The Inner Workings of Monzo’s Help Search Algorithm

Takeaways:
– Going beyond classification for a more general purpose/flexible model;
– How we handle short term discrepancies (i.e. if there’s an outage or other anomalies in queries);
– Our experience switching from Tensorflow to Pytorch;
– Some findings on Pytorch vs Keras.

Transcript

1. Monzo’s Customer Service Augmentation Tech Sessions Nigel Ng Data Scientist
2. At Monzo, we want to provide world class customer service
3. But customer service enquiries scales linearly with number of users
4. How can we meet our goals of having response times < 10 minutes?
5. Reduce number of inbound questions Increase productivity of customer support agents
6. Here’s how we used ML to tackle those problems
7. Reducing queries: Enable natural language search for help content
10. Increasing productivity: Suggest saved responses to a support agent
12. We have ~800 of these saved responses. Approximately 70-80% of queries that come in can be handled by a saved response.
13. We achieved those two goals with a single NLP model
14. Formulate this as an information retrieval problem:
15. Given an incoming question, find the most similar answer from an answer pool
16. We define ‘most similar’ as the pairing (q, a) that yields the highest cosine similarity
17. To find cosine similarity of texts, we need to represent them as vectors Encoder I forgot my PIN I can reset it for you! [0.2, -3.0, …, 1.8, 0.3] [0.3, -2.2, …, 0.9, 0.4]
18. Word2vec works well on our data
19. Encoder So now we need to go from word vectors to paragraph vectors I [0.2, 0.4, …, -0.2] lost [-0.1, 0.1, …, 1.1] my [0.5, 1.2, …, -2.8] pin [-1.4, -0.1, …, -0.5] [-1.1, -0.4, …, 0.8] [0.9, -3.0, …, 1.8, 0.3]
20. Our journey to build such an encoder Just take average/max of the word vectors Paragraph vectors (Mikolov et al., 2015) - I had such high hopes ʭ Paragraph vectors in combination with textual search (BM25, tfidf) Supervised pre-training and removing the last classification layer (Deng et al., 2009) - doesn’t generalize well to less common phrases Vanilla word-level RNN - looks good but routinely fails on longer sentences
21. Our journey to build such an encoder Hierarchical Attention Networks (Yang et al., 2016) - nice! We used this in production for a while. Transformer (Google, 2017) - What we’re currently using.
22. Training the Transformer Model
23. Before using transformer, our models were written in Keras + TF
24. For the transformer model, we used Pytorch
25. We modify the architecture by only taking the encoder
26. ~400k parameters (small model)
27. Customer service conversations are unstructured text data
28. We train with triplets... How do I change my PIN? You can change your card PIN at any large bank (HSBC, Barclays, etc.) ATM in the UK by selecting PIN services ʠ You'll be pleased to know that we never charge you any fees for withdrawing money from an ATM ȓ Q A+ A- IBM, Feng et al. 2015
29. … using a ranking loss / hinge loss objective function m is a margin, we set it to 0.2 per the IBM paper (Feng et al., 2015) If cos(Q, A+) is large, loss is 0, which is what we want
30. Train on GCE instance with 1xP100 GPU for 2-3 days
31. A few ‘tricks’ while training: Replace too-hard or too-easy samples every few epochs of training (Google Facenet, 2015) with semi-hard examples Use the same weights for both questions and answers Learning rate annealing (we found simple reduce-when-plateau to work better than fancy methods like SGDR)
32. Serving the model
33. For customer support, model runs on a GCE instance every minute (CPU only) Pushes to Intercom via API
34. For help search, serve as a Flask microservice in a Docker container on Kubernetes
35. In both cases, we’re using the Pytorch model directly. No exporting to Caffe2
36. (ms) It works well for our volumes x3 pods on k8s
37. Raw TF protobuf on the same Docker specs crashes the microservice
38. Unit tests to check prediction quality before pushing a new model live
39. Results
40. Our saved response usage went up...
41. … which gave us actionable clustering of support queries All fixed in latest version of the app Reduced queries by 10% (~800 queries a week)
42. We also use saved response predictions as classification
43. Users find what they need XX % of the time (recall @ 5)
44. Search also allows further insights into users problems
45. Other learnings
46. Do not train ranking problems as a classification problem How do I change my PIN? You can change your card PIN at any large bank (HSBC, Barclays, etc.) ATM in the UK by selecting PIN services ʠ You'll be pleased to know that we never charge you any fees for withdrawing money from an ATM ȓ How do I change my PIN? 1 0
47. Transformer does 20% better than HAN with same number of parameters http://smerity.com/articles/2017/mixture_of_softmaxes.html
48. Keras is a great tool for rapid prototyping, but impossible to implement more complex models
49. Despite being a dynamic graph, Pytorch performs better than TF in both training and serving
50. … and the size of the binary is smaller (70mb vs 110mb)
51. Only scenario in which TF is faster than Pytorch is CPU training
52. Use right level of abstraction Classification Ranking Text generation Lower abstraction / more complex model
53. Fine-tuning on short term anomalies doesn’t work - catastrophic forgetting Will try to implement Elastic Weight Consolidation (EWC) if I have time
54. Use Pytorch! It’s much more fun to code in with tf.gfile.FastGFile(graph_path, 'rb') as f: graph_def = tf.GraphDef() graph_def.ParseFromString(f.read()) with tf.Graph().as_default() as graph: tf.import_graph_def(graph_def, name='import') torch.load(checkpoint_files[ 0], map_location=lambda storage, loc: storage) Loading model (actual code in repo) TF Pytorch
55. Key takeaways
56. Build multi-purpose models to avoid technical debt Monitor metrics and actual usage habits Give Pytorch a go!
57. Thank you
