Raspberry Pi 好好玩 - 應用展示與遊戲機演進篇 台灣樹莓派 <sosorry@piepie.com.tw> Jul 19, 2014
/COSCUP 2014
姓名標示 — 非商業性 — 相同方式分享 CC (Creative Commons) 姓名標示 —
你必須給予 適當表彰、提供指向本授權 條款的連結,以及 指出(本作品的原始版本)是否已 被變更。你可以任何合理方式為前述表彰,但不得以 任何方式暗示授權人為你或你的使用方式背書。 非商業性 — 你不得將本素材進行商業目的之使 用。 相同方式分享 — 若你重混、轉換本素材,或依本 素材建立新素材,你必須依本素材的授權條款來 散布你的貢獻物。
3 • Raspberry Pi 官方經銷商 • 專注 Raspberry Pi 應用與推廣
, 舉辦社群活動 關於我們
4 • COSCUP,MakerConf,PyCon,HKOSCon 講者 • 投影片 • https://speakerdeck.com/piepie_tw • 程式碼
• https://github.com/piepie-tw 分享 x 教學
None
Raspberry Pi 的起源
7 以前的電腦 http://goo.gl/iU5f9w http://goo.gl/U1aq9E PDP-8 Xerox Alto BBC Micro Power
Macintosh
8 現在的電腦 iphone 10 ?
裝置越來越聰明 人卻越來越糊塗 資訊科學系的學生不懂電腦 ?
David Braben Eben Upton Robert Mullins Alan Mycroft Pete Lomas
Jack Lang Liz
• 信用卡大小般的電腦 Raspberry Pi 是什麼 ? http://www.flickr.com/photos/fotero/7697063016/
• Raspberrypi.org 基金會所設計開發 • 以低價硬體 & 自由軟體刺激電腦科學教育 • 公開的 datasheet
& 線路圖 & 原始碼 • 由 Element14/RS Components 生產製造 Raspberry Pi 是 ...
Raspberry Pi 的演進 2006, Concept edition 2011, USB Prototype Board
2011, Alpha Board 2012, Model B rev 1 2012, Model B rev 2 2014, Compute module 2014, Model B+ http://elinux.org/RPi_HardwareHistory
14 剛出新版本 B+ 了 http://www.raspberrypi.org/help/faqs/
15 Model B+ http://www.element14.com/community/community/raspberry-pi?view=documents
FAQ 第一名: Raspberry Pi 和 Arduino 有什麼不同 ?
超級比一比 http://functy.sourceforge.net/?p=328 Arduino Raspberry Pi Model UNO Model B Solution
microcontroller SoC OS - Linux, RISC OS Architecture 8-bit 32-bit Processor ATMEGA328 BCM2835(ARM) Speed 16MHz 700MHz RAM 2Kbyte 512MB ROM 32Kbyte - USB - 2 x 2.0 Audio - Stereo Out, In w/USB mic Video - HDMI, NTSC or PAL I/O 26, SPI / I2C / UART / PWM 26, SPI / I2C / UART / PWM Language Wiring-based(~C++) BASIC, C/C++, Java, Python, Ruby http://goo.gl/5FCFWF
FAQ 第二名: XXX 比 Raspberry Pi 規格好 , 所以 OOO
開發板大亂鬥 http://goo.gl/LnwNGR
FAQ 第三名: 怎麼使用?
21 選一套喜歡的 OS http://en.wikipedia.org/wiki/Raspberry_Pi
22 連接週邊 http://vimeo.com/90103691
23 立馬取代桌上型電腦 http://functy.sourceforge.net/?p=328
FAQ 第四名: Raspberry Pi 怎麼玩?
多媒體娛樂中心 http://geekify.me/turn-your-raspberry-pi-into-a-full-fledged-media-centre-with-xbmc/
音樂播放器 Raspberry Pi + DAC + Power Supply = Music
Player
行動無線路由器 http://draalin.com/raspberry-pi-projects Raspberry Pi + 3G 網卡 + 無線網卡 =
Portable Wireless Router
Handy IP Cam 以樂高做外殼 加上 Camera 與按鍵
http://www.oz9aec.net/index.php/dvb/490-turn-your-raspberry-pi-into-a-live-hdtv-transmitter Pi 數位電視台 Raspberry Pi + DVB-T modulator = 真人實境數位訊號廣播器
http://arstechnica.com/information-technology/2012/09/university-builds-cheap-supercomputer-with-raspberry-pi-and-legos/ 串接四台 Pi 跑 Distcc 串接 64 台 Pi 跑
MPICH Pi Cluster
31 Pi Camera http://learn.adafruit.com/diy-wifi-raspberry-pi-touch-cam 可做影像辨識的相機 接上喇叭發聲
32 Pi Car 球型自走車 GPS 自走車 4 軸飛行器 即時攝影履帶自走車 自走車擴充板
33 Pi Phone http://www.davidhunt.ie/piphone-a-raspberry-pi-based-smartphone/ Raspberry Pi + 觸控螢幕 + GSM
模組 + 行動電源 = 手機
RAPIRO http://www.kickstarter.com/projects/shota/rapiro-the-humanoid-robot-kit-for-your-raspberry-p
35 成大資工期末專題 http://wiki.csie.ncku.edu.tw/embedded/team2013-3 進階嵌入式系統開發與實作 - 影像伺服系統 (Visual Servo System)
36 耗電量監測 http://www.ladyada.net/make/tweetawatt/
37 地鐵感測器 http://makezine.com/magazine/ultrasonic-train-detector-in-stockholm-subway/
38 地鐵感測器 http://makezine.com/magazine/ultrasonic-train-detector-in-stockholm-subway/
Kano Project http://makezine.com/2013/11/19/the-kano-kit-building-a-raspberry-pi-computer/
動手做 = 學習
一個遊戲機的演進
2013 科學玩意節 / 陽春版 http://goo.gl/vSpiUh
用無線鍵鼠很沒 fu
從按鍵和搖桿開始學起
45 • 開關:按鍵式 , 滑動式 , 傾斜式 ... • 常開
(normal open.) / 常閉 (normal close) • 上拉電阻 / 下拉電阻 按鍵 Button/ 開關 Switch
46 搖桿 Joystick http://www.raspberrypi-spy.co.uk/2014/04/using-a-joystick-on-the-raspberry-pi-using-an-mcp3008/
使用搖桿操縱的 demo board
很快的它就進化了
2014 MakerFaire/ 壓克力外殼
我們現在正在進行的
使用 3D 印表機做出的外殼
下一個目標
• 整機式大台電玩 • 可雙人玩 • 可投幣 • 可擴充遊戲 • 可網路排名計分
• ... http://infinigeek.com/making-the-switch-from-consoles-to-smartphones/
我們還可以從 Raspberry Pi 學到什麼 ?
影像處理 / 人臉辨識與追蹤 https://github.com/tasanakorn/rpi-mmal-demo/tree/develop
ARM 組合語言 Baking Pi Project • Aimed to 16 years+
student • OS development in assembly code • From LED to Screen, then Input http://www.raspberrypi.org/pifox-bare-metal-arm-assembly-language-star-fox/ PiFox Project
Jun 25, 2014/ 第五次 Raspberry Pi 社群聚會講題 用 Raspberry Pi
學 Linux 驅動程式 DHT11 RPi Pin1 (VCC) Pin2 (5V) Pin2 (DATA) Pin12 (GPIO1) Pin3 (NC) x Pin4 (GND) Pin14 (Ground) http://www.slideshare.net/raspberrypi-tw/write-adevicedriveronraspberrypihowto
用 Raspberry Pi 學數位邏輯電路 http://www.myu.ac.jp/~xkozima/lab/raspTutorial3.html
最後
2014 / 08 / 09 https://makerconf.tw
Raspberry Pi Rocks the World Thanks
