  1. @julienviet @vertx_project #Devoxx #vertx Better Performance With HTTP/2 Julien Viet

    Red Hat
  2. @julienviet @vertx_project #Devoxx #vertx Agenda • Why HTTP/2 ? •

    Server side HTTP/2 • HTTP/2 with Vert.x
  3. @julienviet @vertx_project #Devoxx #vertx /me • Open source developer for

    15 years • Current @vertx_project lead • Software engineer at Red Hat • Marseille JUG Leader • http://github.com/vietj • @julienviet
  4. None
  5. None
  6. @julienviet @vertx_project #Devoxx #vertx Latency versus Bandwidth impact Page Load

    Time as bandwidth increases 1000 1550 2100 2650 3200 1Mbps 2Mbps 2Mbps 4Mbps 5Mbps 6Mbps 7Mbps 8Mbps 9Mbps 10Mbps Page Load Time as latency decrease 1000 1750 2500 3250 4000 200 ms 180 ms 160 ms 140 ms 120 ms 100 ms 80 ms 60 ms 40 ms 20 ms
  7. @julienviet @vertx_project #Devoxx #vertx HTTP 1.1 improvements • Persistent connections

  8. @julienviet @vertx_project #Devoxx #vertx Current solutions • Multiple connections •

    CDN • Concatenation / spriting • Compression / minification • Caching • Sharding
  9. @julienviet @vertx_project #Devoxx #vertx HTTP/2 • Evolution of SPDY •

    Same semantic than HTTP/1 • Change the format on the wire • Use a single connection • HTTPS mandatory for browsers • Does not affect websockets
  10. B1n4ry

  11. Frames

  12. COMPR ESS headers headers headers headers headers headers headers headers

    headers headers headers headers headers headers headers headers headers headers
  13. Priorities

  14. Push

  15. Demo @julienviet @vertx_project #Devoxx #vertx

  16. @julienviet @vertx_project #Devoxx #vertx #reactive HTTP/2 is TCP friendly

  17. @julienviet @vertx_project #Devoxx #vertx #reactive Server side HTTP/2

  18. @julienviet @vertx_project #Devoxx #vertx HTTP/1 vs HTTP/2 benchmark Server HTTP/1

    vs HTTP/2 Backend Client 20ms think time
  19. @julienviet @vertx_project #Devoxx #vertx Benchmark Throughput ratio 0 0.25 0.5

    0.75 1 Aimed throughput (req / sec) 200 300 400 500 600 700 800 • Constant throughput benchmark • Pace requests at a different rates • Log the ratio: request performed/ request planned
  20. @julienviet @vertx_project #Devoxx #vertx #reactive Throughput ratio 0 0.25 0.5

    0.75 1 Aimed throughput (req / sec) 200 300 400 500 600 700 800 HTTP/1 - 8 connections pipelined
  21. @julienviet @vertx_project #Devoxx #vertx #reactive What is limiting us ?

  22. FIFO one thing at a time!

  23. HTTP/2 multiplexing

  24. @julienviet @vertx_project #Devoxx #vertx #reactive Throughput ratio 0 0.25 0.5

    0.75 1 Aimed throughput (req / sec) 200 300 400 500 600 700 800 1000 1200 HTTP/1 - 8 connections HTTP/2 - 1 connection / max_concurrent_streams 20
  25. @julienviet @vertx_project #Devoxx #vertx #reactive Let’s try more

  26. @julienviet @vertx_project #Devoxx #vertx #reactive Throughput ratio 0 0.25 0.5

    0.75 1 Aimed throughput (req / sec) 1000 2000 3000 4000 5000 HTTP/2 - 1 connection - max_concurrency_streams 400
  27. None
  28. Congestion

  29. @julienviet @vertx_project #Devoxx #vertx #reactive

  30. @julienviet @vertx_project #Devoxx #vertx #reactive We are using the wrong

    abstractions
  31. @julienviet @vertx_project #Devoxx #vertx #reactive Concurrency not multithreading

  32. @julienviet @vertx_project #Devoxx #vertx #reactive How to make a better

    usage of our resources ?
  33. @julienviet @vertx_project #Devoxx #vertx #reactive HTTP/2 with Eclipse Vert.x

  34. @julienviet @vertx_project #Devoxx #vertx http://vertx.io Vert.x is a toolkit for

    building reactive and polyglot applications for the JVM
  35. @julienviet @vertx_project #Devoxx #vertx #reactive Toolkit

  36. <dependency> <groupId>io.vertx </groupId> <artifactId>vertx-web </artifactId> <version>3.3.3 </version> </dependency> <dependency> <groupId>io.vertx

    </groupId> <artifactId>vertx-mongo-client </artifactId> <version>3.3.3 </version> </dependency>
  37. dependencies { compile “io.vertx:vertx-web:3.3.3” compile “io.vertx:vertx-mongo-client:3.3.3” }

  38. > brew install vert.x … > vertx run server.java

  39. > sdk install vert.x … > vertx run server.java

  40. @julienviet @vertx_project #Devoxx #vertx #reactive Polyglot

  41. public class Server extends AbstractVerticle { public void start() {

    vertx.createHttpServer() .requestHandler(request -> { request.response() .putHeader(“content-type”, “text/plain”) .end(“Hello from Vert.x”)); ).listen(8080); } }
  42. shared class Server() extends Verticle() { start() => vertx.createHttpServer() .requestHandler((req)

    => req.response() .putHeader(“content-type”, “text/plain”) .end(“Hello from Vert.x!”)) .listen(8080); }
  43. vertx.createHttpServer() .requestHandler(function(req) { req.response() .putHeader(“content-type”, “text/plain”) .end(“Hello from Vert.x!”); }).listen(8080);

  44. vertx.createHttpServer() .requestHandler({ req -> req.response() .putHeader(“content-type”, “text/plain”) .end(“Hello from Vert.x!”)

    }).listen(8080)
  45. $vertx.create_http_server() .request_handler { |req| req.response() .put_header(“content-type”, “text/plain”) .end “Hello from

    Vert.x!” }.listen 8080
  46. class Server extends ScalaVerticle { override def start(): Unit =

    { vertx .createHttpServer() .requestHandler(_.response() .putHeader(“content-type”, “text/plain”) .end(“Hello from Vert.x”)) .listen(8080) } }
  47. class Server : AbstractVerticle() { override fun start() { vertx.createHttpServer()

    .requestHandler() { req -> req.response() .putHeader(“content-type”, “text/plain”) .end("Hello from Vert.x”) } .listen(8080) } }
  48. @julienviet @vertx_project #Devoxx #vertx #reactive Reactive all the things

  49. @julienviet @vertx_project #Devoxx #vertx Blocking user service interface UserService {

    User loadUser(String userName) throws NotFoundException(); void close(); } User user = service.loadUser(“julien”); System.out.println(user.getName()); service.close(); System.out.println(“done”);
  50. @julienviet @vertx_project #Devoxx #vertx Asyncifying the service interface UserService {

    void loadUser(String userName, Handler<AsyncResult<User >> handler); void close(Handler<Void> handler); } @FunctionalInterface interface Handler<E> { /** * Something has happened, so handle it. */ void handle(E event); }
  51. @julienviet @vertx_project #Devoxx #vertx Asyncifying the service userService.loadUser((Handler<AsyncResult<User >> event)

    -> { if (event.succeeded()) { User user = event.result(); System.out.println(user.getName()); } else { event.cause().printStackTrace(); } userService.close(v - >{ System.out.println(“done”); }); });
  52. @julienviet @vertx_project #Devoxx #vertx What events can be ? Ȑ

    NIO selectors disk operations timers messages  database etc…
  53. @julienviet @vertx_project #Devoxx #vertx Events at scale Ȑ  

       Ȑ Ȑ Ȑ Ȑ Ȑ buffer ->{…} timerID ->{…} asyncFile ->{…} rows ->{…} message ->{…}
  54. @julienviet @vertx_project #Devoxx #vertx Reactor pattern with Event Loop Single

    thread
  55. @julienviet @vertx_project #Devoxx #vertx Event Loop benefits • Easier to

    scale • Mechanical sympathetic • Simple concurrency model
  56. @julienviet @vertx_project #Devoxx #vertx HTTP/2 with Vert.x • Server and

    client • h2 with Jetty ALPN or native OpenSSL / BoringSSL • h2c • HTTP Request / response API • HTTP/2 specific features for extensions like gRPC
  57. @julienviet @vertx_project #Devoxx #vertx Non blocking server public static void

    main(String [] args) { HttpServerOptions options = new HttpServerOptions() .setUseAlpn(true) .setSsl(true) .setKeyStore(new JksOptions() .setPath(“keystore.jks”). .setPassword(“the-password”)); Vertx vertx = Vertx.vertx(); HttpServer server = vertx.createHttpServer(options); ... }
  58. @julienviet @vertx_project #Devoxx #vertx Non blocking server public static void

    main(String [] args) { … HttpServer server = vertx.createHttpServer(options); server.requestHandler(req -> { req.response() .putHeader(“Content-Type”, “text/plain”) .end(“Hello World”); }); server.listen(8080); }
  59. @julienviet @vertx_project #Devoxx #vertx Non blocking client public static void

    main(String [] args) { HttpServerOptions options = new HttpServerOptions() .setProtocolVersion(HttpVersion.HTTP_2) .setUseAlpn(true) .setSsl(true) .setKeyStore(new TrustOptions() .setPath(“trustore.jks”). .setPassword(“the-password”)); HttpClient client = vertx.createHttpClient(options); … }
  60. @julienviet @vertx_project #Devoxx #vertx Non blocking client public static void

    main(String [] args) { … HttpClient client = vertx.createHttpClient(options); client.getNow(“http: //backend”, resp -> { int status = resp.status(); resp.bodyHandler(body -> { System.out.println(body.length()); }); }); }
  61. @julienviet @vertx_project #Devoxx #vertx Non blocking proxy server.requestHandler(req -> {

    HttpServerResponse resp = req.response(); client.getNow(“http: //backend”, clientResp -> { int code = clientResp.status() resp.setStatus(code); clientResp.bodyHandler(body -> { resp.end(body); }); }); });
  62. @julienviet @vertx_project #Devoxx #vertx #reactive

  63. @julienviet @vertx_project #Devoxx #vertx #reactive

  64. @julienviet @vertx_project #Devoxx #vertx #reactive Throughput ratio 0 0.25 0.5

    0.75 1 Aimed throughput (req / sec) 1000 2000 3000 4000 5000 HTTP/2 blocking HTTP/2 non blocking
  65. @julienviet @vertx_project #Devoxx #vertx #reactive Using a single core!

  66. @julienviet @vertx_project #Devoxx #vertx #reactive Let’s for for multicore

  67. @julienviet @vertx_project #Devoxx #vertx Multi-reactor pattern

  68. @julienviet @vertx_project #Devoxx #vertx #reactive Throughput ratio 0 0.25 0.5

    0.75 1 Aimed throughput (req / sec) 1000 2000 3000 4000 5000 7000 9000 11000 13000 HTTP/2 blocking HTTP/2 non blocking -1 core HTTP/2 non blocking - 2 cores
  69. @julienviet @vertx_project #Devoxx #vertx #reactive

  70. @julienviet @vertx_project #Devoxx #vertx TL;DR; • Unleash concurrency with HTTP/2

    • Keep the good old HTTP semantics • Non blocking is a key factor for high concurrency • Vert.x is a great fit for HTTP/2 • reactive ecosystem • easy to scale
  71. @julienviet @vertx_project #Devoxx #vertx Thank you • QA • Come

    grab your Vert.x sticker! • Links • http://vertx.io • https://github.com/vietj/http2-bench • http://www.belshe.com/2010/05/24/more-bandwidth-doesnt-matter- much/ • https://www.infoq.com/presentations/latency-pitfalls • https://hpbn.co
