2015 Ohio LinuxFest Assimilation Talk

Overview of the Assimilation Project for the 2015 Ohio LinuxFest.

Transcript

1. How to Painlessly Discover What You
   How to Painlessly Discover What You
   Don't Know - Before It Bites You
   Don't Know - Before It Bites You
   #AssimProj @OSSAlanR
   http://assimproj.org/
   Alan Robertson
   Assimilation Systems Limited
   http://assimilationsystems.com


   View Slide

2. © 2015 Assimilation Systems Limited
   2/45
   Biography
   Biography
   ●
   35+ years in IT/development – 10 years in
   system management (SysAdmin)
   ●
   Founded Linux-HA project - led 1998-2007 –
   aka “Heartbeat” - now called Pacemaker
   ●
   Founded Assimilation Project in 2010
   ●
   Founded Assimilation Systems Limited in 2013
   ●
   Alumnus of Bell Labs, SuSE, IBM


   View Slide

3. © 2015 Assimilation Systems Limited
   3/45
   Disturbing Trends...
   Disturbing Trends...
   ●
   30% of all break-ins come through “lost” systems (Verizon)
   ●
   90% have had failures of unmonitored services (Turnbull)
   ●
   80% are unable to keep systems in compliance (Verizon)
   ●
   30% start monitoring only after a problem (Turnbull)
   ●
   30% of all systems are doing nothing useful (Koomey)
   ●
   Many sites have trouble scaling monitoring (Turnbull)
   ●
   Larger site admins often don’t know dependencies
   ●
   Documentation is incomplete, out of date, expensive


   View Slide

4. © 2015 Assimilation Systems Limited
   4/45
   Assimilation Project Evolution
   Assimilation Project Evolution
   ●
   Inspired by 2 million core computer
   (cyclops64)
   ●
   Concerns for extreme scale
   ●
   Topology aware monitoring
   ●
   Topology discovery w/out security issues
   =►Discovery of everything!


   View Slide

5. © 2015 Assimilation Systems Limited
   5/45
   A 6-dimensional overview
   A 6-dimensional overview
   1.System Management Suite Overview
   2.Basic Technology
   3.Best Practice Analyses
   4.Demo
   5.Current Status
   6.What You Need To Do!


   View Slide

6. © 2015 Assimilation Systems Limited
   6/45
   Why
   Why the Assimilation System
   the Assimilation System
   Management Suite?
   Management Suite?
   ●
   Provides insight and details through a graph-model CMDB
   ●
   Helps you understand and automate your environment
   – Reduce Errors
   – Speed up problem resolution
   ●
   Reduces Manual Documentation
   ●
   CMDB-driven configuration => near-zero configuration
   ●
   Automates Monitoring
   ●
   Enhances Security
   ●
   Designed for Extreme Scale


   View Slide

7. © 2015 Assimilation Systems Limited
   7/45
   What's in the Suite?
   What's in the Suite?
   ●
   Graph CMDB
   ●
   Exception Monitoring
   ●
   Security Discovery
   ●
   Network Connections


   View Slide

8. Complexity
   Complexity
   “Complexity is the enemy of reliability”
   ●
   Complexity likely your single biggest
   problem
   – Near-zero configuration reduces complexity
   – Tight service integration reduces complexity
   – Accurate detailed view improves complexity
   management


   View Slide

9. © 2015 Assimilation Systems Limited
   9/45
   Highly Scalable Discovery-Driven
   Highly Scalable Discovery-Driven
   Automation
   Automation
   Continuous Discovery drives everything
   ●
   Continuous extensible discovery (CMDB)
   – systems, switches, services, dependencies – zero
   network footprint discovery process
   ●
   Extensible exception monitoring
   – more than 100K systems
   ●
   Discovery Drives Best Practice Analyses
   – Initially concentrating on security
   ●
   All data goes into central graph CMDB


   View Slide

10. © 2015 Assimilation Systems Limited
    10/45
    This all sounds unreasonable...
    This all sounds unreasonable...
    ●
    Huge scalability without complexity?
    ●
    Discovery without pings or port scans?
    Really?


    View Slide

11. © 2015 Assimilation Systems Limited
    11/45
    S
    Simple Scalability
    imple Scalability
    I can explain how we scale so your
    grandmother would understand...
    istockphoto
    ©bowdenimages


    View Slide

12. © 2015 Assimilation Systems Limited
    12/45
    Massive Scalability –
    Massive Scalability – or
    or
    “I see dead servers in
    “I see dead servers in O
    O(1) time”
    (1) time”
    ●
    Adding systems does not increase the monitoring work on any system
    ●
    Each server monitors 2 (or 4) neighbors
    ●
    Each server monitors and discovers its own services
    ●
    Ring repair and alerting is O(n) – but a very small amount of work
    Current Implementation


    View Slide

13. © 2015 Assimilation Systems Limited
    13/45
    Minimizing Network Footprint
    Minimizing Network Footprint
    (in our roadmap)
    (in our roadmap)
    ●
    Support diagnosing switch issues
    ●
    Minimize network traffic
    ●
    Ideal for multi-site arrangements


    View Slide

14. © 2015 Assimilation Systems Limited
    14/45
    Service Monitoring based on HA
    Service Monitoring based on HA
    Technologies
    Technologies
    ●
    Well-proven architecture:
    – reliable “no news is good news”
    ●
    Implements Open Cluster Framework
    standard (LSB and others – Nagios coming!)
    ●
    Each system monitors own services
    ●
    Can also start, stop, migrate services


    View Slide

15. © 2015 Assimilation Systems Limited
    15/45
    How does discovery work?
    How does discovery work?
    Nanoprobe scripts perform discovery
    ●
    Each discovers one kind of information
    ●
    Can take arguments from environment
    ●
    Output JSON
    CMA stores Discovery Information
    ●
    JSON stored in Neo4j database
    ●
    CMA discovery plugins => graph nodes and relationships


    View Slide

16. © 2015 Assimilation Systems Limited
    16/45
    OS discovery JSON Snippet
    OS discovery JSON Snippet
    { "nodename": "alanr-1225B",
    "operating-system": "GNU/Linux",
    "machine": "x86_64",
    "processor": "x86_64",
    "hardware-platform": "x86_64",
    "kernel-name": "Linux",
    "kernel-release": "3.8.0-31-generic",
    "kernel-version": "#46-Ubuntu SMP ...",
    "Distributor ID": "Ubuntu",
    "Description": "Ubuntu 13.04",
    "Release": "13.04",
    "Codename": "raring" }


    View Slide

17. © 2015 Assimilation Systems Limited
    17/45
    "sshd": {
    "exe": "/usr/sbin/sshd",
    "cmdline": [ "/usr/sbin/sshd", "-D" ],
    "uid": "root",
    "gid": "root",
    "cwd": "/",
    "listenaddrs": {
    "0.0.0.0:22": {
    "proto": "tcp",
    "addr": "0.0.0.0",
    "port": 22 },
    sshd
    sshd Service
    Service JSON Snippet
    JSON Snippet
    (from netstat and /proc)
    (from netstat and /proc)


    View Slide

18. © 2015 Assimilation Systems Limited
    18/45
    "ssh": {
    "exe": "/usr/sbin/ssh",
    "cmdline": [ "ssh", "servidor" ],
    "uid": "alanr",
    "gid": "alanr",
    "cwd": "/home/alanr/monitor/src",
    "clientaddrs": {
    "10.10.10.5:22": {
    "proto": "tcp",
    "addr": "10.10.10.5",
    "port": 22 },
    ssh
    ssh Client
    Client JSON Snippet
    JSON Snippet
    (from netstat and /proc)
    (from netstat and /proc)


    View Slide

19. © 2015 Assimilation Systems Limited
    19/45
    Service Dependency Graph
    Service Dependency Graph


    View Slide

20. © 2015 Assimilation Systems Limited
    20/45
    Switch Discovery Graph
    Switch Discovery Graph
    from LLDP (or CDP)
    from LLDP (or CDP)


    View Slide

21. © 2015 Assimilation Systems Limited
    21/45
    Why a graph database? (Neo4j)
    Why a graph database? (Neo4j)
    ●
    Humans describe systems as graphs
    ●
    Dependency & Discovery information: graph
    ●
    Speed of graph traversals depends on size of
    subgraph, not total graph size
    ●
    Root cause queries  graph traversals –
    notoriously slow in relational databases
    ●
    Visualization is Natural
    ●
    Schema-less design: good for constantly changing
    heterogeneous environment
    ●
    Graph Model === Object Model


    View Slide

22. © 2015 Assimilation Systems Limited
    22/45
    A Few Canned Queries
    A Few Canned Queries
    allipports get all port/ip/service/hosts
    allswitchports get switch connections
    crashed get crashed servers
    shutdown get gracefully shutdown servers
    downservices get nonworking services
    findip get system owning IP
    findmac get system owning MAC
    unknownips get unknown IP addresses
    unmonitored get unmonitored services


    View Slide

23. © 2015 Assimilation Systems Limited
    23/45
    B
    Best Practice Analyses
    est Practice Analyses
    Under active development
    ●
    Triggered by Discovery Updates
    – Analysis occurs within seconds of change
    – No change => No analysis
    ●
    We can analyze anything discovered
    ●
    Expect to create alerts and reports
    ●
    SIEM integration


    View Slide

24. © 2015 Assimilation Systems Limited
    24/45
    Sample Security Best Practices
    Sample Security Best Practices
    ●
    Inappropriate services (telnet, etc)
    ●
    Settings in /proc/sys/
    ●
    Security Patch Coverage
    – OS vendor (RedHat, SuSE, Canonical, etc)
    – Application (Oracle, IBM, WordPress, etc)
    ●
    Other OS settings
    ●
    Common Application Settings
    ●
    Looking at best practices
    FYI: Collaborating with Lynis project and Linux Foundation


    View Slide

25. © 2015 Assimilation Systems Limited
    25/45
    Other Sample Security Features
    Other Sample Security Features
    ●
    Discovery of “forgotten” IP addresses
    ●
    Monitoring of Open Ports and Services
    ●
    Collection of network-facing app checksums
    ●
    Nmon profiling of new MAC addresses
    ●
    Checksum outliers analysis
    ●
    Security Best Practice Analyses


    View Slide

26. © 2015 Assimilation Systems Limited
    26/45
    IT Best Practices Project
    IT Best Practices Project
    ITBestPractices.info
    ●
    IT-Bestpractices GitHub project
    ●
    Working on Linux Foundation Sponsorship
    ●
    Apache 2 License (or similar)
    ●
    Initial Sources
    – DISA STIGs
    – Lynis project
    – Individual contributions


    View Slide

27. © 2015 Assimilation Systems Limited
    27/45
    IT Best Practices Goals
    IT Best Practices Goals
    ●
    Make Best Practice rules available in JSON
    – Curate mechanically-verifiable practices
    – Human-readable descriptions of issues and
    remedies
    – Multiple language support
    – Not limited to security best practices
    – Web server under development


    View Slide

28. © 2015 Assimilation Systems Limited
    28/45
    Sample short description
    Sample short description
    The system must limit the ability of processes to
    have simultaneous write and execute access to
    memory.


    View Slide

29. © 2015 Assimilation Systems Limited
    29/45
    Sample long description
    Sample long description
    ExecShield uses the segmentation feature on all
    x86 systems to prevent execution in memory
    higher than a certain address. It writes an address
    as a limit in the code segment descriptor, to control
    where code can be executed, on a per-process
    basis. When the kernel places a process's memory
    regions such as the stack and heap higher than
    this address, the hardware prevents execution in
    that address range.


    View Slide

30. © 2015 Assimilation Systems Limited
    30/45
    Sample Security Rule check
    Sample Security Rule check
    The status of the "kernel.exec-shield" kernel parameter can
    be queried by running the following command:
    $ sysctl kernel.exec-shield
    $ grep kernel.exec-shield /etc/sysctl.conf
    The output of the command should indicate a value of "1". If
    this value is not the default value, investigate how it could
    have been adjusted at runtime, and verify it is not set
    improperly in "/etc/sysctl.conf".
    If the correct value is not returned, this is a finding.


    View Slide

31. © 2015 Assimilation Systems Limited
    31/45
    Assimilation /proc/sys Rule
    Assimilation /proc/sys Rule
    Disallow executing code on writable pages
    “nist_V-38597”:
    {“rule”: “EQ($kernel.exec-shield, 1)”,
    “category”: “security”
    }


    View Slide

32. © 2015 Assimilation Systems Limited
    32/45
    Assimilation Networking Rule
    Assimilation Networking Rule
    Buffer bloat prevention
    “itbp-0001”:
    {“rule”: “IN($kernel.core.default_qdisc,
    fq_codel, codel)”,
    “category”: “networking”
    }


    View Slide

33. © 2015 Assimilation Systems Limited
    33/45
    D
    Discovery / Monitoring / Best
    iscovery / Monitoring / Best
    Practices Demo
    Practices Demo
    ●
    Demonstrate basic capabilities
    – Discovery-driven monitoring configuration
    – Discovery-driven 'tripwire-like' checksums
    – Monitoring – failures / successes
    – Host down notification
    – Best Practices
    ●
    No configuration was supplied
    – everything comes from discovery
    http://assimilationsystems.com/90_second_demo/


    View Slide

34. © 2015 Assimilation Systems Limited
    34/45
    Current Status
    Current Status
    ●
    1.0 (Independence Day) release out 4 July 2015
    ●
    Security is our next major emphasis
    ●
    Great unit and system tests
    ●
    Strongly encrypted communication
    ●
    Quite a few discovery methods written
    ●
    Extensible Automated Discovery Triggers
    ●
    Discovery => Automatic Monitoring + Network-Facing Checksums
    ●
    Compatible with Nagios remote monitoring agent API
    ●
    REST + Command Line Queries


    View Slide

35. © 2015 Assimilation Systems Limited
    35/45
    Get Involved!
    Get Involved!
    ●
    Trials! Early Adopters!
    ●
    Contributors
    – Testers, Continuous Integration
    – Best practice experts
    – Designers
    – Developers (C, Python, Shell, PowerShell, JavaScript)
    – Porters (esp Windows)
    – Promoters, Publicists, Packagers, etc.


    View Slide

36. © 2015 Assimilation Systems Limited
    36/45
    Resistance Is Futile!
    Resistance Is Futile!
    These slides: bit.ly/DOSUG0915
    Mailing List: bit.ly/AssimML
    @OSSAlanR
    #assimilation on irc.freenode.net
    Project Web Site: assimproj.org
    Company Web Site: assimilationsystems.com
    Download: assimilationsystems.com/download


    View Slide

37. © 2015 Assimilation Systems Limited
    37/45
    Risk Management/Mitigation
    Risk Management/Mitigation
    ●
    Intrusions
    ●
    Vulnerable Software
    ●
    Licensed Software
    ●
    Audit Risk
    ●
    Outages
    ●
    System management


    View Slide

38. © 2015 Assimilation Systems Limited
    38/45
    Monitoring Pros and Cons
    Monitoring Pros and Cons
    Pros
    Simple & Scalable
    Uniform work distribution
    No single point of failure
    Distinguishes switch vs
    host failure
    Easy on LAN, WAN
    Multi-tenant approach
    Cons
    Active agents
    Potential slowness
    at power-on


    View Slide

39. © 2015 Assimilation Systems Limited
    39/45
    Sixth Dimension:
    Sixth Dimension:
    Graph Schema
    Graph Schema
    Two Schema subgraphs
    ●
    Client / server
    dependency
    ●
    Switch interconnect


    View Slide

40. First Dimension
    First Dimension:
    :
    Problems Addressed
    Problems Addressed
    ●
    Discovering and maintaining documentation
    (CMDB) using continuous discovery
    – Services, Systems, Dependencies, Switches, Interconnects,
    Configuration
    ●
    Monitoring and alerting: services, systems and
    compliance
    ●
    Managing compliance
    ●
    Mitigating risk


    View Slide

41. © 2015 Assimilation Systems Limited
    43/45
    Why Discovery? (DevOps)
    Why Discovery? (DevOps)
    ●
    Documentation: incomplete, incorrect
    ●
    Dependencies: unknown
    ●
    Planning: Needs accurate data
    ●
    Best Practices: Verification needs data
    ●
    ITIL CMDB (Configuration Management
    Data Base)
    Our Discovery: continuous, low-profile


    View Slide

42. © 2015 Assimilation Systems Limited
    44/45
    Second Dimension:
    Second Dimension:
    Unique Powerful Features
    Unique Powerful Features
    1. Continuous Discovery
    2. Discovery: Zero network footprint
    3. Centralized graph database
    4. We know everything that changes
    5. Discover and update dependency information
    6. Discovery and monitoring tightly integrated –
    discovery drives automation


    View Slide

43. © 2015 Assimilation Systems Limited
    45/45
    (even more) Features...
    (even more) Features...
    7. Discovery and monitoring easily extensible
    8. Naturally scalable to > 100K systems
    9. Minimal network load
    10.Server failures distinguishable from switch failures
    11.Best practice and vulnerability alerts
    12.Multi-tenant support


    View Slide

44. © 2015 Assimilation Systems Limited
    46/45
    Third Dimension:
    Third Dimension:
    Fully distributed work
    Fully distributed work
    Two philosophical underpinnings
    1. Monitoring and Discovery are fully distributed
    2. Reliable “no news is good news”
    Only responses to changes are centralized


    View Slide

45. © 2015 Assimilation Systems Limited
    47/45
    Sample /proc/sys Rules
    Sample /proc/sys Rules
    “BPC-00002-1”:
    {“rule”: “OR(EQ($kernel.core_uses_pid, 1),
    NE($kernel.core_pattern, ""))”
    “url”: “https://trello.com/c/6LOXeyDD” },
    “BPC-00003-1”: {“rule”: “EQ($kernel.ctrl-alt-del, 0)”,
    “url”: “https://trello.com/c/aUmn4WFg”},
    “BPC-00006-1”: {“rule”: “EQ($kernel.sysrq, 0)”,
    “url”: “https://trello.com/c/QSovxhup” },


    View Slide
