The classification problem: challenges and solutions (ed. 2015)

The classification problem: challenges and solutions (ed. 2015)

Participants will learn:
- Why classification is critical
- Why classification is difficult
- How we can make it sane
All the participants will learn the power, traps and pitfalls of classification, regardless of the configuration management tool they use.
The simple ENC solution that we implemented in Opera will be fully described; CFEngine users will have the ability to reuse it in their own environments, while users of other tools will be able to rethink their ENC solutions from a fresh perspective.

Marco Marongiu

February 12, 2015
Tweet

More Decks by Marco Marongiu

Other Decks in Technology

Transcript

  1. The classification problem:
    challenges and solutions
    Marco Marongiu (@brontolinux)

    View Slide

  2. Agenda

    Why classification is critical

    Why classification is difficult

    How we can make it sane

    Final take-aways

    View Slide

  3. Part 1:
    the problem

    View Slide

  4. !!!
    !!!
    !!!
    !!!
    !!!

    View Slide

  5. Configuration management
    «Configuration Management is the process of
    identifying and defining the items in the system,
    controlling the change of these items throughout
    their life-cycle, recording and reporting the status
    of items and change requests, and verifying the
    completeness and correctness of items»
    -- IEEE Glossary of Software Engineering Terminology (Standard
    729-1983)

    View Slide

  6. Configuration management
    «Configuration Management is the process of
    identifying and defining the items in the system,
    controlling the change of these items throughout
    their life-cycle, recording and reporting the status
    of items and change requests, and verifying the
    completeness and correctness of items»
    -- IEEE Glossary of Software Engineering Terminology (Standard
    729-1983)

    View Slide

  7. In configuration management
    you don't apply a
    configuration to
    a system, you
    rather apply it
    to classes
    of systems!

    View Slide

  8. Part 2:
    challenges

    View Slide

  9. Exceptions
    are the rule

    View Slide

  10. Generic settings, the same for all systems
    Amsterdam
    DNS server NTP server Syslog server SSH configs
    Oslo
    Other random exceptions
    Seattle Iceland

    View Slide

  11. Internal classification doesn't scale
    definitions
    explosion
    difficult
    reporting
    «The business should define what systems
    belong in which classes. The Cfengine
    administrator should build policy. Once the
    Cfengine administrator is left to manually
    defining classes within policy, you become
    a bottleneck»
    -- M.Svoboda, LinkedIn
    human
    bottleneck

    View Slide

  12. Definitions explosion
    class1
    exception1 exception2

    View Slide

  13. Definitions explosion
    class1
    exception1
    exception3
    exception2
    c1&!(ex1|ex2|ex3)
    ex1&!(ex2|ex3) ex2&!(ex1|ex3)
    ex3&!(ex1|ex2)
    (ex1&ex2)&!ex3
    (ex2&ex3)&!ex1
    ex1&ex2&ex3
    (ex1&ex3)&!ex2

    View Slide

  14. Reporting
    Not a problem caused by bad
    classification alone
    it's actually an indication that you lack a good inventory and
    compliance reporting system, but if it applies to you...
    If all the classes are defined in
    configuration files, and the class
    definitions are not trivial...
    ...how easy is it to tell at a glance if a
    host belongs to a certain class?

    View Slide

  15. Reporting
    ✔ take an infrastructure of 30000 nodes (LinkedIn-size!)
    ✔ try to report on something using SSH in a loop
    ✔ if no problem happens, and it takes ~3s per server on
    average, it takes 90000 seconds (>24h)
    ✔ if you do it with 10 parallel proceses, it's still 2.5h
    ✗ ...and you haven't started analysing the data yet
    ✗ ...and you haven't made it available to management yet
    ✗ ...and you need an up-to-date inventory of all nodes to
    provide accurate results
    ✗ ...and since not everybody has SSH access to the nodes or to
    the inventory, you are the only one (and the bottleneck)
    who can make that report!
    ✗ ...and it's an ideal case!

    View Slide

  16. Your task is building policies,
    not defining classes

    View Slide

  17. What if you had the ability to write a policy and
    use a class within that policy -- but the business
    could control which machines were associated
    with that class external to Cfengine? [...] The
    business can deploy an application to a machine,
    and Cfengine automatically responds in its policy
    because new classes have been set on the client
    automatically. Other business units can create
    classes of machines, and file a ticket for you to
    implement XYZ against the class they created.
    You are allowing your business to work the way it
    wants to.
    -- M.Svoboda, LinkedIn

    View Slide

  18. Part 3:
    Solutions

    View Slide

  19. Infrastructure complexity
    low complexity high complexity
    Technical skills
    well versed
    non technical
    Basic interface
    &
    basic backend
    Basic interface
    &
    sophisticated
    backend
    Sophisticated
    interface
    &
    sophisticated
    backend
    Sophisticated
    interface
    &
    basic backend

    View Slide

  20. Puppet and ENC
    An external node classifier is an arbitrary script
    or application which can tell Puppet which classes
    a node should have [...] that can be called by
    puppet master; it doesn’t have to be written in
    Ruby. Its only argument is the name of the
    node to be classified, and it returns a YAML
    document describing the node. [...] To tell puppet
    master to use an ENC, you need to set two
    configuration options: node_terminus has to be
    set to “exec”, and external_nodes should have the
    path to the executable.

    View Slide

  21. m
    odules!
    ENC in CFEngine means...

    View Slide

  22. our implementation: hENC
    power &
    simplicity
    config info
    in plain
    text files
    module
    protocol
    a simple
    Perl script

    View Slide

  23. View Slide

  24. CFEngine's module protocol
    (up to version 3.5)
    +activated_class
    -cancelled_class
    =my_var=my value
    @my_list={ 'list','of','4','values'}
    =my_array[element]=value
    @my_array[list]={ 'list','of','4','values'}

    View Slide

  25. #!/bin/sh
    /bin/egrep -h ^[=@+-] $* 2> /dev/null

    View Slide

  26. #!/usr/bin/perl
    use strict ;
    use warnings ;
    my %class ; # classes container
    my %variable ; # variables container
    # Silence errors (e.g.: missing files)
    close STDERR ;
    while (my $line = <>) {
    chomp $line ;
    my ($setting,$id) = ( $line =~ m{^\s*([=\@/+-_])(.+)\s*$} ) ;
    next if not defined $setting ; # line didn't match the module protocol
    # add a class
    if ($setting eq '+') {
    # $id is a class name, or should be.
    $class{$id} = 1 ;
    }
    # undefine a class
    if ($setting eq '-') {
    # $id is a class name, or should be.
    $class{$id} = -1 ;
    }
    # reset the status of a class
    if ($setting eq '_') {
    # $id is a class name, or should be.
    delete $class{$id} if exists $class{$id} ;
    }

    View Slide

  27. # define a variable/list
    if ($setting eq '=' or $setting eq '@') {
    # $id is "variable = something", or should be
    my ($varname) = ( $id =~ m{^(.+?)=} ) ;
    $variable{$varname} = $line ;
    }
    # reset a variable/list
    if ($setting eq '/') {
    # $id is "variable = something", or should be
    delete $variable{$id} if exists $variable{$id} ;
    }
    # discard the rest
    }
    # print out classes
    foreach my $classname (keys %class) {
    print "+$classname\n" if $class{$classname} > 0 ;
    print "-$classname\n" if $class{$classname} < 0 ;
    }
    # print variable/list assignments, the last one wins
    foreach my $assignment (values %variable) {
    print "$assignment\n" ;
    }

    View Slide

  28. general defaults
    location
    environment
    node
    project
    location overrides
    environment
    general defaults
    general defaults
    location
    environment
    general defaults
    node

    View Slide

  29. bundle agent enc {
    vars:
    any::
    [...]
    ##################################################################
    # General defaults
    "defaults" string => "$(basedir)/_default_" ;
    ##################################################################
    # Select the location (class => file)
    "location_class[amsterdam]" string => "_amsterdam_" ;
    "location_class[ashburn]" string => "_ashburn_" ;
    "location_class[oslo]" string => "_oslo_" ;
    "location_class[seattle]" string => "_seattle_" ;
    "location_class[thor]" string => "_thor_" ;
    "location_class[wroclaw]" string => "_wroclaw_" ;
    # @(locations) gets all class names mentioned in location_class
    "locations" slist => getindices("location_class") ;
    # loop through @(locations), get the right file for this location
    "location"
    comment => "Select a path for the location",
    string => "$(locdir)/$(location_class[$(locations)])",
    ifvarclass => "$(locations)" ;

    View Slide

  30. classes:
    any::
    "enc_has_location" expression => isvariable("location") ;
    "enc_has_locenvironment" expression => isvariable("locenvironment") ;
    "enc_has_project" expression => isvariable("project") ;
    "enc_has_override" expression => isvariable("override") ;
    "enc_has_projenv" expression => isvariable("projenv") ;
    "enc_has_node" expression => isvariable("node") ;

    View Slide

  31. vars:
    [. . .]
    ##################################################################
    # put it all together:
    # initialize the list:
    "list"
    comment => "Build the ENC list",
    policy => "free",
    slist => { "$(defaults)" } ;
    enc_has_location::
    "list"
    comment => "Increment ENC list with location",
    policy => "free",
    slist => { @(list), "$(location)" } ;
    enc_has_locenvironment::
    "list"
    comment => "Increment ENC list with per-location environment",
    policy => "free",
    slist => { @(list), "$(locenvironment)" } ;
    [. . .]
    enc_has_node::
    "list"
    comment => "Increment ENC list with node settings",
    policy => "free",
    slist => { @(list), "$(node)" } ;

    View Slide

  32. methods:
    "ENC"
    comment => "External node classification",
    usebundle => henc("enc.list") ;
    vars:
    ntp_unicast::
    "servers"
    slist => { @(henc.ntp_servers) } ;

    View Slide

  33. bundle agent henc(enclist_name) {
    vars:
    henc_has_list::
    "enclist" slist => { "@($(enclist_name))" } ;
    "enc_fullpath" slist => maplist("$(site.inputs)/$(this)","enclist") ;
    "encargs" string => join(" ","enc_fullpath") ;
    classes:
    "henc_has_list" expression => isvariable("enclist_name") ;
    "henc_has_args" expression => isvariable("encargs") ;
    "henc_can_classify" and => { "henc_has_list","henc_has_args" } ;
    files:
    any::
    "$(site.lmodules)/henc"
    comment => "Copy/update hierarchical merger",
    copy_from => digest_cp("$(site.modules)/henc"),
    perms => root_executable ;
    henc_has_list::
    "$(site.inputs)/$(enclist)"
    comment => "Cache henc files locally",
    copy_from => digest_cp("$(site.masterfiles)/$(enclist)") ;
    commands:
    henc_can_classify.!henc_classes_activated::
    "$(site.lmodules)/henc"
    comment => "Hierarchical classification for $(sys.fqhost)",
    args => "$(encargs)",
    classes => always("henc_classes_activated"),
    module => "true" ;
    }

    View Slide

  34. final take-aways
    smart
    classification
    is crucial...
    ...but doesn't
    need to be
    complicated...
    ...unless your
    infrastructure is.
    sometimes,
    even plain text
    is good enough!

    View Slide

  35. View Slide

  36. comments?
    @brontolinux
    [email protected]
    http://syslog.me
    http://no.linkedin.com/in/marcomarongiu/

    View Slide

  37. TAKK
    for meg

    View Slide
