  1. http://www.zendcon.com/ Making Magento go fast By Thijs Feryn

  2. my name Thijs Hi, is

  3. And I’m @ThijsFeryn on Twitter

  4. None
  5. I’m an Evangelist At

  6. I’m at a board member

  7. https://joind.in/talk/view/15531 Feedback

  8. None
  9. Magento is kinda slow …

  10. But tremendously flexible

  11. In the beginning we were somewhat clueless

  12. But we learned a lot!

  13. It did take some time though

  14. Operations approach

  15. The first attempts

  16. First attempts ✓Install powerful machines ✓Lots of RAM & CPU

    ✓Loadbalancing on the webservers ✓Master/master replication on the MySQL servers ✓High memory limit ✓APC byte code caching
  17. Looking for Magento knowledge

  18. First Magento skills ✓Activate caching in the admin panel ✓Flat

    catalogs ✓The Magento compiler ✓JS & CSS minification
  19. The Magento compiler is a lie!

  20. Use a real byte code cache instead

  21. Things started to speed up But it wasn’t fantastic

  22. First conclusions

  23. First conclusions ✓It uses a lot of RAM & CPU

    ✓And a whole lot of I/O ✓The MySQL server gets hammered
  24. We  learned  how  to  cache

  25. By default on disk in in /var/cache

  26. ./mage-­‐-­‐c   ./mage-­‐-­‐a   ./mage-­‐-­‐4   ./mage-­‐-­‐7   ./mage-­‐-­‐e

    ./mage-­‐-­‐5   ./mage-­‐-­‐b   ./mage-­‐-­‐9   ./mage-­‐-­‐0   ./mage-­‐-­‐f   ./mage-­‐-­‐3   ./mage-­‐-­‐6   ./mage-­‐-­‐8   ./mage-­‐-­‐d   ./mage-­‐-­‐1
  27. ./mage-­‐-­‐8/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_STORE_BE_EN_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_STORE_LU_EN_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_STORE_NL_NL_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_STORE_LU_EN_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_STORE_LU_FR_CONFIG_CACHE

    ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_STORE_FR_EN_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_STORE_LU_FR_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_STORE_BE_FR_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_STORE_ADMIN_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_STORE_BE_FR_CONFIG_CACHE   ./mage-­‐-­‐8/mage-­‐-­‐-­‐MAGE_DB_PDO_MYSQL_DDL_sales_flat_shipment_grid_3   ./mage-­‐-­‐d/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_APP_E4D52B98688947405EDE639E947EE03D   ./mage-­‐-­‐d/mage-­‐-­‐-­‐MAGE_APP_B1FB6E8F13287C01E5C05063633DDA4C   ./mage-­‐-­‐d/mage-­‐-­‐-­‐MAGE_DB_PDO_MYSQL_DDL_log_url_info_1   ./mage-­‐-­‐d/mage-­‐-­‐-­‐MAGE_APP_E4D52B98688947405EDE639E947EE03D   ./mage-­‐-­‐d/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_APP_B1FB6E8F13287C01E5C05063633DDA4C   ./mage-­‐-­‐d/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_DB_PDO_MYSQL_DDL_log_url_info_1   ./mage-­‐-­‐1/mage-­‐-­‐-­‐MAGE_Zend_LocaleC_nl_NL_currencysymbol_   ./mage-­‐-­‐1/mage-­‐-­‐-­‐MAGE_Zend_LocaleC_nl_NL_nametocurrency_   ./mage-­‐-­‐1/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_Zend_LocaleC_nl_NL_currencynumber_   ./mage-­‐-­‐1/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_Zend_LocaleC_nl_NL_currencysymbol_   ./mage-­‐-­‐1/mage-­‐-­‐-­‐MAGE_Zend_LocaleC_nl_NL_currencynumber_   ./mage-­‐-­‐1/mage-­‐-­‐-­‐internal-­‐metadatas-­‐-­‐-­‐MAGE_Zend_LocaleC_nl_NL_nametocurrency_
  28. APC

  29. In app/etc/local.xml <global>          <cache>

                 <backend>apc</backend>                  <prefix>MAGE_</prefix>          </cache>   </global>
  30. Memcached

  31. <global>    <cache>        <memcached>

       <servers>              <server>                <host><![CDATA[127.0.0.1]]></host>                <port><![CDATA[11211]]></port>                <persistent><![CDATA[1]]></persistent>              </server>          </servers>      </memcached>    </cache>   </global> In app/etc/local.xml Multiple servers
  32. Still there are files in /var/cache

  33. 2-level cache ✓Fast backend first (adapter) ✓Then the slow backend

    (disk)
  34. /var/cache in tmpfs mount  -­‐t  tmpfs  -­‐o  size=20m  tmpfs  /var/www/var/cache

  35. Bigger machines

  36. is slow

  37. Especially the older versions

  38. Magento now supports 5.5

  39. Without byte code caching, you’re in trouble

  40. We forgot that byte code caches aren’t efficient on FastCGI

  41. 19280  33686  1.3    0.4  322052  110408  ?  S  14:07

     0:01  /usr/local/php-­‐5.4/bin/php-­‐cgi   18834  33696  0.0    0.0  267780  13608    ?  S  14:07  0:00  /usr/local/php-­‐5.4/bin/php-­‐cgi   19280  33698  0.9    0.4  321808  110948  ?  S  14:07  0:01  /usr/local/php-­‐5.4/bin/php-­‐cgi   19057  33700  0.0    0.0  268124  13416    ?  S  14:07  0:00  /usr/local/php-­‐5.4/bin/php-­‐cgi   18767  33710  0.0    0.0  269728  14156    ?  S  14:08  0:00  /usr/local/php-­‐5.4/bin/php-­‐cgi Separate processes, no joint cache
  42. And we forgot that APC is slowly dying

  43. -FPM

  44. root  26067  0.0  0.0  342892  6248  ?  S  13:43  0:00

     php-­‐fpm:  master  process  (/etc/php5/fpm/php-­‐fpm.conf)   www-­‐data  26068    0.2    1.1  396952  94684  ?  S  13:43  0:03  php-­‐fpm:  pool  www   www-­‐data  26069    0.0    0.6  363472  56456  ?  S  13:43  0:01  php-­‐fpm:  pool  www   www-­‐data  26087    0.0    0.6  362708  50188  ?  S  13:44  0:00  php-­‐fpm:  pool  www Master proces that stores the byte code cache
  45. Opcache is awesome … and a lot faster

  46. Everything in memory!!!

  47. We looked at HHVM

  48. But the database is also important

  49. innodb_buffer_pool_size  =  1024M   Give MySQL more RAM

  50. Turn off query caching

  51. innodb_flush_log_at_trx_commit

  52. Which one will we choose?

  53. <global>      <resources>          <default_setup>

               <connection>                  <host><![CDATA[Master-­‐host]]></host>                  <username><![CDATA[user]]></username>                  <password><![CDATA[pass]]></password>                  <dbname><![CDATA[magentodb]]></dbname>                  <active>1</active>              </connection>          </default_setup>          <default_read>              <connection>                  <use/>                  <host><![CDATA[Slave-­‐host]]></host>                  <username><![CDATA[user]]></username>                  <password><![CDATA[pass]]></password>                  <dbname><![CDATA[magento]]></dbname>                  <type>pdo_mysql</type>                  <model>mysql4</model>                  <initStatements>SET  NAMES  utf8</initStatements>                  <active>1</active>              </connection>          </default_read>        </resources>   </global> R/W   splitting
  54. And all of a sudden, we discovered Redis!

  55. is GREAT! ✓Built-in replication ✓Data types (hash, list, …) ✓Save

    on disk ✓Session clustering ✓Cm_Cache_Backend_Redis by default in Magento 1.8 CE & 1.13 EE ✓No 2-level cache ✓Multiple databases ✓Authentication
  56. Cm_Cache_Backend_Redis https://github.com/colinmollenhour/ Cm_Cache_Backend_Redis

  57. <global>      <cache>          <backend>Cm_Cache_Backend_Redis</backend>

           <backend_options>              <server>127.0.0.1</server>              <port>6379</port>              <persistent></persistent>              <database>1</database>              <password></password>              <force_standalone>0</force_standalone>              <connect_retries>1</connect_retries>              <read_timeout>10</read_timeout>              <automatic_cleaning_factor>0</automatic_cleaning_factor>              <compress_data>1</compress_data>              <compress_tags>1</compress_tags>              <compress_threshold>20480</compress_threshold>              <compression_lib>gzip</compression_lib>          </backend_options>      </cache>   </global> In app/etc/local.xml
  58. Cm_RedisSession https://github.com/colinmollenhour/Cm_RedisSession

  59. In app/etc/modules/Cm_RedisSession.xml <config>      <modules>

     <Cm_RedisSession>              <active>true</active>              <codePool>community</codePool>          </Cm_RedisSession>      </modules>   </config>
  60. <global>      <session_save>db</session_save>      <redis_session>

       <host>127.0.0.1</host>          <port>6379</port>          <password></password>          <timeout>2.5</timeout>          <persistent></persistent>          <db>1</db>          <compression_threshold>2048</compression_threshold>          <compression_lib>gzip</compression_lib>          <log_level>1</log_level>          <max_concurrency>6</max_concurrency>          <break_after_frontend>5</break_after_frontend>          <break_after_adminhtml>30</break_after_adminhtml>          <bot_lifetime>7200</bot_lifetime>      </redis_session>   </global> In app/etc/local.xml
  61. Varnish

  62. Varnish ✓Only works on product catalog & CMS pages ✓Doesn’t

    work on checkout ✓Great for static content ✓No SSL support ✓Best way to cache
  63. Hit rate kinda sucked

  64. Turpentine https://github.com/nexcess/magento-turpentine

  65. Turpentine ✓Community module for Varnish in Magento ✓ESI or AJAX

    for session data ✓Configurable in the admin ✓VCL is pushed via Turpentine to the Varnish over Telnet ✓Takes care of purging ✓SSL termination via Nginx
  66. Lesti_FPC When Varnish is not an option https://github.com/GordonLesti/Lesti_Fpc

  67. <global>      <fpc>          <lifetime>86400</lifetime>

      <debug>false</debug>          <backend>Cm_Cache_Backend_Redis</backend>          <backend_options>              <server>127.0.0.1</server>              <port>6379</port>              <persistent>cache-­‐fpc</persistent>              <database>1</database>              <password></password>              <force_standalone>1</force_standalone>              <connect_retries>1</connect_retries>              <lifetimelimit>86400</lifetimelimit>              <read_timeout>10</read_timeout>              <compress_data>1</compress_data>              <compress_tags>1</compress_tags>              <compress_data>gzip</compress_data>          </backend_options>      </fpc>   </global> In app/etc/local.xml Also  works   with  other   backends
  68. Turn your log tables into blackhole tables You’re not using

    them when you have Varnish/ Lesti_FPC
  69. ALTER  TABLE  `log_customer`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_quote`  ENGINE=BLACKHOLE;

    ALTER  TABLE  `log_summary`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_summary_type`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_url`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_url_info`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_visitor`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_visitor_info`  ENGINE=BLACKHOLE;   ALTER  TABLE  `log_visitor_online`  ENGINE=BLACKHOLE;
  70. Search

  71. Full-text search on the database is stupid … and slow

  72. You can take down certain Magento shops by doing excessive

    search
  73. You could use

  74. But I prefer https://github.com/jreinke/magento-Elasticsearch

  75. Host static files separately (~CDN) http://www.magentocommerce.com/magento-connect/onepica- imagecdn-1.html

  76. Horizontal scalability

  77. Loadbalanced ElasticSearch Redis Loadbalanced MySQL MySQL Loadbalanced frontend Nginx Nginx

    Loadbalanced Varnish Varnish Loadbalanced backend Nginx Nginx Client Admin PHP-FPM PHP-FPM PHP-FPM PHP-FPM SSL endpoint ElasticSearch
  78. Problem!

  79. Cm_Cache_Backend_Redis can’t handle multiple instances

  80. Working on it !

  81. Redis “clustering” ✓Standalone Redis instance per webserver ✓Twemproxy & Twemproxy

    agent ✓Redis Sentinel & keepalived ✓Redis Sentinel patch for Cm_Cache_Backend_Redis (waiting for v1.1 of Predis before I’ll implement it) ✓Redis Cluster patch for Cm_Cache_Backend_Redis (waiting for v1.1 of Predis before I’ll implement it)
  82. Sentinel

  83. Sentinel ✓Discovery service for Redis servers ✓Part of the Redis

    core ✓Monitoring, notification & autofailover ✓Knows which are masters & slaves ✓Avoid problems when the master is down ✓Avoids problems when to master is up again ✓First connect to Sentinel, then to Redis
  84. Loadbalanced Redis master Client Loadbalanced Sentinel Sentinel Redis slave Redis

    slave
  85. port  26379   sentinel  monitor  mymaster  127.0.0.1  6379  2

    sentinel  down-­‐after-­‐milliseconds  mymaster  5000   sentinel  parallel-­‐syncs  mymaster  2   sentinel  client-­‐reconfig-­‐script  mymaster  ./sentinel.sh Sentinel config
  86. $>  redis-­‐cli  -­‐p  26379   127.0.0.1:26379>  sentinel  master  mymaster

     1)  "name"    2)  "mymaster"    3)  "ip"    4)  "127.0.0.1"    5)  "port"    6)  "6379"    7)  "runid"    8)  "e3a3fbab9687857c74266b360a85317aea2a213c"    9)  "flags"   10)  "master"   11)  "pending-­‐commands"   12)  "0"   13)  "last-­‐ping-­‐sent"   14)  "0"   15)  "last-­‐ok-­‐ping-­‐reply"   16)  "268"   17)  "last-­‐ping-­‐reply"   Discover master
  87. $>  redis-­‐cli  -­‐p  26379   127.0.0.1:26379>  sentinel  slave  mymaster

    1)    1)  "name"          2)  "127.0.0.1:6380"          3)  "ip"          4)  "127.0.0.1"          5)  "port"          6)  "6380"          7)  "runid"          8)  "40a20d214c30b5a63a78882ee68d51f2b8506cc0"          9)  "flags"        10)  "slave"        11)  "pending-­‐commands"        12)  "0"        13)  "last-­‐ping-­‐sent"        14)  "0"        15)  "last-­‐ok-­‐ping-­‐reply"        16)  "158"        17)  "last-­‐ping-­‐reply"        18)  "158"   Discover slaves Supports multiple slaves
  88. $>  redis-­‐cli  -­‐p  26379   127.0.0.1:26379>  SENTINEL  get-­‐master-­‐addr-­‐by-­‐name  mymaster

    1)  "127.0.0.1"   2)  "6379" Get master host & port
  89. Keepalived

  90. Keepalived ✓Active-passive setups ✓Manages the virtual IP ✓Master gets virtual

    IP ✓Does failover ✓Uses check scripts
  91. Keepalived vrrp_script  chk_redis_master  {          script  "/vagrant/keepalived.sh"

             interval  2   }   vrrp_instance  redis  {          state  MASTER          interface  eth1          virtual_router_id  51          priority  150          advert_int  1          authentication  {                  auth_type  PASS                  auth_pass  thepasswordispassword          }          virtual_ipaddress  {                  10.10.10.42          }          track_script  {                  chk_redis_master          }           } vrrp_script  chk_redis_master  {          script  "/vagrant/keepalived.sh"          interval  2   }   vrrp_instance  redis  {          state  MASTER          interface  eth1          virtual_router_id  51          priority  100          advert_int  1          authentication  {                  auth_type  PASS                  auth_pass  thepasswordispassword          }          virtual_ipaddress  {                  10.10.10.42          }          track_script  {                  chk_redis_master          }           } Master Slave
  92. Keepalived #!/bin/bash   result=$(redis-­‐cli  -­‐p  26379  SENTINEL  get-­‐master-­‐addr-­‐by-­‐name  mymaster  |

     head  -­‐n1  2>&1)   ip=`/sbin/ifconfig  eth1  |  grep  'inet  addr:'  |  cut  -­‐d:  -­‐f2  |  awk  '{  print  $1}'`   if  [  "$result"  ==  "$ip"  ]  ;   then      echo  "I'm  master"      exit  0   else      echo  "I'm  slave"      exit  1   fi check script
  93. Cm_Cache_Backend_redis patch

  94. Replacing Credis with Predis inside Cm_Cache_Backend_redis Would make more sense

  95. Waiting for v1.1 of Predis

  96. Daniele (Predis project lead) said he’d get it done by

    the end of the year
  97. Twemproxy & Twemproxy agent https://github.com/Stono/redis-twemproxy-agent https://github.com/twitter/twemproxy

  98. Twemproxy ✓Redis & Memcached Proxy ✓Written by Twitter ✓Does sharding

    ✓Persistent connections ✓Disable nodes on failure https://github.com/twitter/twemproxy
  99. Twemproxy twem1:      listen:  127.0.0.1:22122      hash:  fnv1a_64

         hash_tag:  "{}"      distribution:  ketama      auto_eject_hosts:  false      timeout:  400      redis:  true      servers:        -­‐  10.10.10.40:6379:1  master1        -­‐  10.10.10.43:6379:1  master2
  100. Twemproxy agent ✓NodeJS daemon ✓Monitors master status via Sentinel ✓Changes

    Twemproxy config on failover https://github.com/Stono/redis-twemproxy-agent
  101. Twemproxy agent node  cli.js  -­‐h  10.10.10.40  -­‐p  26379  \

    -­‐f  /etc/twemproxy/conf/magento.conf  \   -­‐c  /etc/init.d/twemproxy  restart  \   -­‐l  /var/log/twemproxy/twemproxy_sentinel.log
  102. Redis Cluster

  103. Redis Cluster ✓In v3 ✓Sharding ✓Replication ✓Autofailover ✓Auto shard redirection

    ✓No need for Sentinel
  104. None
  105. Magento v2?

  106. My Redis multi-server patch in production? Redis Cluster & Sentinel

  107. HHVM as the default PHP runtime?

  108. Percona Server as the default MySQL server?

  109. Varnish v4 support?

  110. And that is how me make sure you sleep at

    night
  111. But don’t ask us to write Magento code for you

  112. We have partners for that

  113. But we can make your Magento go fast

  114. None
  115. https://joind.in/talk/view/15531 Feedback
