  1. Leverage HTTP to deliver cacheable websites By Thijs Feryn

  2. Hi, I’m Thijs

  3. I’m @ThijsFeryn on Twitter

  4. I’m an Evangelist At

  5. None
  6. Cache

  7. Don’t recompute if the data hasn’t changed

  8. None
  9. What if we could design our software with HTTP caching

    in mind?
  10. None
  11. Reverse caching proxy

  12. Normally User Server

  13. With ReCaPro * User ReCaPro Server * Reverse Caching Proxy

  14. Content Delivery Network

  15. HTTP caching mechanisms Expires: Sat, 09 Sep 2017 14:30:00 GMT

    Cache-control: public, max-age=3600, s-maxage=86400 Cache-control: private, no-cache, no-store
  16. Common problems

  17. None
  18. None
  19. Time To Live

  20. Cache variations

  21. Authentication

  22. Introducing the demo app

  23. None
  24. Silex framework

  25. Twig templates

  26. ✓Multi-lingual (Accept-Language) ✓Nav ✓Header ✓Footer ✓Main ✓Login page & private

    content Introducing the app
  27. None
  28. <?php require_once __DIR__ . '/../vendor/autoload.php'; use Symfony\Component\HttpFoundation\Response; use Symfony\Component\HttpFoundation\RedirectResponse; use

    Symfony\Component\HttpFoundation\Request; use Symfony\Component\Translation\Loader\YamlFileLoader; $app = new Silex\Application(); $app['locale'] = 'en'; $app->register(new Silex\Provider\TwigServiceProvider(), ['twig.path' => __DIR__.'/../views']); $app->register(new Silex\Provider\TranslationServiceProvider(), ['locale_fallbacks' => ['en','nl']]); $app->register(new Silex\Provider\SessionServiceProvider()); $app->extend('translator', function($translator, $app) { $translator->addLoader('yaml', new YamlFileLoader()); $translator->addResource('yaml', dirname(__DIR__).'/locales/en.yml', 'en'); $translator->addResource('yaml',dirname( __DIR__).'/locales/nl.yml', 'nl'); return $translator; }); $app['credentials'] = [ 'admin' => '$2y$10$431rvq1qS9ewNFP0Gti/o.kBbuMK4zs8IDTLlxm5uzV7cbv8wKt0K' ]; $app->before(function (Request $request) use ($app){ $request->setLocale($request->getPreferredLanguage()); $app['translator']->setLocale($request->getPreferredLanguage()); }); $app->after(function(Request $request, Response $response) use ($app){ $response->headers->set('Content-Length',strlen($response->getContent())); });
  29. $app->get('/', function () use($app) { if($app['session']->has('username')) { $loginLogoutUrl = $app['url_generator']->generate('logout');

    $loginLogoutLabel = 'log_out'; } else { $loginLogoutUrl = $app['url_generator']->generate('login'); $loginLogoutLabel = 'log_in'; } $response = new Response($app['twig']->render('index.twig', ['loginLogoutUrl'=>$loginLogoutUrl,'loginLogoutLabel'=>$loginLogoutLabel]),200); return $response; })->bind('home'); $app->get('/login', function (Request $request) use($app) { if($app['session']->has('username')) { return new RedirectResponse($app['url_generator']->generate('home')); } $response = new Response($app['twig']->render('login.twig'),200); return $response; })->bind('login'); $app->get('/logout', function () use($app) { $response = new RedirectResponse($app['url_generator']->generate('login')); $app['session']->invalidate(); return $response; })->bind('logout'); Routes
  30. <!DOCTYPE html>
 <html xmlns="http://www.w3.org/1999/html" xmlns:hx="http://purl.org/NET/hinclude">
 <head>
 <title>{% block title %}{%

    endblock %} - Developing cacheable websites</title>
 <meta name="viewport" content="width=device-width, initial-scale=1.0">
 <meta http-equiv="Content-Type" content="text/html; charset=utf-8" />
 <link rel="stylesheet" href="//maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/ bootstrap.min.css" integrity="sha384- BVYiiSIFeK1dGmJRAkycuHAHRg32OmUcww7on3RYdg4Va+PmSTsz/K68vbdEjh4u" crossorigin="anonymous">
 <script src="//rawgit.com/mnot/hinclude/master/hinclude.js"></script>
 <script
 src="https://code.jquery.com/jquery-2.2.4.min.js"
 integrity="sha256-BbhdlvQf/xTY9gja0Dq3HiwQF8LaCRTXxZKRutelT44="
 crossorigin="anonymous"></script>
 <script src="//rawgit.com/carhartl/jquery-cookie/master/src/jquery.cookie.js"></ script>
 </head>
 <body>
 <div class="container-fluid">
 {{ include('header.twig') }}
 <div class="row">
 <div class="col-sm-3 col-lg-2">
 {{ include('nav.twig') }}
 </div>
 <div class="col-sm-9 col-lg-10">
 {% block content %}{% endblock %}
 </div>
 </div>
 {{ include('footer.twig') }}
 </div>
 </body>
 </html> Base template
  31. {% extends "base.twig" %}
 {% block title %}Home{% endblock %}


    {% block content %}
 <div class="page-header">
 <h1>{{ 'example' | trans }} <small>{{ 'rendered' | trans({'%date%':"now"|date("Y- m-d H:i:s")}) }}</small></h1>
 </div>
 <p>Lorem ipsum dolor sit amet, consectetur adipiscing elit. Mauris consequat orci eget libero sollicitudin, non ultrices turpis mollis. Aliquam sit amet tempus elit. Ut viverra risus enim, ut venenatis justo accumsan nec. Praesent a dolor tellus. Maecenas non mauris leo. Pellentesque lobortis turpis at dapibus laoreet. Mauris rhoncus nulla et urna mollis, et lobortis magna ornare. Etiam et sapien consequat, egestas felis sit amet, dignissim enim.</p>
 <p>Quisque quis mollis justo, imperdiet fermentum velit. Aliquam nulla justo, consectetur et diam non, luctus commodo metus. Vestibulum fermentum efficitur nulla non luctus. Nunc lorem nunc, mollis id efficitur et, aliquet sit amet ante. Sed ipsum turpis, vehicula eu semper eu, malesuada eget leo. Vestibulum venenatis dui id pulvinar suscipit. Etiam nec massa pharetra justo pharetra dignissim quis non magna. Integer id convallis lectus. Nam non ullamcorper metus. Ut vestibulum ex ut massa posuere tincidunt. Vestibulum hendrerit neque id lorem rhoncus aliquam. Duis a facilisis metus, a faucibus nulla.</p>
 {% endblock %} Home page template
  32. <div class="jumbotron">
 <div class="page-header">
 <h1>{{ 'welcome'|trans }} <em id="usernameLabel"></em></h1>
 <small>{{

    'rendered' | trans({'%date%':"now"|date("Y-m-d H:i:s")}) }}</ small>
 </div>
 </div> Header template
  33. <footer><hr /><small>Footer {{ 'rendered' | trans({'%date%':"now"|date("Y-m-d H:i:s")}) }}</small></footer> Footer template

  34. <nav class="navbar navbar-default navbar-fixed-side">
 <ul class="nav">
 <li><a href="{{ url('home') }}">Home</a></li>


    <li><a href="{{ loginLogoutUrl| default(url('login')) }}">{{ loginLogoutLabel|default('log_in') | trans }}</a></ li>
 <li><a href="{{ url('private') }}">Private</a></li>
 </ul>
 <small>{{ 'rendered' | trans({'%date%':"now"|date("Y-m-d H:i:s")}) }}</small>
 </nav> Navigation template
  35. home: Home
 welcome : Welcome to the site
 rendered :

    Rendered at %date%
 example : An example page
 log_in : Log in
 login : Login
 log_out : Log out
 username : Username
 password : Password
 private : Private
 privatetext : Looks like some very private data English locale file
  36. home: Start
 welcome : Welkom op de site
 rendered :

    Samengesteld op %date%
 example : Een voorbeeldpagina
 log_in : Inloggen
 login : Login
 log_out : Uitloggen
 username : Gebruikersnaam
 password : Wachtwoord
 private : Privé
 privatetext : Deze tekst ziet er vrij privé uit Dutch locale file
  37. None
  38. The mission Maximum Cacheability

  39. Cache-control

  40. $app->get('/', function () use($app) { $response = new Response($app['twig']->render('index.twig'),200); $response

    ->setSharedMaxAge(500) ->setPublic(); return $response; })->bind('home'); Cache-Control: public, s-maxage=500
  41. $app->get('/private', function () use($app) { if(!$app['session']->has('username')) { return new RedirectResponse($app['url_generator']-

    >generate('login')); } $response = new Response($app['twig']->render('private.twig'),200); $response->headers->addCacheControlDirective('no-store', true); $response->headers->addCacheControlDirective('no-cache', true); $response ->setSharedMaxAge(0) ->setPrivate(); return $response; })->bind('private'); Cache-Control: private, no-cache, no-store, s-maxage=0
  42. Doesn't work

  43. PHPSESSID cookie No cache

  44. Block caching

  45. None
  46. Code renders single HTTP response

  47. Lowest common denominator: no cache

  48. <esi:include src="/header" /> Edge Side Includes ✓Placeholder ✓Parsed by Varnish

    ✓Output is a composition of blocks ✓State per block ✓TTL per block
  49. sub vcl_recv { set req.http.Surrogate-Capability = "key=ESI/1.0"; } sub vcl_backend_response

    { if (beresp.http.Surrogate-Control ~ "ESI/1.0") { unset beresp.http.Surrogate-Control; set beresp.do_esi = true; } } Edge Side Includes
  50. ESI vs AJAX

  51. <esi:include src="/header" /> Choose wisely <hx:include src="/header"></hx:include> ESI, parsed by

    Varnish HInclude, parsed by Javascript
  52. HttpFragmentServiceProvider ESI & HInclude support

  53. Subrequests

  54. <div class="container-fluid">
 {{ include('header.twig') }}
 <div class="row">
 <div class="col-sm-3 col-lg-2">


    {{ include('nav.twig') }}
 </div>
 <div class="col-sm-9 col-lg-10">
 {% block content %}{% endblock %}
 </div>
 </div>
 {{ include('footer.twig') }}
 </div> <div class="container-fluid">
 {{ render_esi(url('header')) }}
 <div class="row">
 <div class="col-sm-3 col-lg-2">
 {{ render_esi(url('nav')) }}
 </div>
 <div class="col-sm-9 col-lg-10">
 {% block content %}{% endblock %}
 </div>
 </div>
 {{ render_hinclude(url('footer')) }}
 </div>
  55. <div class="container-fluid"> <esi:include src="/header" /> <div class="row"> <div class="col-sm-3 col-lg-2">

    <esi:include src="/nav" /> </div> <div class="col-sm-9 col-lg-10"> <div class="page-header"> <h1>An example page <small>Rendered at 2017-05-17 16:57:14</ small></h1> </div> <p>Lorem ipsum dolor sit amet, consectetur adipiscing elit. Mauris consequat orci eget libero sollicitudin,…</p> </div> </div> <hx:include src="/footer"></hx:include> </div>
  56. $app->get('/header', function () use($app) { $response = new Response($app['twig']->render('header.twig'),200); $response

    ->setSharedMaxAge(500) ->setPublic(); return $response; })->bind('header'); $app->get('/footer', function () use($app) { $response = new Response($app['twig']->render('footer.twig'),200); $response ->setSharedMaxAge(500) ->setPublic(); return $response; })->bind('footer'); $app->get('/nav', function (Request $request) use($app) { if($app['session']->has('username')) { $loginLogoutUrl = $app['url_generator']->generate('logout'); $loginLogoutLabel = 'log_out'; } else { $loginLogoutUrl = $app['url_generator']->generate('login'); $loginLogoutLabel = 'log_in'; } $response = new Response($app['twig']->render('nav.twig', ['loginLogoutUrl'=>$loginLogoutUrl,'loginLogoutLabel'=>$loginLogoutLabel]),200); $response->headers->addCacheControlDirective('no-store', true); $response->headers->addCacheControlDirective('no-cache', true); $response ->setSharedMaxAge(0) ->setPrivate(); return $response; })->bind('nav'); Separate routes per block
  57. Problem: no language cache variation

  58. Vary: Accept-Language

  59. $app->after(function(Request $request, Response $response) use ($app) { $response->headers->set('Content-Length', strlen($response->getContent())); });

    $app->after(function(Request $request, Response $response) use ($app) { $response->setVary('Accept-Language',false); $response->headers->set('Content-Length', strlen($response->getContent())); });
  60. None
  61. None
  62. ✓Navigation page ✓Private page Weak spots Not cached because of

    stateful content
  63. Move state client-side

  64. Replace PHP session with JSON Web Tokens

  65. JWT eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9.eyJzdWIiOiJhZG1pb iIsImV4cCI6MTQ5NTUyODc1NiwibG9naW4iOnRydWV9.u4Idy- SYnrFdnH1h9_sNc4OasORBJcrh2fPo1EOTre8 ✓3 parts ✓Dot separated ✓Base64 encoded

    JSON ✓Header ✓Payload ✓Signature (HMAC with secret)
  66. eyJzdWIiOiJhZG1pbiIsIm V4cCI6MTQ5NTUyODc1Niwi bG9naW4iOnRydWV9 { "alg": "HS256", "typ": "JWT" } {

    "sub": "admin", "exp": 1495528756, "login": true } HMACSHA256( base64UrlEncode(header) + "." + base64UrlEncode(payload), secret ) eyJhbGciOiJIUzI1NiIsI nR5cCI6IkpXVCJ9 u4Idy- SYnrFdnH1h9_sNc4OasOR BJcrh2fPo1EOTre8
  67. JWT Cookie:token=eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9.eyJz dWIiOiJhZG1pbiIsImV4cCI6MTQ5NTUyODc1NiwibG9naW4iOnRydW V9.u4Idy-SYnrFdnH1h9_sNc4OasORBJcrh2fPo1EOTre8 ✓Stored in a cookie ✓Can be

    validated by Varnish ✓Payload can be processed by any language (e.g. Javascript)
  68. VCL vcl 4.0; import digest; import std; import cookie; import

    var; backend default { .host = "localhost"; .port = "8080"; } Init
  69. VCL sub vcl_recv {
 var.set("key","SlowWebSitesSuck");
 set req.url = std.querysort(req.url);
 if(req.http.accept-language

    ~ "^\s*(nl)") {
 set req.http.accept-language = regsub(req.http.accept- language,"^\s*(nl).*$","\1");
 } else {
 set req.http.accept-language = "en";
 }
 set req.http.Surrogate-Capability="key=ESI/1.0";
 if ((req.method != "GET" && req.method != "HEAD") || req.http.Authorization) {
 return (pass);
 }
 call jwt;
 if(req.url == "/private" && req.http.X-Login != "true") {
 return(synth(302,"/logout"));
 }
 return(hash);
 } Receive request
  70. VCL sub vcl_backend_response {
 set beresp.http.x-host = bereq.http.host;
 set beresp.http.x-url

    = bereq.url;
 if(beresp.http.Surrogate-Control~"ESI/1.0") {
 unset beresp.http.Surrogate-Control;
 set beresp.do_esi=true;
 return(deliver);
 }
 }

 sub vcl_deliver {
 unset resp.http.x-host;
 unset resp.http.x-url;
 unset resp.http.vary;
 }

 sub vcl_synth {
 if (resp.status == 301 || resp.status == 302) {
 set resp.http.location = resp.reason;
 set resp.reason = "Moved";
 return (deliver);
 }
 } Receive backend response Strip headers Custom redirect logic
  71. sub jwt {
 if(req.http.cookie ~ "^([^;]+;[ ]*)*token=[^\.]+\.[^\.]+\.[^\.]+([ ]*;[^;]+)*$") {
 cookie.parse(req.http.cookie);


    cookie.filter_except("token");
 var.set("token", cookie.get("token"));
 var.set("header", regsub(var.get("token"),"([^\.]+)\.[^\.]+\.[^\.]+","\1"));
 var.set("type", regsub(digest.base64url_decode(var.get("header")),{"^.*?"typ"\s*: \s*"(\w+)".*?$"},"\1"));
 var.set("algorithm", regsub(digest.base64url_decode(var.get("header")),{"^.*?"alg"\s*: \s*"(\w+)".*?$"},"\1"));

 if(var.get("type") != "JWT" || var.get("algorithm") != "HS256") {
 return(synth(400, "Invalid token"));
 }

 var.set("rawPayload",regsub(var.get("token"),"[^\.]+\.([^\.]+)\.[^\.]+$","\1"));
 var.set("signature",regsub(var.get("token"),"^[^\.]+\.[^\.]+\.([^\.]+)$","\1")); var.set("currentSignature",digest.base64url_nopad_hex(digest.hmac_sha256(var.get("key"),var.ge t("header") + "." + var.get("rawPayload"))));
 var.set("payload", digest.base64url_decode(var.get("rawPayload")));
 var.set("exp",regsub(var.get("payload"),{"^.*?"exp"\s*:\s*(\w+).*?$"},"\1"));
 var.set("username",regsub(var.get("payload"),{"^.*?"sub"\s*:\s*"(\w+)".*?$"},"\1"));

 if(var.get("signature") != var.get("currentSignature")) {
 return(synth(400, "Invalid token"));
 }

 if(var.get("username") ~ "^\w+$") {
 if(std.time(var.get("exp"),now) >= now) {
 set req.http.X-Login="true";
 } else {
 set req.http.X-Login="false";
 }
 }
 }
 }
  72. cookie.parse(req.http.cookie);
 cookie.filter_except("token");
 var.set("token", cookie.get("token"));
 var.set("header", regsub(var.get("token"),"([^\.]+)\.[^\.]+\.[^\.]+","\1"));
 var.set("type", regsub(digest.base64url_decode(var.get("header")), {"^.*?"typ"\s*:\s*"(\w+)".*?$"},"\1"));
 var.set("algorithm",

    regsub(digest.base64url_decode(var.get("header")), {"^.*?"alg"\s*:\s*"(\w+)".*?$"},"\1")); if(var.get("type") != "JWT" || var.get("algorithm") != "HS256") {
 return(synth(400, "Invalid token"));
 } Validate JWT header
  73. var.set("rawPayload",regsub(var.get("token"),"[^\.]+\.([^\.]+)\.[^\.]+ $","\1"));
 var.set("payload", digest.base64url_decode(var.get("rawPayload")));
 var.set("exp",regsub(var.get("payload"),{"^.*?"exp"\s*:\s*(\w+).*?$"},"\1"));
 var.set("username",regsub(var.get("payload"),{"^.*?"sub"\s*:\s*"(\w+)".*? $"},"\1")); Get payload

  74. var.set("signature",regsub(var.get("token"),"^[^\.]+\.[^\.]+\.([^\.]+) $","\1")); var.set("currentSignature",digest.base64url_nopad_hex(digest.hmac_sha256(var. get("key"),var.get("header") + "." + var.get("rawPayload")))); if(var.get("signature") !=

    var.get("currentSignature")) {
 return(synth(400, "Invalid token"));
 } Verify signature
  75. if(var.get("username") ~ "^\w+$") {
 if(std.time(var.get("exp"),now) >= now) {
 set req.http.X-Login="true";


    } else {
 set req.http.X-Login="false";
 }
 } Verify login action Check expiration Use X- Login in vcl_recv
  76. $app['jwtKey'] = 'SlowWebSitesSuck'; $app['jwtEncode'] = function() use ($app){ return function($username)

    use ($app) { return JWT::encode([ 'sub'=>$username, 'exp'=>time() + 86400, 'login'=>true, ],$app['jwtKey']); }; }; $app['jwtValidate'] = function() use ($app) { return function($token) use ($app) { try { $data = JWT::decode($token,$app['jwtKey'],['HS256']); $data = (array)$data; if(!isset($app['credentials'][$data['sub']])) { return false; } return true; } catch(UnexpectedValueException $e) { return false; } }; }; The code Helper functions
  77. $app->get('/private', function (Request $request) use($app) { if(!$app['jwtValidate']($request->cookies->get('token'))) { return new

    RedirectResponse($app['url_generator']->generate('login')); } $response = new Response($app['twig']->render('private.twig'),200); $response ->setSharedMaxAge(500) ->setPublic(); return $response; })->bind('private'); The code Redirect to login page
  78. $app->get('/nav', function (Request $request) use($app) { if($app['jwtValidate']($request->cookies->get('token'))) { $loginLogoutUrl =

    $app['url_generator']->generate('logout'); $loginLogoutLabel = 'log_out'; } else { $loginLogoutUrl = $app['url_generator']->generate('login'); $loginLogoutLabel = 'log_in'; } $response = new Response($app['twig']->render('nav.twig', ['loginLogoutUrl'=>$loginLogoutUrl,'loginLogoutLabel'=>$loginLogoutLabel] ),200); $response ->setVary('X-Login',false) ->setSharedMaxAge(500) ->setPublic(); return $response; })->bind('nav'); The code Cache variation
  79. Extra cache variation required

  80. Vary: Accept-Language, X-Login Content for logged-in & anonymous differs

  81. Bonus

  82. <script language="JavaScript">
 function getCookie(name) {
 var value = "; "

    + document.cookie;
 var parts = value.split("; " + name + "=");
 if (parts.length == 2) return parts.pop().split(";").shift();
 }
 function parseJwt (token) {
 var base64Url = token.split('.')[1];
 var base64 = base64Url.replace('-', '+').replace('_', '/');
 return JSON.parse(window.atob(base64));
 };
 $(document).ready(function(){
 if ($.cookie('token') != null ){
 var token = parseJwt($.cookie("token"));
 $("#usernameLabel").html(', ' + token.sub);
 }
 });
 </script> Parse JWT in Javascript
  83. Does not require backend access

  84. ✓Application issues JWT ✓Varnish validates JWT ✓Varnish can verify login

    ✓Varnish can redirect to login page ✓No backend access required ✓Only POST /login hits the backend ✓Even works without Varnish ✓Even Javascript can parse JWT ✓Extra cache variation required JWT conclusion
  85. https://github.com/ThijsFeryn/ cacheable-site-silex/tree/v2

  86. None
  87. None
  88. https://twitter.com/thijsferyn https://instagram.com/thijsferyn https://blog.feryn.eu https://talks.feryn.eu https://book.feryn.eu https://youtube.com/thijsferyn https://soundcloud.com/thijsferyn http://itunes.feryn.eu
