Transcript
M5Stack用の 指紋認証センサーを試す IoTLT vol.99
自己紹介 • SNSでの名前 ◦ ufoo68(@ufoo_yuta) • 住まい ◦ 滋賀県 •
すきなこと ◦ シンプルなものづくり
今日の内容 とりあえず買ってみたけど、用途が見つからないセンサを触ってみた回
使うマイコン M5Stack core2
何で開発しよう? UIFlowでやってみよう
UIFlowで開発するメリット • M5Stack用のセンサユニットであれば公式がサンプルコードを用意しれくれている • センサユニットとの接続もUIでできるので、ハードウェアをほとんど意識することなく 気軽に試すことができる • 何より直感的でわかりやすい
指紋センサーができること 1. 指紋の登録 2. 指紋の照合
指紋の登録 一つの指紋(ACCESS ID)に対して固有のID(USER ID)を紐づける 指紋センサー ACCESS ID:1 USER ID:1
指紋の照合 指紋センサー Known or Unknown センサから取得した指紋と、登録されている指紋を照合する
動作確認 https://twitter.com/ufoo_yuta/status/1660950375577559040?s=20 この動画は指紋の登録から検証までストレートにう まく行ったやつ。 登録した指紋でNGが出たりして、動画は何回かと りなおしている。
わかってないこと • 指紋の最大登録数 ◦ 公式のブロックを信じるなら3つまで • 指紋のraw dataは取得できるのか ◦ 少なくともUI
Flowで取得できるデータは、指紋センサーの「 ACCESS ID」とそれに紐づい た「USER ID」のみ ◦ データシートをちゃんと読む必要ある(面倒) • 指紋の照合結果(Known or Unknown)がよくブレる ◦ これは私本人の体質の問題もありそう
