Worldsemi(NeoPixel) 2022/July Product list

Only for current version,
Some spec such as Need Capacior is also only for current version. Some old version hardware(but same product name) is different. Please ask for offical web site.
http://www.world-semi.com/

あくまで最新バージョンのものだけを対象にしています。ここでキャパシタ不要となっているものなども、古いバージョンのハードウェアでは必要なものもあります。
質問は
http://www.world-semi.com/

Transcript

1. View Slide

2. Part 1-About Us
   ► 1.Brief Introduction
   ► 2.Manufacturing Base
   ► 3.Worldsemi Timeline
   ► 4.Corporate Culture
   ► 5.Patent&Qualification
   ► 6.Equipment &Production Workshop
   Part 2-Main Products
   ► 1.IC&New Products Series
   ► 2.Digital LED Series
   ► 3.LED Strip&PCBA
   ► 4.LED RGBIC Fairy String
   ► 5.LED Controller
   Part 3-Case Gallery
   ► 1.Products Applications, Main Partners&Major Customers
   CONTENTS


   View Slide

3. About Worldsemi
   WorldSemi was founded in 2007, we work as the leading LED specialist in IC
   designer for Constant Current LED Driver IC, Chip Driver LED, we are
   recognized as the product development and delivery of LED lighting industry
   leader and we’ve expanded offerings to inclusion of LED strip lights, LED
   point lights and LED controllers etc. As the original manufacturer of WS28xx
   series products (WS2801S, WS2811, WS2812, WS2812B, WS2813,
   WS2815,WS2816,WS2818....), WorldSemi with its advanced equipment, first-
   rate technical staff, and strict quality management system and the high-quality
   service to customers’ trust and support. WorldSemi team believes that high
   performance, super quality and competitive price of our products will satisfy
   your requirements.
   With strong R&D capability, we can provide comprehensive technical support
   and Techno-scheme Design of LED lighting. We believe, “In the course of
   work, we have to keep the action, endless innovation.” From traditional LED
   lighting&decoration industry products to Harman Kardon Bluetooth Speaker,
   to Gaming Machines in Las Vegas, the TV shows' LED stage costumes and
   the Self-balancing Two Wheeled Vehicle, we have been in line of technology
   frontier, we will do all we can to cooperate with new industry and provide them
   best solutions.
   Part 1-About Us
   Brief Introduction


   View Slide

4. Worldsemi Manufacturing Base
   l Total 4,000sqms Workshop
   l 2000sqms Air Cleanliness Workshop
   l 1000sqms Oce Area
   l Brand-new Automatic Production Equipment
   Manufacturing Base


   View Slide

5. WORLDSEMI Timeline
   ► In 2008：Registered WorldSemi Co.,LIMITED in HongKong,engaged in foreign trade up to now.
   ► In 2009：Established ShenZhen Huacaiwei Technology Co.,Ltd,Mainly focused on
   IC wafer development and design,IC Process and Packaging by OEM factory.
   ► In 2014：Registered ShenZhen Huacaiwei Electrnocis Co.,Ltd,
   Developed and added Digital LED packaging production workshop.
   ► In 2018：Registered DongGuan Huacaiwei Technology Co.,Ltd,In the same year,
   We implemented and obtained ISO9001 quality system certification.
   ► In 2022：Dongguan Huacaiwei Technology Co., Ltd. submitted the application for
   national high-tech enterprise qualification in April 2022
   ► In 2022：Submit an application for high-tech enterprise certification to Dongguan Science
   and Technology Bureau, and submit an application for land purchase to the government.
   Apply to buy 25 mu(16666.66 square metre) of state-owned construction land in Dongguan
   City for the construction of Huacaisaiwei Industrial Park.


   View Slide

6. Our Mission:To Improve traditional electronic products’ functions
   and make life more dazzling and colorful!
   Our Vision: To become a global leader in LED lighting control industry.
   Our values: Customer first, Innovation to win, leading industry, Multi-win！
   Corporate Culture


   View Slide

7. Patent&Qualification
   CN201420023319.1 Data Parrel connectrion&Control CN201420364028.9 A kind of Multicolored LED lamp string using power pulsesynchronization
   CN201420459101.0 A Kind of full color led strip CN201420832551.X LED lighting devices and combined LED lighting devices
   CN201520677627.0 A Kind of full color led point light CN201620245689.9 New type lead-frame and led
   CN201620246807.8 Intelligent LED with highly integrated drive circuit CN201620400266.X Full color LED pixel lamp drive control circuit
   CN201810621705.3 A kind of Full color LED strip control method CN201811132310.3 The invention of a method for realizing LEDntransparent display screen
   CN201921452829.X A kind of Integrated constant current control chip LED CN201921460243.8 A kind of 360 degree emitting color string
   CN201922247951.X A small size LED lead-frame with built-in driver IC CN202021095313.7 An light-emitting device for vertically integrated control chips
   CN202010632569.5 A kind of 2 wire input&output led driver circuit and transfer method CN202021291784.5 A kind of Dual-line input/output LED driver circuit
   CN202020370271.7 A kind of new RGBIC transparent fairy string CN202020162037.5 A kind of Three wire full color LED flexible string
   CN202021953935.9 A digital LED module that can be arbitrarily combined CN202022770240.3 A kind of Side package LED light source lead-frame
   CN202022980090.9 A chip packaging structure CN202023024617.7 A kind of Arbitrary series and parallel digital LED control circuit with address
   CN 202120207730.4 The utility model relates to a concave LED lead-frame
   CN202120301360 A kind of led string (patent application in USA, Germany, Japan, Korea has been submitted)
   CN202110141083.6 A kind of LED string, manufacturing method and LED device used in the LED lamp string
   CN202110201065 A single line transmission signal processing circuit (Simultaneous application for utility model and invention patent)
   ......


   View Slide

8. Worldsemi Manufacturing Base
   l Total 4,000sqms Workshop
   l 2000sqms Air Cleanliness Workshop
   l Brand-new Automatic Production Equipment
   Equipment &Production Workshop


   View Slide

9. Part2-Main Products:
   1.IC&New Products Series
   LED Driver IC: WS2801, WS2811, WS2814. WS2818, DMX512IC(In import production）
   Battery Box IC: WS2832 8 Function IC, WS2833 Timing IC
   8Bit Single-chip IC:WS053E 1K ROM MTP 8bit Single CHip SOT23-6, SOP8 SOP16
   WS053F 1K ROM 2 Path A/D MTP 8bit Single-chip(Under Developing）
   WS055 2K ROM 2 Path A/D MTP 8bit Single-chip(Under Developing）
   E-cigarette head IC: (In import production）
   Constant current LDO IC:(It is being developed for mass production and import）
   DC/DC Power Supply IC:(Under market evaluation）


   View Slide

10. 01
    WS2801
    LED industry’s first IC with two-line
    constant current 256 gray level
    point control IC
    (SOP14 package)
    02
    03
    04
    WS2811S : 5V For LED String,SOP8
    WS2811 : 5-12V ,MSOP8,DNF8
    WS2811 ：5-24V,SOP8
    WS2811
    Constant current single wire
    drive IC(SOP8,MSOP8,DFN8）
    WS2818
    Two - line transmission
    breakpoint continuous
    constant - current IC
    (SOP8 CPC8 )
    WS2814
    RGBW LED Driver iC
    (SOP12 Package）
    WS2814A
    (SOP8 Package）
    05
    WS2816
    Constant current dual line
    16bit high brightness drive IC
    SOP8 Package
    DMX512 IC(In import production）
    1.IC&New Products Series


    View Slide

11. Infrared receiving head series :
    Nose Bridge Type, Dot Type, SMT series
    Optocoupler series products: Market evaluation
    1.IC&New Products Series
    Nose Bridge Type Dot Type SMT Series Infrared receiving head series


    View Slide

12. 01
    WS2812 Series LED
    Voltage:DC5V
    Current：RGB Eache channel 5mA/12mA
    Package：
    SMD5050,3535（White/Black Surface）
    MOLDING 2020（Transparent Molding Type）
    Remark：WS2812 Series LED all with 4PINs,
    Except WS2812S 6PIN
    02
    WS2813 Series LED
    Voltage:DC5V（Dual-signal,breakpoint-continuous ）
    Current：RGB Each channel 5mA/16mA
    RGB 3 Channel total 3+9+7=20mA
    Package Type：
    SMD5050,3535White/Black Surface）
    MOLDING2020（Transparent Molding Type）
    Remark：WS2813 Series led are all 6pins,
    03
    WS2815 Series LED
    Voltage:DC12V(Dual-signal,breakpoint-continuous ）
    Package:RGB 3Channels total 12mA
    Package:SMD5050,3535（White/Black Surface）
    Remark:WS2815 Series led are all 6pins)
    2.Digital LED Series
    04
    WS2816
    16bit high gray high frequency
    display dedicated LED
    Voltage:DC5V
    （Dual-signal,breakpoint-continuous ）
    Current:20mA and 10mA
    Package：SMD3535,2121,2427,1313
    Remark：3535,2121 is 6PIN,
    2427 and 1313 are 4PIN
    www.world-semi.com


    View Slide

13. Digital LED :
    WS2812 5V 4PIN Series:
    5050/3535/2427/2020/1313/4020 Package
    -B
    WS2812 Application：
    Transparent LED Display
    2.Digital LED Series-WS2812 Family


    View Slide

14. Part No. Package(mm) Current(mA) Need Capacitor(Y/N) Lead-frame Color Remark Features
    WS2812S 5050-6 Pins 12mA*3 Y White Surface 1000pcs/reel Fisrt Digital LED
    WS2812A 5050-4 Pins 12mA*3 N White Surface 1000pcs/reel High-Brightness
    WS2812B-V5/W
    WS2812B-B
    5050-4 Pins 12mA*3 N White Surface
    Black Surface
    1000pcs/reel
    and 4500pcs/reel
    Best-selling Classic LED
    Black Surface LED
    WS2812C
    WS2812C-B
    5050-4 Pins 5mA*3 Y White Surface
    Black Surface
    1000pcs/reel
    and 4500pcs/reel
    Small current LED
    WS2812E-V5/W 5050-4 Pins 12mA*3 N White Surface 4500pcs/reel Economy LED
    WS2812B-MINI-V3/W 3535-4 Pins 12mA*3 N White Surface 900pcs/reel
    and 3000pcs/reel
    3.5mm small size led
    WS2812B-MINI-X1 3535-4 Pins 12mA*3 N White Surface 1500pcs/reel
    and 6000pcs/reel
    3.5mm Thinner small size
    WS2812B-4020
    WS2812C-4020
    4020-4 Pins 12mA*3
    5mA*3
    N
    Y
    White Surface(Side-view） 2000pcs/reel Side-view big current
    Side-view small current
    WS2812B-2020 2020-4 Pins 12mA*3 N Molding 4500pcs/reel Big current Molding
    WS2812C-2020 2020-4 Pins 5mA*3 Y Molding 4500pcs/reel Small current Molding
    WS2812C-2427 2427-4 Pins 5mA*3 Y White Surface / Small size 2427 led
    WS2812C-1313 1313-4 Pin3 5mA*3 Y White Surface / Small size 1313 led
    2.Digital LED Series-WS2812 Family


    View Slide

15. Digital LED :
    WS2813 5V Dual-signal,breakpoint-continuous:
    5050/3535/2121/1313 Package
    WS2813 Application：
    2.Digital LED Series-WS2813 Family


    View Slide

16. Part No. Package(m
    m)
    Current(mA) Need Capacitor(Y/N) Lead-frame Color Remark Features
    WS2813A-V1 5050-6 Pins 16mA*3 N White Surface 1000pcs/reel High Brightness
    WS2813B-V5/W 5050-6 Pins 16mA*3 N White Surface 1000pcs/reel
    and 4500pcs/reel
    Best-selling Dual-signal
    breakpoint-continuous
    WS2813B-B 5050-6 Pins 16mA*3 N Black Surface 1000pcs/reel
    and 4500pcs/reel
    Black surface Best-
    selling LED
    WS2813C-V3
    WS2813C-B
    5050-6 Pins 9+7+4=20mA N White Surface
    Black Surface
    1000pcs/reel Small current Dual-
    signal breakpoint-
    continuous
    WS2813B-Mini-V1
    WS2813C-Mini
    3535-6 Pins 16mA*3
    9+7+4=20mA
    N
    N
    White Surface 1500pcs/reel
    and 6000pcs/reel
    Big current 3.5mm LED
    Small current 3.5mm
    WS2813B-RGBW 5050-6 Pins 16mA*3 N White Surface 1000pcs/reel RGBW 4channel Dual-
    signal breakpoint-
    continuous
    WS2813C-2020 2020-6Pins 9+7+4=20mA N Molding 4500pcs/reel Molding Type 9:7:4
    White balance led
    WS2813B-2121 2121-6Pins 16mA*3 N White Surface 4000pcs/reel Big current 2.1mm
    WS2813C-2121 2121-6Pins 9+7+4=20mA N White Surface 4000pcs/reel Small current 2.1mm
    2.Digital LED Series-WS2813 Family


    View Slide

17. Digital LED :
    WS2815 12V Dual-signal,breakpoint-continuous：
    5050/3535 5050RGBW
    WS2815
    2.Digital LED Series-WS2815 Family


    View Slide

18. Part No. Package(mm) Current(mA) Need Capacitor(Y/N) Lead-frame Color Remark Features
    WS2815B
    WS2815B-B
    5050-6 Pins 12mA N White Surface
    Black Surface
    1000pcs/reel
    and 4500pcs/reel
    Digital 12V LED
    WS2815E
    WS2815E-B
    5050-6 Pins 12mA Y White Surface 1000pcs/reel
    and 4500pcs/reel
    Best selling digital
    12v led with dual-
    siganl breakpoint-
    continious function
    WS2815E-RGBW 5050-6 Pins 12mA Y White Surface
    Black Surface
    1000pcs/reel
    and 4500pcs/reel
    RGBW Digital 12V LED
    WS2815E-MINI 3535-6 Pins 12mA Y White Surface 1500pcs/reel
    and 6000pcs/reel
    Small size digital 12V
    LED
    2.Digital LED Series-WS2815 Family


    View Slide

19. Digital LED :
    WS2816 16bit high-gray with high refresh frequency series：
    3535/2427/2121/1313
    2.Digital LED Series-WS2816 Family


    View Slide

20. Part No. Package(mm) Current(mA) Need Capacitor(Y/N) Lead-frame Color Remark Features
    WS2816B-MINI 3535-6 Pins 9+7+4=20mA N White Surface 6000
    PCS/REEL
    3.5mm 16bit 20mA led
    WS2816B-2427 2427-4 Pins 9+7+4=20mA N White Surface / 4PIN 16bit 20mA led-2427
    WS2816C-2427 2427-4 Pins 10mA N White Surface / 4PIN 16bit 10mA led-2427
    WS2816B-2121-V1 2121-6Pins 9+7+4=20mA N White Surface 4000
    PCS/REEL
    Best-Selling 16bit 20mA-2121
    WS2816C-2121-V1 2121-6Pins 10mA N White Surface 4000
    PCS/REEL
    Best-Selling 16bit 10mA-2121
    WS2816B-2020 2020-6Pins 9+7+4=20mA N Molding 4500
    PCS/REEL
    Molding 20mA led-2020
    WS2816C-2020 2020-6Pins 10mA N Molding 4500
    PCS/REEL
    Molding 10mA led-2020
    WS2816B-1313 1313-4Pins 9+7+4=20mA N White Surface / Molding 20mA led-1313
    WS2816C-1313 1313-4Pins 10mA N White Surface / Molding 10mA led-1313
    2.Digital LED Series-WS2816 Family


    View Slide

21. Full Color LED Strip:WS2811 12V/24V Series,WS2818 12V/24V Series，
    WS2812、WS2813Series， DMXSeries
    3.LED Strip&PCBA


    View Slide

22. RGBIC Fairy String:WS2812 5V 3 Wire Series,WS2813 5V 4Wire Series,
    WS2815 12V RGB/RGBW Series
    4.LED RGBIC Fairy String
    3Wre 5V RGB 4 Wire 5V RGB 4 Wire Dual-signal 12V RGB 12V RGBW


    View Slide

23. 4.LED RGBIC Fairy String Application


    View Slide

24. Controller&PCBA :
    Single and double light dimmer ,
    RGB microcontrol series, Simple Full color microcontrol,
    All kinds of customized PCBA ,etc...
    5.LED Controller


    View Slide

25. Part 3-Case Gallery:
    Application
    E-Sports/Gaming Machine


    View Slide

26. Application
    3C
    Consumer
    Decorating


    View Slide

27. Application
    Outdoor Light Decorating


    View Slide

28. Transparent Display/
    Glass Sreen
    Application


    View Slide

29. Amusement/Stage Lighting/KTV/Bar Decoration
    Application


    View Slide

30. Main Partners


    View Slide

31. Major Customers


    View Slide

32. View Slide
