1. Moby Project Kunal Kushwaha ( @kunalkushwaha )
2. Agenda - Story of Moby Project - Building Blocks (Foundation) of Moby - runC, - containerD, - LinuxKit - Demo - Docker with Kubernetes (Moby with Kubernetes) - What else in Moby Project.
3. Story of Moby
4. Start Of Container Revolution
5. Escalated quickly all over globe
6. Some amazing products started
7. Conflict of thoughts
8. Communities
9. Docker CE Docker EE @ Docker Inc
10. Essentially all were reinventing the wheel
11. Moby Project An open framework to assemble specialized container systems without reinventing the wheel. It provides a “lego set” of dozens of standard components and a framework for assembling them into custom platforms.
12. Moby Project An open framework to assemble specialized container systems without reinventing the wheel. It provides a “lego set” of dozens of standard components and a framework for assembling them into custom platforms.
13. Building Blocks of Moby
14. runC : Low level container runtime CLI tool for spawning and running containers according to the OCI specification - Client implemented as wrapper around libcontainer (OS level interfaces) - Requires rootfs and config.json
15. runC : Low level container runtime CLI tool for spawning and running containers according to the OCI specification - Client implemented as wrapper around libcontainer (OS level interfaces) - Requires rootfs and config.json Main functionalities provided by runC - Create - Start - Exec - Pause & Resume - Checkpoint - Restore
16. runC : cli example kunal@dev-box:~/demo/alpine-bundle$ ls config.json rootfs kunal@dev-box:~/demo/alpine-bundle$ sudo runc run test / # uname -a Linux runc 4.8.0-59-generic #64-Ubuntu SMP Thu Jun 29 19:38:34 UTC 2017 x86_64 Linux / # exit
17. runC : go client. - go-runc : a golang client implementation of runc - github.com/containerd/go-runc import runc “github.com/containerd/go-runc” . . func main() { . status, err := runc.Run(ctx, “test”, alpineBundlePath, &runc.CreateOpts{}) . }
18. runC Limitations - Do not prepare rootfs or manage image for creating container. - Running container in background, requires extra work (I/O handling through socket) - Attaching External Volume or Networks needs to be done by hand. (using Hooks) - Not portable to other platforms. (platform specific implementation)
19. Container : High level container runtime An industry-standard container runtime. - Simplicity - Robustness - Portability
20. Container : High level container runtime An industry-standard container runtime. - Simplicity - Robustness - Portability - Design - Usage (~25 loc to manage container) - Snapshotter vs Graph Storage - Multi-tenancy
21. Container : High level container runtime An industry-standard container runtime. - Simplicity - Robustness - Portability - Design - Usage (~25 loc to manage container) - Snapshotter vs Graph Storage - Multi-tenancy - Version 1.0.0 released (API Freeze) - Tested against k8s CRI testsuite (cri-containerd) - Supported for atleast 1 year
22. Container : High level container runtime An industry-standard container runtime. - Simplicity - Robustness - Portability - Design - Usage (>25 loc to create container) - Snapshotter vs Graph Storage - Multi-tenancy - Version 1.0.0 released - Tested against k8s CRI testsuite (cri-containerd) - Supported for atleast 1 year - Works on Windows & Linux - Works with any OCI complaint runtime - Batteries included but replaceable.
23. Container design ( OCI )
24. Container - Code examples import “github.com/containerd/containerd” . func main() { . // Create Client client, err := containerd.New(“/run/containerd/containerd.sock”) . // Pull Image image, err := client.Pull(ctx, alpine, containerd.WithPullUnpack) // New Container container, err := client.NewContainer(ctx, id, containerd.WithNewSpec(oci.WithImageConfig(image), containerd.WithNewSnapshot(id, image)) // New Task task, err := container.NewTask(ctx, cio.Stdio) // Start Task err := task.Start(ctx) // Wait for Task completion status, err := task.Wait(ctx) } Working Example code: https://goo.gl/RiKKBS
25. container Namespaces - Provides the isolation to all containerd resources - Images, Containers, Metadata etc. - I.e. Multi-tenancy : Multiple consumers can use same daemon without conflict of their resources. - No need of DIND or Nested Containers. - Still shares underneath immutable resources like image cache etc. - Shall not be considered this isolation from security point of view. import “github.com/containerd/containerd/namespaces” func main() { ctx := namespaces.WithNamespace(context.Background(), “demo”) client.XXX(ctx, ...) }
26. Container Misc - ctr is CLI client for containerd. - Not officially supported, for debugging purpose only - Debug/Profile - pprof data for daemon : /run/containerd/debug.sock - Example usage: github.com/kunalkushwaha/cri-containerd-flame/tree/powertest-flamegraph - Fork from Brain Goff (@cpuguy83) work. cri-containerd-flame - Metrics - Prometheus format of martrics - 127.0.0.1:1234 (Default) - External testing tools. - Bucketbench - Container runtime benchmarking tool. - Ctr-powertest - Container runtime testsuite
27. Container Usecases - Not restricted to orchestrators only. - Cri-containerd : Kubernetes CRI implementation. - Docker CE : Soon. - Linuxkit : for running system and user containers. - Buildkit: Uses to build each layer of cache to build container image. - RancherOS: Soon. (for running system and user containers) - Others - Integrating containerized traditional app with existing management layers. - Products like Balena can be made very quickly without forking projects.
28. LinuxKit LinuxKit, a toolkit for building custom , minimal, immutable Linux distributions - Built with containers for running containers. - Secure defaults - Completely stateless , but persistent storage can be attached. - Everything is replaceable and customizable. - Used to build Docker CE and distro like Docker with K8s.
29. LinuxKit - Input - Consumes yaml file. - Most of defined in yaml is docker image. - Kernel - Init - Onboot - Services - Exceptions: files can be created. - Trust can be defines image should be signed auth. kernel: image: linuxkit/kernel:4.9.68 cmdline: "console=tty0 console=ttyS0 console=ttyAMA0" init: - linuxkit/init:9250948d0de494df8a811edb3242b4584057cfe4 - linuxkit/runc:abc3f292653e64a2fd488e9675ace19a55ec7023 - linuxkit/containerd:e58a382c33bb509ba3e0e8170dfaa5a100504c5b onboot: - name: dhcpcd image: linuxkit/dhcpcd:0d59a6cc03412289ef4313f2491ec666c1715cc9 command: ["/sbin/dhcpcd", "--nobackground", "-f", "/dhcpcd.conf", "-1"] services: - name: getty image: linuxkit/getty:22e27189b6b354e1d5d38fc0536a5af3f2adb79f env: - INSECURE=true trust: org: - linuxkit
30. LinuxKit - Output - Ramfs + bootloader | ISO | format specific to platform - Local hypervisors - HyperKit (macOS) - Hyper-V (Windows) - qemu (macOS, Linux, Windows) - VMware (macOS, Windows) - Cloud based platforms: - Amazon Web Services - Google Cloud - Microsoft Azure - OpenStack - Packet.net - Baremetal: - x86 and arm64 servers on packet.net - Raspberry Pi Model 3b
31. LinuxKit - Output - Ramfs + bootloader | ISO | format specific to platform - Local hypervisors - HyperKit (macOS) - Hyper-V (Windows) - qemu (macOS, Linux, Windows) - VMware (macOS, Windows) - Cloud based platforms: - Amazon Web Services - Google Cloud - Microsoft Azure - OpenStack - Packet.net - Baremetal: - x86 and arm64 servers on packet.net - Raspberry Pi Model 3b Platform(VM/Baremetal) Kernel Init (runc, containerd) Services (as containers) Applications (as containers)
32. LinuxKit Not only build ISO, but can also boot systems - Tool to build bootable formats for different platforms - Cli tools to boot and run the built system. - Can push the images to Cloud Platform(VM/Baremetal) Kernel Init (runc, containerd) Services (as containers) Applications (as containers) USAGE: linuxkit [options] COMMAND Commands: build Build an image from a YAML file metadata Metadata utilities pkg Package building push Push a VM image to a cloud or image store run Run a VM image on a local hypervisor or remote cloud version Print version information help Print this message
33. Demo
34. BuildKit LibEntitlement Current Status
35. Followup Blog : https://blog.mobyproject.org/ Github :https://github.com/moby
36. Thank you.
