Threat Modeling Toolkit

Threat Modeling Toolkit

Threat Modeling is a great way to analyze security early in software development by structuring possible attacks, bad actors and countermeasures over a broad view of the targeted system. This talk will describe basic components of a threat model and how to use them effectively.

Threat Intelligence is where you gather knowledge about the environment and business assets to determine what are the actual threats. But how do you reconcile that with the current architecture in a useful manner?

The toolkit presented in this talk will enable you to systematically structure related information using graphical notations such as flow diagram and attack tree. In case you are wondering where to start in your organization, a quick lightweight risk rating methodology will also be proposed.

And in the end, you’ll see how we can all tie those together and get threat modeling to a point where it’s an efficient application security activity for communication. Doing this will prevent security reviews from missing important things even when chaos prevails during the realization of a project.

Modeling concepts will be demonstrated with an actual IoT device used as example.

Presentation will be done in english.

Speaker Bio:

Jonathan Marcil is the former chapter leader of OWASP Montreal and is now Senior Application Security Engineer at Blizzard Entertainment in beautiful Orange County, California.

Jonathan has been involved with OWASP for many years and has been behind the Media Project which gathered and promoted AppSec conferences video content in the official OWASP YouTube channel. He was also part of NorthSec CTF event as a challenge designer specialized in Web and imaginative contraptions.

He is passionate about Application Security and enjoys architecture analysis, code review, threat modeling and debunking security tools. He holds a diploma in Software Engineering from ÉTS Montreal and has more than 15 years of experience in Information Technology and Security.

OWASP Montréal

May 23, 2017
Tweet

More Decks by OWASP Montréal

Other Decks in Technology

Transcript

  1. Threat Modeling Toolkit
    by Jonathan Marcil
    OWASP Montreal
    May 2017

    View full-size slide

  2. Summary
    • Who’s that guy again?
    • What is Application Security?
    • What is Threat Modeling?
    • Existing models
    • Toolkit component: Simplified Risk Rating
    • Toolkit component: Attack Tree
    • Toolkit component: Data Flow Diagram
    • What’s next?

    View full-size slide

  3. Who am I?
    • You may remember me from such things as..
    – OWASP Montreal, Chapter Leader 2013-2015
    – NorthSec, Challenge designer 2012-2014
    – LAN ETS, Founder 2002-2008
    • Now living in beautiful Irvine, California
    • Application Security at Blizzard Entertainment

    View full-size slide

  4. My definition of Application Security
    • Mix of
    – A book: Building Security In
    – A standard: ISO/IEC 27034 Application Security
    – A direction: Trustworthy Computing, Microsoft
    • Security Development Lifecycle
    – A collaborative mess: Wikipedia
    • All boils down to one thing…
    – Lifecycle and activities

    View full-size slide

  5. My definition of Application Security

    View full-size slide

  6. What is Threat Modeling?
    • Application Security activity to analyze
    security in software development
    • Systematically structure
    –Attacks
    –Bad Actors
    –Countermeasures

    View full-size slide

  7. Threat Intelligence
    • Is not threat modeling
    – It’s half of it!
    • Threat actors
    – And what they have to gain
    • Knowledge base of threats
    – Modeling is a methodology

    View full-size slide

  8. Threat Modeling: For who? And why?
    • Common method for
    – Security practitioners
    – Software engineers
    • Design Review
    • Clarify what the system is for reviewers
    • Highlight ameliorations or requirements
    • Help to catch important things despite the chaos

    View full-size slide

  9. Modeling must be collaborative
    • Communication is key in a project
    • If you do it alone in a corner
    – You are doing it wrong!
    • You can still start the modeling alone and then
    review the model with stakeholders

    View full-size slide

  10. Existing Models

    View full-size slide

  11. Fresh wisdom: Adam Shostack

    View full-size slide

  12. Fresh wisdom
    Four questions for threat modeling:
    • What are you working on?
    • What can go wrong?
    • What do to about it?
    • Did you do an acceptable job at it?

    View full-size slide

  13. Fresh wisdom for pentesting
    You can map threat classification models with
    the types of tools you are using that might
    help for completeness of your tool selection
    As you nmap, tcpdump, lsof, strace of a
    system you're making a model of a system
    in your head. Why not white board it?

    View full-size slide

  14. Fresh wisdom
    Make sure everyone is thinking about the
    same thing. Whiteboard helps with that.
    Don't use a monolithic process, use blocks
    of different tools that you mix together as
    you use / need them.
    Threat modeling is not one single skill.
    It's multiples techniques (DFD, stride) &
    knowledge repertoire (tools, books).

    View full-size slide

  15. Toolkit Components
    • This is what you came for!
    – At slide #15, not bad..

    View full-size slide

  16. Toolkit component:
    Simplified Risk Rating
    • Risk = Exposure * Impact
    • Impact = [LOW, MED, HIGH]
    • Exposure = [INTERNET, DMZ, INTRANET]
    • Just ask people to rate [1,2,3] for each
    • Multiply, adjust result ±1 and note why
    • That’s it you now have risk rating

    View full-size slide

  17. Toolkit Component: Attack Tree
    • Organize the Threat Intelligence
    • Simple tree
    – Root node is goal
    – Leaf nodes are ways to reach it
    – Other nodes are sub-goals
    • Can be flexible
    – And logic gates

    View full-size slide

  18. Attack Tree: Open Safe

    View full-size slide

  19. Attack Tree: IoT
    • Let’s take an example of a device

    View full-size slide

  20. Trick on drawing: code it instead!
    • PlantUML
    @startuml
    skinparam monochrome true
    agent "Mass mining" as mine
    agent "Mass scan" as scan
    agent "DDoS" as ddos
    agent "Control many devices \n(Botnet)" as botnet
    mine --> botnet
    scan --> botnet
    ddos --> botnet
    agent "Use legit command" as legitcmd
    agent "Exploit device flaws" as flaws
    agent "Obtain device access" as access
    botnet --> legitcmd
    botnet --> flaws
    botnet --> access
    agent "Get WiFi LAN access" as wifi
    agent "Get Physical access" as phys
    agent "Place Factory Backdoor" as factory
    agent "Hack cloud server" as cloud
    access --> wifi
    access --> phys
    access --> factory
    access --> cloud
    agent "Make my life miserable" as life
    agent "Randomware" as ransomware
    agent "Invade my privacy" as privacy
    agent "Mess with the lights" as mess
    life --> ransomware
    life --> privacy
    life --> mess
    agent "View my habits" as habits
    agent "Spy me live" as spy
    privacy --> habits
    privacy --> spy
    agent "Steal cloud data" as data
    habits --> data
    spy --> data
    data ---> cloud
    agent "Sniff network" as sniff
    habits ---> sniff
    spy ---> sniff
    access --> sniff
    sniff --> wifi
    sniff --> phys
    @enduml

    View full-size slide

  21. habits ---> access
    spy ---> access
    PlantUML!

    View full-size slide

  22. Toolkit Component: DFD Diagram
    • Data Flow Diagram
    –Actually, not!
    • Connection Flow Diagram
    –Limit amount of visuals
    –Focus on attack surface/vectors

    View full-size slide

  23. Toolkit Component: DFD diagram
    • Provide a security oriented view of the system
    – Representation of the comprehension
    – It will evolve with understanding or
    design/architecture changes!
    • Not an architecture document
    – Focus on details relevant to security
    – Omit what might be important for engineers

    View full-size slide

  24. Flow Diagram Basic Set
    • Square for actor
    • Circle for process
    – Double circle for multiple processes
    • Arrow for connection flow direction
    • Double line for data store
    – I won’t blame anyone using a cylinder instead
    • Red dotted line for boundary
    • 100% compatible with Microsoft SDL notation

    View full-size slide

  25. Flow Diagram: IoT

    View full-size slide

  26. .
    Mobile
    App
    IoT
    Device

    View full-size slide

  27. .
    Browser
    Mobile
    App
    IoT
    Device

    View full-size slide

  28. .
    Browser
    Mobile
    App
    My Script
    IoT
    Device

    View full-size slide

  29. .
    Web Site
    Cloud
    API
    Browser
    Mobile
    App
    My Script
    IoT
    Device

    View full-size slide

  30. .
    Cloud
    Integration
    Web Site
    Cloud
    API
    Browser
    Mobile
    App
    My Script
    IoT
    Device

    View full-size slide

  31. .
    Cloud
    Integration
    Web Site
    Cloud
    API
    Browser
    Mobile
    App
    My Script
    IoT
    Device
    Local
    API

    View full-size slide

  32. .
    User
    Cloud
    Integration
    Web Site
    Cloud
    API
    Browser
    Mobile
    App
    My Script
    MySQL
    database
    IoT
    Device
    Local
    API

    View full-size slide

  33. .
    User
    Internet
    Cloud
    Integration
    Web Site
    Cloud
    API
    Browser
    Mobile
    App
    My Script
    MySQL
    database
    IoT
    Device
    Local
    API

    View full-size slide

  34. .
    User
    Internet
    Cloud
    Integration
    Web Site
    Cloud
    API
    Browser
    Mobile
    App
    My Script
    MySQL
    database
    IoT
    Device
    Local
    API

    View full-size slide

  35. Flow Diagram Extended Set
    • Tech stack label on circle
    • Sticky notes
    • Table of security controls/mitigations
    – Include label numbers to place on the graph for
    positioning
    • Anything you want!
    – Cloud for abstraction
    – Colors/circles for logical links or special meaning
    – Just keep it visually pleasing and as minimalist as possible

    View full-size slide

  36. .
    User
    Internet
    Cloud
    Integration
    Web Site
    Broadcast
    UPnP?
    Cloud
    API
    HTTPS
    Browser
    Mobile
    App
    My Script
    MySQL
    database
    HTTP
    IoT
    Device
    Local
    API
    HTTP
    HTTPS

    View full-size slide

  37. .
    User
    Internet
    Cloud
    Integration
    Web Site
    Social networks,
    weather data, etc.
    Broadcast
    UPnP?
    Cloud
    API
    HTTPS
    Browser
    Mobile
    App
    My Script
    MySQL
    database
    HTTP
    IoT
    Device
    Local
    API
    HTTP
    HTTPS

    View full-size slide

  38. .
    User
    Internet
    Cloud
    Integration
    Web Site
    PHP
    Social networks,
    weather data, etc.
    Broadcast
    UPnP?
    Cloud
    API
    Node.js
    HTTPS
    Browser
    Mobile
    App
    My Script
    Python MySQL
    database
    HTTP
    IoT
    Device
    Local
    API
    HTTP
    HTTPS

    View full-size slide

  39. .
    REVISED
    2/23/2017
    THREAT MODEL DIAGRAM
    IoT
    DRAWN BY
    [email protected]
    VERSION
    0.2
    User
    Internet
    Cloud
    Integration
    Web Site
    PHP
    Social networks,
    weather data, etc.
    Broadcast
    UPnP?
    Cloud
    API
    Node.js
    HTTPS
    Browser
    Send command
    Mobile
    App
    My Script
    Python MySQL
    database
    HTTP
    IoT
    Device
    Local
    API
    HTTP
    HTTPS
    Periodically HTTP GET
    to the API and receive a
    commands to execute
    There's no
    authentication!

    View full-size slide

  40. Security Controls Checklist
    .
    REVISED
    2/23/2017
    THREAT MODEL DIAGRAM
    IoT
    DRAWN BY
    [email protected]
    VERSION
    0.2
    User
    Internet
    Cloud
    Integration
    Web Site
    PHP
    Social networks,
    weather data, etc.
    Broadcast
    UPnP?
    Cloud
    API
    Node.js
    HTTPS
    1 IoT device read only
    Browser
    Send command
    Utilization of proper framework ORM
    2
    Mobile
    App
    My Script
    Python MySQL
    database
    HTTP
    IoT
    Device
    Local
    API
    HTTP
    HTTPS
    3 Add Authentication and HTTPS
    2
    1
    3
    3
    Periodically HTTP GET
    to the API and receive a
    commands to execute
    There's no
    authentication!

    View full-size slide

  41. Conclusion
    • If you need to review the security of a complex
    system, the connection flow diagram is your tool
    • You can use what you learned to align activities
    • If you try it in a meeting and people end up
    clarifying and/or improve the system while you
    say nothing, you won at threat modeling, bravo!

    View full-size slide

  42. Unified Threat Modeling
    • Link Attack tree to Flow diagram
    – Security controls are the way of mitigating the sub-
    goals and prevent exploitation
    • Link Flow diagram to Security testing
    – Identify and direct tests to components
    • Create Abuse cases and feed the Attack tree
    – To be sure we have all threat actors

    View full-size slide

  43. 1
    2
    3
    Security Controls Checklist
    1 IoT device read only
    Utilization of proper framework ORM
    2
    3 Add Authentication and HTTPS

    View full-size slide

  44. Unified Threat Modeling
    Attack
    Tree
    Flow
    Diagram
    Security
    Testing
    Lessons
    Learned
    Abuse
    Case

    View full-size slide

  45. Thanks
    • OWASP Orange County
    • OWASP Montreal
    • Security Org at Blizzard
    • You!
    @jonathanmarcil
    [email protected]

    View full-size slide
