  1. What is WireGuard?
    The modern UDP-based VPN running on ESP32
    May 4, 2023
    #M5JPTour2023 Tokyo
    Welcome (back) Jimmy-san!!
    Kohei MATSUSHITA “Max” / @ma2shita
    Tech. Evangelist at SORACOM, INC.

    View Slide

  2. Tech. Evangelist at SORACOM, INC.
    Kohei Matsushita "Max"
    Evangelizing IoT and SORACOM,
    with over 500 presentations.
    SORACOM provides the IoT platform.
    ➢ Global connectivity for IoT with SIM and Sigfox
    in 160+ countries and territories.
    ➢ Including IoT applications and device management.

    View Slide

  3. Conclusion
    What is WireGuard?
    ➢ The modern UDP-based VPN.
    ➢ Running on many environment, including ESP32.
    ➢ Lightweight footprint and load than TLS.

    View Slide

  4. Oh! NOT enough flash memory?
    Raw MQTT
    MQTT + TLS
    A small code that just only MQTT Push (about 140 lines) including TLS. But…
    Only 402KB remains. Usage is 70%!!
    AWS IoT Core
    Modern SaaS/PaaS.

    View Slide

  5. We DON’T want to use TLS.
    But we need to encrypt with Internet access.
    What do we do? 🤔

    View Slide

  6. はやい、イケてる、安全なVPN
    https://www.wireguard.com/
    ✓ UDP-based.
    ✓ Running on many.
    ✓ Lightweight.

    View Slide

  7. Implementation for lwIP(Lightweight IP stack)
    https://github.com/smartalock/wireguard-lwip

    View Slide

  8. I tweeted. Then…
    https://speakerdeck.com/ciniml/esp32desoracom-arctunaidemita?slide=4
    After 5 days, implementation for
    Arduino core for the ESP32.
    @ciniml has the hand of GOD!!

    View Slide

  9. WireGuard in 3 steps!
    #include
    static WireGuard wg;
    char private_key[] = "{[Interface] PrivateKey from server}";
    IPAddress local_ip(192, 168, 200, 254); // [Interface] Address from server
    char public_key[] = "{[Peer] PublicKey} from server";
    char endpoint_address[] = "{[Peer] Endpoint from server}";
    int endpoint_port = 11010;
    configTime(9 * 60 * 60, 0, "ntp.jst.mfeed.ad.jp", "ntp.nict.jp", "time.google.com");
    delay(3000); // Wait for adjust
    wg.begin(local_ip, private_key, endpoint_address, public_key, endpoint_port);
    Connecting in setup() / 3 lines
    Configure in header / 7 lines
    Import
    1
    2
    3
    Listed in the official repository
    Don't forget to set the time.
    Set value retrieved
    from WireGuard server
    https://github.com/ciniml/WireGuard-ESP32-Arduino

    View Slide

  10. Reduce usage in Flash memory than TLS
    0
    100,000
    200,000
    300,000
    400,000
    500,000
    600,000
    700,000
    800,000
    900,000
    MQTT+TLS MQTT+WireGuard 【参考】MQTTのみ
    Flash memory usage
    MQTT+TLS MQTT+WireGuard 【参考】MQTTのみ
    It’s L3 VPN.
    So upper layer/protocol
    is free.
    ESP32(M5Stack Basic)上でWireGuardを使用したMQTT実装サンプル
    https://qiita.com/ma2shita/items/0f0dce8ff0e45cf9fbac
    Different angle:
    VPN can be added for only
    +30KB to Raw MQTT
    implementation
    -141KB
    +30KB
    +L3 VPN

    View Slide

  11. Excellent portability
    Prepare:
    • Connection is Wi-Fi.
    • WireGuard connection established.
    Start:
    • Ping.
    Next:
    • Connection is changed to cellular.
    (Means the IP address changes.)
    Finally:
    • Continued ping success.
    (Packet loss during changing.)
    IP address independent VPN
    It’s modern!

    View Slide

  12. How do we prepare the server?
    Build with Linux Box
    ➢ WireGuard merged on Linux kernel 5.6
    ➢ Raspberry Pi is easy to set up with pivpn.io
    ➢ CM4Stack, too!!
    Full-managed WireGuard server “SORACOM Arc”
    ➢ Launched in 2021/6. It has free tier.
    ➢ Available via Wi-Fi access.
    ➢ Services for IoT on SORACOM are also available, too.
    ➢ e.g.) Remote access service for SSH, etc. on demand.

    View Slide

  13. Have any concerns?
    ➢ Security? Cipher strength?
    ➢ Throughput? Latency? Load on MCU?
    ➢ UDP?
    Let see my blog!
    Don't worry,
    I'm writing “日本語”.
    https://blog.soracom.com/ja-jp/2023/02/16/what-is-wireguard

    View Slide

  14. Conclusion
    What is WireGuard?
    ➢ The modern UDP-based VPN.
    ➢ Running on many environment, including ESP32.
    ➢ Lightweight footprint and load than TLS.
    Let’s embed to your M5/ESP32, NOW!!
    And I looking for maintainers

    View Slide

  15. Will WireGuard work with ?
    I’m not sure, maybe. Welcome challenger!!

    View Slide
