Iron ore interpretation using gravity-gradient inversions in the Carajás, Brazil

Transcript

1. Iron ore interpretation
   using gravity-gradient inversions
   in the Carajás, Brazil
   Dionisio Uendro Carlos
   Leonardo Uieda*
   Yaoguo Li
   Valéria Cristina Ferreira Barbosa
   Marco Antonio Braga
   Glauco Angeli
   Guilherme Gravina Peres


   View Slide

2. Carajás survey area


   View Slide

3. View Slide

4. View Slide

5. View Slide

6. N1
   plateau


   View Slide

7. N1
   plateau
   Target: hematite
   hard (3.6 g/cm3)
   soft (3.4 g/cm3)


   View Slide

8. N1
   Survey
   System: FTG
   Line spacing: 150 m
   Height: 100 m
   Total survey: ~550 km


   View Slide

9. The data


   View Slide

10. Gzz
    N1 geology


    View Slide

11. Gzz
    N1 geology


    View Slide

12. 3D inversion


    View Slide

13. 2 methods
    Li, Y. (2001), 3-D inversion of gravity gradiometer data, SEG
    Expanded Abstracts, 20, 1470–1473, doi:10.1190/1.1816383
    Uieda, L., and V. C. F. Barbosa (2012), Robust 3D gravity
    gradient inversion by planting anomalous densities, Geophysics,
    77(4), G55–G66, doi:10.1190/geo2011-0388.1
    (1) Planting anomalous densities
    (2) Smooth inversion


    View Slide

14. Planting anomalous densities


    View Slide

15. Observed data
    Mesh


    View Slide

16. Zero
    density contrast


    View Slide

17. Seeds
    (user specified)
    Predicted data


    View Slide

18. Neighbors


    View Slide

19. The best
    New predicted data


    View Slide

20. The best
    New predicted data
    φ=
    √∑
    i=1
    N
    (g
    i
    −d
    i
    )2
    min of Γ=φ+μθ
    and
    compactness


    View Slide

21. The best
    New predicted data


    View Slide

22. View Slide

23. View Slide

24. View Slide

25. View Slide

26. View Slide

27. View Slide

28. View Slide

29. View Slide

30. Fit


    View Slide

31. Smooth inversion


    View Slide

32. Mesh


    View Slide

33. min φ( p)=φ
    d
    +μ φ
    p


    View Slide

34. min φ( p)=φd
    +μφp
    Densities


    View Slide

35. min φ( p)=φd
    +μφp
    Densities Data misfit


    View Slide

36. min φ( p)=φd
    +μφp
    Densities Data misfit
    Smoothness + depth weights


    View Slide

37. min φ( p)=φd
    +μφp
    subject a⩽ p⩽b
    Densities Data misfit
    Smoothness + depth weights


    View Slide

38. True model
    Recovered


    View Slide

39. Different methods
    • Different approaches
    • Different constraints
    • Common data
    • Common target


    View Slide

40. Inversion parameters
    • Gzz component = 9,053 obs
    • Cell size = 75 m
    – Planting = 581,440 cells
    – Smooth = 1,520,960 cells (larger mesh)


    View Slide

41. Seeds
    45 seeds


    View Slide

42. Results


    View Slide

43. View Slide

44. View Slide

45. Smooth
    Planting


    View Slide

46. Smooth
    Planting


    View Slide

47. Cross-section


    View Slide

48. Smooth


    View Slide

49. Smooth
    Hematite


    View Slide

50. Smooth
    Hematite
    Jaspilite


    View Slide

51. Planting anomalous densities


    View Slide

52. Conclusions
    • Joint interpretation
    • Preliminary results
    • Compatible solutions
    • Agree with boreholes
    • Concentrated above 300 m
    • Bellow 200 m could be jaspilite
    – Same density contrast


    View Slide

53. Acknowledgements
    Colorado School of Mines, USA
    Observatório Nacional, Brazil
    Vale S.A.
