OpenShift Console - Customizing for the Developer

Join OpenShift's Developer Experience experts for our regularly scheduled program filled with cloud native, Kubernetes, and OpenShift tips and tricks for developers.

Today we'll be kicking off the OCP4 Console Customization Competition.

Transcript

1. Customizing for the Developer
   OpenShift 4 Console
   Serena Chechile Nichols
   October 2020
   1


   View Slide

2. Admins can customize the
   console for developers
   2


   View Slide

3. 3
   Console logo
   Check out this blog:
   OpenShift 4 Pro Tip:
   Custom Branding
   Customize console logo
   oc create configmap console-custom-logo
   --from-file=/Users/serenadoyle/Desktop/OpenShift.tv/kube.png -n
   openshift-config
   -----
   apiVersion: operator.openshift.io/v1
   kind: Console
   metadata:
   name: cluster
   spec:
   customization:
   customProductName: MyProduct
   customLogoFile:
   name: console-custom-logo
   key: kube.png
   -----
   oc apply -f


   View Slide

4. 4
   Helm Chart Repostority
   In 4.6, you can add
   additional Helm Chart
   Repositories easily via CRs
   You can remove the
   “default repo” :
   redhat-helm-repo
   In the future, when you
   remove all
   HelmChartRepository CRs,
   we will disable the ability to
   create Helm Charts from
   the console
   Add a new Helm Chart Repository to your cluster
   apiVersion: helm.openshift.io/v1beta1
   kind: HelmChartRepository
   metadata:
   name: azure-sample-repo
   spec:
   name: azure-sample-repo
   connectionConfig:
   url:
   https://raw.githubusercontent.com/Azure-Samples/helm-charts
   /master/docs
   -----
   oc apply -f


   View Slide

5. 5
   Builder Images
   This method will remove
   that builder image from
   three (3) areas in the
   console: Samples, Import
   from Git & Builder Images
   in the Dev Catalog
   Remove an existing Builder Image from the console
   Remove “builder” from tags of the ImageStream in the openshift
   namespace that you want to “remove”


   View Slide

6. 6
   Operator Backed Services
   Example: Red Hat
   Integration - AMQ Streams
   Install operators to expose operator backed services
   in the Developer Catalog
   Notes:
   - In 4.6 a new pattern has been added to help you understand when
   the Operator has been successfully installed
   - Once the Operator has been installed, you can go to the Developer
   Catalog to see what’s now available in the developer catalog


   View Slide

7. Users can customize their own
   7


   View Slide

8. 8
   Developer Perspective Navigation
   The third section is a
   customizable area where
   you can add your most
   frequently used resources
   for quick access.
   Check out this blog:
   Improved navigation in the
   OpenShift 4.5 Developer
   perspective
   Users can customize their own navigation in the
   Developer Perspective


   View Slide

9. Futures - what’s coming next
   with customization for the
   developer
   9


   View Slide

10. 10
    Developer Catalog - Catalogs
    Post 4.6 we are looking at a
    mechanism to allow the
    admin to manage
    categories in the
    Developer Catalog
    FUTURE - Customize categories in the Developer
    Catalog


    View Slide

11. 11
    Project Access
    Post 4.6 we are looking at a
    mechanism to allow
    custom roles to be
    displayed in the Role
    dropdown in the Project
    Access page
    FUTURE - Customize rolls available in the Role
    dropdown in Project Access


    View Slide

12. 12
    Quick Starts
    Learn more about Quick
    Starts here
    FUTURE - Create your own Quick Starts
    A quick start is like a guided tutorial that walks users through a set of
    tasks to achieve a particular goal.
    In 4.6 we have introduced the Quick Start pattern. In 4.7 we will be
    providing a Quick Start CR so that Operators and Admins can provide
    their own Quick Starts.
    This design pattern is a perfect way to onboard users, help ensure best
    practices for applications, etc


    View Slide

13. V0000000
    13
    Register today!
    http://bit.ly/ocp4-console-competition-registration
    Emails will be sent to registrants including details of the competition.
    The first 20 participants to register will receive a t-shirt, as long as they submit their entry by 11/30.
    Submit your entry by 11/30
    Join us on openshift.tv to VOTE & see the winners!
    3 winners will be selected.
    Winners will receive a COOL OpenShift hoodie
    OCP4 Console Customization Competition
    13-Oct-2020
    30-Nov-2020
    01-Dec-2020
    Public competition to showcase the best OpenShift web console customizations, using
    supported OpenShift 4 mechanisms.


    View Slide
