Hacking Neos - How to extend and customize Neos and Flow - InspiringCon 2016

This presentation has given by Christian Müller and Sebastian Kurfürst @InspiringCon 2016 in Kolbermoor.

Transcript

1. Hacking Neos Christian Müller Sebastian Kurfürst
2. Sebastian Kurfürst @skurfuerst
4. Christian Müller @daskitsunet
6. intentionally left blank
7. Text here.
11. planned unplanned
12. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
14. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
15. Custom ViewHelpers PHP use TYPO3\Fluid\Core\ViewHelper\AbstractTagBasedViewHelper;

 class ExternalViewHelper extends AbstractTagBasedViewHelper
 { }
16. Views.yaml Yaml -
 requestFilter: 'isPackage("TYPO3.Neos") && isFormat("html")'
 options:
 partialPathAndFilename: 'resource://Neos.MarketPlace/Private/Partials/'

17. Type Converters PHP {
 "image": {
 "__identity": "6aac7ce2-b2e1-4e20-6987-42daa4edfbd2",
 "width": 742
 }
 } Image Object
18. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
19. HTTP Components PHP TYPO3:
 Flow:
 http:
 chain:
 'process':
 chain:
 'customCode':
 position: 'start'
 component: 'My\Own\HttpComponent'
20. Check the Flow Settings.yaml PHP Exception Handler Logger Doctrine Filters Custom Database Mapping Types Resource Handling Authentication Providers
21. TYPO3:

 Flow:

 aop:

 # Registers global objects to be evaluated for dynamic pointcut expressions
 globalObjects:

 securityContext: TYPO3\Flow\Security\Context

 compatibility:

 uriBuilder:

 # A compatibility flag that affects the behavior of the UriBuilder when creating relative URIs:
 # TRUE: The UriBuilder creates relative path like "some/path", a base tag is required in the respective HTML head
 # FALSE: The UriBuilder prefixes the path with the scripts request path: "/document/root/some/path", no base tag will be required
 #
 # NOTE: This flag will be obsolete with version 2.2 and removed in version 3.0 of Flow
 createRelativePaths: FALSE

 core:

 # Flow's application context
 # This setting is automatically set by the configuration manager and can't be set manually.
 context: ''

 # Key of the "main" package of the application. This package's meta data is used for displaying the application
 # name, version etc. in the ./flow command line help and where else needed.
 applicationPackageKey: 'TYPO3.Flow'

 # Path and filename of the PHP binary
 # The constant PHP_BINDIR usually contains the path, but on Windows this doesn't work reliably
 phpBinaryPathAndFilename: '%PHP_BINDIR%/php'

 # optional list of variables (key: value) that will be set for all Flow CLI sub requests
 subRequestEnvironmentVariables: []

 # Set which php.ini file should be used for the CLI sub requests.
 # If not set (that is value equals NULL) the php.ini file of the executing process (usually the web server's) is used.
 # If set to a path and filename, the specified php.ini file is loaded.
 # If set to boolean FALSE, Flow does not try to specify any php.ini file to the sub process.
 subRequestPhpIniPathAndFilename: NULL

 # optional list of INI entries (entry: value) to set for all Flow CLI sub requests.
 # This equals to the -d argument of the php CLI
 # Example:
 # subRequestIniEntries:
 # 'date.timezone': 'UTC'
 subRequestIniEntries: []

 error:

 exceptionHandler:

 # Defines the global, last-resort exception handler.
 # The specified class must implement \TYPO3\Flow\Error\ExceptionHandlerInterface
 className: TYPO3\Flow\Error\ProductionExceptionHandler

 # default options for all rendering groups (see below). Options can be overridden in the respective rendering group
 defaultRenderingOptions:
 renderTechnicalDetails: FALSE
 logException: TRUE

 # Rendering groups can define special renderings depending on status code or class of the
 # thrown exception.
 renderingGroups:

 notFoundExceptions:
 matchingStatusCodes: [404]
 options:
 logException: FALSE
 templatePathAndFilename: 'resource://TYPO3.Flow/Private/Templates/Error/Default.html'
 variables:
 errorDescription: 'Sorry, the page you requested was not found.'

 databaseConnectionExceptions:
 matchingExceptionClassNames: ['TYPO3\Flow\Persistence\Doctrine\Exception\DatabaseException']
 options:
 templatePathAndFilename: 'resource://TYPO3.Flow/Private/Templates/Error/Default.html'
 variables:
 errorDescription: 'Sorry, the database connection couldn''t be established.'

 errorHandler:

 # Defines which errors should result in an exception thrown - all other error
 # levels will be silently ignored. Only errors that can be handled in an
 # user-defined error handler are affected, of course.
 exceptionalErrors: ['%E_USER_ERROR%', '%E_RECOVERABLE_ERROR%']

 debugger:

 # List of regular expressions classes are matched against in the debugger
 # to prevent them from being expanded.
 ignoredClasses:
 'TYPO3\\Flow\\Aop.*': TRUE
 'TYPO3\\Flow\\Cac.*': TRUE
 'TYPO3\\Flow\\Core\\.*': TRUE
 'TYPO3\\Flow\\Con.*': TRUE
 'TYPO3\\Flow\\Http\\RequestHandler': TRUE
 'TYPO3\\Flow\\Uti.*': TRUE
 'TYPO3\\Flow\\Mvc\\Routing.*': TRUE
 'TYPO3\\Flow\\Log.*': TRUE
 'TYPO3\\Flow\\Obj.*': TRUE
 'TYPO3\\Flow\\Pac.*': TRUE
 'TYPO3\\Flow\\Persistence\\(?!Doctrine\\Mapping).*': TRUE
 'TYPO3\\Flow\\Pro.*': TRUE
 'TYPO3\\Flow\\Ref.*': TRUE
 'TYPO3\\Flow\\Sec.*': TRUE
 'TYPO3\\Flow\\Sig.*': TRUE
 'TYPO3\\Flow\\.*ResourceManager': TRUE
 'TYPO3\\Fluid\\.*': TRUE
 '.+Service$': TRUE
 '.+Repository$': TRUE
 'PHPUnit_Framework_MockObject_InvocationMocker': TRUE

 mvc:
 # Defines routes that should be included after existing routes defined in the main Routes.yaml (if any)
 # Note: This only allows to include existing Routes.yaml files from other packages, you can't adjust the routes via Settings.
 #
 # Syntax:
 # 'Some.Package': TRUE
 # 'SomeOther.Package':
 # position: 'after Some.Package'
 #
 routes: []

 http:
 # Defines an explicit base URI that should be used. This affects
 # resource management, routing and all other parts accessing
 # "Http\Request->getBaseUri()".
 #
 # If this setting is NULL, the base URI will be detected from the current
 # request (default).
 baseUri: NULL

 # Defines the workflow of one request from bootstrap to the HTTP response
 #
 # By default this workflow is devided in three sub-chains "preprocess", "process" and "postprocess" but the chain can be restructured as needed
 #
 chain:

 'preprocess':
 position: 'before process'
 chain: []

 'process':
 chain:
 'routing':
 position: 'start'
 component: 'TYPO3\Flow\Mvc\Routing\RoutingComponent'
 'dispatching':
 component: 'TYPO3\Flow\Mvc\DispatchComponent'

 'postprocess':
 chain:
 'standardsCompliance':
 position: 'end'
 component: 'TYPO3\Flow\Http\Component\StandardsComplianceComponent'

 log:

 # Settings for Flow's default loggers
 systemLogger:
 logger: TYPO3\Flow\Log\Logger
 backend: TYPO3\Flow\Log\Backend\FileBackend
 backendOptions:
 logFileURL: '%FLOW_PATH_DATA%Logs/System.log'
 createParentDirectories: TRUE
 severityThreshold: '%LOG_INFO%'
 maximumLogFileSize: 10485760
 logFilesToKeep: 1
 logMessageOrigin: FALSE

 securityLogger:
 backend: TYPO3\Flow\Log\Backend\FileBackend
 backendOptions:
 logFileURL: '%FLOW_PATH_DATA%Logs/Security.log'
 createParentDirectories: TRUE
 severityThreshold: '%LOG_INFO%'
 maximumLogFileSize: 10485760
 logFilesToKeep: 1
 logIpAddress: TRUE

 sqlLogger:
 backend: TYPO3\Flow\Log\Backend\FileBackend
 backendOptions:
 logFileURL: '%FLOW_PATH_DATA%Logs/Query.log'
 createParentDirectories: TRUE
 severityThreshold: '%LOG_INFO%'
 maximumLogFileSize: 10485760
 logFilesToKeep: 1

 i18nLogger:
 backend: TYPO3\Flow\Log\Backend\FileBackend
 backendOptions:
 logFileURL: '%FLOW_PATH_DATA%Logs/I18n.log'
 createParentDirectories: TRUE
 severityThreshold: '%LOG_INFO%'
 maximumLogFileSize: 1048576
 logFilesToKeep: 1

 i18n:

 # The default locale identifier.
 defaultLocale: en

 # The fallback rule to use for locale resolution
 fallbackRule:
 # Strictly use the defined order (without implicit locale fallback)
 strict: FALSE
 # The locales identifiers to use in their desired order
 order: []

 object:

 # If enabled, the Object Manager will - additionally to the class files found
 # in the "Classes" directory - also register class files found in the directory
 # "Tests/Functional/". Enabling this feature obviously only makes sense in a
 # testing context.
 registerFunctionalTestClasses: FALSE

 # Explicitly include classes to object management (Reflection and Configuration building).
 # Sequence of package keys with an array of regular expressions.
 # The package key must match the key found in PackageStates.php regarding case.
 #
 # Each regular expression will be tested against the list of fully qualified
 # class names in the package and classes will be included if matching.
 #
 # For Flow packages (type = "typo3-flow-*") this setting is not required as they're
 # reflected by default. You can however exclude specific (or all) classes from Flow packages
 # by specifying corresponding regular expressions that don't match classes to exclude.
 #
 # Note: The previous setting "excludeClasses" has been deprecated with Flow 3.0
 includeClasses: []

 package:

 # This can be used to make packages inactive, even though they would be
 # activated automatically otherwise.
 inactiveByDefault:
 - 'neos.composerplugin'
 - 'Composer.Installers'
 # Option for the PackageManager::Create to map the packagesPath by package type
 packagesPathByType:
 'typo3-flow-package': 'Application'
 'typo3-flow-framework': 'Framework'

 persistence:

 # Options for the default Doctrine persistence
 backendOptions:
 driver: 'pdo_mysql'
 host: '127.0.0.1'
 dbname: NULL
 user: NULL
 password: NULL
 charset: 'utf8'
 cacheAllQueryResults: FALSE

 doctrine:
 # By default Doctrine proxy compilation is done in the Flow bootstrap
 enable: TRUE
 sqlLogger: NULL
 filters:
 Flow_Security_Entity_Filter: 'TYPO3\Flow\Security\Authorization\Privilege\Entity\Doctrine\SqlFilter'

 # DBAL custom mapping types can be registered here
 dbal:
 mappingTypes:
 'flow_json_array':
 dbType: 'json_array'
 className: 'TYPO3\Flow\Persistence\Doctrine\DataTypes\JsonArrayType'
 'objectarray':
 dbType: 'array'
 className: 'TYPO3\Flow\Persistence\Doctrine\DataTypes\ObjectArray'

 # Doctrine ORM Lifecycle events and their subscribers and listeners.
 # See Flow manual, chapter "Persistence" for further information on how to subscribe to Doctrine events.
 eventSubscribers: []
 eventListeners: []

 reflection:

 # A list of tags to be ignored during reflection

22. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
23. Signals / Slots PHP /**
 * @Flow\Signal
 */
 public function emitObjectUpdated($object)
 { // method filled automatically by AOP (see later.)
 }
24. Observer
25. Replace Interface Implementations PHP
26. Modify Object Configuration PHP
27. Factories
28. Change Injections PHP
30. Aspect-Oriented Programming PHP /**
 * @Flow\Aspect
 */
 class PluginUriAspect
31. Inject Interfaces
32. Add Properties
33. Modify Methods
34. Upcoming: Add Traits
36. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
38. Description Kite Support Win a Kite Kite Support Sign up How to find serial number
39. main (ContentCollection) support (Page) SignUp (Form) KiteSupport (Text) sidebar (ContentCollection) FindSerialNumbers (Image) WinAKite (Text) Node Tree
40. support (Page) Node Type
41. Node References
42. NodeTypes YAML
44. Plugins PHP
46. Node Implementations PHP
47. Node Node Node Node Node Custom Node Node Custom Node
48. Node Migrations PHP
49. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
50. TypoScript
51. TypoScript Objects PHP AbstractTypoScriptObject AbstractArrayTypoScriptObject public function evaluate()
52. Eel Helpers PHP ${Search.query(site).nodeType('TYPO3.Neos:Plugin').execute()}
53. Flow Framework Content Repository Custom Packages Rendering Engine Neos User Interface Media (Images, ...) MVC / Fluid HTTP Object Management / Dependency Injection / Aspect Oriented Programming
54. Text here.
55. Text here.
56. Text here.
57. Adapt Rendering if in Backend Template <f:if condition="{neos:rendering.inBackend()}"> </f:if>
58. Data Sources PHP
60. class MySource extends AbstractDataSource implements DataSourceInterface { protected static $identifier = ‘your-datahandler-identifier’; public function getData( NodeInterface $node = null, array $arguments) { // Implementation follows here } }
61. Custom Editors JS
63. Backend Events JS
64. Custom Backend Modules PHP
66. Questions?
67. Thank you!
