbu Elasticsearch BKD trees 35 • Added for Geo-points • faster to index • faster to query • more disk-efficient • more memory efficient
36. @monicasarbu 0 10000 20000 30000 40000 50000 60000 70000 80000 float half float scaled float (factor = 4000) scaled float (factor = 100) On Disk Usage in kb Points disk usage (kb) docs_values disk usage (kb) Float values 36 • half floats • scaled floats (using a scaling factor) - great for things like percentage points
37. #velo @monicasarbu Why Elasticsearch for time series • Horizontal scalability. Mature and battle tested cluster support. • Flexible aggregations (incl moving averages & Holt Winters) • One system for both logs and metrics • Timelion UI, Grafana • Great ecosystem: e.g. alerting tools 37
38. Packetbeat 38
39. @monicasarbu Supported traffic decoders 39 + Add your own http:// Thrift DNS ICMP AMQP
40. @monicasarbu Unknown traffic, use flows •Look into data for which we don’t understand the application layer protocol •TLS •Protocols we don’t yet support •Get data about IP / TCP / UDP layers •number of packets & bytes •retransmissions •inter-arrival time 40
41. Packetbeat Monitor traffic exchanged between your containers 41
42. @monicasarbu Monitor outside containers 42 App1 Host App2 App3 Packetbeat traffic exchanged between your containers
43. 43 Demo: Metricbeat, Filebeat, Packetbeat Multiple data types, one view in Kibana
44. Thank you • github.com/elastic/beats • discuss.elastic.co • @elastic #elasticbeats • #beats on freenode 44
