  1. Optimizing Spark Jobs

  2. Hey! I am Matild Reema Software Engineer @ Indix Enthusiastic

    Spark developer
  3. Crawl Parse Classify Match Analytics API/ Feeds What do we

    do at Indix?
  4. 100TB Data processed daily 5TB Html data crawled per day

    1.5B Product urls 3000 sites 6000 categories 30B Price points
  5. What is Spark? ?

  6. ◇ Alternate to Hadoop MapReduce ◇ In memory processing engine

    ◇ Support for both batch and stream processing ◇ SQL, MLlib, GraphX ◇ 100x times faster in memory and 10x faster running on disk ◇ Can run on a standalone cluster, Mesos or YARN ◇ HDFS for data storage
  7. How is it different from Hadoop? ?

  8. In memory processing!!

  9. Why is it faster? ◇ Writes intermediate output to memory

    instead of disk ◇ Less disk I/O ◇ Lazy evaluation of tasks - optimizes data processing workflow ◇ In-memory caching helpful when multiple operations access the same dataset
  10. Hadoop’s MapReduce MR Operations Input MR Operations …... HDFS Write

    HDFS Write HDFS Read HDFS Read Input Query 1 Query 2 Query 3 HDFS Read Result 1 Result 2 Result 3
  11. Spark MR Operations Input MR Operations …... Write Write Read

    HDFS Read Input Query 1 Query 2 Query 3 HDFS Read Result 1 Result 2 Result 3 memory memory memory
  12. Sample code val sc = new SparkContext() val rdd =

    sc.parallelize(List(1, 2, 3, 4, 5, 6), 3) // RDD[Int] rdd .filter(no => no % 2) .map(no => no + 1) .saveAsTextFile(“s3://bucket/path”) - Action Transformations
  13. Data representation in Spark ?

  14. RDD ◇ Collection of objects operated in parallel ◇ Transformations

    and actions ◇ Immutable - Every transformation returns a new RDD ◇ Fault tolerant - recomputed Eg: rdd .map(person -> person.age) .filter(_ > 18) Dataframe ◇ Distributed data organized into named columns ◇ Like a relational db ◇ As of Spark 2.0 Dataframe is nothing but a Dataset[Row] Eg: df .select(“age”) .filter(“age > 18”) Datasets ◇ Available since 1.6 ◇ Has all the benefits of an RDD along with Spark SQL’s optimized execution engine ◇ Has a strongly typed API as well as an untyped one(df) Eg: ds .map(person -> person.age) .filter(_ > 18)
  15. Architecture ?

  16. - Driver - Executor - Cores - Cluster manager Spark

    Cluster
  17. What about memory? ?

  18. Memory Configuration spark.memory.storageFraction (0.5) Execution memory (0.5) spark.memory.fraction (0.6) User

    memory (1-spark.memory.fraction) Reserved memory(300 MB) JVM Heap Space
  19. Sample Configurations Config 1 10 executors 8 cores(per executor) 45GB

    executor memory Config 2 20 executors 4 cores(per executor) 23GB executor memory Config 3 50 executors 1 cores(per executor) 9GB executor memory 10 nodes / 8 cores / 64GB per node Goldilocks and the three bears?
  20. Large no. of small executors vs Small no. of large

    executors ?
  21. ◇ Large executors - more cores ◇ Preferable to have

    larger executors - less movement of data across the n/w. ◇ The more the number of cores per executor, the more number of tasks that can run in parallel ◇ Having a single core executor doesn’t fully take advantage of running multiple tasks in the same JVM
  22. “ Most Spark Jobs run as is but there are

    certain pitfalls one should be careful of
  23. Common Issues ◇ Executor OOM ◇ Driver OOM ◇ Straggler

    Tasks ◇ Shuffle Failures ◇ GC Limit Exceeded ◇ No space left on device
  24. Executors going OOM ◇ Executor memory + memory overhead ◇

    Have smaller partitions ◇ >2000 partitions ◇ Avoid groupByKeys while working with RDDs - Switch to reduceByKey if aggregating (Map side combine) - Apply filters before grouping than after
  25. Driver going OOM ◇ Increase driver memory + overhead ◇

    Avoid actions that bring all data to the driver for large datasets(collect) ◇ Too many partitions - Every task sends a map status object back to the driver - Has to deal with multiple map output status requests from the reducers
  26. Straggler Tasks ◇ Skewed data - A single task deals

    with more data than the rest ◇ Increase spark.locality.wait - long running task might be having poor locality ◇ Increase the number of partitions
  27. GC Limit Exceeded ◇ Too much time spent on GC

    ◇ Increase executor heap size (executor memory) ◇ Increase storage memory (spark.memory.storageFraction) ◇ Choose a different GC policy(CMS, ParallelOld GC, G1GC)
  28. Shuffle Failures ◇ Expensive operation - involves disk I/O, data

    serialization, and network I/O ◇ Avoid shuffles when possible - Broadcast the smaller dataset while joining. Moving all of the data of the smaller table could be more expensive than just putting a copy of the small table on all executors. ◇ More cores per executor - still achieves parallelism and lesser shuffles over the network vs having more executors with lesser cores
  29. No space left on device ◇ Continuous eviction of data

    to disk - UnsafeExternalSorter: Thread 75 spilling sort data of 141.0 MB to disk (90 times so far) ◇ Ensure that spark.memory.fraction isn’t too low ◇ If you’re running with minimal number of nodes - increase them ◇ By default the spilled data is written to /tmp, you can add more disks by specifying them in spark.local.dirs
  30. Good Practices

  31. Using Parquet as File Format ◇ Columnar data storage ◇

    75% data compression on an average ◇ Push down filters(1.6 onwards) to reduce disk I/O : Filter pushdowns to access only required columns ◇ Use DirectParquetOutputCommitter - Avoids expensive renames
  32. Use Kryo Serialization ◇ More compact than Java serialization(almost 10x)

    ◇ Faster ◇ Register all custom classes
  33. Use Aggregate functions ◇ Prefer reduceBy, combineBy, aggregateBy over groupBys

    ◇ Support for custom aggregate functions ◇ Map side combines
  34. Persist data ◇ When multiple operations are performed on the

    same data, persist it ◇ Doesn’t recompute every time an action is performed ◇ Helpful during interactive analysis
  35. How do I debug my application? ?

  36. Jobs (Actions)

  37. Stages

  38. Tasks

  39. Executor Metrics

  40. To summarize Avoid unnecessary groupBys in RDDs - replace them

    with aggregate functions wherever possible Never collect/coalesce large data into a single node - Let the executors write out the data in a distributed manner Use parquet file format and kryo serialization Switch to using datasets to take full advantage of Spark’s SQL engine Default partitions may not work all the time - Know when to increase or decrease them Cache data especially in jobs where it is re-used across stages - Avoids re-computation Prefer to have larger executors with more cores - Achieves more parallelism Broadcast variables that are shared to all executors - Also while performing joins with a smaller dataset
  41. Thanks! Any questions? © Presentation template by SlidesCarnival
