  1. 2 December 2005
    Information Visualisation
    Data Presentation
    Prof. Beat Signer
    Department of Computer Science
    Vrije Universiteit Brussel
    beatsigner.com

    View Slide

  2. Beat Signer - Department of Computer Science - [email protected] 2
    March 16, 2023
    Information Visualisation Process
    Data
    Representation
    Data
    Data
    Presentation
    Interaction
    mapping
    perception and
    visual thinking

    View Slide

  3. Beat Signer - Department of Computer Science - [email protected] 3
    March 16, 2023
    Marks and Channels
    ▪ Marks are basic graphical elements (geometric primi-
    tives) to represent items or links
    ▪ Channels control the appearance of marks
    ▪ Vis design space described by orthogonal combination of
    marks and channels
    ▪ Complex visual encodings can be decomposed and
    analysed in terms of their marks and channels
    ▪ building blocks for analysing visual encodings

    View Slide

  4. Beat Signer - Department of Computer Science - [email protected] 4
    March 16, 2023
    Marks
    ▪ Basic geometric/graphical element in an image
    ▪ classified according to the number of spatial dimensions

    View Slide

  5. Beat Signer - Department of Computer Science - [email protected] 5
    March 16, 2023
    Marks …
    ▪ Zero-, one- or two-dimensional marks
    ▪ three-dimensional marks (volumes) are not used frequently
    due to limited perception

    View Slide

  6. Beat Signer - Department of Computer Science - [email protected] 6
    March 16, 2023
    Mark Types
    ▪ Item marks
    ▪ Link marks
    ▪ connection marks
    - pairwise relationship between two items via a line
    ▪ containment marks (enclosure or nesting)
    - hierarchical relationships using areas

    View Slide

  7. Beat Signer - Department of Computer Science - [email protected] 7
    March 16, 2023
    Channels

    View Slide

  8. Beat Signer - Department of Computer Science - [email protected] 8
    March 16, 2023
    Channels …
    ▪ Control appearance of mark independently of the
    dimensionality of the geometric primitive
    ▪ Many visual channels
    ▪ spatial position
    ▪ shape
    ▪ colour (hue, saturation and luminance)
    ▪ motion (e.g. flicker, direction and velocity)
    ▪ size (i.e. length, area and volume)
    ▪ tilt (angle)
    ▪ Size and shape channels cannot be used on all types of
    marks
    ▪ e.g. area marks typically not size or shape coded

    View Slide

  9. Beat Signer - Department of Computer Science - [email protected] 9
    March 16, 2023
    Channel Types
    ▪ Identity channels
    ▪ information about what something is
    ▪ e.g. shape, hue colour channel, motion pattern
    ▪ Magnitude channels
    ▪ how much of something is there
    ▪ e.g. size (length, area or volume), luminance or saturation colour
    channels, angle, …

    View Slide

  10. Beat Signer - Department of Computer Science - [email protected] 10
    March 16, 2023
    Using Marks and Channels
    ▪ Progression of chart types
    ▪ (a) one quantitative and one categorical attribute
    ▪ (b) scatterplot with two quantitative attributes
    ▪ (c) two quantitative and one categorical attribute via hue
    ▪ (d) three quantitative (one via size) and one categorical attribute
    ▪ In examples each attribute encoded via single channel
    ▪ multiple channels might also be used redundantly

    View Slide

  11. Beat Signer - Department of Computer Science - [email protected] 11
    March 16, 2023
    Using Marks and Channels …
    ▪ Use of marks and channels guided by the principles of
    expressiveness and effectiveness
    ▪ after identifying most important attributes ensure that they
    are encoded with the highest ranked channel
    ▪ Expressiveness principle
    ▪ visual encoding should express all of, and only, the information
    in the dataset attributes
    - ordered data (ordered attributes) should be shown in a way that our perceptual
    system senses as ordered → use magnitude channels
    - unordered data (categorical attributes) should not be shown in a way that
    perceptually implies an ordering that does not exist → use identity channels

    View Slide

  12. Beat Signer - Department of Computer Science - [email protected] 12
    March 16, 2023
    Using Marks and Channels …
    ▪ Effectiveness principle
    ▪ importance of attribute should match the salience of the channel
    ▪ most important attributes (depends on the task) encoded with
    most effective channels
    ▪ Attributes encoded with position will dominate the user's
    mental model
    ▪ choice of which attributes to encode with position is the most
    central choice in visual encoding

    View Slide

  13. Beat Signer - Department of Computer Science - [email protected] 13
    March 16, 2023
    Channel Effectiveness
    [Visualization Analysis & Design, Tamara Munzner, 2014]

    View Slide

  14. Beat Signer - Department of Computer Science - [email protected] 14
    March 16, 2023
    Channel Effectiveness …
    ▪ Obvious way to quantify effectiveness via accuracy
    ▪ how close is human perceptual judgement to some objective
    measurement of the stimulus?
    ▪ Different visual channels are perceived with different
    levels of accuracy
    ▪ characterised by Steven's Psychophysical Power Law

    View Slide

  15. Beat Signer - Department of Computer Science - [email protected] 15
    March 16, 2023
    Steven's Psychophysical Power Law
    ▪ Responses to sensory
    experience of magnitude
    are characterisable by
    power laws
    ▪ 𝑆 = perceived sensation
    ▪ I = physical intensity
    ▪ exponent N depends on
    sensory modality
    ▪ most stimuli are magnified
    (superlinear) or compressed
    (sublinear)
    [Visualization Analysis & Design, Tamara Munzner, 2014]

    View Slide

  16. Beat Signer - Department of Computer Science - [email protected] 16
    March 16, 2023
    Error Rates Across Channels
    Results by Cleveland and McGill, 1984

    View Slide

  17. Beat Signer - Department of Computer Science - [email protected] 17
    March 16, 2023
    Channel Effectiveness …
    ▪ Channel effectiveness mainly based on accuracy but
    also takes into account
    ▪ discriminability
    ▪ separability
    ▪ popout
    ▪ grouping

    View Slide

  18. Beat Signer - Department of Computer Science - [email protected] 18
    March 16, 2023
    Discriminability
    ▪ Quantify the number of distinguishable steps (bins) that
    are available within a visual channel
    ▪ some channels (e.g. line width) have a very limited number
    of bins
    ▪ small number of bins is not a problem if the number of values
    to be encoded is also small
    ▪ number of different values that need to be shown for an attribute
    must not be greater than the available bins for the visual channel
    - otherwise aggregate or use different visual channel

    View Slide

  19. Beat Signer - Department of Computer Science - [email protected] 19
    March 16, 2023
    Effective Line Width Use
    ▪ Limited number of
    discriminable bins
    ▪ line width works well
    for 3 or 4 different
    values

    View Slide

  20. Beat Signer - Department of Computer Science - [email protected] 20
    March 16, 2023
    Separability
    ▪ Channels are not always completely independent from
    each other (interchannel interference)
    ▪ ranging from fully separable channels to the inseparably
    combined integral channels (major interference)
    ▪ Visual encoding straightforward with separable channels
    ▪ encoding of different information in integral channels will fail

    View Slide

  21. Beat Signer - Department of Computer Science - [email protected] 21
    March 16, 2023
    Popout
    ▪ Many channels provide visual popout (preattentive
    processing) where a distinct item stands out from many
    others immediately
    ▪ time to spot the different object does not depend on the number
    of distractor objects (a) vs. (b)
    ▪ massively parallel processing of low-level features
    ▪ popout effect slower for shapes ((c) and (d)) than for colour hue
    channel ((a) and (b))
    ▪ channels with individual popout cannot simply be combined
    ((e) and (f))
    - need serial search to find the red circle in (f)
    ▪ Most pairs of channels do not support popout
    ▪ use popout for a single channel at a time

    View Slide

  22. Beat Signer - Department of Computer Science - [email protected] 22
    March 16, 2023
    Popout …

    View Slide

  23. Beat Signer - Department of Computer Science - [email protected] 23
    March 16, 2023
    Popout Channels
    ▪ Popout cannot only occur for colour hue and shape
    channels
    ▪ tilt (a)
    ▪ size (b)
    ▪ shape (c)
    ▪ proximity (d)
    ▪ shadow direction (e)

    View Slide

  24. Beat Signer - Department of Computer Science - [email protected] 24
    March 16, 2023
    Popup Channels …

    View Slide

  25. Beat Signer - Department of Computer Science - [email protected] 25
    March 16, 2023
    Grouping
    ▪ Containment (links) is the strongest cue for grouping
    followed with connection coming in second
    ▪ Items sharing the same level of a categorical attribute
    can also be perceived as a group
    ▪ Proximity is the third strongest grouping approach
    ▪ Similarity (hue, motion and shape)
    ▪ shape and motion channel to be used with care

    View Slide

  26. Beat Signer - Department of Computer Science - [email protected] 26
    March 16, 2023
    Relative versus Absolute Judgements
    ▪ Perceptual system fundamentally based on relative
    judgements and not absolute ones (Weber's Law)
    ▪ e.g. position along a scale can be perceived more accurately than
    pure length judgement without a scale

    View Slide

  27. Beat Signer - Department of Computer Science - [email protected] 27
    March 16, 2023
    Relative Luminance Perception
    ▪ Perception of luminance is contextual based on the
    contrast with surrounding colours

    View Slide

  28. Beat Signer - Department of Computer Science - [email protected] 28
    March 16, 2023
    Colour (Hue) Perception
    ▪ Our visual systems evolved to provide colour constancy
    ▪ same surface identifiable across illumination conditions
    ▪ visual system might work against simple colour encodings
    [Visualization Analysis & Design, Tamara Munzner, 2014]

    View Slide

  29. Beat Signer - Department of Computer Science - [email protected] 29
    March 16, 2023
    Mapping Colour
    ▪ Luminance and saturation
    are magnitude channels
    while hue is an identity
    channel
    ▪ luminance can be used for
    two to four levels (bins)
    ▪ saturation can be used for
    up to three levels (bins)
    - strongly interacts with size
    channel
    ▪ saturation and hue are non-
    separable channels for small
    regions

    View Slide

  30. Beat Signer - Department of Computer Science - [email protected] 30
    March 16, 2023
    Comparing HSL Lightness
    ▪ Computed HSL lightness L is the same for all six colours
    ▪ true luminance as measured by an instrument
    ▪ perceived luminance L* represents what we see
    - more sensitive to certain wavelengths (green and yellow) as shown earlier
    with the spectral sensitivity

    View Slide

  31. Beat Signer - Department of Computer Science - [email protected] 31
    March 16, 2023
    No Implicit Order for Hue
    ▪ Sometimes learned hue orders (not at perception level)
    ▪ green-yellow-red from traffics lights
    ▪ rainbow colour ordering

    View Slide

  32. Beat Signer - Department of Computer Science - [email protected] 32
    March 16, 2023
    Colourmaps
    ▪ A colourmap defines a mapping between colours and
    data values
    ▪ Colourmaps can be categorical or ordered (sequential
    or diverging)
    ▪ use magnitude channels of luminance and saturation
    for ordered data

    View Slide

  33. Beat Signer - Department of Computer Science - [email protected] 33
    March 16, 2023
    Colourmap Categorisation (Taxonomy)
    [Visualization Analysis & Design, Tamara Munzner, 2014]

    View Slide

  34. Beat Signer - Department of Computer Science - [email protected] 34
    March 16, 2023
    Categorical Colourmaps
    ▪ Categorical colourmaps (qualitative colourmaps) are
    normally segmented (not continous)
    ▪ effective for categorical data (next best channel after position)
    ▪ Good resource for creating colourmaps is ColorBrewer

    View Slide

  35. Beat Signer - Department of Computer Science - [email protected] 35
    March 16, 2023
    Categorical Colourmaps …
    ▪ Can use six to twelve distinguishable hue steps (bins)
    for small separated regions
    ▪ includes background colour and default object colours
    ▪ use easy nameable colours: e.g. red, blue, green, yellow, orange,
    brown, pink, magenta, purple and cyan
    ▪ Use highly saturated colours for small regions
    ▪ Use low-saturation colours (pastels) for large regions

    View Slide

  36. Beat Signer - Department of Computer Science - [email protected] 36
    March 16, 2023
    Ineffective Categorical Colourmap Use

    View Slide

  37. Beat Signer - Department of Computer Science - [email protected] 37
    March 16, 2023
    Example of Using Additional Channels
    ▪ Dataset with 27 categorical levels from 7 categories

    View Slide

  38. Beat Signer - Department of Computer Science - [email protected] 38
    March 16, 2023
    Example of Using Additional Channels …

    View Slide

  39. Beat Signer - Department of Computer Science - [email protected] 39
    March 16, 2023
    Example of Using Additional Channels …

    View Slide

  40. Beat Signer - Department of Computer Science - [email protected] 40
    March 16, 2023
    Example of Using Additional Channels …

    View Slide

  41. Beat Signer - Department of Computer Science - [email protected] 41
    March 16, 2023
    Ordered Colourmaps
    ▪ Sequential colourmap ranges from a minimum value
    to a maximum value
    ▪ use luminance (with or without hue) or saturation channel
    ▪ Diverging colourmap
    ▪ use two hues at the endpoints and a neutral colour (e.g. white
    or grey) as a midpoint

    View Slide

  42. Beat Signer - Department of Computer Science - [email protected] 42
    March 16, 2023
    Rainbow versus Two-Hue Colour Map
    ▪ How many hues to use in continous colourmaps?
    ▪ high-level structure versus local neighbourhoods (fine grained
    details)
    ▪ rainbow colourmap makes it easier to discuss specific (nameable)
    subranges

    View Slide

  43. Beat Signer - Department of Computer Science - [email protected] 43
    March 16, 2023
    Rainbow Continous Colourmaps
    ▪ Problems of rainbow continous colourmaps
    ▪ hue is used to indicate order (despite being an identity channel)
    ▪ scale is not perceptually linear
    ▪ fine details cannot be perceived via the hue channel
    - luminance channel much better (luminance contrast required for edge
    detection in our eyes)

    View Slide

  44. Beat Signer - Department of Computer Science - [email protected] 44
    March 16, 2023
    Rainbow Continous Colourmaps …
    ▪ The three problems of rainbow continous colourmaps
    can be addressed by using monotonically increasing
    luminance colourmaps
    ▪ multiple hues are ordered according to their luminance from
    lowest to highest
    ▪ Rainbow colourmap
    ▪ standard rainbow colour-
    map (a) vs. perceptually
    linear rainbows (b) with
    decreased dynamic range
    ▪ segmented rainbow for
    categorical data (c)

    View Slide

  45. Beat Signer - Department of Computer Science - [email protected] 45
    March 16, 2023
    Bivariate Colourmaps
    ▪ Safest use of colour channel is to visually encode a
    single attribute (univariate)
    ▪ In the colourmap categorisation we have seen
    colourmaps encoding two separate attribute (bivariate)
    ▪ if one of the two attributes is binary then it is straightforward to
    create a comprehensible bivariate colourmap
    - choose base set of hues and vary the saturation
    ▪ if both attributes are categorical with multiple levels the results
    will be poor
    ▪ combinations of sequential and diverging attributes should be
    used carefully
    - appear frequently in vis solutions but some people have difficulties
    to interpret their meaning

    View Slide

  46. Beat Signer - Department of Computer Science - [email protected] 46
    March 16, 2023
    Colourblind-Safe Colourmaps
    ▪ A safe strategy is to avoid using the hue channel only
    ▪ e.g. vary luminance or saturation in addition to hue in categorical
    colourmaps
    ▪ Avoid colourmaps emphasising red-green (e.g. diverging
    red-green colourmap)
    ▪ Use colour blindness simulators and tools such
    as Viz Palette

    View Slide

  47. Beat Signer - Department of Computer Science - [email protected] 47
    March 16, 2023
    Size Channels
    ▪ Suitable for ordered data but interacts with most other
    channels
    ▪ length (1D)
    - judgment of length is very accurate
    ▪ area (2D)
    - judgement of area is less accurate
    ▪ volume (3D)
    - volume channel is quite inaccurate

    View Slide

  48. Beat Signer - Department of Computer Science - [email protected] 48
    March 16, 2023
    Tilt/Angle Channel
    ▪ Encode magnitude information based on the orientation
    of a mark
    ▪ tilt: orientation against the global frame of the display
    ▪ angle: orientation of a line with respect to another line
    ▪ Accuracy of our perception of a tilt/angle is not uniform
    ▪ very accurate near exact horizontal, vertical or diagonal positions

    View Slide

  49. Beat Signer - Department of Computer Science - [email protected] 49
    March 16, 2023
    Other Channels
    ▪ Shape channel
    ▪ commonly applied to point marks
    ▪ can also be applied to line marks (e.g. dotted or dashed lines)
    ▪ can distinguish between dozens up to hundreds bins
    - strong interaction between shape and size channel
    ▪ Motion channels
    ▪ direction of motion
    ▪ velocity of motion
    ▪ flicker and blinking frequency
    ▪ very separable from all other static channels
    ▪ strongly draws attention (strong popout)
    - hard to ignore and should be used carefully

    View Slide

  50. Beat Signer - Department of Computer Science - [email protected] 50
    March 16, 2023
    Other Channels …
    ▪ Texture and stippling channel
    ▪ texture can be simplified by considering it as a combination of the
    following three perceptual dimensions
    - orientation, scale and contrast
    ▪ texture can be used to show categorical attributes as well as
    ordered attributes
    ▪ Stippling fills regions of drawings with short strokes
    - e.g. dashed or dotted lines
    - used for area marks in older printing (to simulate grey)

    View Slide

  51. Beat Signer - Department of Computer Science - [email protected] 51
    March 16, 2023
    Exercise 5
    ▪ Visualisation in Python

    View Slide

  52. Beat Signer - Department of Computer Science - [email protected] 52
    March 16, 2023
    Further Reading
    ▪ This lecture is mainly based on the
    book Visualization Analysis & Design
    ▪ chapter 5
    - Marks and Channels
    ▪ chapter 10
    - Map Color and Other Channels

    View Slide

  53. Beat Signer - Department of Computer Science - [email protected] 53
    March 16, 2023
    References
    ▪ Visualization Analysis & Design, Tamara
    Munzner, Taylor & Francis Inc, (Har/Psc edition),
    May, November 2014,
    ISBN-13: 978-1466508910
    ▪ Semiology of Graphics: Diagrams, Networks,
    Maps, Jacques Bertin, ESRI PR (1st edition),
    January 2010,
    ISBN-13: 978-1466508910
    ▪ Information Visualization: Perception
    for Design, Colin Ware, Morgan Kaufmann
    (3rd edition) May 2012,
    ISBN-13: 978-0123814647

    View Slide

  54. Beat Signer - Department of Computer Science - [email protected] 54
    March 16, 2023
    References …
    ▪ ColorBrewer 2.0
    ▪ https://colorbrewer2.org
    ▪ Viz Palette
    ▪ https://projects.susielu.com/viz-palette

    View Slide

  55. 2 December 2005
    Next Lecture
    Data Processing and Visualisation Frameworks

    View Slide
