Hadoop 2.x HDFS Cluster Installation (VirtualBox)

This is a straight-forward tutorial for those who are goring to use HDFS in an academic environment on their notebooks or PCs.

Transcript

1. هدش عیزوت هداد شزادرپ هاگراک یتشهبدیهش -سیدرپ رتویپماک یسدنهم و مولع هدکشناد :سرد هدش عیزوت هداد هاگیاپ :داتسا ییابطابط یداه رتکد :هئارا یقیدص لضفلاوبا رذآ ۱۳۹۳
2. 2 Apache Hadoop 2.x Cluster Installation Amir Sedighi @amirsedighi http://hexican.com Dec 2014
3. 3 References • http://hadoop.apache.org/docs/r2.2.0/ • http://www.vasanthivuppuluri.com/hadoop/instal ling-hadoop-2-5-1-on-64-bit-ubuntu-14-01/ • https://sites.google.com/site/hadoopandhive/ho me
4. 4 Topics • Assumptions • First Node – Installing Java – Downloading and Extracting Hadoop – Hadoop and Java Env Variables – Disabling IP6 – Configuring Hadoop • Cloning • HDFS – Starting HDFS • HDFS Health • FS Commands • Reclaiming Space • Reducing Replication Factor
5. 5 Assumptions • You already know about Linux. – http://www.slideshare.net/AmirSedighi/distrinuted- data-processing-workshop-sbu
6. 6 Installing Java • $ sudo apt-get install default-jdk
7. 7 Downloading and Extracting • http://hadoop.apache.org/releases.html • $ tar -zxvf hadoop-2.2.0.tar.gz
8. 8 Hadoop and Java Env Variables • Append the following definitions to /etc/profile or ~/.bashrc export HADOOP_PREFIX="/home/amir/hadoop-2.2.0" export HADOOP_HOME=$HADOOP_PREFIX export HADOOP_COMMON_HOME=$HADOOP_PREFIX export HADOOP_CONF_DIR=$HADOOP_PREFIX/etc/hadoop export HADOOP_HDFS_HOME=$HADOOP_PREFIX export HADOOP_MAPRED_HOME=$HADOOP_PREFIX export HADOOP_YARN_HOME=$HADOOP_PREFIX export HADOOP_COMMON_LIB_NATIVE_DIR=$HADOOP_HOME/lib/native export HADOOP_OPTS="-Djava.library.path=$HADOOP_HOME/lib" export JAVA_HOME=/usr/java/jdk1.7.0_55 export PATH=$PATH:$JAVA_HOME/bin:/home/amir/hadoop- 2.2.0/bin:/home/amir/hadoop-2.2.0/sbin
9. 9 Disabling IP6 • $ sudo nano /etc/sysctl.conf # Disable IPv6 net.ipv6.conf.all.disable_ipv6 = 1 net.ipv6.conf.default.disable_ipv6 = 1 net.ipv6.conf.lo.disable_ipv6 = 1
10. 10 Hadoop Configuration • You would need to create or modify the following files inside hadoop/etc/hadoop: – slaves – core-site.xml – yarn-site.xml – hdfs-site.xml – hadoop-env.sh
11. 11 slaves • List all DataNodes in slaves file. slave1 slave2 slave3
12. 12 slaves Create slaves in hadoop/etc/hadoop folder: u01 u02 u03 u04 u05 u06 ...
13. 13 etc/hosts and hadoop/etc/hadoop/slaves
14. 14 core-site.xml • Edit core-site.xml and apply the following: <configuration> <property> <name>fs.defaultFS</name> <value>hdfs://u01/</value> <description>NameNode URI</description> </property> </configuration>
15. 15 core-site.xml
16. 16 yarn-site.xml <configuration> <property> <name>yarn.resourcemanager.hostname</name> <value>u01</value> <description>The hostname of the RM.</description> </property> <property> <name>mapreduce.framework.name</name> <value>yarn</value> </property> <property> <name>yarn.nodemanager.aux-services</name> <value>mapreduce_shuffle</value> </property> <property> <name>yarn.nodemanager.aux-services.mapreduce_shuffle.class</name> <value>org.apache.hadoop.mapred.ShuffleHandler</value> </property> </configuration>
17. 17 yarn-site.xml
18. 18 hdfs-site.xml <configuration> <property> <name>dfs.datanode.data.dir</name> <value>file:///home/amir/hadoop-2.2.0/hdfs/datanode</value> </property> <property> <name>dfs.namenode.name.dir</name> <value>file:///home/amir/hadoop-2.2.0/hdfs/namenode</value> </property> </configuration>
19. 19 hdfs-site.xml
20. 20 hadoop-env.sh • Add the following: – export JAVA_HOME=/usr/java/jdk1.7.0_55
21. 21 Reboot • $ sudo reboot
22. 22 Cloning • Extend the cluster by cloning. – NOTE: Find the instruction here: • http://www.slideshare.net/AmirSedighi/distrinuted-data- processing-workshop-sbu
23. 23 HDFS • The Hadoop Distributed File System (HDFS) is a distributed file system designed to run on commodity hardware. • It has many similarities with existing distributed file systems. However, the differences from other distributed file systems are significant. • HDFS is highly fault-tolerant and is designed to be deployed on low-cost hardware. • HDFS provides high throughput access to application data and is suitable for applications that have large data sets. • HDFS relaxes a few POSIX requirements to enable streaming access to file system data. • HDFS was originally built as infrastructure for the Apache Nutch web search engine project. HDFS is part of the Apache Hadoop Core project.
24. 24 HDFS Architecture
25. 25 DataNodes
26. 26 start-dfs.sh
27. 27 HDFS Health • $ jps – NameNode – DataNode • Check log files • Web UI – http://u01:50070
28. 28 HDFS Health
30. 30 HDFS Health, Live Nodes
31. 31 Hadoop FS Commands • cat • chmod • chown • copyFromLocal • copyToLocal • cp • du • expunge • get • ls • mkdir • put • rm • tail
32. 32 HDFS Commands
33. 33 Space Reclamation • Delete Files – $ hadoop fs -rm /filename – $ hadoop fs -expunge • Decrease Replication Factor
34. 34 How to change replication factor of existing files in HDFS • To set replication of an individual file to 4: – hadoop dfs -setrep -w 4 /path/to/file • You can also do this recursively. To change replication of entire HDFS to 1: – hadoop dfs -setrep -R -w 1 /
35. 35 Questions?
