New approach of network function creation based on GO language Ilya Philippov, Intel, CEE-SECR 2017

October 20, 2017

New approach of network function creation based on GO language Ilya Philippov, Intel, CEE-SECR 2017

We will present new approach of network function creation. We suggest to refuse special middle-boxes or virtual machines and move on to fast creation of scalable virtual network functions based on sequential chaining of predefined templates.

We suppose that our publication will be interested for you, if you:

Network developer – as an example of virtual network function creation by chaining predefined fragments.
GO developer – as an example of fast packet processing framework based on connection between GO language and C language DPDK library.
Telecom – as an example of framework, that can help to replace special hardware for packet processing.


October 20, 2017

More Decks by CEE-SECR

Other Decks in Technology


  1. October 2017, St. Petersburg Software Engineering Conference Russia October 2017,

    St. Petersburg Software Engineering Conference Russia New approach of network function creation Ilia Filippov, Intel
  2. Legal Information • Intel technologies’ features and benefits depend on

    system configuration and may require enabled hardware, software or service activation. Learn more at intel.com, or from the OEM or retailer. • No computer system can be absolutely secure. • Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. • Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products. For more complete information visit http://www.intel.com/performance. • Tests document performance of components on a particular test, in specific systems. Differences in hardware, software, or configuration will affect actual performance. Consult other sources of information to evaluate performance as you consider your purchase. For more complete information about performance and benchmark results, visit http://www.intel.com/performance. • Cost reduction scenarios described are intended as examples of how a given Intel- based product, in the specified circumstances and configurations, may affect future costs and provide cost savings. Circumstances will vary. Intel does not guarantee any costs or cost reduction. • Results have been estimated or simulated using internal Intel analysis or architecture simulation or modeling, and provided to you for informational purposes. Any differences in your system hardware, software or configuration may affect your actual performance. • Intel does not control or audit third-party benchmark data or the web sites referenced in this document. You should visit the referenced web site and confirm whether referenced data are accurate. • Intel, the Intel logo and others are trademarks of Intel Corporation in the U.S. and/or other countries. • *Other names and brands may be claimed as the property of others. • © 2017 Intel Corporation. 2
  3. About me • Ilia Filippov - architect and developer of

    YANFF • Senior Software Engineer at Intel Corporation • PhD student of Moscow Institute of Physics and Technology • Located in Austin TX, US 3
  4. NFV – Network Function Virtualization • Before: Middle-boxes • Expensive

    • Inflexible • Costly change • Non-scalable • After: SW at commodity HW • Cheap • Flexible • Scalable • NFV is orthogonal to SDN – Software Defined Network • NFV deployment is orthogonal to NFV development 4 • Network handles lots of things except packet forwarding!
  5. NFV development problems • Changing of whole industry. No hardware

    devices, only software • Who will write functions? • How? • When? • How fast? How often? • Can you write a tiny function which will receive->send packets before the end of this presentation? 5
  6. YANFF - Yet Another Network Function Framework • Framework –

    high level abstractions • Helper: set of components for importing while writing network function • Execution semantics instead of declaration semantics: created network function is a program • Open Source • https://github.com/intel-go/yanff/ • Concurrency, productivity, safety • GO language • Performance • DPDK library as network base 6
  7. Packet processing graph • Functions which process packets – flow

    functions • There is set of 9 flow functions • Receive-Send, Generate-Stop • Separate/Split/Partition-Merge, Handle • Processing graph is built statically by chaining functions 7
  8. Why DPDK – Data Plane Development Kit • State of

    the art in high-perf networking on commodity HW • http://dpdk.org/ • User-mode drivers • No system calls, No context switches • No copying between kernel and user • More profits from DDIO technology • Hugepages • No page swapping, less TLB misses • Memory management • Preallocated set of constant memory spaces • Lockless memory buffers 8
  9. Using of DPDK • DPDK: low-level C library (+ user-mode

    network drivers) • C calls from GO? CGO! • CGO functions calls are expensive • DPDK functions only for low level and at separate cores: • Receive (allocate), Send/Stop (release) 9
  10. Garbage collector • GO language has safe memory release by

    GC • Real time library based on language with GC? Really? • Yes, it is not a framework for mission critical latency tasks • Other tasks are doing well • How • GO GC has comparatively small pauses ~1ms • Packets are in C (DPDK allocated memory) – no garbage • GC can stop everything! Except receives! – They are in C • Packet buffers are enough for stop-the-world for 3ms 10
  11. Customization • Four flow functions are customizable: • Handle, Generate,

    Separate/Split • User function as parameter • Low-level optimization BUT high-level customization • No user involving in prefetches, concurrency, etc. • User function gets each packet or vector of packets for SIMD • Each function can be cloned or stopped • According to the strength of packet flow • And uses separate core 11
  12. Deep in details • Flow functions are chained via lockless

    ring buffers • Copy free paradigm • Ring buffers transfer only pointers to packets • Flow function is a goroutine and is bind to exact core 12
  13. Additional helpers • Packet parsing • Not raw bytes, but

    high-level structure with protocols levels • Checking rules • L2, L3, L4 • Checking ACL from two file formats • Possibility of dynamic ACL changing • Debugging • Writing and reading from PCAP file • Real-time packets number statistics 13
  14. Code example: forwarding/dumping package main import ( "fmt" "github.com/intel-go/yanff/flow" "github.com/intel-go/yanff/packet"

    ) func main() { flow.SystemInit(&flow.Config{ CPUCoresNumber: 10, }) inputFlow := flow.SetReceiver(0) printFlow := flow.SetPartitioner(inputFlow, 50000000, 1) flow.SetHandler(printFlow, hexdumper, nil) outputFlow := flow.SetMerger(inputFlow, printFlow) flow.SetSender(outputFlow, 1) flow.SystemStart() } func hexdumper(currentPacket *packet.Packet, context flow.UserContext) { fmt.Printf("Raw bytes=%x\n", currentPacket.GetRawPacketBytes()) } 14
  15. Results (1/2) IPSec • DPDK performance is state of the

    art • There is no aim to surpass DPDK in performance • The aim is to surpass in productivity and scaling without loosing performance • ~210 code lines YANFF vs ~1500 code lines DPDK 15
  16. Results (2/2) Simple forwarding • Simple Forwarding (9 ACL rules)

    can handle 100% of NIC speed with packets from 256 bytes • *NIC has 28GB/s at 64 byte packets, instead of 40GB/s 16
  17. Further development: deployment • We are going to introduce new

    NFV deployment scheme in the cloud • No OpenStack / OpenNFV • Per tenant scaling between machines • Run to completion model per each tenant on each machine • Cloud boundary node as a gate in/out • This scheme will be suitable for any virtual functions • Works natively with YANFF created functions 17
  18. Conclusion • New framework for rapid development of network functions

    • https://github.com/intel-go/yanff • Under heavy continuous development • Questions? 18
  19. All in all • External (bytes inside network) • Flow

    (*mbufs inside rings) • Packets (as function arguments) Send (Port) Flow -> driver (loop) Receive (Port) driver (loop) -> Flow Stop Flow -> free Separate(SeparateFunction) {input stay} -> Flow Flow -> SeparateFunction -> Flow Merge {slow} Flow -> Flow -> Flow User defined functions Separate Function * -> Packet -> Boolean value -> Handle Function * -> Packet -> Flow functions Handle (SeparateFunction) {can drop} -> Stop Flow -> SeparateFunction-> Flow Generate (GenerateFunction) {can wait} GenerateFunction -> Flow Connections bool Packet functions Parsing packet fields Parse L2 or/and L3 or/and L4 levels Partition (periodicity) -> Flow Flow -> calculation -> Flow Instances (new types) Flow Abstraction without public fields, which is used for pointing connections between Flow functions. Opened by Receive / Split / Separate / Counter / Generate. Closed by Send / Merge / Stop. Packet High-level representation of network packet. Private field is *mbuf, public fields are mac / ip / data /etc: pointers to mbuf with offsets (zero copy). Is extracted before any User defined function. Can be filled after user request by Packet functions. Can be checked by Rule functions. Split Function -> Packet -> № of Flow -> uint Split (SplitFunction) {input closed} -> Flow Flow -> SplitFunction -> Flow -> Flow Checking packet fields by rule Check L2 or/and L3 or/and L4 levels • Flow: type “Flow” Init, Starting, Checking, Flow functions • Packet: type “Packet”, parsing / initializing packet functions • Rules: type “Rule”, parsing rules / checking Packet functions • User package: user defined functions Library External Components Create rule Create checking rule from json / config • Scheduler: Cloning of user defined flow functions • Asm: assembler functions added to GO • Common: technical functions shared by other components • Low: connections with DPDK C implementation Library Internal Components Handle (HandleFunction) {can’t drop} Flow -> HandleFunction -> Flow Port Network door, used in Receive, Send. Initializing packet fields Initialize L2 or/and L3 or/and L4 levels Rule functions Rule Set of checking rules, used in User defined functions. Encapsulate / Decapsulate Generate Function * Packet -> * Can process vector of packets at one time All functions take packet and handling context All functions at separate cores and can be cloned 19
