Android Jetpack Joyride

Android Jetpack Joyride

It includes four components of Android Jetpacks. It includes Room, Paging Library, WorkManager, Palette, Slice etc.

B1a1cc3d71600c6e47c33c65fa08f71f?s=128

Krunal Kapadiya

October 28, 2018
Tweet

More Decks by Krunal Kapadiya

Other Decks in Technology

Transcript

  1. Krunal Kapadiya Volansys @krunal3kapadiya Gandhinagar Android Jetpack Joyride

  2. None
  3. What is Android Jetpack AJ Gandhinagar

  4. What is Jetpack Jetpack is a collection of Android software

    components to make it easier for you to develop great Android apps
  5. Source: d.android.com/jetpack Who uses Jetpack smartly

  6. Benefits of Jetpack d.android.com/jetpack Gandhinagar - Accelerate development - Eliminate

    boilerplate code - Build high quality, robust apps
  7. None
  8. Data Binding Life Cycles LiveData Navigation Paging Room ViewModel WorkManager

    AppCompat Android KTX Multidex Test Animations & Transitions Auto TV & Wear Emoji Fragment Layout Palette Download Manager Media & Playback Permissions Notifications Sharing Slices
  9. Gandhinagar

  10. Navigation

  11. Navigation

  12. Let’s start with code

  13. //app.gradle dependencies { implementation 'android.arch.navigation:navigation-fragment-ktx:1.0.0-alpha06' implementation 'android.arch.navigation:navigation-ui-ktx:1.0.0-alpha06' } Navigation

  14. //activity_main.xml <?xml version="1.0" encoding="utf-8"?> <android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent"

    tools:context=".MainActivity"> <fragment android:id="@+id/my_nav_host_fragment" android:name="androidx.navigation.fragment.NavHostFragment" android:layout_width="match_parent" android:layout_height="match_parent" app:defaultNavHost="true" app:navGraph="@navigation/nav_graph" /> </android.support.constraint.ConstraintLayout> Navigation
  15. Navigation //MainActivity.kt myButton.setOnClickListener { view.findNavController().navigate(R.id.action_first_to_second) }

  16. Navigation //nav_graph.xml <?xml version="1.0" encoding="utf-8"?> <navigation xmlns:android="http://schemas.android.com/apk/res/android"> </navigation>

  17. Navigation

  18. Navigation enterAnim: the animation for the target fragment/activity when we

    navigate to it exitAnim: the animation for the source fragment/activity when we navigate away from it popEnterAnim: the animation for the target fragment/activity when we press back popExitAnim: the animation for the source fragment/activity when we press back
  19. End Main components of Room

  20. Let’s start with code

  21. //app.gradle implementation "android.arch.persistence.room:runtime:1.1.1" annotationProcessor "android.arch.persistence.room:compiler:1.1.1" // Lifecyles, LiveData and ViewModel

    implementation "android.arch.lifecycle:runtime:1.1.1" implementation "android.arch.lifecycle:extensions:1.1.1" annotationProcessor "android.arch.lifecycle:compiler:1.1.1" Room //Movie.kt @Entity(tableName = TABLE_MOVIE) data class Movie(@PrimaryKey val id: Long, val title: String, val popularity: Int, val voteAverage: Int, val posterUrl: String, val description: String)
  22. //MoviesDao @Dao interface MoviesDao { @Insert(onConflict = OnConflictStrategy.REPLACE) fun insert(movieList:

    List<Movie>) @Query(SELECT_MOVIE) fun allMovies(): DataSource.Factory<Int, Movie> } Room
  23. //MoviesDatabase @Database(entities = [Movie::class], version = DATABASE_MOVIE_VERSION) abstract class MoviesDatabase

    : RoomDatabase() { abstract fun movieDao(): MoviesDao companion object { @Volatile private var INSTANCE: MoviesDatabase? = null fun getInstance(context: Context): MoviesDatabase = INSTANCE ?: synchronized(this) { INSTANCE ?: buildMoviesDatabase(context).also { INSTANCE = it } } private fun buildMoviesDatabase(context: Context) = Room.databaseBuilder(context,MoviesDatabase::class.java, DATABASE_MOVIE) .build() } } Room
  24. Main components of Paging

  25. Let’s start with code

  26. //MoviesRepository fun fetchOrGetMovies() : Observable<PagedList<Movie>> = RxPagedListBuilder (moviesRoomDataSource.getMovies(), PAGE_SIZE) .setBoundaryCallback(PageListMovieBoundaryCallback(

    moviesRemoteDataSource, moviesRoomDataSource)) .buildObservable() Paging
  27. //MoviesViewModel class MoviesViewModel(private val moviesRepository: MoviesRepository) : ViewModel() { private

    val compositeDisposable = CompositeDisposable() var pagedListMovie = MutableLiveData<PagedList<Movie>>() fun getMovies() { compositeDisposable.add(moviesRepository.fetchOrGetMovies() .subscribe({ pagedListMovie.value = it }, { it.printStackTrace() })) } override fun onCleared() { super.onCleared() compositeDisposable.dispose() } } Paging
  28. Paging //MainActivity.kt view!!.findViewById<RecyclerView>(R.id.movies_recycler).adapter = moviePagedListAdapter moviesViewModel.pagedListMovie.observe(this, Observer<PagedList<Movie>> { moviePagedListAdapter.submitList(it) })

  29. Paging

  30. End d.android.com/guide/background WorkManager

  31. Let’s start with code

  32. // creating instance WorkManager workManager = WorkManager.getInstance(); WorkManager // how

    to use it WorkRequest request = new OneTimeWorkRequest.Builder(FooWorker.class).build(); workManager.enqueue(request); LiveData<WorkStatus> status = workManager.getStatusByIdLiveData(request.getId()); status.observe(...); //How to cancel workManager.cancelWorkById(request.getId()); // Can also add chain WorkRequest request1 = new OneTimeWorkRequest.Builder(FooWorker.class).build(); WorkRequest request2 = new OneTimeWorkRequest.Builder(BarWorker.class).build(); WorkRequest request3 = new OneTimeWorkRequest.Builder(BazWorker.class).build(); workManager.beginWith(request1, request2).then(request3).enqueue();
  33. WorkManager PeriodicWorkRequest OneTimeWorkRequestBuilder WorkContinuation Constraints

  34. Architecture http://d.android.com/arch - Navigations - Room - Paging - WorkManger

  35. Gandhinagar

  36. End Palette

  37. Let’s start with code

  38. Palette //App gradle implementation 'com.android.support:palette-v7:28.0.0' // Our class // Generate

    palette synchronously and return it fun createPaletteSync(bitmap: Bitmap): Palette = Palette.from(bitmap).generate() // Generate palette asynchronously and use it on a different // thread using onGenerated() fun createPaletteAsync(bitmap: Bitmap) { Palette.from(bitmap).generate { palette -> // Use generated instance } }
  39. UI - Palette

  40. Gandhinagar

  41. Slices A “slice” is a way to surface your app’s

    UI inside of the Google Assistant as a result of a search. Some advantages using Slices API: - Templated - Interactive
  42. Slices Slices

  43. Let’s start with code

  44. Slices //app.gradle implementation 'androidx.slice:slice-core:1.0.0' implementation 'androidx.slice:slice-builders:1.0.0'

  45. Slices //MySliceProvider.java public class MySliceProvider extends SliceProvider { @Override public

    boolean onCreateSliceProvider() { return true; } public Slice onBindSlice(Uri sliceUri) { switch(sliceUri.getPath()) { case "/temperature": return createTemperatureSlice(sliceUri); } return null; } @Nullable private Slice createTemperatureSlice(Uri sliceUri) { // TODO: complete in a later step. return null; } }
  46. Slices //manifest.xml <application ... <!-- To provide slices you must

    define a slice provider --> <provider android:authorities="com.android.example.slicecodelab" android:name=".MySliceProvider" android:exported="true"> </provider> ... </application>
  47. Slices //MySliceProvider.java private Slice createTemperatureSlice(Uri sliceUri) { // Construct our

    parent builder ListBuilder listBuilder = new ListBuilder(getContext(), sliceUri, ListBuilder.INFINITY); // Construct the builder for the row ListBuilder.RowBuilder temperatureRow = new ListBuilder.RowBuilder(listBuilder); // Set title temperatureRow.setTitle(MainActivity.getTemperatureString(getContext())); // TODO: add actions to row; in later step // Add the row to the parent builder listBuilder.addRow(temperatureRow); // Build the slice return listBuilder.build(); }
  48. Make interactive slices //MySliceProvider.java SliceAction tempUp = new SliceAction(getChangeTempIntent(MainActivity.sTemperature +

    1), IconCompat.createWithResource(getContext(), R.drawable.ic_temp_up), "Increase temperature"); SliceAction tempDown = new SliceAction(getChangeTempIntent(MainActivity.sTemperature - 1), IconCompat.createWithResource(getContext(), R.drawable.ic_temp_down), "Decrease temperature");
  49. Behaviour Slices

  50. Gandhinagar

  51. Android KTX And last but not least, one goal of

    Android Jetpack takes advantage of Kotlin language features that make you more productive.
  52. Let’s start with code

  53. Android KTX view.viewTreeObserver.addOnPreDrawListener( object : ViewTreeObserver.OnPreDrawListener { override fun onPreDraw():

    Boolean { viewTreeObserver.removeOnPreDrawListener(this) actionToBeTriggered() return true } });
  54. Android KTX view.doOnPreDraw{actionToBeTriggered()}

  55. Foundation Android KTX

  56. Q&A Gandhinagar

  57. Gandhinagar Thank you! Krunal Kapadiya Volansys @krunal3kapadiya
