  1. AWS Networking 101 Albert Suwandhi

  2. Intro $ whoami AWS Community Builders, IT Lecturer at Universitas

    IBBI & Universitas Pelita Harapan, AWS Champion Authorized Instructor at SL2 Indonesia
  3. Agenda • VPC Concepts and Fundamentals • IP Addressing •

    Subnets • Routing on VPC • DNS in VPC – Amazon Route53 • Security • Connectivity Options
  4. None
  5. Virtual Private Cloud (VPC) • Define and launch AWS resources

    in a logically isolated virtual network • VPC in AWS is Regional Resources • Each region have default VPC • Limits : https://docs.aws.amazon.com/vpc/latest/userguide/amazon- vpc-limits.html
  6. IP Addressing • Avoid ranges that overlap with other networks

    to which you might connect • Recommended : RFC1918 Range • Size : /16 (Maximum) to /28 (Minimum) • Can have a dual-stack VPC by adding an IPv6 CIDR • Fixed sizes for VPC and subnets: /56 for VPC CIDR and /64 for subnets
  7. Subnets • A subnet is a range of IP addresses

    in our VPC. We can launch AWS resources, such as EC2 instances, into a specific subnet. • When we create a subnet, we specify the IPv4/IPv6 CIDR block for the subnet, which is a subset of the VPC CIDR block. • Each subnet must reside entirely within one Availability Zone and cannot span cross zones.
  8. VPC Routing • Route tables contain rules for which path

    packets go to reach the destination • Our VPC has a default route table • But, we can create and assign different route tables to different subnets
  9. None
  10. DNS in VPC

  11. DNS – Route53

  12. Hybrid DNS Resolution https://aws.amazon.com/ar chitecture/reference- architecture-diagrams/

  13. Security • Security Groups • Network ACL • Network Firewall

    • VPC Flow Logs • Traffic Mirroring
  14. Security Groups and Network ACL

  15. Security Groups vs Network ACL

  16. Network Firewall – Example Use Case https://aws.amazon.com/architecture/ reference-architecture-diagrams/

  17. VPC Connectivity Options • Internet Connectivity or NOT • Connecting

    to other VPCs : VPC Peering and Transit Gateway • Connecting to on premise networks : Site to Site VPN, Direct Connect, Client VPN
  18. Public vs Private Subnet

  19. Connecting VPCs : VPC Peering

  20. Connecting VPCs : VPC Peering and TGW

  21. Demo Videos : VPC Peering and TGW

  22. AWS Site to Site VPN

  23. AWS Direct Connect

  24. Demo Videos - VPN Connection

  25. Learn more about AWS Networking • AWS re:Invent 2017: Another

    Day, Another Billion Flows (NET405) • AWS re:Invent 2018: AWS Direct Connect: Deep Dive (NET403) • AWS re:Invent 2019: Deep dive on DNS in the hybrid cloud (NET410) • WS re:Invent 2019: [REPEAT 1] AWS Transit Gateway reference architectures for many VPCs (NET406-R1) • AWS re:Invent 2021 - Networking Foundations • AWS re:Invent 2021 - Advanced Amazon VPC Design and New Capabilities • AWS Reference Architecture : Hybrid DNS resolution with Amazon Route 53 Resolver Endpoints • AWS Reference Architecture : Traffic inspection with AWS Network Firewall • etc
  26. AWS Certifications https://aws.amazon.com/certification/

  27. Contact: albert.suwandhi@gmail.com @albertsuwandhi
