Music Is Just Wiggly Air

Apache Beam Summit 2020

Digital signal processing (DSP) has been made easy with the help of many Python libraries, allowing engineers and researchers to quickly and effortlessly analyze audio, images, and video. However, scaling these algorithms and models to process millions of files has not been equally as seamless. At Spotify, we’re trying to address scaling DSP over our catalog of over 50 million songs. This talk will discuss the challenges we’ve encountered while building the infrastructure needed to support audio processing at scale. I’ll discuss the how we’ve leveraged Apache Beam for streaming data pipelines and the tooling we’ve built on top of Beam to support our heavy resource requirements.

Transcript

1. music is just wiggly air
   Lynn Root | Staff Engineer | @roguelynn
   building infrastructure to support audio research


   View Slide

2. intro
   @roguelynn


   View Slide

3. —
   Audio intelligence research at Spotify advances the state
   of the art in understanding music at scale to enhance how it
   is created, identified and consumed.
   research.spotify.com


   View Slide

4. —
   Audio intelligence research at Spotify advances the state
   of the art in understanding music at scale to enhance how it
   is created, identified and consumed.
   research.spotify.com


   View Slide

5. research workflow
   @roguelynn


   View Slide

6. View Slide

7. View Slide

8. View Slide

9. productionization
   requirements
   @roguelynn


   View Slide

10. —
    graph execution modes


    View Slide

11. —
    top-down execution


    View Slide

12. View Slide

13. View Slide

14. View Slide

15. View Slide

16. View Slide

17. —
    bottom-up execution


    View Slide

18. View Slide

19. View Slide

20. View Slide

21. View Slide

22. View Slide

23. View Slide

24. View Slide

25. —
    research workload


    View Slide

26. —
    python


    View Slide

27. —
    custom environment


    View Slide

28. —
    streaming


    View Slide

29. —
    avoid duplicate work


    View Slide

30. —
    scalability


    View Slide

31. —
    summary
    Top-down & bottom-up
    Python
    Custom environment
    Avoid duplicate work
    Streaming
    Scalability


    View Slide

32. early approaches
    @roguelynn


    View Slide

33. —
    music intelligence pipeline
    Google Cloud
    PubSub
    +
    Microservices


    View Slide

34. —
    Apache Beam


    View Slide

35. —
    Apache Beam
    Google Cloud
    PubSub
    Apache Beam on
    Google Cloud Dataflow
    +


    View Slide

36. —
    what’s left?


    View Slide

37. our solution: klio
    @roguelynn


    View Slide

38. Kleio


    View Slide

39. Kleio


    View Slide

40. —
    goals of klio


    View Slide

41. —
    ecosystem


    View Slide

42. —
    ecosystem: user PoV


    View Slide

43. Develop


    View Slide

44. $ klio job create
    Develop


    View Slide

45. $ klio job create
    Develop
    $ klio job verify


    View Slide

46. $ klio job create
    Develop Test
    $ klio job verify


    View Slide

47. $ klio job create $ klio job test
    Develop Test
    $ klio job verify


    View Slide

48. $ klio job create $ klio job test
    Develop Test
    $ klio job verify $ klio job audit


    View Slide

49. $ klio job create $ klio job test
    Develop Test
    $ klio job verify $ klio job audit
    $ klio job profile


    View Slide

50. $ klio job create $ klio job test
    Develop Test Deploy
    $ klio job verify $ klio job audit
    $ klio job profile


    View Slide

51. $ klio job create $ klio job run
    $ klio job test
    Develop Test Deploy
    $ klio job verify $ klio job audit
    $ klio job profile


    View Slide

52. $ klio job create $ klio job run
    $ klio message publish
    $ klio job test
    Develop Test Deploy
    $ klio job verify $ klio job audit
    $ klio job profile


    View Slide

53. $ klio job create $ klio job run
    $ klio message publish
    $ klio job test
    Develop Test Deploy
    $ klio job verify $ klio job audit
    $ klio job profile $ klio job logs


    View Slide

54. —
    ecosystem: behind the scenes


    View Slide

55. Local / CI Machine


    View Slide

56. $ klio job run
    Local / CI Machine


    View Slide

57. $ klio job run
    $ klio image build
    Local / CI Machine


    View Slide

58. $ klio job run
    $ klio image build
    $ klioexec run
    Local / CI Machine
    worker container


    View Slide

59. $ klio job run
    $ klio image build
    $ klioexec run
    Local / CI Machine Google Cloud
    worker container


    View Slide

60. $ klio job run
    $ klio image build
    $ klioexec run
    Local / CI Machine Google Cloud
    worker container


    View Slide

61. $ klio job run
    $ klio image build
    $ klioexec run
    Local / CI Machine Google Cloud
    worker container


    View Slide

62. $ klio job run
    $ klio message publish
    $ klio image build
    $ klioexec run
    Local / CI Machine Google Cloud
    worker container


    View Slide

63. $ klio job run
    $ klio message publish
    $ klio image build
    $ klioexec run
    Local / CI Machine Google Cloud
    worker container


    View Slide

64. $ klio job run
    $ klio message publish
    $ klio image build
    $ klioexec run
    Local / CI Machine Google Cloud
    worker container
    $ klio job logs


    View Slide

65. —
    architecture


    View Slide

66. —
    architecture: klio job


    View Slide

67. docker container
    data ow worker
    klio job


    View Slide

68. docker container
    data ow worker
    s0ng2
    klio job


    View Slide

69. docker container
    data ow worker
    klio preprocessing
    s0ng2


    View Slide

70. docker container
    data ow worker
    klio preprocessing
    user-implemented
    transform
    s0ng2


    View Slide

71. docker container
    data ow worker
    klio preprocessing
    user-implemented
    transform
    s0ng2
    s0ng2.wav


    View Slide

72. docker container
    data ow worker
    klio preprocessing
    user-implemented
    transform
    s0ng2
    s0ng2.wav s0ng2.json


    View Slide

73. docker container
    data ow worker
    klio preprocessing
    user-implemented
    transform
    klio postprocessing
    s0ng2
    s0ng2.wav s0ng2.json


    View Slide

74. docker container
    data ow worker
    klio preprocessing
    user-implemented
    transform
    klio postprocessing
    s0ng2
    s0ng2.wav s0ng2.json
    s0ng2


    View Slide

75. docker container
    data ow worker
    klio preprocessing
    user-implemented
    transform
    klio postprocessing
    UUID-like
    klio job


    View Slide

76. —
    architecture: klio message


    View Slide

77. Downstream?
    Yes
    No


    View Slide

78. Downstream?
    Drop
    Yes
    No


    View Slide

79. Downstream?
    Drop
    Ping Mode?
    Yes
    No


    View Slide

80. Downstream?
    Drop
    Ping Mode?
    Yes No
    No Yes


    View Slide

81. Downstream?
    Drop
    Ping Mode?
    Pass Thru
    Yes No
    No Yes


    View Slide

82. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Pass Thru
    Yes No
    No Yes


    View Slide

83. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Pass Thru
    Yes No No
    No Yes Yes


    View Slide

84. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Force mode?
    Pass Thru
    Yes No No
    No Yes Yes


    View Slide

85. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Force mode?
    Pass Thru
    Yes No No
    Yes
    No Yes Yes
    No


    View Slide

86. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Force mode?
    Pass Thru Pass Thru
    Yes No No
    Yes
    No Yes Yes
    No


    View Slide

87. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Input data
    exists?
    Force mode?
    Pass Thru Pass Thru
    Yes No No
    Yes
    No Yes Yes
    No


    View Slide

88. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Input data
    exists?
    Force mode?
    Pass Thru Pass Thru
    Yes No No Yes
    Yes
    No Yes Yes No
    No


    View Slide

89. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Input data
    exists?
    Force mode?
    Pass Thru Pass Thru
    Trigger
    Parent
    & Drop
    Yes No No Yes
    Yes
    No Yes Yes No
    No


    View Slide

90. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Input data
    exists?
    Force mode?
    Pass Thru
    Process
    Pass Thru
    Trigger
    Parent
    & Drop
    Yes No No Yes
    Yes
    No Yes Yes No
    No


    View Slide

91. Downstream?
    Drop
    Ping Mode?
    Output data
    exists?
    Input data
    exists?
    Force mode?
    Pass Thru
    Process
    Pass Thru
    Trigger
    Parent
    & Drop
    Yes No No Yes
    Yes
    No Yes Yes No
    No


    View Slide

92. show us code!
    @roguelynn


    View Slide

93. —
    automixer


    View Slide

94. —
    automixer: vanilla Beam


    View Slide

95. $ tree
    .
    ├── Dockerfile
    ├── job-requirements.txt
    ├── mixer.py
    ├── run.py
    └── track_storage.py


    View Slide

96. $ tree
    .
    ├── Dockerfile
    ├── job-requirements.txt
    ├── mixer.py
    ├── run.py
    └── track_storage.py


    View Slide

97. import logging
    import re
    import threading
    import apache_beam as beam
    from apache_beam.io.gcp import gcsio
    from apache_beam.options import pipeline_options
    import mixer
    import track_storage
    class MixerDoFn(beam.DoFn):
    PROJECT = "sigint"
    GCS_BUCKET = "sigint-output"
    GCS_OBJECT_PATH = "automixer-beam"
    OUTPUT_NAME_TPL = "{track1_id}-{track2_id}-mix.ogg"
    GCS_OUTPUT_TPL = "gs://{bucket}/{object_path}/{filename}"
    _thread_local = threading.local()
    @property
    def gcs_client(self):
    client = getattr(self._thread_local, "gcs_client", None)
    if not client:
    self._thread_local.gcs_client = gcsio.GcsIO()
    return self._thread_local.gcs_client
    def process(self, entity_ids):
    track1_id, track2_id = entity_ids.decode("utf-8").split(",")
    output_filename = MixerDoFn.OUTPUT_NAME_TPL.format(
    track1_id=track1_id, track2_id=track2_id
    )
    gcs_output_path = MixerDoFn.GCS_OUTPUT_TPL.format(
    bucket=MixerDoFn.GCS_BUCKET,
    object_path=MixerDoFn.GCS_OBJECT_PATH,
    filename=output_filename,
    )
    # Check if output already exists:
    if self.gcs_client.exists(gcs_output_path):
    # Don't do unnecessary work
    logging.info(
    "Mix for {} & {} already exists: {}".format(
    track1_id, track2_id, gcs_output_path
    )
    )
    return
    # Check if input data is available
    err_msg = "Input for {track} is not available: {e}"
    try:
    track1_input_path = track_storage.download_track(track1_id)
    except Exception as e:
    logging.error(err_msg.format(track=track1_id, e=e))
    return
    try:
    track2_input_path = track_storage.download_track(track2_id)
    except Exception as e:
    logging.error(err_msg.format(track=track2_id, e=e))
    return
    # Get input track ids
    track1 = mixer.Track(track1_id, track1_input_path)
    track2 = mixer.Track(track2_id, track2_input_path)
    # Mix tracks & save to output file
    mixer.mix(track1, track2, output_filename)
    # Upload mix
    logging.info("Uploading mix to {}".format(gcs_output_path))
    with self.gcs_client.open(gcs_output_path, "wb", mime_type="application/octet-stream") as dest:
    with open(output_filename, "rb") as source:
    dest.write(source.read())
    yield entity_ids


    def run():
    input_subscription = "projects/sigint/subscriptions/automixer-klio-input-automixer-klio"
    output_topic = "projects/sigint/topics/automixer-klio-output"
    options = pipeline_options.PipelineOptions()
    gcp_opts = options.view_as(pipeline_options.GoogleCloudOptions)
    gcp_opts.job_name = "automixer-beam"
    gcp_opts.project = "sigint"
    gcp_opts.region = "europe-west1"
    gcp_opts.temp_location = "gs://sigint-dataflow-tmp/automixer-beam/temp"
    gcp_opts.staging_location = "gs://sigint-dataflow-tmp/automixer-beam/staging"
    worker_opts = options.view_as(pipeline_options.WorkerOptions)
    worker_opts.subnetwork = “https://www.googleapis.com/compute/v1/projects/some-network/regions/europe-west1/subnetworks/foo1"
    worker_opts.machine_type = "n1-standard-2"
    worker_opts.disk_size_gb = 32
    worker_opts.num_workers = 2
    worker_opts.max_num_workers = 2
    worker_opts.worker_harness_container_image = "gcr.io/sigint/automixer-worker-beam:1"
    standard_opts = options.view_as(pipeline_options.StandardOptions)
    standard_opts.streaming = True
    standard_opts.runner = "dataflow"
    debug_opts = options.view_as(pipeline_options.DebugOptions)
    debug_opts.experiments = ["beam_fn_api"]
    options.view_as(pipeline_options.SetupOptions).save_main_session = True
    logging.info("Launching pipeline...")
    pipeline = beam.Pipeline(options=options)
    (pipeline | beam.io.ReadFromPubSub(subscription=input_subscription)
    | beam.ParDo(MixerDoFn())
    | beam.io.WriteToPubSub(output_topic))
    result = pipeline.run()
    result.wait_until_finish()
    if __name__ == "__main__":
    fmt = '%(asctime)s %(message)s'
    logging.basicConfig(format=fmt, level=logging.INFO)
    run()


    View Slide

98. import logging
    import re
    import threading
    import apache_beam as beam
    from apache_beam.io.gcp import gcsio
    from apache_beam.options import pipeline_options
    import mixer
    import track_storage
    class MixerDoFn(beam.DoFn):
    PROJECT = "sigint"
    GCS_BUCKET = "sigint-output"
    GCS_OBJECT_PATH = "automixer-beam"
    OUTPUT_NAME_TPL = "{track1_id}-{track2_id}-mix.ogg"
    GCS_OUTPUT_TPL = "gs://{bucket}/{object_path}/{filename}"
    _thread_local = threading.local()
    @property
    def gcs_client(self):
    client = getattr(self._thread_local, "gcs_client", None)
    if not client:
    self._thread_local.gcs_client = gcsio.GcsIO()
    return self._thread_local.gcs_client
    def process(self, entity_ids):
    track1_id, track2_id = entity_ids.decode("utf-8").split(",")
    output_filename = MixerDoFn.OUTPUT_NAME_TPL.format(
    track1_id=track1_id, track2_id=track2_id
    )
    gcs_output_path = MixerDoFn.GCS_OUTPUT_TPL.format(
    bucket=MixerDoFn.GCS_BUCKET,
    object_path=MixerDoFn.GCS_OBJECT_PATH,
    filename=output_filename,
    )
    # Check if output already exists:
    if self.gcs_client.exists(gcs_output_path):
    # Don't do unnecessary work
    logging.info(
    "Mix for {} & {} already exists: {}".format(
    track1_id, track2_id, gcs_output_path
    )
    )
    return
    # Check if input data is available
    err_msg = "Input for {track} is not available: {e}"
    try:
    track1_input_path = track_storage.download_track(track1_id)
    except Exception as e:
    logging.error(err_msg.format(track=track1_id, e=e))
    return
    try:
    track2_input_path = track_storage.download_track(track2_id)
    except Exception as e:
    logging.error(err_msg.format(track=track2_id, e=e))
    return
    # Get input track ids
    track1 = mixer.Track(track1_id, track1_input_path)
    track2 = mixer.Track(track2_id, track2_input_path)
    # Mix tracks & save to output file
    mixer.mix(track1, track2, output_filename)
    # Upload mix
    logging.info("Uploading mix to {}".format(gcs_output_path))
    with self.gcs_client.open(gcs_output_path, "wb", mime_type="application/octet-stream") as dest:
    with open(output_filename, "rb") as source:
    dest.write(source.read())
    yield entity_ids


    def run():
    input_subscription = "projects/sigint/subscriptions/automixer-klio-input-automixer-klio"
    output_topic = "projects/sigint/topics/automixer-klio-output"
    options = pipeline_options.PipelineOptions()
    gcp_opts = options.view_as(pipeline_options.GoogleCloudOptions)
    gcp_opts.job_name = "automixer-beam"
    gcp_opts.project = "sigint"
    gcp_opts.region = "europe-west1"
    gcp_opts.temp_location = "gs://sigint-dataflow-tmp/automixer-beam/temp"
    gcp_opts.staging_location = "gs://sigint-dataflow-tmp/automixer-beam/staging"
    worker_opts = options.view_as(pipeline_options.WorkerOptions)
    worker_opts.subnetwork = “https://www.googleapis.com/compute/v1/projects/some-network/regions/europe-west1/subnetworks/foo1”
    worker_opts.machine_type = "n1-standard-2"
    worker_opts.disk_size_gb = 32
    worker_opts.num_workers = 2
    worker_opts.max_num_workers = 2
    worker_opts.worker_harness_container_image = "gcr.io/sigint/automixer-worker-beam:1"
    standard_opts = options.view_as(pipeline_options.StandardOptions)
    standard_opts.streaming = True
    standard_opts.runner = "dataflow"
    debug_opts = options.view_as(pipeline_options.DebugOptions)
    debug_opts.experiments = ["beam_fn_api"]
    options.view_as(pipeline_options.SetupOptions).save_main_session = True
    logging.info("Launching pipeline...")
    pipeline = beam.Pipeline(options=options)
    (pipeline | beam.io.ReadFromPubSub(subscription=input_subscription)
    | beam.ParDo(MixerDoFn())
    | beam.io.WriteToPubSub(output_topic))
    result = pipeline.run()
    result.wait_until_finish()
    if __name__ == "__main__":
    fmt = '%(asctime)s %(message)s'
    logging.basicConfig(format=fmt, level=logging.INFO)
    run()
    125 LoC


    View Slide

99. # start job from local dev machine
    (env) $ docker build . -t my-worker-image:v1
    (env) $ docker push my-worker-image:v1
    (env) $ python run.py


    View Slide

100. # start job from worker container
     $ docker build . -t my-worker-image:v1
     $ docker push my-worker-image:v1
     $ docker run --rm -it \

     —entrypoint /bin/bash \
     -v ~/.config/gcloud/:/usr/gcloud/ \
     -v $(pwd)/:/usr/src/app/ \
     -e GOOGLE_APPLICATION_CREDENTIALS=/path/to/creds.json \
     -e GOOGLE_CLOUD_PROJECT=my-gcp-project \
     my-worker-image:v1 \

     python run.py


     View Slide

101. —
     automixer: klio


     View Slide

102. $ tree
     .
     ├── Dockerfile
     ├── job-requirements.txt
     ├── klio-job.yaml
     ├── mixer.py
     ├── run.py
     └── track_storage.py


     View Slide

103. $ tree
     .
     ├── Dockerfile
     ├── job-requirements.txt
     ├── klio-job.yaml
     ├── mixer.py
     ├── run.py
     └── track_storage.py


     View Slide

104. $ tree
     .
     ├── Dockerfile
     ├── job-requirements.txt
     ├── klio-job.yaml
     ├── mixer.py
     ├── run.py
     └── track_storage.py


     View Slide

105. import os
     import apache_beam as beam
     from klio.transforms import decorators
     import mixer
     import track_storage
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     # Get input track ids
     track1_id, track2_id = data.element.split(",")
     track1 = mixer.Track(track1_id)
     track2 = mixer.Track(track2_id)
     # Cross fade tracks
     local_output_path = mixer.mix(track1, track2)
     # Upload crossfaded track
     gcs_output_path = os.path.join(
     self._klio.config.job_config.outputs[0].data_location,
     local_output_path
     )
     self._klio.logger.info("Uploading mix to {}".format(gcs_output_path))
     track_storage.upload_track(gcs_output_path, local_output_path)
     yield data


     View Slide

106. import os
     import apache_beam as beam
     from klio.transforms import decorators
     import mixer
     import track_storage
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     # Get input track ids
     track1_id, track2_id = data.element.split(",")
     track1 = mixer.Track(track1_id)
     track2 = mixer.Track(track2_id)
     # Cross fade tracks
     local_output_path = mixer.mix(track1, track2)
     # Upload crossfaded track
     gcs_output_path = os.path.join(
     self._klio.config.job_config.outputs[0].data_location,
     local_output_path
     )
     self._klio.logger.info("Uploading mix to {}".format(gcs_output_path))
     track_storage.upload_track(gcs_output_path, local_output_path)
     yield data
     30 LoC


     View Slide

107. import os
     import apache_beam as beam
     from klio.transforms import decorators
     import mixer
     import track_storage
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     # Get input track ids
     track1_id, track2_id = data.element.split(",")
     track1 = mixer.Track(track1_id)
     track2 = mixer.Track(track2_id)
     # Cross fade tracks
     local_output_path = mixer.mix(track1, track2)
     # Upload crossfaded track
     gcs_output_path = os.path.join(
     self._klio.config.job_config.outputs[0].data_location,
     local_output_path
     )
     self._klio.logger.info("Uploading mix to {}".format(gcs_output_path))
     track_storage.upload_track(gcs_output_path, local_output_path)
     yield data
     30 LoC
     75% off!
     over


     View Slide

108. $ klio job run


     View Slide

109. from klio.transforms import decorators
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     ...


     View Slide

110. from klio.transforms import decorators
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     ...


     View Slide

111. from klio.transforms import decorators
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     ...


     View Slide

112. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

113. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

114. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

115. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

116. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

117. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

118. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

119. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

120. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

121. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

122. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

123. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

124. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

125. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

126. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

127. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav
     gs://my-job/output-bucket/s0m3-aud10-1d.wav


     View Slide

128. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav
     gs://my-job/output-bucket/s0m3-aud10-1d.wav


     View Slide

129. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav
     gs://my-job/output-bucket/s0m3-aud10-1d.wav


     View Slide

130. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

131. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav
     gs://my-parent-job/output-bucket/s0m3-aud10-1d.ogg


     View Slide

132. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

133. job_name: my-job
     pipeline_options:
     streaming: True
     # <-- snip -->
     job_config:
     events:
     inputs:
     - type: pubsub
     topic: my-parent-job-output-topic
     subscription: my-job-input-subscription
     outputs:
     - type: pubsub
     topic: my-job-output-topic
     data:
     inputs:
     - type: gcs
     location: gs://my-parent-job/output-bucket
     file_suffix: ogg
     outputs:
     - type: gcs
     location: gs://my-job/output-bucket
     file_suffix: wav


     View Slide

134. import logging
     import re
     import threading
     import apache_beam as beam
     from apache_beam.io.gcp import gcsio
     from apache_beam.options import pipeline_options
     import mixer
     import track_storage
     class MixerDoFn(beam.DoFn):
     PROJECT = "sigint"
     GCS_BUCKET = "sigint-output"
     GCS_OBJECT_PATH = "automixer-beam"
     OUTPUT_NAME_TPL = "{track1_id}-{track2_id}-mix.ogg"
     GCS_OUTPUT_TPL = "gs://{bucket}/{object_path}/{filename}"
     _thread_local = threading.local()
     @property
     def gcs_client(self):
     client = getattr(self._thread_local, "gcs_client", None)
     if not client:
     self._thread_local.gcs_client = gcsio.GcsIO()
     return self._thread_local.gcs_client
     def process(self, entity_ids):
     track1_id, track2_id = entity_ids.decode("utf-8").split(",")
     output_filename = MixerDoFn.OUTPUT_NAME_TPL.format(
     track1_id=track1_id, track2_id=track2_id
     )
     gcs_output_path = MixerDoFn.GCS_OUTPUT_TPL.format(
     bucket=MixerDoFn.GCS_BUCKET,
     object_path=MixerDoFn.GCS_OBJECT_PATH,
     filename=output_filename,
     )
     # Check if output already exists:
     if self.gcs_client.exists(gcs_output_path):
     # Don't do unnecessary work
     logging.info(
     "Mix for {} & {} already exists: {}".format(
     track1_id, track2_id, gcs_output_path
     )
     )
     return
     # Check if input data is available
     err_msg = "Input for {track} is not available: {e}"
     try:
     track1_input_path = track_storage.download_track(track1_id)
     except Exception as e:
     logging.error(err_msg.format(track=track1_id, e=e))
     return
     try:
     track2_input_path = track_storage.download_track(track2_id)
     except Exception as e:
     logging.error(err_msg.format(track=track2_id, e=e))
     return
     # Get input track ids
     track1 = mixer.Track(track1_id, track1_input_path)
     track2 = mixer.Track(track2_id, track2_input_path)
     # Mix tracks & save to output file
     mixer.mix(track1, track2, output_filename)
     # Upload mix
     logging.info("Uploading mix to {}".format(gcs_output_path))
     with self.gcs_client.open(gcs_output_path, "wb", mime_type="application/octet-stream") as dest:
     with open(output_filename, "rb") as source:
     dest.write(source.read())
     yield entity_ids


     def run():
     input_subscription = "projects/sigint/subscriptions/automixer-klio-input-automixer-klio"
     output_topic = "projects/sigint/topics/automixer-klio-output"
     options = pipeline_options.PipelineOptions()
     gcp_opts = options.view_as(pipeline_options.GoogleCloudOptions)
     gcp_opts.job_name = "automixer-beam"
     gcp_opts.project = "sigint"
     gcp_opts.region = "europe-west1"
     gcp_opts.temp_location = "gs://sigint-dataflow-tmp/automixer-beam/temp"
     gcp_opts.staging_location = "gs://sigint-dataflow-tmp/automixer-beam/staging"
     worker_opts = options.view_as(pipeline_options.WorkerOptions)
     worker_opts.subnetwork = “https://www.googleapis.com/compute/v1/projects/some-network/regions/europe-west1/subnetworks/foo-1“
     worker_opts.machine_type = "n1-standard-2"
     worker_opts.disk_size_gb = 32
     worker_opts.num_workers = 2
     worker_opts.max_num_workers = 2
     worker_opts.worker_harness_container_image = "gcr.io/sigint/automixer-worker-beam:1"
     standard_opts = options.view_as(pipeline_options.StandardOptions)
     standard_opts.streaming = True
     standard_opts.runner = "dataflow"
     debug_opts = options.view_as(pipeline_options.DebugOptions)
     debug_opts.experiments = ["beam_fn_api"]
     options.view_as(pipeline_options.SetupOptions).save_main_session = True
     logging.info("Launching pipeline...")
     pipeline = beam.Pipeline(options=options)
     (pipeline | beam.io.ReadFromPubSub(subscription=input_subscription)
     | beam.ParDo(MixerDoFn())
     | beam.io.WriteToPubSub(output_topic))
     result = pipeline.run()
     result.wait_until_finish()
     if __name__ == "__main__":
     fmt = '%(asctime)s %(message)s'
     logging.basicConfig(format=fmt, level=logging.INFO)
     run()


     View Slide

135. import os
     import apache_beam as beam
     from klio.transforms import decorators
     import mixer
     import track_storage
     class AutomixerJob(beam.DoFn):
     @decorators.handle_klio
     def process(self, data):
     # Get input track ids
     track1_id, track2_id = data.element.split(",")
     track1 = mixer.Track(track1_id)
     track2 = mixer.Track(track2_id)
     # Cross fade tracks
     local_output_path = mixer.mix(track1, track2)
     # Upload crossfaded track
     gcs_output_path = os.path.join(
     self._klio.config.job_config.outputs[0].data_location,
     local_output_path
     )
     self._klio.logger.info("Uploading mix to {}".format(gcs_output_path))
     track_storage.upload_track(gcs_output_path, local_output_path)
     yield data


     View Slide

136. —
     klio vs vanilla Beam


     View Slide

137. take aways
     @roguelynn


     View Slide

138. —
     what worked?


     View Slide

139. —
     what was hard?


     View Slide

140. —
     what’s next?


     View Slide

141. thanks!
     Lynn Root | @roguelynn
     We’re hiring: spotifyjobs.com
     Find more information on klio at docs.klio.io and github.com/spotify/klio


     View Slide
