The road to open networks

The road to open networks

Open Source has won: nowadays most of the internet runs on top of open source software and we trust it on devices big and small for everyday computing. We’ve come a long way in building trust into open source software, but the landscape was very different a couple of decades ago. This trust in open source has created room for open models to spread to other areas such as Open Source Hardware, Open Data, Open Access, and more recently Open Networks.

Since 2015, the community of The Things Network is building a global, free and open network for the Internet of Things based on LoRaWAN technology. Today, The Things Network is active in more than 400 cities across 84 countries and there are thousands of users worldwide contributing to consolidate the notion that open network infrastructure can be trusted just as much as we trust open source software. Some of the largest local communities of The Things Network are located Switzerland.

Gonzalo Casas

October 20, 2017
Tweet

More Decks by Gonzalo Casas

Other Decks in Technology

Transcript

  1. THE ROAD TO OPEN NETWORKS
    Building an open and free Internet of Things network
    [email protected] | twitter.com/gnz

    View Slide

  2. THE THINGS NETWORK
    A global community, building open source
    software and hardware to operate a
    crowd-sourced IoT network.

    View Slide

  3. IN SWITZERLAND

    View Slide

  4.  TECHNOLOGY
     COMMUNITY
     SOCIAL CHANGE

    View Slide

  5. WHAT IS LORAWAN?

    View Slide

  6. LORAWAN
    • LoRa (Long Range): Radio modulation technique
    • LoRaWAN: MAC protocol for Wide Area Networks (OSI Layer 2 and 3)
    sensors
    nodes
    gateways backend
    application
    backend
    LoRa ip ip

    View Slide

  7. LORAWAN
    3 * 10
    10 km range
    10 USD/node
    10 years battery life

    View Slide

  8. LONG RANGE
    2km - 5km in urban setting
    40km+ in rural setting
    © ttnmapper.org , Open Street Map

    View Slide

  9. INSANELY
    LONG RANGE
    (under extreme conditions)
    201 km ground-to-ground
    by Andreas Spiess, TTN Basel
    http://www.sensorsiot.org/
    © ttnmapper.org

    View Slide

  10. INSANELY
    LONG RANGE
    (under extreme conditions)
    333 km air-to-ground (helium balloon)
    by @telkamp (mapping @jpmeijers)
    © ttnmapper.org

    View Slide

  11. LOW COST
    Node/transceiver: CHF 8.5
    Gateway: ~CHF 250 (indoor)
    Open source stack + ISM bands
    Low CAPEX, almost negligible OPEX
    Photos by @gnz, CC-BY-SA

    View Slide

  12. FREE & OPEN SOURCE STACK

    View Slide

  13. UNLICENSED SPECTRUM
    Anyone can deploy a LoRaWAN network!

    View Slide

  14. LOW POWER
    Class A Class B Class C
    Always send,
    receive after send.
    Up to 10 years.
    Deep sleep: ~10 μA
    TX ~40 mA
    RX ~14 mA
    Time-synchronized
    receive windows.
    Always-on receive
    mode.
    Not supported
    Support not ready,
    but planned

    View Slide

  15. LIMITATIONS
    Bandwidth
    Payload size
    Regulatory limits
    0.3 bps to 50 kbps
    51 bytes (DR0)
    222 bytes (DR4)
    Fair usage policy
    1% Duty Cycle
    30 seconds/day airtime
    10 downlinks/day

    View Slide

  16. ZURICH COMMUNITY

    View Slide

  17. THE SPARK

    View Slide

  18. View Slide

  19. CORE TEAM

    View Slide

  20. © 2015 Wireless Solutions by IMST GmbH

    View Slide

  21. MEETUPS
    CORE TEAM

    View Slide

  22. Photo by Ali Soy, @alisoy1502

    View Slide

  23. Photos by @gnz, CC-BY-SA

    View Slide

  24. MEETUPS
    CORE TEAM
    FIRST GATEWAYS

    View Slide

  25. Photos by @gnz, CC-BY-SA

    View Slide

  26. MEETUPS
    CORE TEAM
    FIRST GATEWAYS
    GOING LIVE!

    View Slide

  27. Photos by @gnz, CC-BY-SA

    View Slide

  28. Photos by @gnz, CC-BY-SA

    View Slide

  29. Photos by @gnz, CC-BY-SA

    View Slide

  30. COMMUNITY GROWTH
    MEETUPS
    CORE TEAM
    FIRST GATEWAYS
    GOING LIVE!

    View Slide

  31. View Slide

  32. MEETUPS
    CORE TEAM
    FIRST GATEWAYS
    GOING LIVE!
    COMMUNITY GROWTH
    SUSTAINABILITY

    View Slide

  33. SOCIAL CHANGE

    View Slide

  34. View Slide

  35. CAN WE TRUST AN OPEN
    NETWORK?

    View Slide

  36. Linux is a cancer that
    attaches itself in an
    intellectual property sense
    to everything it
    Photo by Aanjhan Ranganathan, CC BY 2.0
    Steve Ballmer, ex-CEO Microsoft and
    incontinent over-stater of facts
    1st June 2001

    View Slide

  37. View Slide

  38. View Slide

  39. THE WORLD RUNS ON OSS

    View Slide

  40. REDUNDANCY
    CRYPTOGRAPHY
    -and-running?
    DECENTRALIZATION

    View Slide

  41. OSS + OPEN STANDARDS

    View Slide

  42. THANKS!
    Gonzalo Casas
    Open Network Infrastructure Association
    [email protected] | twitter.com/gnz

    View Slide

  43. LINKS
    https://ttn-ch.herokuapp.com/
    https://opennetworkinfrastructure.org/
    https://www.thethingsnetwork.org/country/switzerland/
    https://bit.ly/onia-dinacon17
