[INTERSPEECH 2024] Challenge of singing voice s...

Takuma OKAMOTO
September 04, 2024

[INTERSPEECH 2024] Challenge of singing voice synthesis using only text-to-speech corpus with FIRNet source-filter neural vocoder

Presentation slides of "Challenge of singing voice synthesis using only text-to-speech corpus with FIRNet source-filter neural vocoder," at INTERSPEECH 2024.

[Paper]
https://www.isca-archive.org/interspeech_2024/okamoto24_interspeech.html

[Demo speech samples]
https://ast-astrec.nict.go.jp/demo_samples/svs_using_only_tts_corpus/

Takuma OKAMOTO

September 04, 2024
Tweet

More Decks by Takuma OKAMOTO

Other Decks in Research

Transcript

  1. 1 Takuma Okamoto1, Yamato Ohtani1, Sota Shimizu2,1, Tomoki Toda3,1 and

    Hisashi Kawai1 1National Institute of Information and Communications Technology, Japan 2Kobe University, Japan 3Nagoya University, Japan ˏKos Island, Greece Challenge of Singing Voice Synthesis Using Only Text-To-Speech Corpus With FIRNet Source-Filter Neural Vocoder
  2. Introduction Conventional methods and problems Proposed method: Uni fi ed

    text-to-speech (TTS) and singing voice synthesis (SVS) framework Experiments Demo samples Conclusion Outline 2 Speech demo samples
  3. High- fi delity and fast neural TTS and SVS models

    TTS: Input text -> speaking speech waveform SVS: Input musical scores (lyrics and notes) -> singing speech waveform Actual applications Useful to perform SVS with the same speaker voice as TTS Problems SVS corpora are more expensive to collect than TTS corpora Introduction 3 Investigating SVS only using TTS data
  4. NICT developed neural TTS on smartphones 4 High- fi delity

    and fast 21-language neural TTS on smartphones Latencies: 0.5 on mid-range (Google Pixel 5) and 0.2 on high-range (Google Pixel 8) <latexit sha1_base64="vH77virhZKTWfm8KwVfm+8tUBjI=">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</latexit> waveform <latexit sha1_base64="9lozoQVeb9VJg5paKElYHBNoA94=">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</latexit> Speech <latexit sha1_base64="FrsV4cKr6F1l5sv4wX+gnZsUCw4=">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</latexit> Transformer encoder <latexit sha1_base64="FJ0D/ZeHQu3FRThIyKcgfsBca50=">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</latexit> + <latexit sha1_base64="RZj7uXeSndNbOBS+nLu16RV9QTs=">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</latexit> ConvNeXt decoder <latexit sha1_base64="71BES6LtwKZxQtoggo/cnrWiehk=">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</latexit> MS-FC-HiFi-GAN <latexit sha1_base64="n5YBLnGZDzV76gGpS8AvQqocPMI=">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</latexit> Input text <latexit sha1_base64="o19XOGySTCO60QMItwO6FbfdcDk=">AAACdnichVG7SgNBFD1ZXzE+ErURBBFDfBSGGwsVq4CNjZAYo4JK2F3HuLgvdicRDf6AP2AhFgoaxM+w8Qcs/ASxVNDCwpvNgqiod5iZM2fuuXNmRnNNw5dEDxGlpbWtvSPaGevq7umNJ/r6V32n4umiqDum461rqi9MwxZFaUhTrLueUC3NFGva3kJjf60qPN9w7BV54IotSy3bxo6hq5KpUqJvYkmYU74rdOk5ZU+1JkuJJKUpiJGfIBOCJMLIOYk6NrENBzoqsCBgQzI2ocLntoEMCC5zW6gx5zEygn2BI8RYW+EswRkqs3s8lnm1EbI2rxs1/UCt8ykmd4+VI0jRPV3TM93RDT3S+6+1akGNhpcDnrWmVril+PFg4fVflcWzxO6n6k/PEjuYC7wa7N0NmMYt9Ka+enjyXJhfTtXG6IKe2P85PdAt38CuvuiXebF8ihh/QOb7c/8Eq9PpzEx6Jj+dzM6FXxHFEEYxwe89iywWkUORz93HGa5Qj7wpw0pKGW+mKpFQM4AvodAHmz+Qkw==</latexit> (Mel-spectrogram) <latexit sha1_base64="ZZgq5fXtX2X3C98nDbWxLPNkdEM=">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</latexit> Intermediate features <latexit sha1_base64="3myQj8xu3v6K4CeekliClhhqvgA=">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</latexit> Fast and high fidelity coustic model <latexit sha1_base64="a3FUWWYwXc0LWMZF+N2Bz+KqLNk=">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</latexit> Fast and high-fidelity <latexit sha1_base64="aTRGb8jc53UerQlwbIirCgMm2Kg=">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</latexit> waveform generative model Show & Tell paper T. Okamoto, Y. Ohtani and H. Kawai, “Mobile PresenTra: NICT fast neural text-to-speech system on smartphones with incremental inference of MS-FC-HiFi-GAN for low-latency synthesis,” in Proc. Interspeech, Sept. 2024, pp. 997—998. (Show & Tell)
  5. High- fi delity and fast neural TTS and SVS models

    TTS: Input text -> speaking speech waveform SVS: Input musical scores (lyrics and notes) -> singing speech waveform Actual applications Useful to perform SVS with the same speaker voice as TTS Problem SVS corpora are more expensive to collect than TTS corpora Introduction 5 Realizing SVS only using TTS data
  6. Ranges of fundamental frequency and phoneme duration in SVS are

    wider than those in TTS JSUT: Single speaker TTS corpus for Japanese (Takamichi+ 2020) JVS-Song: SVS corpus for Japanese singed by the same speaker of JSUT Why challenging? 6 <latexit sha1_base64="CrnGTEe5VWFhiwIYpXre3PvfOxM=">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</latexit> (a) Fundamental frequency <latexit sha1_base64="rrIE699hZMXQUqObtl1RZB8LLhI=">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</latexit> (b) Phoneme duration
  7. UniSyn: Uni fi ed end-to-end TTS and SVS model (Lei+

    AAAI 2023) Trained from multi-speaker TTS and SVS corpus SVS can be performed for a speaker whose singing data are not included in the training set Collection of multi-speaker TTS and SVS corpora is costly. Melody unsupervised SVS model (Choi+ ICASSP 2022) SVS using only TTS data (Only demo samples) Only SVS can be performed but TTS cannot be performed Di ffi cult to extrapolate fundamental frequency
 outside the range of training data Fundamental frequency trajectory tends to be stair-stepped Previous methods and problems 7 LJSpeech can sing songs!!
  8. High- fi delity cascade neural TTS model Acoustic model: Conformer-Fastspeech

    2 with monotonic alignment search Neural vocoder: HiFi-GAN conditioned on mel-spectrogram Baseline TTS model 8 <latexit sha1_base64="0uKxGGvi94ot8NH/8VrRtJh9r1Y=">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</latexit> Input text <latexit sha1_base64="3zQaeuifeEvx5T7XRr3g02kWXWo=">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</latexit> Phoneme (+ accentual) sequence <latexit sha1_base64="FYxxytaCdEJdhqb7izOlkTUtjdE=">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</latexit> Comformer-based decoder <latexit sha1_base64="MoXGCRVLJi/s3ZMINkGhf/4GNkc=">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</latexit> Variance adapter <latexit sha1_base64="T4G9oOvoRuRg/iwO2HEuM7n6CcU=">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</latexit> Comformer-based encoder <latexit sha1_base64="M39mT0XH052bw90RJwiYmVT6EDA=">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</latexit> Embedding layer <latexit sha1_base64="UYCLutWGVSku8uGQS1n3qt0e7v4=">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</latexit> Text analyzer <latexit sha1_base64="39v1XxDePhoGim/SyYBCr4T9528=">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</latexit> Predicted acoustic feature <latexit sha1_base64="1Il3IXqFo8nAXk4pW34xs4OTfQU=">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</latexit> CFS2-based acoustic model <latexit sha1_base64="hicsiIYs4zPr0QXVoB2URdgYWjw=">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</latexit> Output speech waveform <latexit sha1_base64="vBDfZdpurARh14trxuiHdxl8u2g=">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</latexit> Mel-spectrogram <latexit sha1_base64="Rgh4Cv8b1Tfqb9/jIWkYO1zmUNU=">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</latexit> Monotonic alignment search <latexit sha1_base64="7HUyvZKz0mWJXbLTg01YenyNt68=">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</latexit> Neural vocoder <latexit sha1_base64="LNBVAhJKtVI2EU9b4kYa+ZzBjpk=">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</latexit> HiFi-GAN <latexit sha1_base64="Yo3tZ28KfDNoWn6DhmoSB4FRJX4=">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</latexit> (Mel-spectrogram) <latexit sha1_base64="kS78Oo6jIgL9scIJQoWPwhkxkx8=">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</latexit> Encoder output <latexit sha1_base64="sjV7/xW9Kfmfc7IiRKz5lmImyr0=">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</latexit> Target energy <latexit sha1_base64="cviEIOqAJOp9MS/3QH9DWiOjuq4=">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</latexit> Target log fo <latexit sha1_base64="oG/qAavCdLlV1JR4O9BDmvIeFWE=">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</latexit> Decoder input <latexit sha1_base64="oRXI7vrRQvwVQ6gAKsuPHXCjNNg=">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</latexit> Energy predictor <latexit sha1_base64="U8FJD4xNas/AIrX7jSTFwf47Z1M=">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</latexit> Energy Conv1D <latexit sha1_base64="tX8q8Q7i2z+dc+Js3rSaj1JvkG4=">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</latexit> log fo predictor <latexit sha1_base64="+VxB7yi+1EMHWkbD9EiTkDEs47I=">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</latexit> log fo Conv1D <latexit sha1_base64="UUNL8Lb8njYcr/XxzgSwZqnbL9c=">AAACZnichVFNS8NAEH2N3/WrKqLgJVgUT2USS1s9FUTwIqi1KqhIEtcaTJOQpIVa/AOCVz14UhARf4YX/4AH/4HiUcGLBydpRTyos+zO7Nt5M293ddcy/YDoMSa1tLa1d3R2xbt7evv6EwODa75T8QxRNBzL8TZ0zReWaYtiYAaW2HA9oZV1S6zrB3Ph+XpVeL7p2KtBzRXbZa1km3umoQUMFRYL8zuJJKVmchk1nZEpRZRVVCUM1Gx6Oi0rjISWRNOWnMQ1trALBwYqKEPARsCxBQ0+j00oILiMbaPOmMeRGZ0LHCHO3ApnCc7QGD3gtcS7zSZq8z6s6Udsg7tYPD1mypigB7qhV7qnW3qmj19r1aMaoZYae73BFe5O//Fo4f1fVpl9gP1v1p+aA+whF2k1WbsbIeEtjAa/enj2WphdmahP0iW9sP4LeqQ7voFdfTOulsXKOeL8AV+vLP8erKkpJZNKL6vJfK75FZ0Ywzim+L2zyGMBSyhy3xJOcIqz2JPUJw1LI41UKdbkDOGHSfInm2yKuA==</latexit> MSE <latexit sha1_base64="UUNL8Lb8njYcr/XxzgSwZqnbL9c=">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</latexit> MSE <latexit sha1_base64="f+YTRma+EXocuri8WskzPsRWRyE=">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</latexit> Duration predictor <latexit sha1_base64="t5aWuMO6xko25Bg3NsXWWTXc+mM=">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</latexit> Target duration <latexit sha1_base64="UUNL8Lb8njYcr/XxzgSwZqnbL9c=">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</latexit> MSE <latexit sha1_base64="oSvyUr66jQQ3XQSSoNQPb38HXN4=">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</latexit> (Logarithmic domain) <latexit sha1_base64="/zctHQTWmsgO6A/GmvDN+3QYK9U=">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</latexit> Training only <latexit sha1_base64="jq8hKKEjw2gghwMYDOW9ouW9gYo=">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</latexit> Inference for TTS only <latexit sha1_base64="7gwikfOr6tn7VutnHoTvVP3Ca9g=">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</latexit> Gaussian <latexit sha1_base64="17eYvcbLlLJre3AWF5yQAsI0XTU=">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</latexit> upsampling
  9. Extracting text, fundamental frequency and phoneme duration from musical sores

    Input text: Lyrics Fundamental frequency and phoneme duration: Notes Singing voice synthesis by using TTS model 9 Phoneme d e N d e N m u sh i m u sh i k a t a ts u m u r i Note G4 E4 Number of frames 12.5 25 Number of phonemes 1 1 37.5 2 25 2 37.5 2 12.5 2 25 2 25 2 25 2 50 2 G4 G4 C4 C4 C4 D4 37.5 2 12.5 2 25 2 E4 E4 D4 C4 D4 Input text Fundamental Frequency Phoneme duration When predicted durations of phonemes “d” and “e” are 6 and 10 frames, modi fi ed durations for SVS are 37.5 × 6 / (6 + 10) and 37.5 × 10 / (6 + 10) C4 261.63 Hz D4 293.67 Hz E4 329.63 Hz F4 349.23 Hz G4 392.00 Hz A4 440.00 Hz B4 493.88 Hz C5 523.25 Hz
  10. <latexit sha1_base64="0uKxGGvi94ot8NH/8VrRtJh9r1Y=">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</latexit> Input text <latexit sha1_base64="3zQaeuifeEvx5T7XRr3g02kWXWo=">AAACg3ichVFNSxtBGH7cNq1NtcZ6KQiyNKRYhDAJrRWhIHjpMWrzAWkIu9M3urg7u92dDdjgzVP/gAdPLUhRj/Yf9NI/4MGfID0qePHgm82CtEF9h5l55pn3eeeZGTtwnUgLcTpiPHiYefR49En26dj4s4nc5PNa5MehpKr0XT9s2FZErqOoqh3tUiMIyfJsl+r25nJ/v96lMHJ89VFvBdTyrHXldBxpaabauZnKhq/II3N2zrSkJKVjy31tRvQlJiWpncuLokjCHAalFOSRRsXP/cQnfIYPiRgeCAqasQsLEbcmShAImGuhx1zIyEn2CdvIsjbmLOIMi9lNHtd51UxZxet+zShRSz7F5R6y0kRBnIgDcS7+iCNxJq5urdVLavS9bPFsD7QUtCe+vVi7vFfl8ayxcaO607NGBwuJV4e9BwnTv4Uc6Ltfd8/XFlcLvVfih/jL/r+LU/Gbb6C6F3J/hVb3kOUPKP3/3MOgVi6W5otvV8r5pYX0K0YxjZeY5fd+hyV8QAVVPncHhzjGLyNjzBll480g1RhJNVP4J4z316AdlIM=</latexit> Phoneme (+ accentual) sequence

    <latexit sha1_base64="FYxxytaCdEJdhqb7izOlkTUtjdE=">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</latexit> Comformer-based decoder <latexit sha1_base64="MoXGCRVLJi/s3ZMINkGhf/4GNkc=">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</latexit> Variance adapter <latexit sha1_base64="T4G9oOvoRuRg/iwO2HEuM7n6CcU=">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</latexit> Comformer-based encoder <latexit sha1_base64="M39mT0XH052bw90RJwiYmVT6EDA=">AAACdHichVHLSsNAFD2Nr1ofjboRdFEsFVdlKvjAVUEEl63aB1QpSTrWoXmRpIVa/AF/wIUrRRHxM9z4Ay76CeKyohsX3qQBUVFvmMyZM/fcOTNXtXXheox1I9LA4NDwSHQ0NjY+MRmXp6aLrtV0NF7QLN1yyqricl2YvOAJT+dl2+GKoeq8pDY2/f1SizuusMw9r23zA0Opm+JQaIpHVFWObxkqr9WEWU/oSps7VTnJ0iyIxE+QCUESYeQs+Qb7qMGChiYMcJjwCOtQ4NJXQQYMNnEH6BDnEBLBPscJYqRtUhanDIXYBv3rtKqErElrv6YbqDU6RafhkDKBFHtkt6zHHtgde2Lvv9bqBDV8L22a1b6W29X46ezu278qg2YPR5+qPz17OMR64FWQdztg/FtofX3r+Ky3u7GT6iyyS/ZM/i9Yl93TDczWi3ad5zvniFEDMt+f+ycoLqczq+mV/HIyux62Ioo5LGCJ3nsNWWwjh0LQk3Nc4TryKs1LSSnVT5UioWYGX0JKfwA4k4/3</latexit> Embedding layer <latexit sha1_base64="UYCLutWGVSku8uGQS1n3qt0e7v4=">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</latexit> Text analyzer <latexit sha1_base64="39v1XxDePhoGim/SyYBCr4T9528=">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</latexit> Predicted acoustic feature <latexit sha1_base64="1Il3IXqFo8nAXk4pW34xs4OTfQU=">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</latexit> CFS2-based acoustic model <latexit sha1_base64="hicsiIYs4zPr0QXVoB2URdgYWjw=">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</latexit> Output speech waveform <latexit sha1_base64="4Ts6aQBT2bqEeh17ObF1s0elMXo=">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</latexit> Musical score <latexit sha1_base64="V7QSiWRHN/fxVxKfQBtCr7sl+Sc=">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</latexit> Lyrics <latexit sha1_base64="QT9u9GUadN9qIbOUeEHE3rUgwFs=">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</latexit> Note <latexit sha1_base64="PqsipI/xZsQGfSNdyT3LSKS2C+Y=">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</latexit> log fo <latexit sha1_base64="kd9jGTD4kykBh5hiEPl34FzrIVo=">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</latexit> Duration <latexit sha1_base64="wd6WZ3lKT4bxlxWYA6HDhytt55M=">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</latexit> Mel-cepstrum <latexit sha1_base64="vBDfZdpurARh14trxuiHdxl8u2g=">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</latexit> Mel-spectrogram <latexit sha1_base64="TBp335Uq73K40mymvpZqc0ZR3HI=">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</latexit> or <latexit sha1_base64="Rgh4Cv8b1Tfqb9/jIWkYO1zmUNU=">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</latexit> Monotonic alignment search <latexit sha1_base64="7HUyvZKz0mWJXbLTg01YenyNt68=">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</latexit> Neural vocoder <latexit sha1_base64="Yo3tZ28KfDNoWn6DhmoSB4FRJX4=">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</latexit> (Mel-spectrogram) <latexit sha1_base64="LNBVAhJKtVI2EU9b4kYa+ZzBjpk=">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</latexit> HiFi-GAN <latexit sha1_base64="kS78Oo6jIgL9scIJQoWPwhkxkx8=">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</latexit> Encoder output <latexit sha1_base64="sjV7/xW9Kfmfc7IiRKz5lmImyr0=">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</latexit> Target energy <latexit sha1_base64="cviEIOqAJOp9MS/3QH9DWiOjuq4=">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</latexit> Target log fo <latexit sha1_base64="oG/qAavCdLlV1JR4O9BDmvIeFWE=">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</latexit> Decoder input <latexit sha1_base64="oRXI7vrRQvwVQ6gAKsuPHXCjNNg=">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</latexit> Energy predictor <latexit sha1_base64="U8FJD4xNas/AIrX7jSTFwf47Z1M=">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</latexit> Energy Conv1D <latexit sha1_base64="tX8q8Q7i2z+dc+Js3rSaj1JvkG4=">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</latexit> log fo predictor <latexit sha1_base64="+VxB7yi+1EMHWkbD9EiTkDEs47I=">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</latexit> log fo Conv1D <latexit sha1_base64="UUNL8Lb8njYcr/XxzgSwZqnbL9c=">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</latexit> MSE <latexit sha1_base64="UUNL8Lb8njYcr/XxzgSwZqnbL9c=">AAACZnichVFNS8NAEH2N3/WrKqLgJVgUT2USS1s9FUTwIqi1KqhIEtcaTJOQpIVa/AOCVz14UhARf4YX/4AH/4HiUcGLBydpRTyos+zO7Nt5M293ddcy/YDoMSa1tLa1d3R2xbt7evv6EwODa75T8QxRNBzL8TZ0zReWaYtiYAaW2HA9oZV1S6zrB3Ph+XpVeL7p2KtBzRXbZa1km3umoQUMFRYL8zuJJKVmchk1nZEpRZRVVCUM1Gx6Oi0rjISWRNOWnMQ1trALBwYqKEPARsCxBQ0+j00oILiMbaPOmMeRGZ0LHCHO3ApnCc7QGD3gtcS7zSZq8z6s6Udsg7tYPD1mypigB7qhV7qnW3qmj19r1aMaoZYae73BFe5O//Fo4f1fVpl9gP1v1p+aA+whF2k1WbsbIeEtjAa/enj2WphdmahP0iW9sP4LeqQ7voFdfTOulsXKOeL8AV+vLP8erKkpJZNKL6vJfK75FZ0Ywzim+L2zyGMBSyhy3xJOcIqz2JPUJw1LI41UKdbkDOGHSfInm2yKuA==</latexit> MSE <latexit sha1_base64="f+YTRma+EXocuri8WskzPsRWRyE=">AAACd3ichVHLSgMxFD0dX7U+WutGcGGxKF2VTBEtrgq6cGmrrYJKmRlTDZ3ODDNpsRZ/wB9wIQgKouJnuPEHXPgJ4rKCCC68nQ6IinpDkpOTe25OEt0xhScZewwpPb19/QPhwcjQ8MhoNDYWL3l23TV40bBN293UNY+bwuJFKaTJNx2XazXd5Bt6damzv9Hgridsa102Hb5T0/YsURGGJokqx+LLddeHCZLtCkPabjmWZGnmR+InUAOQRBCrduwK29iFDQN11MBhQRI2ocGjtgUVDA5xO2gR5xIS/j7HESKkrVMWpwyN2CqNe7TaCliL1p2anq826BSTukvKBGbYA7thbXbPbtkTe/+1Vsuv0fHSpFnvarlTjh5PrL3+q6rRLLH/qfrTs0QFWd+rIO+Oz3RuYXT1jcOT9tpiYaY1yy7YM/k/Z4/sjm5gNV6MyzwvnCJCH6B+f+6foJRJq/PpuXwmmcsGXxHGJKaRovdeQA4rWEWRzj3AGa5wHXpTppRZJdVNVUKBZhxfQlE/AKoCkYo=</latexit> Duration predictor <latexit sha1_base64="t5aWuMO6xko25Bg3NsXWWTXc+mM=">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</latexit> Target duration <latexit sha1_base64="UUNL8Lb8njYcr/XxzgSwZqnbL9c=">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</latexit> MSE <latexit sha1_base64="oSvyUr66jQQ3XQSSoNQPb38HXN4=">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</latexit> (Logarithmic domain) <latexit sha1_base64="scFVnQQc5J1RQMAmhGi3WaF62uM=">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</latexit> Duration of each note <latexit sha1_base64="BGi+APzWNtjHPRYmbWXxRjQsLaQ=">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</latexit> Compensate <latexit sha1_base64="rXXiKz7//+R7/pgc+sgfASK9s6U=">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</latexit> log fo of each phoneme <latexit sha1_base64="/zctHQTWmsgO6A/GmvDN+3QYK9U=">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</latexit> Training only <latexit sha1_base64="jq8hKKEjw2gghwMYDOW9ouW9gYo=">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</latexit> Inference for TTS only <latexit sha1_base64="/SYMe84PvLGMEeTH4Vd17iD7f/Q=">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</latexit> Inference for SVS only <latexit sha1_base64="7gwikfOr6tn7VutnHoTvVP3Ca9g=">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</latexit> Gaussian <latexit sha1_base64="17eYvcbLlLJre3AWF5yQAsI0XTU=">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</latexit> upsampling <latexit sha1_base64="IsP4a3aLkIdYItbxWM1ojX3DSdc=">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</latexit> Variance adapter Uni fi ed TTS and SVS framework 10
  11. Problem of SVS with baseline TTS model Low extrapolation accuracy

    of fundamental frequency and phoneme duration Proposed method with three modi fi cations Acoustic model: Baseline with phoneme embedding skip connection (PESC) Neural vocoder: FIRNet with source- fi lter vocoder (WORLD) features Input fundamental frequency shift Proposed method 11 <latexit sha1_base64="CrnGTEe5VWFhiwIYpXre3PvfOxM=">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</latexit> (a) Fundamental frequency <latexit sha1_base64="rrIE699hZMXQUqObtl1RZB8LLhI=">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</latexit> (b) Phoneme duration
  12. <latexit sha1_base64="0uKxGGvi94ot8NH/8VrRtJh9r1Y=">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</latexit> Input text <latexit sha1_base64="3zQaeuifeEvx5T7XRr3g02kWXWo=">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</latexit> Phoneme (+ accentual) sequence

    <latexit sha1_base64="FYxxytaCdEJdhqb7izOlkTUtjdE=">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</latexit> Comformer-based decoder <latexit sha1_base64="MoXGCRVLJi/s3ZMINkGhf/4GNkc=">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</latexit> Variance adapter <latexit sha1_base64="T4G9oOvoRuRg/iwO2HEuM7n6CcU=">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</latexit> Comformer-based encoder <latexit sha1_base64="M39mT0XH052bw90RJwiYmVT6EDA=">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</latexit> Embedding layer <latexit sha1_base64="UYCLutWGVSku8uGQS1n3qt0e7v4=">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</latexit> Text analyzer <latexit sha1_base64="hicsiIYs4zPr0QXVoB2URdgYWjw=">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</latexit> Output speech waveform <latexit sha1_base64="1Il3IXqFo8nAXk4pW34xs4OTfQU=">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</latexit> CFS2-based acoustic model <latexit sha1_base64="E+sWn7s/7MaD6bsaVEBnTsornB0=">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</latexit> with PESC <latexit sha1_base64="4Ts6aQBT2bqEeh17ObF1s0elMXo=">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</latexit> Musical score <latexit sha1_base64="V7QSiWRHN/fxVxKfQBtCr7sl+Sc=">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</latexit> Lyrics <latexit sha1_base64="QT9u9GUadN9qIbOUeEHE3rUgwFs=">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</latexit> Note <latexit sha1_base64="PqsipI/xZsQGfSNdyT3LSKS2C+Y=">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</latexit> log fo <latexit sha1_base64="kd9jGTD4kykBh5hiEPl34FzrIVo=">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</latexit> Duration <latexit sha1_base64="ZhnkEug4CtRY/uI5grPDrzt6U1k=">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</latexit> Predicted WORLD feature <latexit sha1_base64="wd6WZ3lKT4bxlxWYA6HDhytt55M=">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</latexit> Mel-cepstrum <latexit sha1_base64="KQj24O9rwM8VbnO5EJvRWQ+VGFE=">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</latexit> (log fo, V/UV, mel-cepstrum, band-aperiodicity) <latexit sha1_base64="Rgh4Cv8b1Tfqb9/jIWkYO1zmUNU=">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</latexit> Monotonic alignment search <latexit sha1_base64="no6pyJ1hODCII7z5mco/b5WHEbE=">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</latexit> Gaussian upsampling <latexit sha1_base64="7HUyvZKz0mWJXbLTg01YenyNt68=">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</latexit> Neural vocoder <latexit sha1_base64="Zk8gteKuGct0YdLZBDd05sBLQgk=">AAACa3ichVG7SgNBFD1Z3/GRqI2oRTBEtAmzghqsBEG0EY3mAVFkdx11yL7YnQRi8AcsbSy0URARP8PGH7DwE0SsFGwsvNksiIp6l9k5c+aeO2fu6K4pfMnYQ0RpaW1r7+jsinb39PbF4v0Ded+peAbPGY7peEVd87kpbJ6TQpq86Hpcs3STF/TyQmO/UOWeLxx7Q9ZcvmVpe7bYFYYmiSpOLC5nV7ic3I4nWZoFkfgJ1BAkEcaqE7/CJnbgwEAFFjhsSMImNPj0laCCwSVuC3XiPEIi2Oc4RJS0FcrilKERW6b/Hq1KIWvTulHTD9QGnWLS8EiZQIrds2v2wu7YDXtk77/Wqgc1Gl5qNOtNLXe3Y0dD62//qiyaJfY/VX96lthFJvAqyLsbMI1bGE199eDkZX0um6qPswv2RP7P2QO7pRvY1Vfjco1nTxGlB1C/t/snyE+l1Zn09NpUcj4TPkUnRjCGCer3LOaxhFXkgj4f4xRnkWdlUBlWRpupSiTUDOJLKKkPxZiMHQ==</latexit> (FIRNet) <latexit sha1_base64="/zctHQTWmsgO6A/GmvDN+3QYK9U=">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</latexit> Training only <latexit sha1_base64="jq8hKKEjw2gghwMYDOW9ouW9gYo=">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</latexit> Inference for TTS only <latexit sha1_base64="/SYMe84PvLGMEeTH4Vd17iD7f/Q=">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</latexit> Inference for SVS only For improving phoneme expansion accuracy Monotonic alignment search is trained with
 embedding features instead of encoded features Phoneme embedding skip connection 12
  13. Excitation generator Residual FIR network Resonance FIR network Speech waveform

    Concatenate Causal conv block Causal conv block MGC V/UV Cont. log fO BAP Mixed excitation Input features Residual signal Causal conv block (a) Network architecture N V C B M Fundamental frequency controllable neural vocoder (Ohtani+ ICASSP 2024) Two types of FIR fi lter are trained with neural networks Simple excitation signal is convulsed with these FIR fi lters Fast inference compared with other models
 e.g. Harmonic-Net+, Si-Fi-GAN Demo samples
 fo x 1.0

 fo x 0.5

 fo x 2.0 FIRNet neural vocoder 13 Speech demo samples
  14. For improving fundamental frequency prediction accuracy Converting input fundamental frequency


    inside the range of training data Shit amount is calculated from mean value
 in training set and intermediate value in
 synthesized songs Input fundamental frequency shift 14 <latexit sha1_base64="3zQaeuifeEvx5T7XRr3g02kWXWo=">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</latexit> Phoneme (+ accentual) sequence <latexit sha1_base64="FYxxytaCdEJdhqb7izOlkTUtjdE=">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</latexit> Comformer-based decoder <latexit sha1_base64="MoXGCRVLJi/s3ZMINkGhf/4GNkc=">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</latexit> Variance adapter <latexit sha1_base64="T4G9oOvoRuRg/iwO2HEuM7n6CcU=">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</latexit> Comformer-based encoder <latexit sha1_base64="M39mT0XH052bw90RJwiYmVT6EDA=">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</latexit> Embedding layer <latexit sha1_base64="UYCLutWGVSku8uGQS1n3qt0e7v4=">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</latexit> Text analyzer <latexit sha1_base64="1Il3IXqFo8nAXk4pW34xs4OTfQU=">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</latexit> CFS2-based acoustic model <latexit sha1_base64="E+sWn7s/7MaD6bsaVEBnTsornB0=">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</latexit> with PESC <latexit sha1_base64="4Ts6aQBT2bqEeh17ObF1s0elMXo=">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</latexit> Musical score <latexit sha1_base64="V7QSiWRHN/fxVxKfQBtCr7sl+Sc=">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</latexit> Lyrics <latexit sha1_base64="QT9u9GUadN9qIbOUeEHE3rUgwFs=">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</latexit> Note <latexit sha1_base64="kd9jGTD4kykBh5hiEPl34FzrIVo=">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</latexit> Duration <latexit sha1_base64="ZhnkEug4CtRY/uI5grPDrzt6U1k=">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</latexit> Predicted WORLD feature <latexit sha1_base64="no6pyJ1hODCII7z5mco/b5WHEbE=">AAACeXichVG7SgNBFD1Z3/EVH4VgEw2KWISJgoqVYKFlfEQDUcLsOsbBfbGzG9DgD/gDFjYqiEQ/w8YfsPATxFLBQgvvbhZERb3Lzpw5c8+9Z2Z015TKZ+whoTU1t7S2tXckO7u6e3pTff0bygk8QxQMx3S8os6VMKUtCr70TVF0PcEt3RSb+v5iuL9ZFZ6Sjr3uH7hi2+IVW+5Kg/tElVODSzxQSnI7HbiKW9TSriTLqQzLsijSP0EuBhnEkXdSV9jCDhwYCGBBwIZP2ASHoq+EHBhc4rZRI84jJKN9gSMkSRtQlqAMTuw+jRValWLWpnVYU0Vqg7qY9HukTGOM3bM6e2Z37IY9svdfa9WiGqGXA5r1hla45d7jobXXf1UWzT72PlV/evaxi7nIqyTvbsSEpzAa+urhyfPa/OpYbZxdsCfyf84e2C2dwK6+GJcrYvUU4QPkvl/3T7Axlc3NZGdWpjILc/FTtGMYo5ig+57FApaRR4H6HuIMdVwn3rQRbUKbbKRqiVgzgC+hTX8A6r2SEw==</latexit> Gaussian upsampling <latexit sha1_base64="5rBwJ8nkoe0wnj9Gb8jvsDYF2Ls=">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</latexit> log(fo fshift) <latexit sha1_base64="zd5VihNibr3R6tzl4KJuYTR/oVg=">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</latexit> (log(fo fshift), V/UV, mel-cepstrum, band-aperiodicity) <latexit sha1_base64="xv9t3jcmHPTHdLit8b4v52M2C5M=">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</latexit> +fshift <latexit sha1_base64="sm4NQ/xZPzDfyYYwvxKdOd5E9DQ=">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</latexit> (fo, V/UV, mel-cepstrum, band-aperiodicity)
  15. Experimental conditions Speech Corpus: JSUT for training and evaluation and

    JSUT-song only for evaluation Sampling frequency: 24 kHz Trained and inferred PyTorch 2.0.1 Trained using an NVIDIA Tesla A100 GPU with 40 GB of memory ESPnet2-TTS recipe for JSUT corpus Frame shift: 10 ms 120 beats per minute for SVS Input fundamental frequency shift: 261.6 + (523.3 − 261.6) / 2 − 206 = 186.5 Hz Experiments 15 Mean value of training data Intermediate value of synthesized songs
  16. Results of objective evaluations 16 Table 1: Results of objective

    evaluations. The values in the columns for mel-cepstral distortion (MCD) and log fo root-mean-square error (RMSE) are the means and standard deviations. AM and NV represent acoustic model and neural vocoder, respectively. TTS SVS AM NV Input fo shift Acoustic feature MCD [dB] log fo RMSE MCD [dB] log fo RMSE CFS2 HiFi-GAN mel-spectrogram 6.20 ± 0.49 0.22 ± 0.06 11.4 ± 0.83 0.41 ± 0.14 CFS2 HiFi-GAN WORLD 6.39 ± 0.51 0.22 ± 0.06 12.0 ± 1.08 0.41 ± 0.10 PESC HiFi-GAN WORLD 6.35 ± 0.51 0.22 ± 0.06 11.5 ± 1.17 0.37 ± 0.09 PESC HiFi-GAN √ WORLD - - 10.9 ± 0.92 0.57 ± 0.15 CFS2 FIRNet WORLD 6.41 ± 0.50 0.23 ± 0.06 12.2 ± 1.02 0.35 ± 0.10 PESC FIRNet WORLD 6.39 ± 0.49 0.23 ± 0.06 11.6 ± 1.18 0.34 ± 0.09 PESC FIRNet √ WORLD - - 10.5 ± 1.00 0.30 ± 0.11 els. The JSUT-Song corpus was used only for evaluating the SVS model. Following the procedure established for ESPnet2- TTS [8], 4,500 utterances, 250 utterances, and 250 utterances were used for the training set, validation set, and test set for TTS, respectively. For TTS in Japanese, the G2P function based on pyopenjtalk and enhanced with prosody symbols [34] was used, following [8, 11]. For the subjective evaluations of TTS, 10 utterances were randomly selected. For the objective and subjective evaluations of SVS, the first phrases of 10 songs from lated by the ESPnet2-TTS toolkit [8, 9]. To evaluate the syn- thesized TTS and SVS speech subjectively, mean opinion score (MOS) tests [38] were conducted for (a) normal TTS, (b) nor- mal SVS, (c) T × 0.5 SVS (240 beats per minute), (d) fo × 0.5 SVS (−1 octave), and (e) fo × 2.0 SVS (+1 octave). In (d) and (e), fo was controlled before the neural vocoders. Each sub- ject evaluated 200 samples: 10 utterances × 20 models. The naturalness of each sample was rated on a five-point scale: (1) bad, (2) poor, (3) fair, (4) good, and (5) excellent. Twenty adult
  17. Results of subjective evaluations 17 <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">AAACZnichVFNSwJBGH7cvsxKrYiCLpIYnWQU+qCTEJRHP/IDTGR3m2xx3V12V8GkPxB0zUOngojoZ3TpD3TwHxQdDbp06HVdiJLqHWbmmWfe551nZiRDVSybsa5HGBkdG5/wTvqmpmf8geDsXN7SG6bMc7Ku6mZREi2uKhrP2Yqt8qJhcrEuqbwg1Xb6+4UmNy1F1/btlsHLdbGqKUeKLNpEZZO7e5VgmEWZE6FhEHNBGG6k9OAtDnAIHTIaqINDg01YhQiLWgkxMBjEldEmziSkOPscp/CRtkFZnDJEYms0VmlVclmN1v2alqOW6RSVuknKECLsid2xHntk9+yFffxaq+3U6Htp0SwNtNyoBM6Wsu//quo02zj+Uv3p2cYRthyvCnk3HKZ/C3mgb550etntTKS9yq7ZK/m/Yl32QDfQmm/yTZpnLuGjD4j9fO5hkI9HYxvR9XQ8nIi6X+HFMlawRu+9iQSSSCFH51Zxjgt0PM+CX1gQFgepgsfVzONbCKFP+I+KXQ==</latexit> HFG <latexit sha1_base64="70NiwEj00eCt+oK8h3RttTtjuk4=">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</latexit>

    CFS2 <latexit sha1_base64="70NiwEj00eCt+oK8h3RttTtjuk4=">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</latexit> CFS2 <latexit sha1_base64="70NiwEj00eCt+oK8h3RttTtjuk4=">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</latexit> CFS2 <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">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</latexit> FIRN <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">AAACZ3ichVHLSgMxFD0d3/XRqiAFN2pRXJWM4ANXgiC6kbbaVlCRmTFtg/NiJi1o8QdcuFVwpSAifoYbf8CFn1BcKrhx4Z3pgKioNyQ5Obnn5iTRXVP4krGnmNLW3tHZ1d0T7+3rH0gkB4eKvlPzDF4wHNPxtnTN56aweUEKafIt1+OapZu8pB8sB/ulOvd84dib8tDlu5ZWsUVZGJoMqJW1/PpeMs0yLIyxn0CNQBpRZJ3kDXawDwcGarDAYUMSNqHBp7YNFQwucbtoEOcREuE+xzHipK1RFqcMjdgDGiu02o5Ym9ZBTT9UG3SKSd0j5Rgm2SO7ZS/sgd2xJnv/tVYjrBF4OaRZb2m5u5c4SW28/auyaJaofqr+9CxRxkLoVZB3N2SCWxgtff3o7GVjMT/ZmGJX7Jn8X7Indk83sOuvxnWO5y8Qpw9Qvz/3T1CcyahzmdncTHopE31FN0YxgWl673ksYRVZFOjcKk5xhvNYU0koI0qqlarEIs0wvoQy/gHS4orB</latexit> FIRN <latexit sha1_base64="skJSgymI+j5dOSNyaBA9EHCyFQc=">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</latexit> ORG <latexit sha1_base64="mTBL0sYsGqtmnxncxbhrYSq/crk=">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</latexit> Melspc <latexit sha1_base64="K4Imk4lLcDN1a+X+vK5ieFVbqCk=">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</latexit> WORLD <latexit sha1_base64="VGfzfaPQ0qj9M3VPYsQD15KWE44=">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</latexit> (a) Normal TTS <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="70NiwEj00eCt+oK8h3RttTtjuk4=">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</latexit> CFS2 <latexit sha1_base64="70NiwEj00eCt+oK8h3RttTtjuk4=">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</latexit> CFS2 <latexit sha1_base64="70NiwEj00eCt+oK8h3RttTtjuk4=">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</latexit> CFS2 <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">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</latexit> FIRN <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">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</latexit> FIRN <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">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</latexit> FIRN <latexit sha1_base64="skJSgymI+j5dOSNyaBA9EHCyFQc=">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</latexit> ORG <latexit sha1_base64="mTBL0sYsGqtmnxncxbhrYSq/crk=">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</latexit> Melspc <latexit sha1_base64="K4Imk4lLcDN1a+X+vK5ieFVbqCk=">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</latexit> WORLD <latexit sha1_base64="Uzo9vABtgJ9nG/DGlzWgZFZuuCs=">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</latexit> (b) Normal SVS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">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</latexit> IFS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">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</latexit> IFS <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">AAACZ3ichVHLSgMxFD0dX7U+WhWk4EYtFVclU/CBq4IILltrVahFZsbUhk5nhpm0UIs/4MKtgisFEfEz3PgDLvwEcangxoV3pgOiot6Q5OTknpuTRHdM4UnGHiNKT29f/0B0MDY0PDIaT4yNb3l20zV4ybBN293RNY+bwuIlKaTJdxyXaw3d5Nt6fdXf325x1xO2tSnbDq80tANLVIWhSZ/KrxVX9xIplmFBTP8EaghSCCNvJ66xi33YMNBEAxwWJGETGjxqZahgcIiroEOcS0gE+xxHiJG2SVmcMjRi6zQe0Kocshat/ZpeoDboFJO6S8pppNkDu2Ev7J7dsif2/mutTlDD99KmWe9qubMXP04W3/5VNWiWqH2q/vQsUcVy4FWQdydg/FsYXX3r8PSluLKR7syxS/ZM/i/YI7ujG1itV+OqwDfOEaMPUL8/90+wlc2oi5mFQjaVy4RfEcUUZjFP772EHNaRR4nOreEEpziLPClxZVJJdlOVSKiZwJdQZj4AyvmKvQ==</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="pbMliQNUovHz+7ATPiA7JhDKlLc=">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</latexit> HFG <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">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</latexit> FIRN <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">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</latexit> FIRN <latexit sha1_base64="m6wBwGwGNCYgzPL/wzT7yFwt8kM=">AAACZ3ichVHLSgMxFD0d3/XRqiAFN2pRXJWM4ANXgiC6kbbaVlCRmTFtg/NiJi1o8QdcuFVwpSAifoYbf8CFn1BcKrhx4Z3pgKioNyQ5Obnn5iTRXVP4krGnmNLW3tHZ1d0T7+3rH0gkB4eKvlPzDF4wHNPxtnTN56aweUEKafIt1+OapZu8pB8sB/ulOvd84dib8tDlu5ZWsUVZGJoMqJW1/PpeMs0yLIyxn0CNQBpRZJ3kDXawDwcGarDAYUMSNqHBp7YNFQwucbtoEOcREuE+xzHipK1RFqcMjdgDGiu02o5Ym9ZBTT9UG3SKSd0j5Rgm2SO7ZS/sgd2xJnv/tVYjrBF4OaRZb2m5u5c4SW28/auyaJaofqr+9CxRxkLoVZB3N2SCWxgtff3o7GVjMT/ZmGJX7Jn8X7Indk83sOuvxnWO5y8Qpw9Qvz/3T1CcyahzmdncTHopE31FN0YxgWl673ksYRVZFOjcKk5xhvNYU0koI0qqlarEIs0wvoQy/gHS4orB</latexit> FIRN <latexit sha1_base64="q4d1FJ6EXIJzStPuf3Jeqv+hgT0=">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</latexit> FS <latexit sha1_base64="K4Imk4lLcDN1a+X+vK5ieFVbqCk=">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</latexit> WORLD <latexit sha1_base64="K4Imk4lLcDN1a+X+vK5ieFVbqCk=">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</latexit> WORLD <latexit sha1_base64="K4Imk4lLcDN1a+X+vK5ieFVbqCk=">AAACaHichVHLLgRBFD3TXmO8GgvERkyIVad6Eo9YSVhYSDC0kSDS3WqoTL/S3TPJmPgBG0vEikREfIaNH7DwCViS2Fi43dOJILiVqjp16p5bp6oMzxJByNhDSmpobGpuSbdm2to7Orvk7p61wC37JtdM13L9dUMPuCUcroUitPi653PdNixeMEqz0X6hwv1AuM5qWPX4lq3vOqIoTD0kSiss5hfmtuUsU1gcQz+BmoAsklhy5StsYgcuTJRhg8NBSNiCjoDaBlQweMRtoUacT0jE+xwHyJC2TFmcMnRiSzTu0mojYR1aRzWDWG3SKRZ1n5RDGGH37Jq9sDt2wx7Z+6+1anGNyEuVZqOu5d5212H/ytu/KpvmEHufqj89hyhiKvYqyLsXM9EtzLq+sn/8sjKdH6mNsgv2TP7P2QO7pRs4lVfzcpnnz5ChD1C/P/dPsJZT1AllfDmXnVGSr0hjEMMYo/eexAzmsQSNzhU4wglOU0+SLPVJA/VUKZVoevElpOEPq9qLJA==</latexit> WORLD <latexit sha1_base64="16dkjTRdT4lDHK28M7+QKM82nIA=">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</latexit> (c) T ⇥ 0.5 SVS <latexit sha1_base64="ObSUkdcz1UMeAxI/DOTtSd/ZL50=">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</latexit> (d) fo ⇥ 0.5 SVS <latexit sha1_base64="R7TbaQhUKQvutxUki0+q3j5+XbE=">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</latexit> (e) fo ⇥ 2.0 SVS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">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</latexit> IFS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">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</latexit> IFS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">AAACZnichVFNSwJBGH7cvsxKrYiCLpIYnWQU+qCTEETd/MgPMJHdbbTFdXfZXQWT/kDQNQ+dCiKin9GlP9DBf1B0NOjSodd1IUqqd5iZZ555n3eemZEMVbFsxroeYWR0bHzCO+mbmp7xB4KzczlLb5gyz8q6qpsFSbS4qmg8ayu2yguGycW6pPK8VNvp7+eb3LQUXTuwWwYv1cWqplQUWbSJyuzvZsrBMIsyJ0LDIOaCMNxI6sFbHOIIOmQ0UAeHBpuwChEWtSJiYDCIK6FNnElIcfY5TuEjbYOyOGWIxNZorNKq6LIarfs1LUct0ykqdZOUIUTYE7tjPfbI7tkL+/i1Vtup0ffSolkaaLlRDpwtZd7/VdVptnH8pfrTs40KthyvCnk3HKZ/C3mgb550epntdKS9yq7ZK/m/Yl32QDfQmm/yTYqnL+GjD4j9fO5hkItHYxvR9VQ8nIi6X+HFMlawRu+9iQT2kESWzq3iHBfoeJ4Fv7AgLA5SBY+rmce3EEKfEqCKag==</latexit> IFS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">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</latexit> IFS <latexit sha1_base64="C/y6XvvzlmmCUH0vj0dFKdeLaIY=">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</latexit> IFS <latexit sha1_base64="Ev1UgSjKD+V+DDArs7G82BtvH5U=">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</latexit> ( 1 octave) <latexit sha1_base64="9Z1gSzCJb0ZHkOY/QOz9OTrqyNc=">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</latexit> (+1 octave) <latexit sha1_base64="2YZdNcwSZB72sKmPbWcIROBaMFk=">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</latexit> (240 BPM) <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC <latexit sha1_base64="AUV+cNY/T1UCo4j8yefaWzA08Is=">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</latexit> PESC
  18. Proposed method: Uni fi ed TTS and SVS models only

    using TTS data Phoneme embedding skip connection -> improving duration control FIRNet neural vocoder with WORLD features -> extrapolating fundamental frequency Input fundamental frequency shift -> improving fundamental frequency control Conclusion 18 Speech demo samples
