Voracle - Compression Oracle Attacks on VPN Tunnels

Leaking secrets from OpenVPN using compression oracle side channel.

Transcript

1. Compression Oracle
   Attacks on VPN
   Networks
   Nafeez


   View Slide

2. Nafeez
   AppSec research, static analysis tools, writing code

   Maker @ assetwatch.io - Simple & Transparent Attack
   Surface Discovery

   @sketpic_fx


   View Slide

3. Overview
   Compression Side Channel and Encryption

   History of attacks

   VPNs and how they use compression

   Voracle attack

   How to find if your "VPN" is vulnerable

   Way forward


   View Slide

4. Data Compression
   LZ77
   Replace redundant patterns

   102 Characters

   Everything looked dark and bleak, everything looked gloomy,
   and everything was under a blanket of mist
   89 Characters

   Everything looked dark and bleak, (-34,18)gloomy,
   and (-54,11)was under a blanket of mist


   View Slide

5. Data Compression
   Huffman Coding
   Replace frequent bytes with shorter codes

   https://en.wikipedia.org/wiki/Huffman_coding



   View Slide

6. Data Compression
   DEFLATE - LZ77 + Huffman Coding

   ZLIB, GZIP are well known DEFLATE libraries



   View Slide

7. Compression Side Channel
   First known research in 2002



   View Slide

8. The Side Channel
   Length of encrypted payloads



   View Slide

9. Plain Text Data
   Compress
   Encrypt
   Encrypted Data +
   Data Length


   View Slide

10. Plain Text Data
    Compress
    Encrypt
    Add Attacker
    Controlled Bytes
    Encrypted Data +
    Data Length


    View Slide

11. Plain Text Data
    Compress
    Encrypt
    Add Attacker
    Controlled Bytes
    Observe Encrypted
    Traffic
    Encrypted Data +
    Data Length


    View Slide

12. Compression Oracle Attack
    Chosen Plain Text Attack

    Brute force the secret byte by byte

    Force a compression using the chosen byte and the
    existing bytes in the secret


    View Slide

13. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=1
    Encrypted Length = 30
    secret=637193-some-app-data;secret=1


    View Slide

14. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=1
    Encrypted Length = 30
    secret=637193-some-app-data;secret=1
    Application Data
    Attacker injected
    bytes
    Whole data before
    compression /
    encryption


    View Slide

15. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=1
    Encrypted Length = 30
    secret=637193-some-app-data;secret=1
    Compressible Compressible


    View Slide

16. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=2
    Encrypted Length = 30
    secret=637193-some-app-data;secret=2


    View Slide

17. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=3
    Encrypted Length = 30
    secret=637193-some-app-data;secret=3


    View Slide

18. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=4
    Encrypted Length = 30
    secret=637193-some-app-data;secret=4


    View Slide

19. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=5
    Encrypted Length = 30
    secret=637193-some-app-data;secret=5


    View Slide

20. secret=637193-some-app-data;
    Compress
    Encrypt
    Data Length
    secret=6
    Encrypted Length = 29
    secret=637193-some-app-data;secret=6
    More Compression, Smaller Length
    Compression increased
    by 1 byte


    View Slide

21. How can we convert this
    into a real world attack on
    browsers?


    View Slide

22. Plain Text Data
    Compress
    Encrypt
    Add Attacker
    Controlled Bytes
    Observe Encrypted
    Traffic
    Encrypted Data +
    Data Length


    View Slide

23. Add Attacker
    Controlled Bytes
    Observe Encrypted
    Traffic
    Ambient authority of
    Cookies in browsers
    Simple cross-domain
    requests with POST body
    MITM. People do this
    all the time


    View Slide

24. EkoParty 2012
    Back in 2012
    Juliano Rizzo, Thai Duong


    View Slide

25. CRIME, 2012
    www.ekoparty.org/archive/2012/CRIME_ekoparty2012.pdf


    View Slide

26. TIME Attack 2013
    Tal Be'ery, Amichai Shulman
    Timing side channel purely via browsers, using TCP window
    sizes.

    Extending CRIME to HTTP Responses


    View Slide

27. BREACH Attack 2013
    BreachAttack.com
    Angelo Prado, Neal Harris, Yoel Gluck


    View Slide

28. So far
    CRIME style attacks have been mostly targeted on HTTPS

    There are more - HEIST, Practical Developments to BREACH


    View Slide

29. So, whats new today?


    View Slide

30. VPN Tunnels


    View Slide

31. TLS VPNs are pretty
    common these days


    View Slide

32. View Slide

33. What do most of these
    SaaS VPNs have in
    common?


    View Slide

34. OpenVPN


    View Slide

35. High level overview
    Authentication & Key Negotiation (Control Channel)

    Data Channel Compression
    Data Channel Encryption


    View Slide

36. Compress everything
    UDP

    TCP

    Bi-Directional


    View Slide

37. OpenVPN Compression
    Algorithms
    LZO

    LZ4

    -LZ77 Family-


    View Slide

38. We have a compress then
    encrypt on all of data channel


    View Slide

39. VORACLE Attack


    View Slide

40. Under a VPN, HTTP
    WebApps are still
    insecure !


    View Slide

41. Things are safe, if the underlying app
    layer already uses an encryption channel.


    View Slide

42. Things might go bad, if the VPN tunnel is
    helping you encrypt already non-
    encrypted data


    View Slide

43. Lets see how this attack works on an
    HTTP website using an encrypted VPN


    View Slide

44. VPN Server and Client has compression enabled
    Requirements
    Attacker can observe VPN traffic
    VPN User visits attacker.com


    View Slide

45. Attack Setup
    VPN User


    View Slide

46. Attack Setup
    VPN User
    Browser


    View Slide

47. Attack Setup
    VPN User
    Browser
    HTTP WebApp


    View Slide

48. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression


    View Slide

49. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression


    View Slide

50. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression
    Attacker


    View Slide

51. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression
    Attacker
    attacker.com


    View Slide

52. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression
    Attacker
    attacker.com
    Passive
    MITM


    View Slide

53. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression
    Attacker
    attacker.com
    Passive
    MITM
    Injected Ads,

    Malicous Blogs,

    etc.


    View Slide

54. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression
    Attacker
    attacker.com
    Passive
    MITM
    Injected Ads,

    Malicous Blogs,

    etc.
    Can Observe VPN
    Data packet Lengths


    View Slide

55. Attack Setup
    VPN User
    Browser
    HTTP WebApp
    Trusted VPN with Compression
    Attacker
    attacker.com
    Passive
    MITM
    Injected Ads,

    Malicous Blogs,

    etc.
    Can Observe VPN
    Data packet Lengths
    Can Send Cross
    Domain requests to
    the HTTP WebApp


    View Slide

56. Attacker can now conduct Compression Oracle attacks on
    HTTP requests and responses


    View Slide

57. https://github.com/OpenVPN/openvpn3
    Browser
    VPN Client
    VPN Server OpenVPN Server
    WebApp http://insecure.skepticfx.com
    Mozilla Firefox
    Steal sessionId cookie from a cross-domain website
    Attack Goal
    Demo


    View Slide

58. Voracle
    https://github.com/skepticfx/voracle


    View Slide

59. Attack Challenges
    No Server Name Indication(SNI) or TLS certificates.

    VPN traffic is too chatty. Everything goes through it

    Hard to determine attacker's own traffic


    View Slide

60. Browser needs to send HTTP
    requests in single TCP Data Packet
    Also


    View Slide

61. Google Chrome splits Plain HTTP
    requests into Header and Body
    So we can't get the compression
    window in the same request


    View Slide

62. Mozilla Firefox sends them all
    in a single TCP data packet
    Now we get the compression
    window in the same request


    View Slide

63. Detecting Voracle in your
    VPN


    View Slide

64. If your VPN provider is using OpenVPN -
    take a look at your client configuration.


    View Slide

65. OpenVPN Client
    Configuration (*.OVPN)


    View Slide

66. Or you can test this dynamically by
    triggering compression and observing the
    length


    View Slide

67. DIY Voracle Detection
    Fire up Wireshark

    Connect to your VPN under test

    Send a few Curl requests with compression

    Observe VPN Payload Length


    View Slide

68. curl -s -o /dev/null -X POST http://website.com
    -d "--some-data-- Secret=37346282;
    --blah-- Secret=1 Secret=1"
    Length = x

    Curl and Observe Length


    View Slide

69. curl -s -o /dev/null -X POST http://website.com
    -d "--some-data-- Secret=37346282;
    --blah-- Secret=2 Secret=2"
    Length = x

    Curl and Observe Length


    View Slide

70. curl -s -o /dev/null -X POST http://website.com
    -d "--some-data-- Secret=37346282;
    --blah-- Secret=3 Secret=3"
    Length = x-1

    Curl and Observe Length
    More Compression, Smaller Length


    View Slide

71. Fix?


    View Slide

72. Fixing Compression is an
    interesting problem


    View Slide

73. Remember when SPDY
    was vulnerable to
    CRIME?


    View Slide

74. HPACK in HTTP/2
    selectively disables header
    compression for sensitive
    fields


    View Slide

75. https://http2.github.io/http2-spec/compression.html


    View Slide

76. cf-nocompress
    https://blog.cloudflare.com/a-solution-to-compression-oracles-on-the-web/


    View Slide

77. For VPNs, Disable
    compression entirely for
    all plain text transactions


    View Slide

78. Turning compression
    off by default is
    opinionated


    View Slide

79. OpenVPN chose to warn the implementors
    more explicitly to turn off data Compression.
    https://github.com/OpenVPN/openvpn/commit/a59fd147


    View Slide

80. turned off
    compression entirely


    View Slide

81. Its time, everything
    moves to HTTPS


    View Slide

82. Takeaway
    EndUsers & Website owners - If you are using VPN to
    access plain text websites over the internet, its time to move
    them to HTTPs.

    VPN Providers - Explicitly state what your VPN protects
    against. If you are claiming your VPN tunnel protects against
    plain text web apps, ensure you do not compress them.


    View Slide

83. Thank you!
    @skeptic_fx
