Life of a Document in Elasticsearch

Boaz Leskes
November 25, 2015

Life of a Document in Elasticsearch

This a variant an Elastic{ON} 15 talk with the same title. This talk was given a the Vrije Universiteit as a guest lecture.

Abstract:
Ever wondered about the lifecycle of a single document in Elasticsearch? What happens when you index it? How does Elasticsearch ensure a document is replicated and found across the whole cluster reliably? Does deleting a document really physically remove the document from disk? How do we get from a blob of text and keywords to near real-time search and analytics?

This talk will explain the when, where and why of your document's life inside of Elasticsearch. Alex and Boaz will take you through the journey of a document across a cluster, taking off with JSON and the curly braces, travelling through the network into the memory and all the analysis chains, heading further onto storage when writing into the transaction logs and Apache Lucene index, being read back by executing searches, all the way until the document is finally deleted.

Even though this talk will cover a lot of different aspects, it's a talk for those who may be less familiar with core searchfunctionality. You do not need to be an Apache Lucene wizard to follow along and find this session useful.

Boaz Leskes

November 25, 2015
Tweet

More Decks by Boaz Leskes

Other Decks in Technology

Transcript

  1. Life of a document in Elasticsearch
    Boaz Leskes - @bleskes

    View Slide

  2. { } CC-BY-ND 4.0
    Agenda
    2
    Life of a document in Elasticsearch

    View Slide

  3. { } CC-BY-ND 4.0
    Agenda
    3
    Life of a document in Elasticsearch
    How, when and where is a document
    stored/processed in Elasticsearch?

    View Slide

  4. { } CC-BY-ND 4.0
    Wait… Elasticsearch?
    • Distributed, highly available, data storage & retrieval
    • Search engine / aggregation engine / analytics
    • Suggestions / percolation / highlighting / geo
    • Document store
    • Horizontally distributed
    • High availability
    • Real time & near real time
    • Open Source
    • Apache License
    • Proprietary plugins available for security & messaging
    4

    View Slide

  5. { } CC-BY-ND 4.0
    Exhibit A: A JSON document
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    5

    View Slide

  6. { } CC-BY-ND 4.0
    Exhibit A: A JSON document
    PUT /books/book/978-1449358549
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    6

    View Slide

  7. { } CC-BY-ND 4.0
    Indexing a document
    7
    Elasticsearch
    Client
    PUT /books/book/978-1449358549
    200 OK

    View Slide

  8. { } CC-BY-ND 4.0
    Indexing a document
    8
    Client
    PUT /books/book/978-1449358549
    200 OK
    ?

    View Slide

  9. { } CC-BY-ND 4.0
    Receiving: Where to put it?
    9
    node 1 PUT /books/book/978-1449358549
    {
    }

    View Slide

  10. { } CC-BY-ND 4.0
    Receiving: Where to put it?
    10
    node 1 PUT /books/book/978-1449358549
    {
    }
    hash(978-1449358549) % number_of_shards

    View Slide

  11. { } CC-BY-ND 4.0
    Receiving: Where to put it?
    11
    node 1
    PUT /books/book/978-1449358549
    {
    }
    node 2

    View Slide

  12. { } CC-BY-ND 4.0
    Next step: Analysis
    12
    Each field is put into the inverted index
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }

    View Slide

  13. { } CC-BY-ND 4.0
    Analysis
    13
    Each field is put into the inverted index
    Clinton Gormley ->
    Input Tokenization Analysis
    Clinton Gormley [Clinton, Gormley] [clinton, gormley]
    Zachary Tong [Zachary, Tong] [zachary, tong]

    View Slide

  14. { } CC-BY-ND 4.0
    Analysis
    14
    Resulting in a postings list
    Clinton Gormley ->
    Value Document ID
    clinton 1
    gormley 1
    tong 1
    zachary 1

    View Slide

  15. { } CC-BY-ND 4.0
    Lucene at work: Field by field
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    15

    View Slide

  16. { } CC-BY-ND 4.0
    Special case: _all field
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    16

    View Slide

  17. { } CC-BY-ND 4.0
    Special case: _source field
    {
    "name" : "Elasticsearch - The definitive guide",
    "pages" : 721, "isbn13" : "978-1449358549",
    "authors" : [ "Clinton Gormley" , "Zachary Tong" ],
    "publish_date" : "2015/01/31",
    "category" : "IT > Search Engines",
    "description" : "Whether you need full-text search
    or real-time analytics...",
    }
    17

    View Slide

  18. { } CC-BY-ND 4.0
    Multifields
    PUT /books/book/_mapping
    {
    "book" : {
    "properties" : {
    "authors": {
    "type": "string", "analyzer": "standard",
    "fields": { "raw": { "type": "string", "index": “not_analyzed" } }
    }
    }
    }
    }
    18
    Sorting & Aggregations

    View Slide

  19. { } CC-BY-ND 4.0
    Multifields
    19
    Resulting in multiple postings lists
    Field: authors Value Document ID
    clinton 1
    gormley 1
    tong 1
    zachary 1
    Value Document ID
    Clinton Gormley 1
    Zachary Tong 1
    Field: authors.raw

    View Slide

  20. { } CC-BY-ND 4.0
    Completion suggester
    • Auto-complete, search-as-you-type
    • Data structure is stored on disk on indexing, then loaded
    into memory
    20

    View Slide

  21. { } CC-BY-ND 4.0
    Term vectors
    • Used for term vector highlighter and more like this query
    • Single document inverted index
    • Allows to easily find sorted unique terms as well as
    original positions and offsets
    21

    View Slide

  22. { } CC-BY-ND 4.0
    Persisting a document
    22
    buffer
    translog

    View Slide

  23. { } CC-BY-ND 4.0
    Indexing a document
    23
    buffer
    translog

    View Slide

  24. { } CC-BY-ND 4.0
    Elasticsearch refresh
    24
    buffer
    translog
    segment

    View Slide

  25. { } CC-BY-ND 4.0
    Elasticsearch flush
    25
    buffer
    translog
    segment
    fsync

    View Slide

  26. { } CC-BY-ND 4.0
    Where are we now?
    • Document received via network
    • Document received on the correct node
    • Document analyzed, stored in translog & buffer
    • No reply to the client yet that everything is done
    26

    View Slide

  27. { } CC-BY-ND 4.0
    Replication on indexing
    27
    Document level replication
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0

    View Slide

  28. { } CC-BY-ND 4.0
    Replication on indexing
    28
    Document level replication
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0

    View Slide

  29. { } CC-BY-ND 4.0
    Replication on indexing
    29
    Document level replication
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0

    View Slide

  30. { } CC-BY-ND 4.0
    Replication on indexing
    30
    Document level replication
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0

    View Slide

  31. { } CC-BY-ND 4.0
    Replication on indexing
    31
    Document level replication
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0
    Document got written 6 times!
    HTTP/1.1 200 OK

    View Slide

  32. { } CC-BY-ND 4.0
    Searching
    32

    View Slide

  33. { } CC-BY-ND 4.0
    Searches: Collecting node
    33
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0
    query hits node
    GET /books/book/_search?q=elasticsearch

    View Slide

  34. { } CC-BY-ND 4.0
    Searches: Collecting node
    34
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0
    QUERY phase executed on each shard

    View Slide

  35. { } CC-BY-ND 4.0
    Searches: Collecting node
    35
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0
    QUERY results are sorted

    View Slide

  36. { } CC-BY-ND 4.0
    Searches: Collecting node
    36
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0
    FETCH phase executed

    View Slide

  37. { } CC-BY-ND 4.0
    Searches: Collecting node
    37
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0
    FETCH results are returned

    View Slide

  38. { } CC-BY-ND 4.0
    Searches: Collecting node
    38
    node 1
    a0 a1
    node 2
    a1 a0
    node 3
    a1 a0

    View Slide

  39. { } CC-BY-ND 4.0
    Search types
    • Full text search
    – Goes on disk, access segments, execute search
    • Aggregation
    – Loads data into memory from segments, executes on
    in-memory data structure
    39

    View Slide

  40. { } CC-BY-ND 4.0
    GET /books/book/_search?search_type=count
    {
    "aggs" : {
    "author-top10" : {
    "terms" : {
    "field" : "authors"
    }
    }
    }
    }
    40
    Memory: Fielddata

    View Slide

  41. { } CC-BY-ND 4.0 41
    This does not work for aggs
    Clinton Gormley ->
    Term Document ID
    clinton 1
    gormley 1
    tong 1
    zachary 1
    Memory: Fielddata

    View Slide

  42. { } CC-BY-ND 4.0
    Memory: Fielddata
    42
    Uninverting the index from a raw field
    Document ID Term
    1 Clinton Gormley, Zachary
    Tong
    Term Document ID
    Clinton Gormley 1
    Zachary Tong 1

    View Slide

  43. { } CC-BY-ND 4.0
    Memory: Fielddata
    • Used for sorting & aggregations
    • All values of a field are loaded into memory
    • Per segment data structure
    • Can take a lot of memory
    43

    View Slide

  44. { } CC-BY-ND 4.0
    Doc values
    44
    On-Disk vs. in-memory
    PUT /books/book/_mapping
    {
    "book" : {
    "properties" : {
    "authors": {
    "type": "string", "analyzer": "standard",
    "fields": { "raw": { "type": "string", "index": “not_analyzed",
    "doc_values" : true } }
    }
    }
    }
    }

    View Slide

  45. { } CC-BY-ND 4.0
    Where are we now?
    • Original source is sent to collecting node during queries
    • Document lives in a segment as part of a shard/index
    • Document fields live in memory as part of fielddata
    • Segments are put into the filesystem cache by the OS
    45

    View Slide

  46. { } CC-BY-ND 4.0
    Scaling your cluster
    46

    View Slide

  47. { } CC-BY-ND 4.0
    Relocation
    47
    Let’s offload our fast node
    node 1
    0P
    STARTED
    1P
    STARTED
    node 2
    node.box_type: large node.box_type: small
    PUT /books/
    {
    "settings" : {
    "index.routing.allocation.include.tag" : “large"
    }
    }

    View Slide

  48. { } CC-BY-ND 4.0
    Relocation
    48
    Let’s offload our fast node
    node 1
    0P
    STARTED
    1P
    STARTED
    node 2
    node.box_type: large node.box_type: small
    PUT /books/_settings
    {
    "index.routing.allocation.include.tag" : "small"
    }

    View Slide

  49. { } CC-BY-ND 4.0
    Relocation
    49
    Let’s offload our fast node
    node 1
    0P
    STARTED
    1P
    RELOCATING
    node 2
    node.box_type: large node.box_type: small
    PUT /books/_settings
    {
    "index.routing.allocation.include.tag" : "small"
    }
    1P
    INITIALIZING

    View Slide

  50. { } CC-BY-ND 4.0
    Relocation
    50
    Let’s offload our fast node
    node 1
    0P
    STARTED
    node 2
    node.box_type: large node.box_type: small
    PUT /books/_settings
    {
    "index.routing.allocation.include.tag" : "small"
    }
    1P
    STARTED

    View Slide

  51. { } CC-BY-ND 4.0
    Relocation
    51
    Let’s offload our fast node
    node 1
    0P
    RELOCATING
    node 2
    node.box_type: large node.box_type: small
    PUT /books/_settings
    {
    "index.routing.allocation.include.tag" : "small"
    }
    1P
    STARTED
    1P
    INITIALIZING

    View Slide

  52. { } CC-BY-ND 4.0
    Relocation
    52
    Let’s offload our fast node
    node 1 node 2
    node.box_type: large node.box_type: small
    PUT /books/_settings
    {
    "index.routing.allocation.include.tag" : "small"
    }
    1P
    STARTED
    1P
    STARTED

    View Slide

  53. { } CC-BY-ND 4.0
    Relocation
    53
    What does RELOCATING mean?
    • Point in time snapshot is copied (segments)
    • Write operations occur and create new
    segments
    • All write operations are stored in translog
    • This translog is sent to the other node and
    replayed
    node 1
    0P
    STARTED
    1P
    RELOCATING

    View Slide

  54. { } CC-BY-ND 4.0
    Relocation
    • Process of copying whole shards across the cluster
    • Triggered by
    – adding/removing nodes from the cluster
    – exceeded disk thresholds
    – shard allocation filtering
    54

    View Slide

  55. { } CC-BY-ND 4.0
    Where are we now?
    • Relocation moves shards across the cluster
    • Document is duplicated by being copied from one node
    to another, as part of a segment
    • Segments are kept open until operation is complete
    55

    View Slide

  56. { } CC-BY-ND 4.0
    Deleting data
    56

    View Slide

  57. { } CC-BY-ND 4.0
    Data deletion
    57
    node 1
    b0 b1
    node 2
    b1 b0
    node 3
    b0 b1
    DELETE /books/

    View Slide

  58. { } CC-BY-ND 4.0
    Data deletion
    58
    node 1 node 2 node 3
    DELETE /books/

    View Slide

  59. { } CC-BY-ND 4.0
    Restore from a snapshot
    59
    node 1 node 2 node 3
    POST /_snapshot/books/20150310/_restore

    View Slide

  60. { } CC-BY-ND 4.0
    Restore from a snapshot
    60
    node 1 node 2 node 3
    POST /_snapshot/books/20150310/_restore
    Repository
    S3, FS,
    HDFS
    Azure

    View Slide

  61. { } CC-BY-ND 4.0
    Restore from a snapshot
    61
    node 1 node 2 node 3
    POST /_snapshot/books/20150310/_restore
    b0
    b1

    View Slide

  62. { } CC-BY-ND 4.0
    Restore from a snapshot
    62
    node 1 node 2 node 3
    POST /_snapshot/books/20150310/_restore
    b1
    b0 b1
    b0

    View Slide

  63. { } CC-BY-ND 4.0
    Creating a snapshot
    63
    node 1 node 2 node 3
    PUT /_snapshot/books/20150310
    b1
    b0 b1
    b0

    View Slide

  64. { } CC-BY-ND 4.0
    Data deletion
    64
    node 1
    b0 b1
    node 2
    b1 b0
    node 3
    b0 b1
    DELETE /books/book/978-1449358549

    View Slide

  65. { } CC-BY-ND 4.0
    Document deletion
    • Documents are immutable
    • Deletes are soft, document ids are added in a tombstone
    file to be marked for deletion
    • Actual deletion happens on next merge of that segment
    65

    View Slide

  66. { } CC-BY-ND 4.0
    Lucene merges
    66
    segment
    • Segments are created all the time when
    indexing data
    • Merging creates one big segment from
    several smaller ones

    View Slide

  67. { } CC-BY-ND 4.0
    Lucene merges
    67
    segment
    segment

    View Slide

  68. { } CC-BY-ND 4.0
    Lucene merges
    68
    segment
    segment
    segment

    View Slide

  69. { } CC-BY-ND 4.0
    Lucene merges
    69
    segment
    segment
    segment
    segment

    View Slide

  70. { } CC-BY-ND 4.0
    Lucene merges
    70
    segment
    segment
    segment
    segment document exists twice!

    View Slide

  71. { } CC-BY-ND 4.0
    Lucene merges
    71
    segment
    segment
    segment
    segment

    View Slide

  72. { } CC-BY-ND 4.0
    Lucene merges
    72
    segment

    View Slide

  73. { }
    Thanks for listening!
    Questions?
    @bleskes

    View Slide

  74. { }
    This work is licensed under the Creative Commons
    Attribution-NoDerivatives 4.0 International License.
    To view a copy of this license, visit:
    http://creativecommons.org/licenses/by-nd/4.0/
    or send a letter to:
    Creative Commons
    PO Box 1866
    Mountain View, CA 94042
    USA
    CC-BY-ND 4.0

    View Slide
