1. Python on bare metal
   fast & efficient code with MicroPython
   Jessica Greene @sleepypioneer


   View Slide

2. MicroPython
    A complete reimplementation of Python
    Designed to be efficient with resources
    Designed to run bare metal
   Includes:
    A compiler, runtime & familiar REPL
    Support for basic libraries
    Extra modules to control hardware


   View Slide

3. PyBoard, ESP32, ESP8266 & more...


   View Slide

4. Challenges of working on microcontrollers
   BATTERY POWERED VERY LITTLE MEMORY
   (RAM, ROM)
   NORMALLY REQUIRE
   LOW LEVEL LANGUAGE


   View Slide

5. How does MicroPython solve the issue of having a low
   amount of RAM?
   Interned strings, most already in ROM
   Small integers stuffed in a pointer to avoid using heap (trick from lisp)
   Optimised method calls to not use heap
   Garbage collection


   View Slide

6. Normal python uses
   megabytes RAM if
   not 100s
   MicroPython can run
   with only 8 kilobytes
   & it runs without an
   OS, so on bare
   metal
   Python Vs MicroPython


   View Slide

7. How you can impact
   this with your code?


   View Slide

8. Tips: Memory allocation
   Doesn’t use heap Uses Heap
   Expressions Importing
   If, while, for and try statements Defining functions & classes
   Local variables Assigning global variables for the first time
   Small integer arithmetic Creating data structures
   Inplace operations on existing data structures
   Calling functions/ methods with positional or
   keyword args


   View Slide

9. Tips: CPU time
   USE FUNCTIONS TO
   AVOID GLOBAL
   SCOPES
   USE LOCAL
   VARIABLES
   CACHE MODULE
   FUNCTIONS &
   OBJECT METHODS
   AS LOCALS
   PREFER LONGER
   EXPRESSIONS NOT
   SPLIT UP ONES
   RUNTIME IS FAST!
   E.G. STR.STARTSWITH


   View Slide

10. Tips: RAM usage
    DON'T USE HEAP
    WHEN POSSIBLE
    SHORTER VARIABLE
    NAMES, REUSE
    THEM; EG X,Y,I, LEN,
    VAR
    DON'T USE * OR **
    ARGS
    SCRIPT
    MINIFICATION
    ULTIMATE SOLUTION:
    FREEZE SCRIPTS INTO
    THE FIRMWARE (AT
    COMPILE TIME)


    View Slide

11. Code example


    View Slide

12. LED Blink script
    import time, machine
    led = machine.Pin('LED_BLUE')
    for i in range(N):
    led.on()
    led.off()
    50kHz
    @dpgeorge


    View Slide

13. Inside a function - removes global variables 60kHz
    import time, machine
    led = machine.Pin('LED_BLUE')
    def blink_simple(n):
    for i in range(n):
    led.on()
    led.off()
    @dpgeorge


    View Slide

14. Preload methods & range() optimisation
    def blink_preload(n):
    on = led.on # returns a bound method
    off = led.off
    r = range(n) # optimise the range
    for i in r:
    on()
    off()
    180kHz
    @dpgeorge


    View Slide

15. Loop unrolling
    def blink_preload_unrolled8(n):
    n //= 8
    on = led.on
    off = led.off
    r = range(n)
    for i in r:
    on()
    off()
    on()
    off()
    ....
    220kHz
    @dpgeorge


    View Slide

16. Native mode
    @micropython.native
    def blink_preload_unrolled8_native(n:int):
    n //= 4
    on = led.on
    off = led.off
    r = range(n)
    for i in r:
    on()
    off()
    on()
    off()
    ....
    290kHz
    @dpgeorge


    View Slide

17. Viper mode
    @micropython.viper
    def blink_unrolled8_viper(n:int):
    n //= 8
    p = ptr16(stm.GPIOB + stm.GPIO_BSRR)
    for i in range(n):
    p[0] = 1 << 4 # high
    p[1] = 1 << 4 # low
    p[0] = 1 << 4 # high
    p[1] = 1 << 4 # low
    ....
    12890kHz
    @dpgeorge


    View Slide

18. In assembler
    @micropython.asm_thumb
    def blink_asm(r0):
    lsr(r0, r0, 3)
    movwt(r1, stm.GPIOB + stm.GPIO_BSRR)
    mov(r2, 1 << 4)
    label(loop)
    strh(r2, [r1, 0]) # high
    strh(r2, [r1, 2]) # low
    strh(r2, [r1, 0]) # high
    strh(r2, [r1, 2]) # low
    ....
    27359.25kHz
    @dpgeorge


    View Slide

19. Takeaways
    ○ If your code runs faster it can sleep
    for longer and that saves battery!
    ○ ROM everything that you can
    ○ Use runtime methods!
    ○ Local not global variables!


    View Slide

20. THANK YOU!
    www.github.com/sleepypioneer/fast_and_efficient_micropython
    www.micropython.org
    www.github.com/micropython


    View Slide
