Indexing and search tons of data with ElasticSearch and Django

Transcript

1. PYCON OTTO Florence April 6-9 2017 Indexing and search tons of data with ElasticSearch and Django ernesto arbitrio
2. PYCON OTTO whoami “Tech researcher at FBK(.eu)” “Python addicted, system integrator, dad, husband, cooking enthusiast” twitter: __pamaron__ email: ernesto.arbitrio@gmail.com github.com/ernestoarbitrio
3. PYCON OTTO the problem
4. PYCON OTTO the problem 30 TByte data
5. PYCON OTTO What ElasticSearch is? Distributed search engine • Open Source • Document Based • JSON over HTTP protocol • Built on top of Apache© Lucene
6. PYCON OTTO What ElasticSearch does? • Indexes heterogeneous data • Fast data searching • Support your data discovery applications
7. PYCON OTTO Document Based • JSON • Dynamic Schema/Schemaless • Relationship ◦ Nested ◦ Parent/Child
8. PYCON OTTO Nested example
9. PYCON OTTO Parent-child • The parent document can be updated without reindexing the children. • Child documents can be added, changed, or deleted without affecting either the parent or other children. This is especially useful when child documents are large in number and need to be added or changed frequently. • Child documents can be returned as the results of a search request.
10. PYCON OTTO Queries (unstructured) Core methods match, multi_match, phrase, fuzzy, regexp, wildcard Compound queries bool, filtered, function score NOT CACHED
11. PYCON OTTO Filters (structured) Core filters term, range, exists, geo_distance, geo_bbox, script Compound filters bool, and/or/not FAST, CACHEABLE The goal of filtering is to reduce the number of documents that have to be examined by the scoring queries.
12. PYCON OTTO When to Use Which As a general rule, use query clauses for full-text search or for any condition that should affect the relevance score, and use filters for everything else.
13. PYCON OTTO Pure ElasticSearch query EXAMPLE … over HTTP for instance curl -XPOST "http://localhost:9200/_search" -d '{ "aggs": { "posted_dates": { "terms": {"field": "PostedDate"} } }, "query": { "bool": { "filter": [{ "match": {"Categories": "A"} }], "must": [{ "match": {"Subject": "Lorem"} }], "must_not": [{ "match": {"Body": "amet"} }] } } }'
14. PYCON OTTO Pure python query EXAMPLE import requests import json query={ 'aggs': { 'posted_dates': {'terms': {'field': 'PostedDate'}} }, 'query': { 'bool': { 'filter': [{ 'match': {'Categories': 'A'} }], 'must': [{ 'match': {'Subject': 'Lorem'} }], 'must_not': [{ 'match': {'Body': 'amet'} }] } } } uri = "http://localhost:9200/_search" response = requests.get(uri, data=query) results = json.loads(response.text)
15. PYCON OTTO ElasticSearch Different deployment envs Nginx, PaaS, thrifth Restful APIs 90+ end points, 600+ parameters, escaping, encoding
16. PYCON OTTO elasticsearch-py Official low-level client for Elasticsearch 1-to-1 REST API Opinion-free Very extendable
17. PYCON OTTO Document Example (demo email) { "Abstract": "Cara Elena, ho rivisto la norma operativa i...", "Body": "Cara Elena, some text here…..", "Categories": "", "CopyTo": [ "mario.rossi@mail.it" ], "DeliveredDate": "22/11/2011 12.53.25", "DeliveryPriority": "N", "DocumentCreated": "22/11/2011 12.53.17", "DocumentUniqueId": "908268A52DDAA2CF727724498EC4AF08", "Form": "Memo", "From": "Riccardo Mauri <mauri@prova.it>", "PostedDate": "22/11/2011 12.53.17", "SendTo": [ "Elena.Bianchi@domain.it" ], "Subject": "Rev norma operativa parti correlate" }
18. PYCON OTTO elasticsearch-py | example In [1]: from elasticsearch import Elasticsearch In [2]: es = Elasticsearch() In [3]: es.indices.create(index='emails', ignore=400) Out[3]: {'acknowledged': True, 'shards_acknowledged': True} In [4]: es.index(index="emails", doc_type="email", id=4, body={}) Out[4]: {'_id': '4', '_index': 'emails', '_shards': {'failed': 0, 'successful': 1, 'total': 2}, '_type': 'email', '_version': 1, 'created': True, 'result': 'created'} In [5]: es.get(index="emails", doc_type="email", id=4)['_source'] Out [5]: {'Abstract': 'Cara Elena, ho rivisto la norma operativa i...', 'Body': 'Cara Elena, some text here…..', 'Categories': '', ... ,'Subject': 'Rev norma operativa parti correlate'} { "Abstract": "Cara Elena, ho rivisto", "Body": "Cara Elena, some text here…..", "Categories": "", "CopyTo": [ "mario.rossi@mail.it" ], … }
19. PYCON OTTO elasticsearch-py | example res = es.search(body={ 'aggs': { 'posted_dates': { 'terms': {'field': 'PostedDate'} } }, 'query': { 'bool': { 'filter': [{ 'match': {'Categories': 'A'} }], 'must': [{ 'match': {'Subject': 'Lorem'} }], 'must_not': [{ 'match': {'Body': 'amet'} }] } } })
20. PYCON OTTO elasticsearch-dsl s = Search(using=client, index="emails").filter("match", Categories="A")\ .filter("match", Subject="Lorem")\ .filter(~Q("match", Body="amet")) agg = A('terms', field = 'PostedDate') s.aggs.bucket('posted_dates', agg) response = s.execute()
21. response Response object response = s.execute() if not response.success(): print("Partial results!") Iterate and get hits for h in response: print(h._meta.id, h.subject) Access to aggregations agg_date = response.aggregations.posted_dates.buckets[0] PYCON OTTO
22. PYCON OTTO migration path query = { 'query': { 'bool': { 'filter': [{'match': {'Categories': 'A'}}], 'must': [{'match': {'Subject': 'Lorem'}}], 'must_not': [{'match': {'Body': 'amet'}}] } } } q = Search.from_dict(query) … query = s.to_dict()
23. PYCON OTTO persistence example class email(DocType): subject = Text(analyzer='snowball', fields={'raw': Keyword()}) body = Text(analyzer='snowball') posted_date = Date() Lines = Integer() category = Text(analyzer='snowball') class Meta: index = 'emails' def save(self, ** kwargs): self.lines = len(self.body.split()) return super(email, self).save(** kwargs) def is_draft(self): return True is self.posted_date else False
24. PYCON OTTO persistence example # create the mappings in elasticsearch email.init() # create and save and article message = email(meta={'id': 42}, subject='Hello world!') article.body = ''' looong text ''' article.posted_date = datetime.now() article.save() article = Article.get(id=42) print(article.is_draft())
25. PYCON OTTO +
26. PYCON OTTO Display the data class SearchIndexView(LoginRequiredMixin, View): template_name = 'search_engine/index.html' form_class = SenderForm def get(self, request, **kwargs): context = {'form': self.form_class()} return render(request, self.template_name, context) def post(self, request): person = request.POST['person'] # the person to filter page = request.GET.get('page', 1) from_ = (int(page) - 1) * settings.ES_PAGE_SIZE s = Search(using=client, index="emails").filter("match", From=person) results = s.execute() context = {'form': self.form_class(request.POST), 'tot_results': results['hits']['total'], 'res': results['hits']['hits']} return render(request, self.template_name, context)
27. PYCON OTTO … and if we get thousand of results records? Pagination is the answer GET /_search?size=5 GET /_search?size=5&from=5 GET /_search?sizxe=5&from=10
28. PYCON OTTO ES Custom Django Paginator class DSEPaginator(Paginator): def __init__(self, *args, **kwargs): super(DSEPaginator, self).__init__(*args, **kwargs) if isinstance(self.object_list, dict): self.count = self.object_list['hits']['total'] else: self.count = self.object_list.hits.total def page(self, number): number = self.validate_number(number) return Page(self.object_list, number, self)
29. PYCON OTTO Display the data class SearchIndexView(LoginRequiredMixin, View): … … results = s.execute() paginator = DSEPaginator(results, settings.ES_PAGE_SIZE) try: posts = paginator.page(page) except PageNotAnInteger: posts = paginator.page(1) except EmptyPage: posts = paginator.page(paginator.num_pages) context = {'form': self.form_class(request.POST), 'tot_results': results['hits']['total'], 'posts': posts} return render(request, self.template_name, context) settings.ES_PAGE_SIZE = 25
30. PYCON OTTO Highlighting GET /_search { "query" : { "match": { "content": "kimchy" } }, "pre_tags": ["<em>"], "post_tags": ["</em>"], "highlight" : { "fields" : { "content" : {} } } }
31. PYCON OTTO Highlighting search().highlight('subject', 'body')
32. PYCON OTTO PROBLEMS
33. PYCON OTTO Indexing happens during request time Celery can helps you
34. PYCON OTTO @shared_task(bind=True, default_retry_delay=60, max_retries=3) def index_emails(self, pk): try: article = Email.objects.get(pk=pk) except Email.ObjectDoesNotExist: self.retry() try: search_email = SearchEmail.get(id=pk) except elasticsearch.NotFoundError: search_email = SearchEmail(id=pk) search_email.title = instance.title # ... search_email.save()
35. PYCON OTTO What I want to see Autogenerated mapping Django Admin integration Management commands to (re)index … batteries included
36. PYCON OTTO QUESTIONS?
37. PYCON OTTO THANKS!!! Keep in touch ernesto.arbitrio@gmail.com twitter.com/__pamaron__
