Edge vs. Level triggered logic

A brief explanation of "edge triggered" and "level triggered" logic.

Transcript

1. Google Cloud Platform
   Kubernetes: Edge vs. Level
   Triggered Logic
   Tim Hockin
   Principal Software Engineer
   @thockin


   View Slide

2. Google Cloud Platform
   Once upon a time there was hardware
   When the hardware needed attention, it would
   signal the CPU == “interrupt”
   Interrupts used be a literal wire from the device
   to the CPU


   View Slide

3. Google Cloud Platform
   Device CPU
   interrupt line


   View Slide

4. Google Cloud Platform
   The device can change the voltage on the wire
   The CPU can detect changes in voltage


   View Slide

5. Google Cloud Platform
   low voltage
   high voltage
   edge edge


   View Slide

6. Google Cloud Platform
   Simple: the device “pulses” the interrupt line
   The CPU reacts
   This is “edge triggered”


   View Slide

7. Google Cloud Platform
   Device CPU


   View Slide

8. Google Cloud Platform
   Problem: what happens if the CPU doesn’t detect
   a pulse?
   The interrupt doesn’t get serviced!


   View Slide

9. Google Cloud Platform
   low voltage
   high voltage
   level level


   View Slide

10. Google Cloud Platform
    The device can change the voltage and keep it
    there until the interrupt is serviced
    The CPU can’t miss edges
    The device can “stack” interrupt reasons - leave
    the voltage until all reasons are ACK’ed
    This is “level triggered”


    View Slide

11. Google Cloud Platform
    Device CPU


    View Slide

12. Google Cloud Platform
    What does this mean for Kubernetes?
    State is more useful than events
    Level-driven software is about asserting state
    Clients can check and re-check state at any time
    This is the heart of Kubernetes’ controller model


    View Slide
