The Art of Incremental Stream Processing

Purely functional, elegant, correct, incremental and composable stream processing that is CPU and memory efficient. This is our (worthy) goal, but where do we start?

This problem space is being extensively explored across a variety of languages and libraries, each with subtly different trade-offs and not-so subtly different APIs and terminology. However, these libraries share common goals, and most share common ancestry from Oleg Kiselyov's original Iteratee work or its Free Monad based derivatives.

This talk aims to build up an intuition for stream processing in general by first building up the core concepts and language of stream processing, and then grounding those by carefully examining the trade-offs and internals of several productionised implementations. Of particular interest are the pipes and conduits libraries from the Haskell community, and scalaz-stream from the Scala community.

Transcript

1. Incremental
   The Art of
   Stream
   Processing
   @markhibberd


   View Slide

2. I have a problem


   View Slide

3. View Slide

4. ~150k Emails


   View Slide

5. ~4GB Emails


   View Slide

6. 100s of new email / day


   View Slide

7. ~5 I want to Read


   View Slide

8. ~2 I want to Reply To


   View Slide

9. Messages delivered where
   and when I need them


   View Slide

10. Ability to locate important
    messages from days past


    View Slide

11. From oleg-at-okmij.org Thu Sep 18 23:51:59 2008
    To: haskell-cafe@haskell.org
    Subject: Lazy vs correct IO [Was: A round of golf]
    Message-ID: <20080919065159.616A5AF09@Adric.metnet.fnmoc.navy.mil>
    Date: Thu, 18 Sep 2008 23:51:59 -0700 (PDT)
    Status: OR
    !
    Lennart Augustsson wrote
    !
    > main = do
    > name:_ <- getArgs
    > file <- readFile name
    > print $ length $ lines file
    !
    Given the stance against top-level mutable variables, I have not
    expected to see this Lazy IO code. After all, what could be more against
    the spirit of Haskell than a `pure' function with observable side
    effects. With Lazy IO, one indeed has to choose between correctness
    and performance. The appearance of such code is especially strange
    after the evidence of deadlocks with Lazy IO, presented on this list
    less than a month ago. Let alone unpredictable resource usage and
    reliance on finalizers to close files (forgetting that GHC does not
    guarantee that finalizers will be run at all).
    !
    Is there an alternative?


    View Slide

12. From oleg-at-okmij.org Thu Sep 18 23:51:59 2008
    To: haskell-cafe@haskell.org
    Subject: Lazy vs correct IO [Was: A round of golf]
    Message-ID: <20080919065159.616A5AF09@Adric.metnet.fnmoc.navy.mil>
    Date: Thu, 18 Sep 2008 23:51:59 -0700 (PDT)
    Status: OR
    !
    Lennart Augustsson wrote
    !
    > main = do
    > name:_ <- getArgs
    > file <- readFile name
    > print $ length $ lines file
    !
    Given the stance against top-level mutable variables, I have not
    expected to see this Lazy IO code. After all, what could be more against
    the spirit of Haskell than a `pure' function with observable side
    effects. With Lazy IO, one indeed has to choose between correctness
    and performance. The appearance of such code is especially strange
    after the evidence of deadlocks with Lazy IO, presented on this list
    less than a month ago. Let alone unpredictable resource usage and
    reliance on finalizers to close files (forgetting that GHC does not
    guarantee that finalizers will be run at all).
    !
    Is there an alternative?


    View Slide

13. Zeitgeist


    View Slide

14. !
    13 find "$MAILDIR" -type f | \
    14 xargs -n 1 stat -f "%m|%N" | \
    15 sort -n | \
    16 cut -d '|' -f 2 | \
    17 xargs grep -l "$QUERY" | \
    18 head -5 | \
    19 xargs less


    View Slide

15. !
    5 data Email =
    6 Email { date :: Int, content :: String }
    7 deriving (Show, Eq)
    8
    9 search :: String -> [Email] -> [Email]
    10 search term =
    11 take 5
    12 . filter (isInfixOf term . content)
    13 . sortBy (compare `on` date)


    View Slide

16. Reality Calling


    View Slide

17. Use mmap(2) instead of read(2)
    to read input, which can result
    in better performance under
    some circumstances but can
    cause undefined behaviour. ”
    “--mmap
    — $(man grep)


    View Slide

18. !
    275 struct file *
    276 grep_open(const char *path)
    277 {
    278 struct file *f;
    279
    280 f = grep_malloc(sizeof *f);
    281 memset(f, 0, sizeof *f);
    282 if (path == NULL) {
    283 /* Processing stdin implies --line-buffered.
    284 */
    285 lbflag = true;
    286 f->fd = STDIN_FILENO;
    287 } else if ((f->fd = open(path, O_RDONLY)) == -
    288 1)
    289 goto error1;
    290
    291 if (filebehave == FILE_MMAP) {
    292 struct stat st;
    293
    294 if ((fstat(f->fd, &st) == -1) || (st.st_size >
    295 OFF_MAX) ||
    296 (!S_ISREG(st.st_mode)))
    297 filebehave = FILE_STDIO;
    298 else {
    299 int flags = MAP_PRIVATE | MAP_NOCORE |
    300 MAP_NOSYNC;
    301 #ifdef MAP_PREFAULT_READ
    302 flags |= MAP_PREFAULT_READ;
    303 #endif
    304 fsiz = st.st_size;
    305 buffer = mmap(NULL, fsiz, PROT_READ, flags,
    306 f->fd, (off_t)0);
    307 if (buffer == MAP_FAILED)
    308 filebehave = FILE_STDIO;
    309 else {
    310 bufrem = st.st_size;
    311 bufpos = buffer;
    312 madvise(buffer, st.st_size, MADV_SEQUENTIAL)
    313 ;
    314 }
    315 }
    316 }
    317
    318 if ((buffer == NULL) || (buffer == MAP_FAILED))
    319 buffer = grep_malloc(MAXBUFSIZ);
    320
    321 if (filebehave == FILE_GZIP &&
    322 (gzbufdesc = gzdopen(f->fd, "r")) == NULL)
    323 goto error2;
    324
    325 #ifndef WITHOUT_BZIP2
    326 if (filebehave == FILE_BZIP &&
    327 (bzbufdesc = BZ2_bzdopen(f->fd, "r")) ==
    328 NULL)
    329 goto error2;
    330 #endif
    331
    332 /* Fill read buffer, also catches errors early
    333 */
    334 if (bufrem == 0 && grep_refill(f) != 0)
    335 goto error2;
    336
    337 /* Check for binary stuff, if necessary */
    338 if (binbehave != BINFILE_TEXT && memchr(bufpos,
    339 '\0', bufrem) != NULL)
    340 f->binary = true;
    341
    342 return (f);
    343
    344 error2:
    345 close(f->fd);
    346 error1:
    347 free(f);
    348 return (NULL);
    349 }
    350
    351


    View Slide

19. “With Lazy IO, one indeed has
    to choose between correctness
    and performance.”
    — Oleg Kiselyov


    View Slide

20. !
    5 type Maildir =
    6 FilePath
    7
    8 data Email =
    9 Email { date :: Int, content :: String }
    10 deriving (Show, Eq)
    11
    12 search :: String -> Maildir -> IO [Email]
    13 search term =
    14 {— oh noes! It’s so horrible
    15 I can’t even show it -}


    View Slide

21. Is there an alternative?


    View Slide

22. Intuition 1: A Language


    View Slide

23. I Need To Produce Values


    View Slide

24. !
    1 type In i
    !
    !
    !


    View Slide

25. I Need To Consume Values


    View Slide

26. !
    1 type In i
    2
    3 type Out o
    !
    !
    !


    View Slide

27. I Need To Transform Values


    View Slide

28. !
    1 type In i
    2
    3 type Out o
    4
    5 data Pipeline i o
    !
    !
    !


    View Slide

29. I May Have Effects


    View Slide

30. !
    1 type In i m
    2
    3 type Out o m
    4
    5 data Pipeline i o m
    !
    !
    !


    View Slide

31. I May Compute A Value


    View Slide

32. !
    1 type In i m a
    2
    3 type Out o m a
    4
    5 data Pipeline i o m a
    !
    !
    !


    View Slide

33. A (Simple) Interface


    View Slide

34. !
    1 type In i m a = Pipeline i () m a
    2
    3 type Out o m a = Pipeline Void o m a
    4
    5 data Pipeline i o m a
    !
    !
    !


    View Slide

35. !
    1 type In i m a = Pipeline i () m a
    2
    3 type Out o m a = Pipeline Void o m a
    4
    5 data Pipeline i o m a
    6 = Done a
    7 | Yield o (Pipeline i o a)
    8 | Await (i -> Pipeline i o a)


    View Slide

36. Intuition 2: Pipelines


    View Slide

37. Prepare Classify Deliver
    Poll


    View Slide

38. Prepare Classify Deliver
    Poll


    View Slide

39. Prepare Classify Deliver
    Poll
    Mail


    View Slide

40. Prepare Classify Deliver
    Poll
    Mail


    View Slide

41. Prepare Classify Deliver
    Poll
    Mail
    Features


    View Slide

42. Prepare Classify Deliver
    Poll
    Features


    View Slide

43. Prepare Classify Deliver
    Poll
    Features
    Scores


    View Slide

44. Prepare Classify Deliver
    Poll
    Scores


    View Slide

45. Prepare Classify Deliver
    Poll
    :: In Mail :: Pipeline Mail Features :: Out Scores
    :: Pipeline Features Scores


    View Slide

46. Getting Real


    View Slide

47. !
    1 data Proxy i' i o' o m a
    2
    3 type Producer i m a = Proxy X () () o m a
    4 type Consumer o m a = Proxy () i () X m a
    5 type Pipe i o m a = Proxy () i () o m a
    Pipes
    !
    1 type In i m a
    2
    3 type Out o m a
    4
    5 type Pipeline i o m a


    View Slide

48. !
    1 data Proxy i' i o' o m a
    2
    3 type Producer i m a = Proxy X () () o m a
    4 type Consumer o m a = Proxy () i () X m a
    5 type Pipe i o m a = Proxy () i () o m a
    Pipes
    Explicit Input and Output
    at Each Component


    View Slide

49. !
    1 data Proxy i' i o' o m a
    2
    3 type Producer i m a = Proxy X () () o m a
    4 type Consumer o m a = Proxy () i () X m a
    5 type Pipe i o m a = Proxy () i () o m a
    Pipes
    Effects On Producers,
    Consumers And Pipes


    View Slide

50. !
    1 data Proxy i' i o' o m a
    2
    3 type Producer i m a = Proxy X () () o m a
    4 type Consumer o m a = Proxy () i () X m a
    5 type Pipe i o m a = Proxy () i () o m a
    Pipes
    Can Terminate With A
    Value Anywhere In Pipeline


    View Slide

51. 1 data Pipe l i o u m r
    2
    3 newtype ConduitM i o m r =
    4 ConduitM { unConduitM :: Pipe i i o () m r }
    5
    6 type Source m o = ConduitM () o m ()
    7 type Sink i m a = ConduitM i Void m a
    8 type Conduit i m o = ConduitM i o m ()
    Conduit
    !
    1 type In i m a
    2
    3 type Out o m a
    4
    5 type Pipeline i o m a


    View Slide

52. 1 data Pipe l i o u m r
    2
    3 newtype ConduitM i o m r =
    4 ConduitM { unConduitM :: Pipe i i o () m r }
    5
    6 type Source m o = ConduitM () o m ()
    7 type Sink i m a = ConduitM i Void m a
    8 type Conduit i m o = ConduitM i o m ()
    Conduit
    Explicit Input and Output
    at Each Component


    View Slide

53. 1 data Pipe l i o u m r
    2
    3 newtype ConduitM i o m r =
    4 ConduitM { unConduitM :: Pipe i i o () m r }
    5
    6 type Source m o = ConduitM () o m ()
    7 type Sink i m a = ConduitM i Void m a
    8 type Conduit i m o = ConduitM i o m ()
    Conduit
    Effects On Sources,
    Sinks And Conduits


    View Slide

54. 1 data Pipe l i o u m r
    2
    3 newtype ConduitM i o m r =
    4 ConduitM { unConduitM :: Pipe i i o () m r }
    5
    6 type Source m o = ConduitM () o m ()
    7 type Sink i m a = ConduitM i Void m a
    8 type Conduit i m o = ConduitM i o m ()
    Conduit
    Can Only Terminate With A
    Value On a Sink


    View Slide

55. 1 sealed abstract class Process[F[_],O]
    2
    3 type Process0[O] = Process[Env[_,_]#Is, O]
    4 type Process1[I, O] = Process[Env[I,_]#Is, O]
    5 type Sink[F[_], O] = Process[F, O => F[Unit]]
    Scalaz Streams
    !
    1 type In i m a
    2
    3 type Out o m a
    4
    5 type Pipeline i o m a


    View Slide

56. !
    1 data Process m o
    2
    3 type Process0 o = forall a. Process (Is a) o
    4 type Process1 i o = Process (Is i) o
    5 type Sink m o = Process m (o -> m ())
    Scalaz Streams
    !
    1 type In i m a
    2
    3 type Out o m a
    4
    5 type Pipeline i o m a


    View Slide

57. !
    1 data Process m o
    2
    3 type Process0 o = forall a. Process (Is a) o
    4 type Process1 i o = Process (Is i) o
    5 type Sink m o = Process m (o -> m ())
    Scalaz Streams
    Model Request And Production
    Rather Than Input and Output


    View Slide

58. !
    1 data Process m o
    2
    3 type Process0 o = forall a. Process (Is a) o
    4 type Process1 i o = Process (Is i) o
    5 type Sink m o = Process m (o -> m ())
    Scalaz Streams
    Effects Are Returned As
    Values, Transducers are Pure


    View Slide

59. !
    1 data Process m o
    2
    3 type Process0 o = forall a. Process (Is a) o
    4 type Process1 i o = Process (Is i) o
    5 type Sink m o = Process m (o -> m ())
    6
    7 runFoldMap :: (Monad m, Monoid b) =>
    8 Process m o -> (o -> m b) -> m b
    Scalaz Streams
    Computation of Values
    Modelled Externally


    View Slide

60. Prepare Classify Deliver
    Poll
    :: Producer Mail :: Pipe Mail Features :: Consumer Score
    :: Pipe Features Score
    Pipes


    View Slide

61. Prepare Classify Deliver
    Poll
    :: Source Mail :: Conduit Mail Features :: Sink Score
    :: Conduit Features Score
    Conduit


    View Slide

62. Prepare Classify Deliver
    Poll
    :: Process m Mail :: Process1 Mail Features :: Sink m Score
    :: Process1 Features Score
    Scalaz Stream


    View Slide

63. Horizontal Composition


    View Slide

64. Prepare Classify Deliver
    Poll
    Mail Delivery


    View Slide

65. Prepare Classify Deliver
    Poll
    Mail Delivery


    View Slide

66. Throttle Read
    Scan
    Poll


    View Slide

67. Prepare Classify Deliver
    Poll
    :: In Event :: Pipeline Mail Features :: Out Event
    :: Pipeline Features Score


    View Slide

68. Prepare Classify Deliver
    Poll
    :: In Event :: Pipeline Mail Features :: Out Event
    :: Pipeline Features Score
    (>|) :: Pipeline i o m a -> Pipeline o o’ m a -> Pipeline i o’ m a


    View Slide

69. Prepare Classify Deliver
    Poll
    :: In Event :: Pipeline Mail Features :: Out Event
    :: Pipeline Features Score
    >| >| >|
    :: Pipeline () Void
    (>|) :: Pipeline i o m a -> Pipeline o o’ m a -> Pipeline i o’ m a


    View Slide

70. Prepare Classify Deliver
    Poll
    :: In Event :: Pipeline Mail Features :: Out Event
    :: Pipeline Features Score
    >| >| >|
    eval :: Pipeline () Void m a -> m a
    (>|) :: Pipeline i o m a -> Pipeline o o’ m a -> Pipeline i o’ m a


    View Slide

71. Prepare Classify Deliver
    Poll
    :: Producer Event :: Pipe Mail Features :: Consumer Score
    :: Pipe Features Score
    >-> >-> >->
    Pipes
    :: Effect


    View Slide

72. Prepare Classify Deliver
    Poll
    :: Producer Event :: Pipe Mail Features :: Consumer Score
    :: Pipe Features Score
    >-> >-> >->
    Pipes’
    runEffect :: Effect m a -> m a


    View Slide

73. Prepare Classify Deliver
    Poll
    :: Source Event :: Conduit Mail Features :: Sink Score
    :: Conduit Features Score
    =$= =$= =$=
    Conduit
    :: Source ()


    View Slide

74. Prepare Classify Deliver
    Poll
    :: Source Event :: Conduit Mail Features :: Sink Score
    :: Conduit Features Score
    $= =$= =$
    Conduit’
    :: Source ()


    View Slide

75. Prepare Classify Deliver
    Poll
    :: Source Event :: Conduit Mail Features :: Sink Score
    :: Conduit Features Score
    $= =$= $$
    Conduit’’
    :: m ()


    View Slide

76. Prepare Classify Deliver
    Poll
    :: Process m Event :: Process1 Mail Features :: Sink m Score
    :: Process1 Features Score
    |> |> to
    Scalaz Stream
    :: Process m ()


    View Slide

77. Prepare Classify Deliver
    Poll
    :: Process m Event :: Process1 Mail Features :: Sink m Score
    :: Process1 Features Score
    |> |> to
    Scalaz Stream’
    run :: Process m a -> m ()


    View Slide

78. Is Composition About
    Combinators or Laws?


    View Slide

79. id
    Poll
    id id
    Poll
    Poll


    View Slide

80. Vertical Composition


    View Slide

81. Prepare Classify Deliver
    Poll
    Mail Delivery


    View Slide

82. Throttle Read
    Scan
    Poll


    View Slide

83. Throttle Read
    Scan
    Events


    View Slide

84. Throttle Read
    Scan
    Events


    View Slide

85. Throttle Read
    Scan
    Events
    Events


    View Slide

86. Throttle Read
    Scan
    Events


    View Slide

87. Throttle Read
    Scan
    Events
    Mail


    View Slide

88. Throttle Read
    Work
    Home
    Work Throttle
    2 3
    5


    View Slide

89. Throttle Read
    Work
    Home
    Work Throttle
    1
    5
    3


    View Slide

90. Throttle Read
    Work
    Home
    Work Throttle
    1
    5
    2


    View Slide

91. Throttle Read
    Work
    Home
    Work Throttle
    1
    5
    2


    View Slide

92. Throttle Read
    Work
    Home
    Work Throttle
    0
    5
    2


    View Slide

93. Throttle Read
    Work
    Home
    Work Throttle
    0
    5
    1


    View Slide

94. Throttle Read
    Work
    Home
    Work Throttle
    0
    5
    1
    0


    View Slide

95. Throttle Read
    Home
    Work
    Home Throttle
    Work
    1
    5


    View Slide

96. Throttle Read
    Home
    Work
    Home Throttle
    Work
    1
    4


    View Slide

97. Throttle Read
    Home
    Work
    Home Throttle
    Work
    0
    4


    View Slide

98. Throttle Read
    Home
    Work
    Home Throttle
    Work
    0
    4


    View Slide

99. Throttle Read
    Work
    Home
    Home Throttle
    Work
    3
    4
    Work Throttle


    View Slide

100. Throttle Read
     Work
     Home
     Work Throttle
     Pipes
     :: Producer Event :: Pipe Event Event :: Pipe Event Mail
     >-> >->
     >>=
     forever


     View Slide

101. Throttle Read
     Work
     Home
     Work Throttle
     Conduit
     :: Source Event :: Conduit Event Event :: Conduit Event Mail
     $= =$=
     >>=
     forever


     View Slide

102. Throttle Read
     Work
     Home
     Work Throttle
     Scalaz Stream
     :: Process m Event :: Process1 Event Event :: Process1 Event Mail
     >| >|
     fby
     repeat


     View Slide

103. Intuition 3: Parsers


     View Slide

104. 1 type In i m a = Pipeline i () m a
     2
     3 type Out o m a = Pipeline Void o m a
     4
     5 data Pipeline i o m a
     6 = Done a
     7 | Yield o (Pipeline i o a)
     8 | Await (i -> Pipeline i o a)
     9
     !
     !
     !
     !
     !


     View Slide

105. 1 type In i m a = Pipeline i () m a
     2
     3 type Out o m a = Pipeline Void o m a
     4
     5 data Pipeline i o m a
     6 = Done a
     7 | Yield o (Pipeline i o a)
     8 | Await (i -> Pipeline i o a)
     9
     10 yield :: o -> Pipeline i o m ()
     11 yield = Yield o (Done ())
     12
     13 await :: Pipeline i o m i
     14 await = Await Done


     View Slide

106. 1 one :: Pipeline i i m ()
     2 one = do
     3 i <- await
     4 yield i
     5
     6 cat :: Pipeline i i m ()
     7 cat = forever one
     8
     9 pairs :: Pipeline i (i, i) m ()
     10 pairs = forever $ do
     11 i1 <- await
     12 i2 <- await
     13 yield (i1, i2)
     !


     View Slide

107. !
     1 counter :: Monad m => Pipeline i (Int, i) m ()
     2 counter = flip evalStateT 0 . forever $ do
     3 i <- lift await
     4 n <- get
     5 lift . yield $ (n, i)
     6
     7 filter :: (i -> Bool) -> Pipeline i i m a
     8 filter f = forever $ do
     9 i <- await
     10 when (f i) $ yield i
     !
     !
     !
     !


     View Slide

108. !
     1 yield :: o -> Pipe i o m ()
     2
     3 await :: Pipe i o m i
     !
     1 yield :: o -> ConduitM i o m r
     2
     3 await :: ConduitM i o m (Maybe i)
     4
     5 awaitForever :: (\i -> ConduitM i o m a)
     6 -> ConduitM i o m ()
     !
     1 emit :: o -> Process f o
     2
     3 await1 :: Process1 i i
     Pipes
     Conduit
     Scalaz Stream


     View Slide

109. Subtlety Fights Back


     View Slide

110. Internal vs External
     Management of Resources


     View Slide

111. Layered Streams


     View Slide

112. Constant Memory
     Streaming


     View Slide

113. How much does elegance
     cost?


     View Slide

114. to be continued...
     @markhibberd


     View Slide
