Measurement as an Architectural Concern

Modern software engineering practices stress the need to optimise for learning throughout the software delivery process, which means that we need to create rapid feedback loops to allow this learning. Feedback loops work by allowing us to see how our work affects key measures such as quality, complexity, scalability, security, frequency of release, lead time, change failure rate and many other more specific measures for our individual situations. However the difficulty we often face is that it is difficult to measure many of the factors that we care about. This is often because we don't treat the ability to measure our systems as a requirement, but try to add measurement on-demand when needed. Would it not be better to treat measurement as an explicit architectural concern and incorporate it into our architecture practices? In this talk we will try to do just that, by examining what types of measurement we are likely to need, the techniques we can use to provide those types of measurement and how to incorporate consideration of measurement as an architectural concern into our work.

Transcript

1. Eoin Woods
   (Towards) Measurement as an
   Architectural Concern


   View Slide

2. View Slide

3. Eoin Woods
   • Endava’s Chief Engineer, based in London (since 2015)
   • 10+ years in products - Bull, Sybase, InterTrust
   • 10 years in capital markets - UBS and BGI
   • Software developer, architect, now Chief Engineer
   • Author, editor, speaker, community guy


   View Slide

4. WHY MEASUREMENT?
   7


   View Slide

5. Feedback
   • The need for feedback is constantly talked about
   • Agile
   • DevOps
   • Digital products
   • Continuous architecture
   • Optimising learning
   • But how to implement good feedback loops is less often
   discussed
   8


   View Slide

6. Feedback and Measurement
   • Feedback inherently relies on measurement
   • We often need to measure many kinds of things
   • We often don’t discuss what to measure and how to measure it
   • In many software projects measurement can be complicated
   9


   View Slide

7. What is Measurement?
   “Measurement: process of experimentally obtaining one
   or more quantity values that can reasonably be attributed
   to a quantity”
   • “Quantity : property of a phenomenon, body, or substance,
   where the property has a magnitude that can be expressed as a
   number and a reference”
   • “Quantity Value: value of a quantity value number and reference
   together expressing magnitude of a quantity”
   (Joint Committee for Guides in Metrology, 2008)
   10
   “Measurement: A quantitatively expressed
   reduction of uncertainty based on one or
   more observations.”
   (Douglas Hubbard,
   How to Measure Anything, 3e, 2014)
   Measurement is the quantification of attributes of an
   object or event, which can be used to compare with
   other objects or events
   (Wikipedia)


   View Slide

8. Metric vs Measurement
   A metric - the definition of something to be
   measured (its attributes and characteristics, e.g.
   ”CPU usage” or ”annual revenue per customer”)
   A measurement - the result (n.), or process (v.),
   of establishing a specific value for a metric
   11


   View Slide

9. Measurement vs Monitoring and Observability
   Measurement – making quantitative observations of the
   system in production and its development environment,
   in order to establish whether or not the system and its
   development process are moving towards or away from
   stated technical or business goals.
   Monitoring and Observability – making observations
   about a system in production in order to understand the
   current state of the system, establish if it is behaving
   ”normally”, and if not, how best to remediate that
   situation.
   12
   Complementary concepts with different objectives, which can use many of the same
   technologies. Monitoring and observability can be a rich source of measurements.


   View Slide

10. DIFFICULTIES WITH MEASUREMENT
    13


    View Slide

11. Measuring Software Systems
    14
    Goal-Question-Metric Software Analysis
    Fitness Functions
    Observability
    Business Metrics Dashboards
    Data Analytics
    We have a lot of promising pieces … but it all needs to be assembled
    Monitoring
    Testing


    View Slide

12. Measuring Software Systems
    • This sounds like an architecture problem
    • Is “being measurable“ a quality attribute?
    • If we want the system to be measurable how do
    we organise these pieces to make it so?
    15
    this talk is a step in this direction
    Photo by Daniel Andrade on Unsplash


    View Slide

13. We Can Measure Many Things
    16
    Customer retention
    Net revenue retention
    Gross revenue retention
    revenue
    Annual recurring revenue
    Customer churn
    Customer renewals
    Customer cancellations
    Customer signups
    activations referrals
    daily active users
    User time per visit
    % customer promoters
    Net promoter score CPU utilisation
    Memory utilisation
    Max memory in use
    Exceptions per 1000 user sessions
    XS
    Component coupling
    Reliability
    Velocity increase%
    Outage minutes per month
    Defects in operation
    Mean time to recover
    Unit test coverage
    Acceptance test coverage
    Deployment frequency
    Lead time for change
    Time to restore service
    Change failure rate
    Days since last incident
    Modularity maturity index
    Module coupling
    Vulnerabilities


    View Slide

14. We Can Measure Many Things
    17
    Customer retention
    Net revenue retention
    Gross revenue retention
    revenue
    Annual recurring revenue
    Customer churn
    Customer renewals
    Customer cancellations
    Customer signups
    activations referrals
    daily active users
    User time per visit
    % customer promoters
    Net promoter score
    CPU utilisation
    Memory utilisation
    Max memory in use
    Exceptions per 1000 user sessions
    XS
    Component coupling
    Reliability
    Team velocity increase%
    Outage minutes per month
    Defects in operation
    Mean time to recover
    Unit test coverage
    Acceptance test coverage
    Deployment frequency
    Lead time for change
    Time to restore service
    Change failure rate
    Days since last incident
    Modularity maturity index
    Module coupling Vulnerabilities


    View Slide

15. Many Things Can Be Used to Measure
    18
    Power BI
    yCrash


    View Slide

16. 19
    It can all end up being a bit complicated!


    View Slide

17. Architectural Thinking
    20
    Models
    Tactics
    Tradeoffs
    Pitfalls


    View Slide

18. MEASUREMENT AS AN
    ARCHITECTURAL CONCERN
    21


    View Slide

19. Treating Measurement as an Architectural Concern
    22
    Concerns What are we trying to achieve?
    (requirements, constraints, objectives, intentions)
    Tactics How are we going to address those concerns?
    Activities What are we going to do to apply those tactics?
    Pitfalls What is likely to go wrong and what to we do to
    avoid that?
    As an aside this is an “Architectural Perspective” … see www.viewpoints-and-perspectives.info


    View Slide

20. Architectural Concerns for Measurement
    • What to measure?
    • Who wants to know? What do they want to know? Why do they
    want to know that?
    • How to measure it?
    • With acceptable accuracy, with acceptable currency, at
    acceptable runtime cost, at acceptable long-term cost
    • How to present and use it?
    • To provide effective, actionable feedback, to be suitable in the
    context where it is needed, to be clear and unambiguous
    23


    View Slide

21. Architectural Tactics for Measurement
    24
    What to Measure
    • Identify users of the feedback & set clear goals
    • Use structured approach (e.g. GQM) to identify useful metrics
    • Define metrics clearly
    • Consider internal vs external and artefact vs operational metrics
    How to Measure
    • Use a reference model to organize the approach
    • Use existing proven mechanisms wherever possible
    • Use interoperable protocols wherever possible
    • Use fitness functions to identify problems proactively
    How to Present
    • Specific presentation for specific goals
    • Aim for simple and consistent presentation (use existing styles)
    • Use existing proven frameworks wherever possible
    • Make UIs self-describing with built-in documentation


    View Slide

22. Architectural Tactics for Measurement
    25
    What to Measure
    • Identify users of the feedback & set clear goals
    • Use structured approach (e.g. GQM) to identify useful metrics
    • Define metrics clearly
    • Consider internal vs external and artefact vs operational metrics
    How to Measure
    • Use a reference model to organize the approach
    • Use existing proven mechanisms wherever possible
    • Use interoperable protocols wherever possible
    • Use fitness functions to identify problems proactively
    How to Present
    • Specific presentation for specific goals
    • Aim for simple and consistent presentation (use existing styles)
    • Use existing proven frameworks wherever possible
    • Make UIs self-describing with built-in documentation


    View Slide

23. Tactic: Goal-Question-Metric (GQM)
    • Long established structured technique to achieve goal-
    oriented measurements
    • Focuses attention on how metrics are used and their
    value, helps to prioritise useful metrics and avoid waste
    • Goal: statement describing what you want to understand
    • Questions: characterise the goal and allow progress
    towards it to be judged
    • Metrics: clear definitions of the quantifiable
    measurements to be made
    27
    Victor Basili and David Weiss, ”A methodology for collecting valid software engineering data”, IEEE ToSE, November 1984
    Michael Keeling, “Measure the unknown with the GQM approach”, Chapter 10, Software Architecture Metrics, O’Reilly, 2022
    M M M
    GOAL
    Q Q


    View Slide

24. Goal-Question-Metric (GQM)
    28
    Understand request
    processing capacity to
    predict future platform
    needs
    How much memory is in
    use?
    How much cpu is in use?
    How much storage is in
    use?
    Have we ever run out of
    resources?
    What is our current
    workload?
    Memory % by machine over time
    Min, max, avg memory in period
    CPU % by machine over time
    Min, max, avg CPU in period
    Store free % by machine over time
    Min, max, avg free % in period
    App resource exceptions in period
    Infra resource alerts in period
    Txn/hour over time
    Max txn/hour in period


    View Slide

25. Tactic: Define Metrics Clearly
    29
    Name A clear, descriptive, unambiguous short name for the metric
    Description A description of what the metric is measuring and its context
    Purpose Why collect the metric? What is the value of its measurements? What will it be
    used for?
    Units What units will the measurements be denominated in? (Counter, monetary
    amounts, integer values, time intervals, technical sizes, …)
    Characteristics How accurate do the measurements need to be to be useful? How precise do the
    measurements need to be? What measurement resolution do we need?
    Data Source How do you make the measurement? What do you measure? Where do you
    measure? Are any calculations needed?


    View Slide

26. Tactic: Reference Model - Functional Layers
    Measure
    Collect
    Preprocess and Derive
    Store
    Visualise and Present
    Metrics measurement
    Metrics collection & transport
    Inflight processing and derived value
    calculation
    Time series storage of metrics values
    Dashboards, alerts, reports
    Derived from James Turnbull, The Art of Monitoring (2016)


    View Slide

27. Tactic: Reference Model - Functional Structure
    Repo
    Operational System
    Measurement Transport
    Measurement
    Store
    Metdefs
    Presentation
    &
    Visualisation
    Preproc & Derive
    Operational
    Measurements
    Business
    Measurements
    Artefact
    Measurements
    Deployment
    Artefacts
    SDLC
    tools
    SDLC
    Measurements
    metric collector
    fitness function
    application
    measurement
    data flow


    View Slide

28. Reference Model: Simple First Step
    Repo Operational System
    DB
    Host
    Flat
    files
    logscraper.sh
    bizmetrics.sql
    ArchUnit SpotBugs
    Flat
    files
    MySQL
    “LOAD DATA”
    Met
    defs
    Jira
    Log
    files
    metric collector
    fitness function
    application
    measurement
    data flow


    View Slide

29. Reference Model: Simple First Step
    Repo Operational System
    DB
    Host
    Flat
    files
    logscraper.sh
    bizmetrics.sql
    ArchUnit SpotBugs
    Flat
    files
    MySQL
    “LOAD DATA”
    Met
    defs
    Jira
    Log
    files
    Collectors &
    Fitness Fns
    Measurement
    Transport
    Measurement
    Store
    Presentation &
    Visualisation
    Metric
    Definitions
    metric collector
    fitness function
    application
    measurement
    data flow


    View Slide

30. Reference Model: Complex Example
    Operational System
    Operational &
    Business
    Measurements
    Repo
    Deployment
    Artefacts Open Telemetry Client
    Jira
    Prometheus
    OTel Collector
    Node Exporter
    SQL Exporter
    Grafana
    Custom Plugin
    Metric
    Definitions
    Node Exporter
    Pipeline
    Measurements
    Custom SDLC
    Exporter
    SDLC
    Measurements
    metric collector
    fitness function
    application
    measurement
    data flow


    View Slide

31. Reference Model: Complex Example
    Operational System
    Operational &
    Business
    Measurements
    Repo
    Deployment
    Artefacts Open Telemetry Client
    Jira
    Prometheus
    OTel Collector
    Node Exporter
    SQL Exporter
    Grafana
    Custom Plugin
    Metric
    Definitions
    Node Exporter
    Pipeline
    Measurements
    Custom SDLC
    Exporter
    SDLC
    Measurements
    Metric
    Definitions
    Collectors &
    Fitness Fns
    Collectors
    Measurement
    Transport
    Collectors &
    Transport
    Measurement Store &
    Preproc & Derive
    Presentation &
    Visualisation
    Collectors &
    Transport
    metric collector
    fitness function
    application
    measurement
    data flow


    View Slide

32. Activities
    36
    Identify the
    Stakeholders
    Identify
    Measurement
    Goals
    Identify Candidate
    Metrics
    Define Metrics
    Identify Data
    Sources for Metrics
    Create Suitable
    Measurement
    Infrastructure
    Perform
    Measurement
    Analyse
    Measurements
    measurement
    goals not met
    measurement
    goals met
    Feedback to
    Stakeholders


    View Slide

33. Pitfalls
    37
    Focusing on mechanisms rather than measurements
    Measuring what is easy to measure (rather than valuable)
    (Just) technical rather than business metrics
    Prioritising accuracy over usefulness
    Not taking action based on the measurements
    Measuring without a purpose (=> too much measuring)


    View Slide

34. TO CONCLUDE
    38


    View Slide

35. Measurement as an Architectural Concern
    • Feedback is important in most modern approaches
    • Feedback needs measurement
    • It turns out measurement is quite complicated, and
    projects can get into a bit of a mess
    • Treating it as quality attribute helps to focus attention on
    measurement
    • Our architectural perspective reminds us of concerns,
    tactics, activities and pitfalls to help us structure our
    approach and avoid problems
    39
    https://unsplash.com/photos/DKSWyxtcPVQ


    View Slide

36. Measurement as an Architectural Concern
    40
    Concerns What to measure? (Who, what, why); How to measure it? (accuracy, currency, runtime cost,
    long-term cost) How to present and use it? (effective, actionable feedback for the context)
    Tactics
    What: Identify users of the feedback; Set clear goals with the users; Use structured approach
    (e.g. GQM) to identify clear measures; Consider internal vs external and artefact vs operational
    How: reference models; proven mechanisms; interoperable protocols; fitness functions
    Present: Specific presentation; simple and consistent (existing styles); proven frameworks; self-
    describing Uis
    Activities Identify stakeholders, goals and metrics; Define metrics; Identify data sources; Create
    measurement infrastructure; Measure; Analyse; Feedback; Evaluate; Iterate
    Pitfalls
    Focusing on mechanisms rather than measurements; Measuring what is easy to measure (rather
    than valuable); (Just) technical rather than business metrics; Prioritising accuracy over
    usefulness; Not taking action based on the measurements; Measuring without a purpose (=> too
    much measuring)


    View Slide

37. Measurement as an Architectural Concern
    41
    Concerns What to measure? (Who, what, why); How to measure it? (accuracy, currency, runtime cost,
    long-term cost) How to present and use it? (effective, actionable feedback for the context)
    Tactics
    What: Identify users of the feedback; Set clear goals with the users; Use structured approach
    (e.g. GQM) to identify clear measures; Consider internal vs external and artefact vs operational
    How: reference models; proven mechanisms; interoperable protocols; fitness functions
    Present: Specific presentation; simple and consistent (existing styles); proven frameworks; self-
    describing Uis
    Activities Identify stakeholders, goals and metrics; Define metrics; Identify data sources; Create
    measurement infrastructure; Measure; Analyse; Feedback; Evaluate; Iterate
    Pitfalls
    Focusing on mechanisms rather than measurements; Measuring what is easy to measure (rather
    than valuable); (Just) technical rather than business metrics; Prioritising accuracy over
    usefulness; Not taking action based on the measurements; Measuring without a purpose (=> too
    much measuring)
    What to measure?
    Goal-Question-
    Metric
    How to measure?
    Reference model
    And remember …
    common pitfalls !
    Measurement is
    worth taking
    seriously
    Visualise for the
    audience and goal


    View Slide

38. To Find Out More
    42


    View Slide

39. View Slide

40. View Slide

41. Eoin Woods
    Endava
    eoin.woods@endava.com
    @eoinwoodz and @eoinwoods@mastodonapp.uk
    45
    THANK YOU … QUESTIONS?


    View Slide
