1. “Who left the lights on?”
   Slides from a workshop presented by Peter Rukavina
   on February 27, 2015 at
   the University of Prince Edward Island, Robertson Library and
   sponsored by ARMA Prince Edward Island Chapter
   These slides are released under a Creative Commons license.
   You are encouraged to distribute them as far and as

   wide as possible under the terms of the license.


   View Slide

2. View Slide

3. Thank You
   • Simon Lloyd for the invitation.
   • Mark Demone for the coordination.
   • Melissa Belvadi, Don Moses, Alkarim Bhalesha and
   Jerrad Gilbert at Robertson Library for digital
   logistics here in the lab.


   View Slide

4. “Who left the lights on?”
   How a government-industry open data partnership
   is driving innovation in the delivery of electricity

   load and generation data to Islanders
   The Apocalyptic Lightbulb Conspiracy by Daniel Hoherd is licensed under CC BY-NC 2.0


   View Slide

5. “Is there a situation in
   which it is beneficial to
   Maritime Electric to have
   consumption drop?”
   Jim Lea, Maritime Electric CEO, replies…
   March 27, 2003, Delta Prince Edward
   Clip from audio recording Maritime Electric Public Information Session by Peter Rukavina, March 27, 2003.


   View Slide

6. Ton Zijlstra from Cognitive Cities Conference is licensed by CC BY-NC-ND 3.0


   View Slide

7. “Who left the lights on?”
   I want to know

   how much electricity PEI is using,
   where it comes from,
   and how much of it is renewable
   The Apocalyptic Lightbulb Conspiracy by Daniel Hoherd is licensed under CC BY-NC 2.0


   View Slide

8. “Who left the lights on?”
   I want to know

   the load,
   the generation,
   and the generation mix
   The Apocalyptic Lightbulb Conspiracy by Daniel Hoherd is licensed under CC BY-NC 2.0


   View Slide

9. “Who left the lights on?”
   I want to have a gut feeling for

   the load,
   the generation,
   and the generation mix
   The Apocalyptic Lightbulb Conspiracy by Daniel Hoherd is licensed under CC BY-NC 2.0


   View Slide

10. “Who left the lights on?”
    I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix
    The Apocalyptic Lightbulb Conspiracy by Daniel Hoherd is licensed under CC BY-NC 2.0


    View Slide

11. Windmill by Stephen Downes is licensed under CC BY-NC 2.0


    View Slide

12. Tools of an Artist by John is licensed under CC BY-NC-SA 2.0


    View Slide

13. Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

14. 100 watts
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

15. 1000 watts
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

16. 1 kilowatt
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

17. 1 kilowatt for one hour =
    1 kilowatt hour
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

18. 1 kilowatt for one hour =
    1 kWh
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

19. Photo by Peter Rukavina.


    View Slide

20. 1 million watts
    x 10,000
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

21. 1 megawatt
    x 10,000
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0


    View Slide

22. 1 MW
    Bulb by Andrew Enright is licensed under CC BY-NC-SA 2.0
    x 10,000


    View Slide

23. 50 MW Diesel
    60 MW Oil
    Screen shot from Google Maps “Earth” view taken February 26, 2015. Map data © 2015 Google.


    View Slide

24. Tools of an Artist by John is licensed under CC BY-NC-SA 2.0


    View Slide

25. HTML
    • HyperText Markup Language
    • Describes the “contents” of the web
    • The “markup” adds meaning to text, like “make this
    a big title”:



    Who left the lights on?
    • On any page on the web, you can “View Source” to
    see the HTML of the page


    View Slide

26. https://thimble.webmaker.org/


    View Slide

27. CSS
    • Cascading Style Sheets
    • Describes the “look” of the web
    • Defines how HTML will appear in the browser
    • Like “make all the big titles” red:



    h1 {

    color: red;

    }


    View Slide

28. JavaScript
    • The “programming language” of the web
    • Supported by almost all web browsers
    • Allows “interactive stuff” to happen in the browser
    • Simple and easy to learn, like:



    var temp_c = 0;

    var temp_f = temp_c * 1.8 + 32;


    View Slide

29. View Slide

30. View Slide

31. var temp_c = 100;

    var temp_f = temp_c * 1.8 + 32;

    temp_f


    View Slide

32. http://jsfiddle.net/


    View Slide

33. Add jQuery


    View Slide

34. HTML


    View Slide

35. JavaScript


    View Slide

36. CSS


    View Slide

37. http://l.ruk.ca/temp-convert


    View Slide

38. JSON
    • JavaScript Object Notation
    • A lingua franca for passing data around the web.
    • The “fat-free alternative to XML”
    • Very easily used by JavaScript because it’s a
    subset of the way objects are represented in
    JavaScript.


    View Slide

39. Some JSON
    {
    firstname: "Peter",
    lastname: "Rukavina",
    telephone: "902-628-8544"
    }


    View Slide

40. [
    {
    "street_num": 32,
    "street_nm": "RIVERVIEW CR",
    "comm_nm": "VERNON BRIDGE",
    "county": "QUN",
    "latitude": 46.17488,
    "longitude": -62.8834
    },
    {
    "street_num": 11,
    "street_nm": "PEMBROKE CR",
    "comm_nm": "STRATFORD",
    "county": "QUN",


    View Slide

41. The Web of JSON
    • “Web pages” don’t need to be (only) human-
    readable
    • Open data on the web works best when…
    • it’s simply attached to a URL
    • it’s in an easily-manipulated format
    • it’s easy to understand


    View Slide

42. http://www.electionspei.ca/
    api/
    provincial/
    districts/
    index.php?
    street_nm=PRINCE&
    street_no=100


    View Slide

43. {
    "addresses_found": 1,
    "addresses": [
    {
    "district": {
    "name": "Charlottetown - Victoria Park",
    "returningofficer": {
    "firstname": "Amy",
    "lastname": "Doyle",
    "street": "25 Cumberland St.",
    "city": "Charlottetown",
    "phone": "892-0846"
    },
    "number": "12",
    "url": {
    "html": "http:\/\/www.electionspei.ca\/
    provincial\/districts\/district12",
    "xml": "http:\/\/www.electionspei.ca\/
    xml\/provincial\/districts\/district12"
    }


    View Slide

44. http://l.ruk.ca/json-holland


    View Slide

45. http://l.ruk.ca/json-holland


    View Slide

46. View Slide

47. {
    "type": "FeatureCollection",
    "crs": { "type": "name", "properties":
    { "name": "urn:ogc:def:crs:OGC:
    1.3:CRS84" } },
    "features": [
    { "type": "Feature", "properties": { "LOT":
    "GEORGETOWN", "AREA": 0.001879, "PERIMETER":
    0.297538 }, "geometry": { "type": "Polygon",
    "coordinates": [ [ [ -62.572620405028403,
    46.199679527058578 ], [ -62.580760470484037,
    46.219434133419306 ], [ -62.579024444158172,
    46.219831688011375 ], [ -62.577552427247561,
    46.219943190658306 ], [ -62.576511573647167,
    46.219610925737399 ], [ -62.575648113478202,
    46.218968914354932 ], [ -62.573996965015965,
    46.218782798817166 ], [ -62.573314930094163,


    View Slide

48. View Slide

49. View Slide

50. View Slide

51. Powered by GeoJSON


    View Slide

52. View Slide

53. View Slide

54. Windmill by Stephen Downes is licensed under CC BY-NC 2.0


    View Slide

55. I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix


    View Slide

56. Richard Brown
    Minister of Environment, Energy and Forestry
    Photo of Richard Brown from Liberal Party of Prince Edward Island


    View Slide

57. Ron Estabrooks
    Energy Advisor with the PEI Energy Corporation
    Photo of Ron Estabrooks taken at the open house to officially launch the Hermanville/Clearspring wind development from www.gov.pe.ca.


    View Slide

58. Still from Ton Zijlstra from Cognitive Cities Conference is licensed by CC BY-NC-ND 3.0


    View Slide

59. Ron Estabrooks
    Energy Advisor with the PEI Energy Corporation
    Photo of Ron Estabrooks taken at the open house to officially launch the Hermanville/Clearspring wind development from www.gov.pe.ca.


    View Slide

60. I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix


    View Slide

61. RTOs and ISOs
    • Regional Transmission Organization or
    Independent System Operator
    • Organizations that manage the electricity network
    • Like the “switchboards” for the electricity network,
    which has been called “most complex machine
    ever devised by man.”
    • For PEI the network is managed by the NBSO: the
    New Brunswick System Operator


    View Slide

62. View Slide

63. http://l.ruk.ca/nbso-web


    View Slide

64. NBSO as HTML


    View Slide

65. Tools of an Artist by John is licensed under CC BY-NC-SA 2.0


    View Slide

66. Open, but Not Enough
    • It’s “open” but it’s not “open enough”
    • There’s not enough structure to the data, especially
    if I want to use it with other tools (to archive it, to
    graph it, etc.)
    • Solution: convert the HTML into JSON.


    View Slide

67. http://l.ruk.ca/nbso-convert


    View Slide

68. {
    "NB-Load": "2272",
    "NB-Demand": "2353",
    "ISO-NE": "493",
    "NMISA": "31",
    "HYDRO-QUEBEC": "-945",
    "NOVA-SCOTIA": "0",
    "PEI": "165"
    }
    http://l.ruk.ca/nsbo-json


    View Slide

69. I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix


    View Slide

70. Pachube + SoundCloud Mashup by Peter Rukavina licensed under CC BY 3.0


    View Slide

71. I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix


    View Slide

72. Clip of audio from CBC Spark interview with Peter Rukavina by Nora Young, recorded June 19, 2011.


    View Slide

73. “Closed” Data from
    Charlottetown


    View Slide

74. “Closed” Data from

    Cornwall


    View Slide

75. “Closed” Data from

    Stratford
    Town of Stratford Building Permit Summary 7/1/2013 to 7/31/2013
    Applicant Estimated Development
    Date PermitID Applicant Name Phone # PID Lot# Address Permit Type Project Value Permit Fee
    JUL-15-2013 DP078-13 Robert Gaudet 902-367-6129 932111 171 6 Carrington Road Accessory Building - New $1,200.00 $30.00
    JUL-25-2013 DP056-13 Stratford Quickstop 1044494 1 Jubilee Drive Accessory Building - New $11,000.00 $100.00
    Sub Totals: $12,200.00 $130.00
    JUL-05-2013 DP072-13 Rosemary Scott 902-569-3021 728188 135 33 Celtic Lane Accessory Structure (Pool, Deck, etc) - $800.00 $30.00
    Addition
    JUL-16-2013 DP077-13 Kent Building Supply - 329375 154 Spinnaker Drive Accessory Structure (Pool, Deck, etc) - $5,000.00 $30.00
    Andrew Sanderson Addition
    Sub Totals: $5,800.00 $60.00
    JUL-26-2013 DP085-13 Richard E. Woodfield 902-367-3637 1010693 7 Picton Beete Cr Accessory Structure (Pool, Deck, etc) - $3,000.00 $30.00
    New
    JUL-12-2013 DP076-13 Jamie Doiron 902-629-0224 486118 14 Towerwood Drive Accessory Structure (Pool, Deck, etc) - $3,000.00 $30.00
    New
    JUL-03-2013 DP039-13 Chris and Jennifer 902-569-2114 471508 10 Aintree Drive Accessory Structure (Pool, Deck, etc) - $6,000.00 $30.00
    Whitlock New
    JUL-30-2013 DP016-13 Craig and Jennifer 902-566-1801 1014638 93 Bonavista Avenue Accessory Structure (Pool, Deck, etc) - $25,000.00 $30.00
    Lawlor New
    JUL-15-2013 DP062-13 Drew and Karen 902-894-3959 1029180 22 Saints Crescent Accessory Structure (Pool, Deck, etc) - $50,000.00 $30.00
    MacIntyre New
    Sub Totals: $87,000.00 $150.00
    JUL-31-2013 DP059-13 Craftsman 940650 11 Galway Court Single Family Dwelling - Addition $18,000.00 $56.80
    Construction
    JUL-05-2013 DP071-13 Roger Johnson 902-569-4882 709154 73 Rankin Drive Single Family Dwelling - Addition $40,000.00 $114.40
    JUL-10-2013 DP070-13 Greenleaf Construction 902-566-3358 603613 1 2 Battery Point Drive Single Family Dwelling - Addition $150,000.00 $43.68
    Sub Totals: $208,000.00 $214.88
    JUL-25-2013 DP081-13 D.C. McCardle 902-367-9200 398586 70 77 Southampton Drive Single Family Dwelling - New $180,000.00 $458.20
    JUL-18-2013 DP079-13 D.C. McCardle Ltd 902-367-9200 398586 72 85 Southampton Dr Single Family Dwelling - New $200,000.00 $469.40
    JUL-30-2013 DP084-13 Barry MacDonald 1045749 13 11 Donegal Lane Single Family Dwelling - New $300,000.00 $1,187.60
    Thursday, August 01, 2013 Town of Stratford Building Permit Summary 7/1/2013 to 7/31/2013 Page 1 of 2


    View Slide

76. What if I want to…


    View Slide

77. What if I want to…


    View Slide

78. Windmill by Stephen Downes is licensed under CC BY-NC 2.0


    View Slide

79. I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix


    View Slide

80. Richard Brown
    Minister of Environment, Energy and Forestry
    Photo of Richard Brown from Liberal Party of Prince Edward Island


    View Slide

81. Ron Estabrooks
    Energy Advisor with the PEI Energy Corporation
    Photo of Ron Estabrooks taken at the open house to officially launch the Hermanville/Clearspring wind development from www.gov.pe.ca.


    View Slide

82. View Slide

83. 60 MW from oil
    50 MW from diesel
    39 MW from diesel
    200 MW
    from cables
    11 MW
    from oil
    12 MW from wind
    30 MW from wind
    30 MW from wind
    99 MW
    from wind
    23 MW
    from wind


    View Slide

84. Generation Mix
    • 194 MW (maximum) from wind energy
    • 160 MW from local fossil fuel generators
    • 200 MW from submarine cables


    View Slide

85. Peak Load 220 MW


    View Slide

86. I want everyone to have a gut feeling for

    the load,
    the generation,
    and the generation mix


    View Slide

87. “Can we get real-time
    data on load and
    generation?”


    View Slide

88. (one year passes)


    View Slide

89. Yes!


    View Slide

90. http://l.ruk.ca/pei-wind


    View Slide

91. Tools of an Artist by John is licensed under CC BY-NC-SA 2.0


    View Slide

92. View Slide

93. View Slide

94. http://l.ruk.ca/pei-json


    View Slide

95. PEI as JSON
    [
    {
    "data1": 210.15,
    "data2": 139.22,
    "data3": 7.98,
    "data4": 82.02,
    "data5": 57.2,
    "updateDate": 1424875441,
    "error": 0
    }
    ]


    View Slide

96. http://e.ruk.ca/pei-json


    View Slide

97. PEI as (Better) JSON
    {
    "on-island-load": 210.15,
    "on-island-wind": 139.22,
    "on-island-fossil": 7.98,
    "wind-local": 82.02,
    "wind-export": 57.2,
    "percentage-wind": "66.25"
    }


    View Slide

98. http://l.ruk.ca/pei-fiddle


    View Slide

99. View Slide

100. http://l.ruk.ca/pei-archive


     View Slide

101. http://l.ruk.ca/pei-graph


     View Slide

102. View Slide

103. View Slide

104. “I have become slightly obsessed by your
     energy graph and am very grateful that you have
     found a way to record the load and wind power
     generated in PEI. Do you by any chance have a
     spread sheet of these values? I am looking at
     using storage to balance wind fluctuations and
     was hoping to try and using the real load and
     wind data to accomplish that.”


     View Slide

105. http://pei.consuming.ca/


     View Slide

106. View Slide

107. View Slide

108. I want everyone to have a gut feeling for

     the load,
     the generation,
     and the generation mix


     View Slide

109. Windmill by Stephen Downes is licensed under CC BY-NC 2.0


     View Slide

110. View Slide

111. I want everyone to have a gut feeling for

     whether it’s a
     good time to use electricity or not


     View Slide

112. View Slide

113. “PEI Energy Thingy”
     • Uses a Raspberry Pi, an inexpensive, web-
     connected, touch-screen computer
     • Uses the JSON version of the PEI load and
     generation data
     • Provides simple feedback:

     red - bad time to use energy (no wind, fossil)

     yellow - average time to use energy

     green - good time to use energy (high wind)


     View Slide

114. Maritime Electric
     www.gov.pe.ca
     energy.reinvented.net
     SCADA
     (proprietary)
     JSON
     (open)
     JSON
     (more open)
     red,
     yellow or
     green


     View Slide

115. http://innovis.cpsc.ucalgary.ca/


     View Slide

116. http://innovis.cpsc.ucalgary.ca/


     View Slide

117. I want to have a gut feeling for

     my own load
     “From MW to KW”


     View Slide

118. Social Consumption Project
     • Can we measure household electricity usage in
     real time?
     • Can we display this usage information to people in
     the house?
     • Can we use social pressures and a feeling of
     competition to motivate a decrease in
     consumption?


     View Slide

119. Tools of an Artist by John is licensed under CC BY-NC-SA 2.0


     View Slide

120. View Slide

121. Meter Type 8
     Itron Brand
     Serial Number
     Current Reading
     (in kWh)


     View Slide

122. My Electricity Meter
     • Broadcasts its current reading by radio in the

     900 MHz range.
     • This broadcast is in the clear (not encrypted).
     • Anyone in range of the meter can receive the
     readings.


     View Slide

123. View Slide

124. My Water Meter
     • Broadcasts its current reading by radio in the

     900 MHz range.
     • This broadcast is in the clear (not encrypted).
     • Anyone in range of the meter can receive the
     readings.


     View Slide

125. View Slide

126. Grid Insight AMRUSB-1
     • An inexpensive (< $100) USB stick containing a
     radio receiver capable of reading and decoding
     electricity and water meter readings.
     • The readings can be processed by almost any
     computer, including a Raspberry Pi.


     View Slide

127. View Slide

128. Windmill by Stephen Downes is licensed under CC BY-NC 2.0


     View Slide

129. Social Consumption Project
     • Can we measure household electricity usage in
     real time?
     • Can we display this usage information to people in
     the house?
     • Can we use social pressures and a feeling of
     competition to motivate a decrease in
     consumption?
     and water!
     ^


     View Slide

130. View Slide

131. Social Consumption Project
     • Five Charlottetown test households.
     • Equipped with water and electricity meters and
     wireless Internet.
     • Households okay with sharing their consumption
     data with others in the test group and with the
     public.


     View Slide

132. Web Database


     View Slide

133. http://l.ruk.ca/scp-table


     View Slide

134. http://l.ruk.ca/scp-compare


     View Slide

135. http://l.ruk.ca/scp-peter


     View Slide

136. http://consuming.ca/


     View Slide

137. View Slide

138. Social Consumption Project
     • Can we measure household electricity usage in
     real time?
     • Can we display this usage information to people
     in the house?
     • Can we use social pressures and a feeling of
     competition to motivate a decrease in
     consumption?


     View Slide

139. Tools of an Artist by John is licensed under CC BY-NC-SA 2.0


     View Slide

140. Node-RED


     View Slide

141. What is Node-RED?
     • A visual “drag and drop” way of wiring together
     devices and data.
     • No programming required.
     • Runs locally on your computer, and is accessed
     using a web browser on your computer.
     • The Social Consumption Project Raspberry Pi
     computers use it to read and upload electricity and
     water meter data to the web.


     View Slide

142. Fire up Node-RED


     View Slide

143. Fire up Node-RED
     cd /usr/local/nodered/node-red-0.10.3
     node red


     View Slide

144. Fire up Node-RED
     127.0.0.1:1880


     View Slide

145. View Slide

146. Add an inject node


     View Slide

147. View Slide

148. Configure it


     View Slide

149. Add a http request node


     View Slide

150. View Slide

151. http://e.ruk.ca/pei-json


     View Slide

152. Wire the nodes together


     View Slide

153. Add a debug node


     View Slide

154. Click Deploy


     View Slide

155. Click the Inject trigger


     View Slide

156. See the magic happen…


     View Slide

157. Add a json node


     View Slide

158. Add a template node


     View Slide

159. Add a switch node


     View Slide

160. Add 2 template nodes


     View Slide

161. Add 2 template nodes


     View Slide

162. Add a debug node


     View Slide

163. The Flow


     View Slide

164. Click Deploy


     View Slide

165. Click the Inject trigger


     View Slide

166. See the magic happen…


     View Slide

167. Social Consumption Project


     View Slide

168. View Slide

169. Windmill by Stephen Downes is licensed under CC BY-NC 2.0


     View Slide

170. I want everyone to have a gut feeling for

     the load,
     the generation,
     and the generation mix
     I want everyone to have a gut feeling for

     whether it’s a
     good time to use electricity or not
     I want to have a gut feeling for

     my own load
     ✔
     ✔
     ✔


     View Slide

171. Open Data

     Guiding Principles
     • You can’t anticipate what citizens will use your
     open data for (maybe they will make music from
     electricity).
     • Reduce as many barriers as possible to easy,
     painless access to data: find the right format(s) and
     put the data right on the web, with a URL.
     • “Eat your own dogfood” – develop systems that
     consume you own open data.


     View Slide

172. Still from Ton Zijlstra from Cognitive Cities Conference is licensed by CC BY-NC-ND 3.0
     Be the one public servant
     in the blue shirt…


     View Slide
