1. DRUID
   A REAL-TIME ANALYTICAL DATA STORE NISHANT BANGARWA DRUID COMMITTER DRUID.IO @DRUIDIO
2. 2014 THIS PRESENTATION ‣ Demo ‣ Problems ‣ Druid Architecture ‣ Benchmarks and numbers ‣ Many hard problems looking for solutions
3. DEMO IN CASE THE INTERNET DIDN’T WORK PRETEND YOU SAW SOMETHING COOL
4. PROBLEMS
5. 2013 WE HAVE LOT OF EVENT DATA! timestamp page language city country ... added deleted! 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65! 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62! 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45! 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53! ...
6. 2014 DATA EXPLORATION
7. 2014 DATA INGESTION
8. 2014 AVAILABILITY
9. WHAT WE TRIED
10. 2014 I. RDBMS - Relational Database WHAT WE TRIED
11. 2014 ‣ Star Schema ‣ Aggregate Tables ‣ Query Caching I. RDBMS - THE SETUP
12. 2014 ‣ Queries that were cached • fast ‣ Queries against aggregate tables • fast to acceptable ‣ Queries against base fact table • generally unacceptable I. RDBMS - THE RESULTS
13. 2014 I. RDBMS - PERFORMANCE Naive benchmark scan rate ~5.5M rows / second / core 1 day of summarized aggregates 60M+ rows 1 query over 1 week, 16 cores ~5 seconds Page load with 20 queries over a week of data long time
14. 2014 I. RDBMS - Relational Database WHAT WE TRIED
15. 2014 I. RDMBS - Relational Database II.NoSQL - Key/Value Store WHAT WE TRIED
16. 2014 ‣ Pre-aggregate all dimensional combinations ‣ Store results in a NoSQL store II. NOSQL - THE SETUP ts gender age revenue 1 M 18 US$ 0.15 1 F 25 US$ 1.03 1 F 18 US$ 0.01 Key Value 1 revenue=$1.19 1,M revenue=$0.15 1,F revenue=$1.04 1,18 revenue=$0.16 1,25 revenue=$1.03 1,M,18 revenue=$0.15 1,F,18 revenue=$0.01 1,F,25 revenue=$1.03
17. 2014 ‣ Queries were fast • range scan on primary key ‣ Inflexible • not aggregated, not available ‣ Not continuously updated • aggregate first, then display ‣ Processing scales exponentially II. NOSQL - THE RESULTS
18. 2014 ‣ Dimensional combinations => exponential increase ‣ Tried limiting dimensional depth • still expands exponentially ‣ Example: ~500k records • 11 dimensions, 5-deep • 4.5 hours on a 15-node Hadoop cluster • 14 dimensions, 5-deep • 9 hours on a 25-node Hadoop cluster II. NOSQL - PERFORMANCE
19. 2014 I. RDMBS - Relational Database II.NoSQL - Key/Value Store WHAT WE TRIED
20. 2014 I. RDMBS - Relational Database II.NoSQL - Key/Value Store III. ??? WHAT WE TRIED
21. 2014 ‣ Problem with RDBMS: scans are slow ‣ Problem with NoSQL: computationally intractable WHAT WE LEARNED
22. 2014 ‣ Problem with RDBMS: scans are slow ‣ Problem with NoSQL: computationally intractable ! ! ! ! ! ‣ Tackling the RDBMS issue seems easier WHAT WE LEARNED
23. “ ” INTRODUCING DRUID
24. 2014 WHAT IS DRUID? ‣ Open-source ‣ Column-oriented ‣ Distributed ‣ Fast ‣ Real-time ‣ Highly-Available ‣ Approximate or Exact ‣ Data store
25. ARCHITECTURE
26. 2014 ARCHITECTURE Realtime Nodes Query API
27. 2014 ‣ Log-structured merge-tree ‣ Ingest data and buffer events in memory in a write-optimized data structure ‣ Periodically persist collected events to disk (converting to a read-optimized format) ‣ Query data as soon as it is ingested REAL-TIME NODES
28. 2014 ARCHITECTURE Realtime Nodes Query API Query API Historical Nodes a Hand Off Data
29. 2014 ‣ Main workhorses of a Druid cluster ‣ Shared-nothing architecture ‣ Load immutable read-optimized data ‣ Respond to queries HISTORICAL NODES
30. 2014 ARCHITECTURE Query API Historical Nodes Realtime Nodes Query API Broker Nodes Query API Query Rewrite Scatter/Gather a Hand Off Data
31. 2014 ‣ Query scatter/gather (send requests to nodes and merge results) ‣ (Distributed) Caching BROKER NODES
32. Historical Nodes Broker Nodes Real-time Nodes Data Stream Coordinator Nodes Queries ARCHITECTURE a Hand Off Data
33. 2013 • Distributes data across historical nodes • Assigns historical nodes to load & drop data • Manages replication COORDINATOR NODES
34. 2013 DATA! timestamp page language city country ... added deleted! 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65! 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62! 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45! 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53! ...
35. 2014 COLUMN COMPRESSION · DICTIONARIES ‣ Create ids • Justin Bieber -> 0, Ke$ha -> 1 ‣ Store • page -> [0 0 0 1 1 1] • language -> [0 0 0 0 0 0] timestamp page language city country ... added deleted! 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65! 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62! 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45! 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53! ...
36. 2014 BITMAP INDICES ‣ Justin Bieber -> [0, 1, 2] -> [111000] ‣ Ke$ha -> [3, 4, 5] -> [000111] ‣ Compressed with CONCISE timestamp page language city country ... added deleted! 2011-01-01T00:01:35Z Justin Bieber en SF USA 10 65! 2011-01-01T00:03:63Z Justin Bieber en SF USA 15 62! 2011-01-01T00:04:51Z Justin Bieber en SF USA 32 45! 2011-01-01T01:00:00Z Ke$ha en Calgary CA 17 87! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 43 99! 2011-01-01T02:00:00Z Ke$ha en Calgary CA 12 53! ...
37. 2014 FAST AND FLEXIBLE QUERIES JUSTIN BIEBER [1, 1, 0, 0] KE$HA [0, 0, 1, 1] JUSTIN BIEBER OR KE$HA [1, 1, 1, 1] row page 0 Justin(Bieber 1 Justin(Bieber 2 Ke$ha 3 Ke$ha
38. DRUID IN PRACTICE
39. 2014 REALTIME INGESTION >200K EVENTS / SECOND SUSTAINED 10 – 100K EVENTS / SECOND / CORE ! ! ! DRUID IN PRODUCTION
40. 2014 CLUSTER SIZE
 150TB OF DATA (~10 TRILLION RAW EVENTS)
 >2000 CORES (>100 NODES, 15TB RAM) ! IT’S CHEAP
 MOST COST EFFECTIVE AT THIS SCALE DRUID IN PRODUCTION
41. 2014 0.0 0.5 1.0 1.5 0 1 2 3 4 0 5 10 15 20 90%ile 95%ile 99%ile Feb 03 Feb 10 Feb 17 Feb 24 time query time (seconds) datasource a b c d e f g h Query latency percentiles QUERY LATENCY (500MS AVERAGE) 90% < 1S 95% < 5S 99% < 10S ! ! ! DRUID IN PRODUCTION
42. 2014 QUERY VOLUME >1000 QUERIES / MINUTE VARIETY OF GROUP BY & TOP-K QUERIES ! ! ! DRUID IN PRODUCTION
43. 2013 REPLICATION ROLLING DEPLOYMENTS + RESTARTS GROW = START PROCESSES SHRINK = KILL PROCESSES 2 YEARS · NO DOWNTIME FOR SOFTWARE UPDATE AVAILABILITY
44. 2013 DRUID AS A PLATFORM Batch Ingestion (Hadoop) Streaming Ingestion (Storm) Druid Approximate Algorithms Machine Learning (SciPy, R, ScalaNLP) Visualizations
45. 2014 LOOKING FOR COLLABORATION ‣ Druid is open source ! ‣ Multi-tenancy • Tied Requests, Better resource management, query prioritization ‣ Approximate Algorithms • must be memory bounded and allow distributed folding • e.g. HyperLogLog, approximate histograms, t-digest ‣ Memory bounded, fast, distributed Joins
46. THANK YOU
47. Fangjin Yang & Nelson Ray 2013 • Eric Tschetter • Fangjin Yang • Xavier Léauté • Gian Merlino ACKNOWLEDGEMENTS
48. Compute Nodes Broker Nodes Real-time Nodes Zookeeper Queries MySQL Data Stream Master Nodes ARCHITECTURE Deep Storage
