Event Logging at Belly

Using Fluentd to move logs into HDFS, S3, and RabbitMQ

Transcript

1. Kevin Reedy
   @kevinreedy
   kevin@bellycard.com
   http://tech.bellycard.com
   Event Logging at Belly
   !
   Using fluentd to move logs into HDFS,
   S3, and RabbitMQ


   View Slide

2. Event Logging at Belly @kevinreedy
   What is Belly?


   View Slide

3. Event Logging at Belly @kevinreedy


   View Slide

4. The Nation’s Largest Loyalty Network
   “From Sea To Shining Sea” - literally.
   Tap into Belly’s nationwide network of millions of active Members and thousands of Merchant Partners.
   Interact with more customers better.
   Tens of Millions
   Of Visits
   Millions
   Of Members
   Thousands
   Of Locations


   View Slide

5. Event Logging at Belly @kevinreedy
   What is Belly?
   •A digital customer loyalty platform
   •One card or app for the entire network
   •Over 2,000,000 members
   •Over 8,000 merchants
   •Over 15,000,000 visits
   •Unique rewards


   View Slide

6. Event Logging at Belly @kevinreedy
   Who is this Kevin guy
   • Grew up “in Chicago”
   • Networks and Telecom degree from DePaul
   University
   • Infrastructure Architect on the very small systems
   team at Belly
   • At Belly for a year
   • Previously at Tap.Me, OpenDNS, Riverbed


   View Slide

7. Event Logging at Belly @kevinreedy
   Event Logging
   At Belly


   View Slide

8. Event Logging at Belly @kevinreedy
   Event Logging - Inputs
   •User Events
   •Client Events
   •API Events
   •Business Events


   View Slide

9. Event Logging at Belly @kevinreedy
   User Events
   •Mobile Applications
   •In-Store Tablet Application
   •Homepage


   View Slide

10. Event Logging at Belly @kevinreedy
    Client Events
    •In-store tablet
    •Heartbeats
    •Error Logs


    View Slide

11. Event Logging at Belly @kevinreedy
    API Events
    • User Creation
    • Checkins
    • Reward Redemption
    • Email
    • Send
    • Delivered
    • Opened
    • Clicked
    • Spam Reported


    View Slide

12. Event Logging at Belly @kevinreedy
    Business Events
    •Salesforce Callbacks
    •Meetings
    •Installs
    •Closes


    View Slide

13. Event Logging at Belly @kevinreedy
    Event Logging - Outputs
    •Hadoop HDFS
    •S3
    •RabbitMQ


    View Slide

14. Event Logging at Belly @kevinreedy
    FluentD
    •Open-source tool to collect events and
    logs
    •Code and Plugins written in Ruby
    •Everything is JSON
    •150+ plugins, including Hadoop, S3,
    MongoDB, Elasticsearch
    •Provides Disk and RAM Buffering


    View Slide

15. Event Logging at Belly @kevinreedy
    Bee
    •Data Validation and Sanitization
    Service
    •Written in Ruby
    •Rules are defined in YAML
    •Events from untrusted sources must
    first pass through Bee
    •This includes mobile clients


    View Slide

16. Event Logging at Belly @kevinreedy
    Bee


    View Slide

17. Event Logging at Belly @kevinreedy
    Putting it all together


    View Slide

18. Event Logging at Belly @kevinreedy
    API Layer
    •API Servers and Bee Servers run
    Fluentd locally
    •Fast response time
    •Buffering locally if there are issues
    •Fluentd also has a UDP input if you’d
    rather have best effort delivery


    View Slide

19. Event Logging at Belly @kevinreedy
    API ➡ Aggregation Layer
    • Each API Fluentd instance forwards to two sets of
    servers:
    • Fluentd aggregators in Chicago
    • Fluentd aggregators in EC2 us-east-1
    • Currently each aggregator set is 2 hosts
    • API Fluentd instances treat each aggregation set as
    Master/Master, but this is configurable


    View Slide

20. Event Logging at Belly @kevinreedy
    Aggregation Layer
    •Limits the number of connections to
    Output Layer
    •Provides disk buffering for S3 and HDFS
    Outputs
    •Provides minimal buffering for
    RabbitMQ Outputs


    View Slide

21. Event Logging at Belly @kevinreedy
    Aggregation ➡ Output Layer
    • Forest Output Plugin
    • Output Plugins for Fluentd
    • S3
    • https://github.com/fluent/fluent-plugin-s3
    • HDFS
    • https://github.com/fluent/fluent-plugin-webhdfs
    • HttpsFs instead of WebHDFS
    • RabbitMQ
    • https://github.com/restorando/fluent-plugin-amqp


    View Slide

22. Event Logging at Belly @kevinreedy
    Applications
    •Ad-hoc queries in Hive
    •Hiverunner
    •User Facts Service
    •Honey Reports
    •Checkins Map


    View Slide

23. Event Logging at Belly @kevinreedy
    Honey Reports


    View Slide

24. Event Logging at Belly @kevinreedy
    Honey Reports


    View Slide

25. Event Logging at Belly @kevinreedy
    Checkins Map


    View Slide

26. Event Logging at Belly @kevinreedy
    Future Plans
    •Evaluate using RabbitMQ as the
    Aggregation Layer
    •Application Logs as an Input
    •Splunk or Elasticsearch / Kibana as
    Outputs


    View Slide

27. Event Logging at Belly @kevinreedy
    Questions?
    !
    !
    …if there is time


    View Slide

28. Event Logging at Belly @kevinreedy
    Keep in touch
    •twitter: @kevinreedy
    •email: kevin@bellycard.com
    •internets: http://tech.bellycard.com


    View Slide
