Transcript

  1. [email protected] www.rittmanmead.com @rittmanmead
    Robin Moffatt, Principal Consultant, Rittman Mead | December 2015
    Smarter Regression Testing for OBIEE
    1

    View Slide

  2. [email protected] www.rittmanmead.com @rittmanmead
    About Me
    2
    •Principal Consultant with Rittman Mead

    ‣ OBIEE & ODI
    ‣ SysAdmin
    ‣ Performance
    •Previously …

    • OBIEE/DW developer at large UK retailer
    • SQL Server DBA, Business Objects, DB2, COBOL….

    •Oracle ACE

    •Frequent blogger for Rittman Mead : http://ritt.md/rmoff

    •Twitter: @rmoff

    •IRC: rmoff / #obihackers / freenode

    View Slide

  3. [email protected] www.rittmanmead.com @rittmanmead
    About Rittman Mead
    3
    •World’s leading specialist partner for technical
    excellence, solutions delivery and innovation in
    Oracle Data Integration, Business Intelligence,
    Analytics and Big Data
    •Providing our customers targeted expertise; we are a
    company that doesn’t try to do everything… only
    what we excel at
    •70+ consultants worldwide including 1 Oracle ACE
    Director and 2 Oracle ACEs
    •Founded on the values of collaboration, learning,
    integrity and getting things done
    Optimizing your investment in Oracle Business Analytics
    •Comprehensive service portfolio designed to
    support the full lifecycle of any analytics solution

    View Slide

  4. [email protected] www.rittmanmead.com @rittmanmead
    Regression Testing
    4
    •Why
    •How
    •including BVT!

    View Slide

  5. [email protected] www.rittmanmead.com @rittmanmead
    Smart Regression Testing
    5
    Better OBIEE development

    delivered more rapidly and

    with greater quality

    View Slide

  6. [email protected] www.rittmanmead.com @rittmanmead
    Why Regression Test?
    6
    Confidence

    View Slide

  7. [email protected] www.rittmanmead.com @rittmanmead
    Why?
    7
    Confidence
    (A|a)gility in development
    Happier users

    View Slide

  8. [email protected] www.rittmanmead.com @rittmanmead
    What?
    8
    • Regression Testing is not just a
    prolonged exercise on a Gantt
    chart, just before go live
    • Smart Regression Testing is be run
    on demand, targeting the change
    made and assuring quality during
    development

    View Slide

  9. [email protected] www.rittmanmead.com @rittmanmead
    Detect Problems Early
    9
    •Fresh in the developer’s mind

    - Easier to fix
    •Fewer surprises during big test cycles

    - More honest & realistic project
    status reports
    •Better overall QA for the system

    - Happier users

    View Slide

  10. [email protected] www.rittmanmead.com @rittmanmead
    Save Time
    10
    • Manually checking for regressions

    • slow & error-prone

    • limited test coverage
    • boring!
    • Automated regression testing

    • fast & reliable

    • much greater test coverage

    View Slide

  11. [email protected] www.rittmanmead.com @rittmanmead
    What Could Possibly Go Wrong?
    11
    • Data

    - Are the numbers still correct?

    • Functionality

    - Do dashboards still run without error?
    - Do dashboards still render in the same way?

    • Security

    - Data
    - Visible Dashboards

    View Slide

  12. [email protected] www.rittmanmead.com @rittmanmead
    OBIEE Conceptual Overview
    12
    Analysis Analysis
    Data Sources
    Dashboard
    RPD
    BI Server
    -------------------- Sending query to database named orcl (id: <<19108>>),

    connection pool named Connection Pool 01
    select sum(T117.FCAST_COST_AMT) as c1,
    T107.PROD_TYPE_DESC as c2,
    T127.MONTH_YYYYMM as c4
    from
    GCBC_SALES.TIMES T127 /* Dim_TIMES */ ,
    […]

    View Slide

  13. [email protected] www.rittmanmead.com @rittmanmead
    Whoops… I broke it!
    13
    • RPD may still pass consistency
    check - but do you know if you
    broke existing reports and
    dashboards?
    •Cleanup / Refactoring

    •Developments

    •Bugfixes
    1. The RPD

    View Slide

  14. [email protected] www.rittmanmead.com @rittmanmead
    Whoops… I broke it!
    14
    2. OBIEE front end
    •Cleanup / Refactored calculations

    •Presentation Catalog changes

    •Application Role changes

    View Slide

  15. [email protected] www.rittmanmead.com @rittmanmead
    Whoops… I broke it!
    15
    3. Database
    •Refactored designs

    • View -> Table
    • Table -> MView
    •Indexes

    •Partitioning

    View Slide

  16. [email protected] www.rittmanmead.com @rittmanmead
    Whoops… I broke it …
    16
    •Software upgrades

    •Environment changes

    View Slide

  17. [email protected] www.rittmanmead.com @rittmanmead
    Scope
    17
    • Don’t waste time testing what’s not used

    • Enable Usage Tracking NOW!

    View Slide

  18. [email protected] www.rittmanmead.com @rittmanmead
    What Makes a Good Regression Test?
    18
    Easy
    Better tests
    Fast Flexible
    Scalable

    View Slide

  19. [email protected] www.rittmanmead.com @rittmanmead
    Where Can We Detect Problems?
    19
    •Logical





    •Physical





    •Front End
    4
    1
    3
    5
    2
    User WebLogic Server OBIEE system components Data Source(s)
    BI Server
    BI Server
    Presentation
    Services
    Managed Server
    Managed Server
    JavaHost
    Presentation
    Services
    Web Browser
    Web Browser
    BI Plug-in
    BI Plug-in
    Analysis request
    Logical
    SQL
    Physical
    Query x n
    Logical
    Resultset
    Rendered Analysis
    RPD
    RPD
    DWH
    [ ... ]
    [ ... ]
    DWH
    [ ... ]
    [ ... ]
    2
    3
    4
    5
    1
    Query
    results x n

    View Slide

  20. [email protected] www.rittmanmead.com @rittmanmead
    Regression Testing Opportunities
    20
    •OBIEE Logical model

    • Does the RPD still work and return the same results for a given logical query?



    •Physical Database

    • Does the Physical SQL that OBIEE generates still run?



    •OBIEE front end

    • From the point of view of an end user, does it look right?

    View Slide

  21. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    21
    • New in OBIEE 12c

    - Available for use with 11g too
    • Modular - run just the
    plugins you need for the test

    - Data
    - Logical query
    - Visual
    - BI catalog

    View Slide

  22. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    22
    • Distributed only as part of the
    OBIEE 12c Windows Client Tools

    • Hidden away …











    • Windows or Linux

    • Check doc folder in the zip for full instructions

    View Slide

  23. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    23
    • Set up an XML file pointing to your server(s)

    • Run BVT initial

    • Run BVT secondary

    • Compare results

    View Slide

  24. [email protected] www.rittmanmead.com @rittmanmead
    Regression Testing Database Changes
    24
    User WebLogic Server OBIEE system components Data Source(s)
    BI Server
    BI Server
    Presentation
    Services
    Managed Server
    Managed Server
    JavaHost
    Presentation
    Services
    Web Browser
    Web Browser
    BI Plug-in
    BI Plug-in
    RPD
    RPD
    DWH
    [ ... ]
    [ ... ]
    DWH
    [ ... ]
    [ ... ]
    Physical
    SQL
    Dataset

    View Slide

  25. [email protected] www.rittmanmead.com @rittmanmead
    Regression Testing Database Changes
    25
    • If only the DB has changed, then just test the DB.
    nqquery.log / Usage
    Tracking
    SQL*Plus

    View Slide

  26. [email protected] www.rittmanmead.com @rittmanmead
    Logical OBIEE Regression Testing
    26
    User WebLogic Server OBIEE system components Data Source(s)
    BI Server
    BI Server
    Presentation
    Services
    Managed Server
    Managed Server
    JavaHost
    Presentation
    Services
    Web Browser
    Web Browser
    BI Plug-in
    BI Plug-in
    RPD
    RPD
    DWH
    [ ... ]
    [ ... ]
    DWH
    [ ... ]
    [ ... ]
    Logical
    SQL
    Dataset

    View Slide

  27. [email protected] www.rittmanmead.com @rittmanmead
    Logical SQL in OBIEE
    27
    Analysis
    Logical SQL
    Resultset via nqcmd
    Analysis results
    BI Server
    RPD

    View Slide

  28. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    28
    • Use the report and
    logicalquery test plugins

    • Connects to the server
    and runs each analysis

    • Stores the results as
    CSV

    • Stores the Logical SQL

    View Slide

  29. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    29
    • Make a change to your
    system - or point BVT at
    a different environment

    • Run the same test again,
    specifying the second
    deployment in the XML
    Baseline
    Deployment/
    Environment
    Secondary
    Deployment/
    Environment
    ./bin/obibvt -deployment AfterChanges -config testconfig.xml

    View Slide

  30. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    30
    • Once you’ve got your two samples, run BVT again to
    compare them

    • It compares the CSV and Logical SQL on disk and reports
    any differences

    • Writes one HTML file per test plugin
    ./bin/obibvt -compareresults Results/Baseline Results/AfterChange -config testconfig.xml

    View Slide

  31. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    31
    • Links to view report on each environment
    and files being compared

    • If you want to know the actual difference
    you’ll need to run your own diff tool (eg
    WinMerge)

    View Slide

  32. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    32

    View Slide

  33. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    33
    • Be aware of the config option “fudge factor” (DiffTolerance)
    necessary to deal with handling of floating point numbers
    across platforms

    • Watch out for false negatives with Logical SQL from
    expected variance in FETCH FIRST xxxx ROWS etc

    View Slide

  34. [email protected] www.rittmanmead.com @rittmanmead
    Regression Testing the OBIEE Front End
    34
    HTML, JS, CSS,
    PNG
    User WebLogic Server OBIEE system components Data Source(s)
    BI Server
    BI Server
    Presentation
    Services
    Managed Server
    Managed Server
    JavaHost
    Presentation
    Services
    Web Browser
    Web Browser
    BI Plug-in
    BI Plug-in
    RPD
    RPD
    DWH
    [ ... ]
    [ ... ]
    DWH
    [ ... ]
    [ ... ]
    HTML, JS, CSS,
    PNG
    HTML, JS, CSS,
    PNG
    HTML, JS, CSS,
    PNG

    View Slide

  35. [email protected] www.rittmanmead.com @rittmanmead
    Regression Testing the OBIEE Front End
    35
    • Front End testing is complex!

    • Two options to make sense of
    HTML, JavaScript, CSS, images:

    - Programatically - Parse server
    response
    - Visually - Render server response

    View Slide

  36. [email protected] www.rittmanmead.com @rittmanmead
    Front End test methods: Parsing
    36
    - Makes pass/fail tests easier
    • A string is present, or it is not
    - Higher rate of false negatives
    • It’s easier to miss problems
    - High development & maintenance

    cost
    • Need to reverse-engineer DOM
    • Often relies on non-deterministic internal IDs to

    accurately pinpoint assertions

    View Slide

  37. [email protected] www.rittmanmead.com @rittmanmead
    Front End test methods: Rendering
    37
    • More accurate

    - Can detect differences not expected
    or explicitly coded for
    • More prone to false positives

    - Lots of things change on a page for
    valid reasons (dates, alerts, etc)
    • Still requires DOM knowledge but
    less reliance on internal IDs
    Before
    After
    Test Result: Fail

    View Slide

  38. [email protected] www.rittmanmead.com @rittmanmead
    Visual Regression Testing
    38
    • Toolset

    - CasperJS
    - PhantomCSS

    • Server based, no dependency on

    desktop or web browser

    - Uses PhantomJS, WebKit-based

    “headless” browser

    View Slide

  39. [email protected] www.rittmanmead.com @rittmanmead
    Visual Regression Testing In Action
    39
    1. Tool takes automatic snapshot of dashboard pages. This is
    the baseline.

    View Slide

  40. [email protected] www.rittmanmead.com @rittmanmead 40
    2. Make Analysis/RPD changes
    Visual Regression Testing In Action

    View Slide

  41. [email protected] www.rittmanmead.com @rittmanmead 41
    3. Tool captures new screenshots and compares against
    baseline. Any differences are reported.
    Before After
    Test Output
    Visual Regression Testing In Action

    View Slide

  42. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    42
    • Uses custom code based around Selenium to automagically
    screenshot each report and dashboard

    • Compares resulting images before/after, based on a
    threshold that can

    be altered

    View Slide

  43. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    43

    View Slide

  44. [email protected] www.rittmanmead.com @rittmanmead
    Baseline Validation Tool
    44

    View Slide

  45. [email protected] www.rittmanmead.com @rittmanmead
    Working smarter - summary
    45
    Test Physical Logical Front End
    What Changed?
    Report / Dashboard No No Yes
    RPD No Yes Yes
    Database Yes Yes Yes

    View Slide

  46. [email protected] www.rittmanmead.com @rittmanmead
    #EOF
    46
    email

    [email protected]
    web

    http://ritt.md/rmoff
    twitter

    @rmoff
    irc

    rmoff @ #obihackers
    Rittman Mead
    User Engagement Service
    http://ritt.md/ue
    Rittman Mead

    Performance Analytics Service
    http://ritt.md/pa

    View Slide
