2015 Open Source Monitoring Conference (OSMC) slides

You can find a video recording of this talk here: http://assimilationsystems.com/videos/2015-open-source-monitoring-conference/

Transcript

1. Painlessly Discovering and Monitoring
   Painlessly Discovering and Monitoring
   Systems, Services and Compliance
   Systems, Services and Compliance
   #AssimProj @OSSAlanR
   http://assimproj.org/
   Alan Robertson
   Assimilation Systems Limited
   http://assimilationsystems.com


   View Slide

2. © 2015 Assimilation Systems Limited
   2
   Biography
   Biography
   ●
   35+ years in IT/development – 10 years in
   system management (SysAdmin)
   ●
   Founded Linux-HA project - led 1998-2007 –
   aka “Heartbeat” - now called Pacemaker
   ●
   Founded Assimilation Project in 2010
   ●
   Founded Assimilation Systems Limited in 2013
   ●
   Alumnus of Bell Labs, SuSE, IBM


   View Slide

3. © 2015 Assimilation Systems Limited
   3
   Assimilation Project Evolution
   Assimilation Project Evolution
   ●
   Inspired by 2 million core computer
   (cyclops64)
   ●
   Concerns for extreme scale
   ●
   Topology aware monitoring
   ●
   Topology discovery w/out security issues
   =►Discovery of everything!


   View Slide

4. © 2015 Assimilation Systems Limited
   4
   A 6-dimensional overview
   A 6-dimensional overview
   1.System Management Suite Overview
   2.Basic Technology
   3.Best Practice Analyses
   4.Demo
   5.Current Status
   6.What You Need To Do!


   View Slide

5. © 2015 Assimilation Systems Limited
   5
   Disturbing Trends...
   Disturbing Trends...
   30% of break-ins come through “lost” systems (Verizon)
   90% have had failures of unmonitored services (Turnbull)
   80% are unable to stay in compliance (Verizon)
   30% only start monitoring only after a problem (Turnbull)
   30% of systems doing nothing useful (Koomey)


   View Slide

6. © 2015 Assimilation Systems Limited
   6
   More Trends...
   More Trends...
   ●
   Larger sites have trouble scaling monitoring
   (Turnbull)
   ●
   Larger site admins often don’t know dependencies
   ●
   Documentation is incomplete, out of date, expensive


   View Slide

7. © 2015 Assimilation Systems Limited
   7
   You can't manage what you can't
   You can't manage what you can't
   see...
   see...
   We give you X-Ray vision into your infrastructure
   ●
   Provides insight and details through a graph-model CMDB
   ●
   Helps you understand and automate your environment
   – Reduce Errors
   – Speed up problem resolution
   ●
   Reduces Manual Documentation
   ●
   CMDB-driven configuration => near-zero configuration
   ●
   Automates Monitoring
   ●
   Enhances Security
   ●
   Designed for Extreme Scale


   View Slide

8. © 2015 Assimilation Systems Limited
   8
   What's in the Suite?
   What's in the Suite?
   ●
   Graph CMDB
   ●
   Exception Monitoring
   ●
   Security Discovery
   ●
   Network Connections


   View Slide

9. © 2015 Assimilation Systems Limited
   9
   Our Unique Value
   Our Unique Value
   ●
   Security – continuous security compliance
   ●
   Scalability – scales like nothing else
   ●
   Complexity Management – reduces and
   helps you manage complexity


   View Slide

10. © 2015 Assimilation Systems Limited
    10
    Complexity
    Complexity
    “Complexity is the enemy of reliability”
    ●
    Complexity likely your single biggest
    problem
    – Near-zero configuration reduces complexity
    – Tight service integration reduces complexity
    – Accurate detailed information provides insights
    which help manage complexity


    View Slide

11. © 2015 Assimilation Systems Limited
    11
    Highly Scalable Discovery-Driven
    Highly Scalable Discovery-Driven
    Automation
    Automation
    Continuous Discovery drives everything
    ●
    Continuous extensible discovery (CMDB)
    – systems, switches, services, dependencies – zero
    network footprint discovery process
    ●
    Extensible exception monitoring
    – more than 100K systems
    ●
    Discovery Drives Best Practice Analyses
    – Initially concentrating on security
    ●
    All data goes into central graph CMDB


    View Slide

12. © 2015 Assimilation Systems Limited
    12
    This all sounds unreasonable...
    This all sounds unreasonable...
    ●
    Huge scalability without complexity?
    ●
    Discovery without pings or port scans?
    Really?


    View Slide

13. © 2015 Assimilation Systems Limited
    13
    S
    Simple Scalability
    imple Scalability
    I can explain how we scale so your
    grandmother would understand...
    istockphoto
    ©bowdenimages


    View Slide

14. © 2015 Assimilation Systems Limited
    14
    Massive Scalability –
    Massive Scalability – or
    or
    “I see dead servers in
    “I see dead servers in O
    O(1) time”
    (1) time”
    ●
    Adding systems does not increase the monitoring work on any system
    ●
    Each server monitors 2 (or 4) neighbors
    ●
    Each server monitors and discovers its own services
    ●
    Ring repair and alerting is O(n) – but a very small amount of work
    Current Implementation


    View Slide

15. © 2015 Assimilation Systems Limited
    15
    Minimizing Network Footprint
    Minimizing Network Footprint
    (in our roadmap)
    (in our roadmap)
    ●
    Support diagnosing switch issues
    ●
    Minimize network traffic
    ●
    Ideal for multi-site arrangements


    View Slide

16. © 2015 Assimilation Systems Limited
    16
    Service Monitoring based on HA
    Service Monitoring based on HA
    Technologies
    Technologies
    ●
    Well-proven architecture:
    – reliable “no news is good news”
    ●
    Implements Open Cluster Framework
    standard, LSB and Nagios remote agent APIs
    ●
    Each system monitors own services
    ●
    Can also start, stop, migrate services


    View Slide

17. © 2015 Assimilation Systems Limited
    17
    How does discovery work?
    How does discovery work?
    Nanoprobe scripts perform discovery
    ●
    Each discovers one kind of information
    ●
    Can take arguments from environment
    ●
    Output JSON
    CMA stores Discovery Information
    ●
    JSON stored in Neo4j database
    ●
    CMA discovery plugins => graph nodes and relationships


    View Slide

18. © 2015 Assimilation Systems Limited
    18
    OS discovery JSON Snippet
    OS discovery JSON Snippet
    { "nodename": "alanr-1225B",
    "operating-system": "GNU/Linux",
    "machine": "x86_64",
    "processor": "x86_64",
    "hardware-platform": "x86_64",
    "kernel-name": "Linux",
    "kernel-release": "3.8.0-31-generic",
    "kernel-version": "#46-Ubuntu SMP ...",
    "Distributor ID": "Ubuntu",
    "Description": "Ubuntu 13.04",
    "Release": "13.04",
    "Codename": "raring" }


    View Slide

19. © 2015 Assimilation Systems Limited
    19
    "sshd": {
    "exe": "/usr/sbin/sshd",
    "cmdline": [ "/usr/sbin/sshd", "-D" ],
    "uid": "root",
    "gid": "root",
    "cwd": "/",
    "listenaddrs": {
    "0.0.0.0:22": { "proto": "tcp" }
    }
    sshd
    sshd Service
    Service JSON Snippet
    JSON Snippet
    (from netstat and /proc)
    (from netstat and /proc)


    View Slide

20. © 2015 Assimilation Systems Limited
    20
    "ssh": {
    "exe": "/usr/sbin/ssh",
    "cmdline": [ "ssh", "servidor" ],
    "uid": "alanr",
    "gid": "alanr",
    "cwd": "/home/alanr/monitor/src",
    "clientaddrs": {"10.10.10.5:22": {"proto": "tcp"}
    }
    ssh
    ssh Client
    Client JSON Snippet
    JSON Snippet
    (from netstat and /proc)
    (from netstat and /proc)


    View Slide

21. © 2015 Assimilation Systems Limited
    21
    Service Dependency Graph
    Service Dependency Graph


    View Slide

22. © 2015 Assimilation Systems Limited
    22
    Switch Discovery Graph
    Switch Discovery Graph
    from LLDP (or CDP)
    from LLDP (or CDP)


    View Slide

23. © 2015 Assimilation Systems Limited
    23
    Why a graph database? (Neo4j)
    Why a graph database? (Neo4j)
    ●
    Humans describe systems as graphs
    ●
    Dependency & Discovery information: graph
    ●
    Speed of graph traversals depends on size of subgraph,
    not total graph size
    ●
    Root cause queries  graph traversals – notoriously slow
    in relational databases
    ●
    Visualization is Natural
    ●
    Schema-less design: good for constantly changing
    heterogeneous environment
    ●
    Graph Model === Object Model


    View Slide

24. © 2015 Assimilation Systems Limited
    24
    A Few Canned Queries
    A Few Canned Queries
    allipports get all port/ip/service/hosts
    allswitchports get switch connections
    crashed get crashed servers
    shutdown get gracefully shutdown servers
    downservices get nonworking services
    findip get system owning IP
    findmac get system owning MAC
    unknownips get unknown IP addresses
    unmonitored get unmonitored services


    View Slide

25. © 2015 Assimilation Systems Limited
    25
    B
    Best Practice Analyses
    est Practice Analyses
    Under active development
    ●
    Triggered by Discovery Updates
    – Analysis occurs within seconds of change
    – No change => No analysis
    ●
    We can analyze anything discovered
    ●
    Expect to create alerts and reports
    ●
    SIEM integration


    View Slide

26. © 2015 Assimilation Systems Limited
    26
    Sample Security Best Practices
    Sample Security Best Practices
    ●
    Inappropriate services (telnet, etc)
    ●
    Settings in /proc/sys/
    ●
    Security Patch Coverage
    – OS vendor (RedHat, SuSE, Canonical, etc)
    – Application (Oracle, IBM, WordPress, etc)
    ●
    Other OS settings
    ●
    Common Application Settings
    ●
    Looking at best practices
    FYI: Collaborating with Lynis project and Linux Foundation


    View Slide

27. © 2015 Assimilation Systems Limited
    27
    Other Sample Security Features
    Other Sample Security Features
    ●
    Discovery of “forgotten” IP addresses
    ●
    Monitoring of Open Ports and Services
    ●
    Collection of network-facing app checksums
    ●
    Nmon profiling of new MAC addresses
    ●
    Checksum outliers analysis
    ●
    Security Best Practice Analyses


    View Slide

28. © 2015 Assimilation Systems Limited
    28
    IT Best Practices Project
    IT Best Practices Project
    ITBestPractices.info
    ●
    IT-Bestpractices GitHub project
    ●
    Working on Linux Foundation Sponsorship
    ●
    Apache 2 License (or similar)
    ●
    Initial Sources
    – DISA STIGs
    – Lynis project
    – PCI DSS rules
    – Individual contributions


    View Slide

29. © 2015 Assimilation Systems Limited
    29
    IT Best Practices Goals
    IT Best Practices Goals
    ●
    Make Best Practice rules available in JSON
    – Curate mechanically-verifiable practices
    – Human-readable descriptions of issues and
    remedies
    – Multiple language support
    – Not limited to security best practices
    – Web server under development


    View Slide

30. © 2015 Assimilation Systems Limited
    30
    Sample short description
    Sample short description
    The system must limit the ability of processes to
    have simultaneous write and execute access to
    memory.


    View Slide

31. © 2015 Assimilation Systems Limited
    31
    Sample long description
    Sample long description
    ExecShield uses the segmentation feature on all
    x86 systems to prevent execution in memory
    higher than a certain address. It writes an address
    as a limit in the code segment descriptor, to control
    where code can be executed, on a per-process
    basis. When the kernel places a process's memory
    regions such as the stack and heap higher than
    this address, the hardware prevents execution in
    that address range.


    View Slide

32. © 2015 Assimilation Systems Limited
    32
    Sample Security Rule check
    Sample Security Rule check
    The status of the "kernel.exec-shield" kernel parameter can
    be queried by running the following command:
    $ sysctl kernel.exec-shield
    $ grep kernel.exec-shield /etc/sysctl.conf
    The output of the command should indicate a value of "1". If
    this value is not the default value, investigate how it could
    have been adjusted at runtime, and verify it is not set
    improperly in "/etc/sysctl.conf".
    If the correct value is not returned, this is a finding.


    View Slide

33. © 2015 Assimilation Systems Limited
    33
    Assimilation /proc/sys Rule
    Assimilation /proc/sys Rule
    Disallow executing code on writable pages
    “nist_V-38597”:
    {“rule”: “EQ($kernel.exec-shield, 1)”,
    “category”: “security”
    }


    View Slide

34. © 2015 Assimilation Systems Limited
    34
    Assimilation Networking Rule
    Assimilation Networking Rule
    Buffer bloat prevention
    “itbp-0001”:
    {“rule”: “IN($kernel.core.default_qdisc,
    fq_codel, codel)”,
    “category”: “networking”
    }


    View Slide

35. © 2015 Assimilation Systems Limited
    35
    D
    Discovery / Monitoring / Best
    iscovery / Monitoring / Best
    Practices Demo
    Practices Demo
    ●
    Demonstrate basic capabilities
    – Discovery-driven monitoring configuration
    – Discovery-driven 'tripwire-like' checksums
    – Monitoring – failures / successes
    – Host down notification
    – Best Practices
    ●
    No configuration was supplied
    – everything comes from discovery
    http://assimilationsystems.com/90_second_demo/


    View Slide

36. © 2015 Assimilation Systems Limited
    36
    Current Status
    Current Status
    ●
    1.1.0 release out 3 November 2015
    ●
    Way-cool simplified installer!
    ●
    Continuous Security Monitoring
    – ~50 best practice rules implemented
    ●
    Great unit and system tests
    ●
    Strongly encrypted communication
    ●
    Quite a few discovery methods written
    ●
    Extensible Automated Discovery Triggers
    ●
    Discovery => Automatic Monitoring + Network-Facing Checksums
    ●
    Compatible with Nagios remote monitoring agent API
    ●
    REST + Command Line Queries


    View Slide

37. © 2015 Assimilation Systems Limited
    37
    Get Involved!
    Get Involved!
    ●
    Trials! Early Adopters!
    ●
    Contributors
    – Testers, Continuous Integration
    – Best practice experts
    – Designers
    – Developers (C, Python, Shell, PowerShell, JavaScript)
    – Porters (esp Windows)
    – Promoters, Publicists, Packagers, etc.


    View Slide

38. © 2015 Assimilation Systems Limited
    38
    Resistance Is Futile!
    Resistance Is Futile!
    These slides: bit.ly/DOSUG0915
    Mailing List: bit.ly/AssimML
    @OSSAlanR
    #assimilation on irc.freenode.net
    Project Web Site: assimproj.org
    Company Web Site: assimilationsystems.com
    Download: assimilationsystems.com/download


    View Slide

39. © 2015 Assimilation Systems Limited
    39
    Risk Management/Mitigation
    Risk Management/Mitigation
    ●
    Intrusions
    ●
    Vulnerable Software
    ●
    Licensed Software
    ●
    Audit Risk
    ●
    Outages
    ●
    System management


    View Slide

40. © 2015 Assimilation Systems Limited
    40
    Monitoring Pros and Cons
    Monitoring Pros and Cons
    Pros
    Simple & Scalable
    Uniform work distribution
    No single point of failure
    Distinguishes switch vs
    host failure
    Easy on LAN, WAN
    Multi-tenant approach
    Cons
    Active agents
    Potential slowness
    at power-on


    View Slide

41. © 2015 Assimilation Systems Limited
    41
    Sixth Dimension:
    Sixth Dimension:
    Graph Schema
    Graph Schema
    Two Schema subgraphs
    ●
    Client / server
    dependency
    ●
    Switch interconnect


    View Slide

42. First Dimension
    First Dimension:
    :
    Problems Addressed
    Problems Addressed
    ●
    Discovering and maintaining documentation
    (CMDB) using continuous discovery
    – Services, Systems, Dependencies, Switches, Interconnects,
    Configuration
    ●
    Monitoring and alerting: services, systems and
    compliance
    ●
    Managing compliance
    ●
    Mitigating risk


    View Slide

43. © 2015 Assimilation Systems Limited
    45
    Why Discovery? (DevOps)
    Why Discovery? (DevOps)
    ●
    Documentation: incomplete, incorrect
    ●
    Dependencies: unknown
    ●
    Planning: Needs accurate data
    ●
    Best Practices: Verification needs data
    ●
    ITIL CMDB (Configuration Management
    Data Base)
    Our Discovery: continuous, low-profile


    View Slide

44. © 2015 Assimilation Systems Limited
    46
    Second Dimension:
    Second Dimension:
    Unique Powerful Features
    Unique Powerful Features
    1. Continuous Discovery
    2. Discovery: Zero network footprint
    3. Centralized graph database
    4. We know everything that changes
    5. Discover and update dependency information
    6. Discovery and monitoring tightly integrated –
    discovery drives automation


    View Slide

45. © 2015 Assimilation Systems Limited
    47
    (even more) Features...
    (even more) Features...
    7. Discovery and monitoring easily extensible
    8. Naturally scalable to > 100K systems
    9. Minimal network load
    10.Server failures distinguishable from switch failures
    11.Best practice and vulnerability alerts
    12.Multi-tenant support


    View Slide

46. © 2015 Assimilation Systems Limited
    48
    Third Dimension:
    Third Dimension:
    Fully distributed work
    Fully distributed work
    Two philosophical underpinnings
    1. Monitoring and Discovery are fully distributed
    2. Reliable “no news is good news”
    Only responses to changes are centralized


    View Slide

47. © 2015 Assimilation Systems Limited
    49
    Sample /proc/sys Rules
    Sample /proc/sys Rules
    “BPC-00002-1”:
    {“rule”: “OR(EQ($kernel.core_uses_pid, 1),
    NE($kernel.core_pattern, ""))”
    “url”: “https://trello.com/c/6LOXeyDD” },
    “BPC-00003-1”: {“rule”: “EQ($kernel.ctrl-alt-del, 0)”,
    “url”: “https://trello.com/c/aUmn4WFg”},
    “BPC-00006-1”: {“rule”: “EQ($kernel.sysrq, 0)”,
    “url”: “https://trello.com/c/QSovxhup” },


    View Slide
