  1. Interoperation between
    InterMines
    Legume Federation, June 22, 2015
    Vivek Krishnakumar
    Chris Town
    J. Craig Venter Institute

    View Slide

  2. InterMine in a nutshell
    • Open-source data warehouse software
    • Integration of complex biological data
    • Parsers for common biological data formats
    • Extensible framework for custom data
    • Cookie-cutter interface, highly customizable
    • Interact using sophisticated web query tools
    • Programmatic access using web-service API

    View Slide

  3. Open-source Project
    • Source code available online
    • Distributed with the GNU
    LGPL license
    • GitHub Repo:
    https://github.com/intermine/int
    ermine
    • GitHub Organization:
    https://github.com/intermine
    intermine / intermine
    > bio
    > biotestmine
    > config
    > flymine
    > humanmine
    > imbuild
    > intermine
    > testmodel
    .gitignore
    .travis.yml
    LICENSE
    LICENSE.LIBS
    README.md
    RELEASE_NOTES

    View Slide

  4. Richard N. Smith et al. Bioinformatics 2012;28:3163-3165
    InterMine system architecture

    View Slide

  5. InterMine system architecture
    Web Application
    • Java Server Pages (JSP), HTML, JS, CSS
    • Interfaces with Java Servlets and IM web-services
    Web Server
    • Tomcat 7.0.x, serves Web application ARchive file
    • ant based build system using Java SDK
    Database Server
    • PostgreSQL 9.2 or above
    • range query, btree, gist enabled (refer docs here)
    http://intermine.readthedocs.org/en/latest/system-requirements/

    View Slide

  6. Alex Kalderimis et al. Nucl. Acids Res. 2014;42:W468-W472
    InterMine web services
    http://iodocs.labs.intermine.org
    JBrowse

    View Slide

  7. Federated Authentication
    • Apart from the standard login scheme
    (username/password), InterMine supports industry
    standard OAuth2 based login flows, implemented
    by Google, GitHub, Agave, etc.
    • ThaleMine (Arabidopsis) relies on this
    infrastructure to authenticate users against the
    araport.org tenant registered within the Agave
    infrastructure
    • Documentation available here:
    http://intermine.readthedocs.org/en/latest/webapp/
    properties/web-properties/#openauth2-settings-
    aka-openid-connect

    View Slide

  8. Interoperability?
    • Ability of InterMine instances to
    communicate ‘automatically’ with each
    other
    • By way of leveraging web services
    • Questions to be answered:
    ¡
    What do they say to each other?
    ¡
    How do they say it?
    ¡
    What mechanisms are used?
    ¡
    Enabling these mechanisms…

    View Slide

  9. Data Model
    • Data Model === Schema of InterMine
    instance
    • Defined in XML format
    • Core data model (based on SO) can be
    extended to suit requirements
    • Access a mines data model in JSON format
    http://MINE_URL/service/model/?format=json
    • Compatibility of data models across mines
    ensures interoperability

    View Slide

  10. Advantages of common data
    model
    • Data mining scripts developed for one
    mine immediately compatible with
    others
    • Promotes crowdsourcing
    ¡
    one/more groups write
    tools/widgets/parsers
    ¡
    can be easily reused by others
    • Enables cross species analysis

    View Slide

  11. Available tools
    • Multi-mine search tool
    https://github.com/alexkalderimis/multimine-search-tool
    ¡
    Based on InterMine Lucene-based search index
    ¡
    Allows for interoperation when data models are different
    • Integration based on Homologs:
    ¡
    Ontology integration using `dagify`
    https://github.com/intermine/dagify
    ¡
    Pathway Integration by way of collating shared pathways
    • InterMine Staircase
    ¡
    Powerful client-side interface enabling data analysis
    workflows and cross-mine integration via web services
    http://staircase.herokuapp.com

    View Slide

  12. InterMine Staircase

    View Slide

  13. InterMine Staircase
    Configure access to multiple mines

    View Slide

  14. InterMine Staircase
    Cross-mine search

    View Slide

  15. InterMine Staircase
    Filter results by facets

    View Slide

  16. InterMine Staircase
    Prepare and enrich lists

    View Slide

  17. InterMine Staircase
    Perform mine-to-mine list conversions

    View Slide

  18. InterMine Staircase
    App/tool compatibility

    View Slide

  19. InterMine Staircase
    Application model
    MedicMine SoyMine....

    View Slide

  20. Available Reference Mines
    • ThaleMine: https://github.com/Arabidopsis-Information-Portal/intermine/
    ¡
    Integrates variety of genomic datasets pertaining to Arabidopsis thaliana col-0
    ¡
    Leverages both data warehousing and federation methods
    ¡
    Represents wide variety of data: genes, proteins, function, expression, co-expression,
    interactions, pathways, homologs, alleles, polymorphism, stocks, germplasm,
    phenotypes
    • MedicMine: https://github.com/jcvi-plant-genomics/intermine/
    ¡
    Warehouse for Medicago truncatula A17 genomic data
    ¡
    Houses variety of data: genes, proteins, function, expression
    • PhytoMine: https://github.com/JoeCarlson/intermine/
    ¡
    Warehouse for 47 different Angiosperm genomes
    ¡
    Developed on a Chado à InterMine migration path
    ¡
    Houses variety of data: genes, proteins, expression, homologs, protein families,
    variation
    • FlyMine: https://github.com/intermine/intermine/

    View Slide

  21. Recommendations and Challenges
    • Recommendations:
    ¡
    Develop core plant InterMine model
    ¡
    Follow InterMine guidelines
    ¡
    Learn from prior initiatives - InterMOD
    • Challenges
    ¡
    Users/developers are used to current way of
    doing things
    ¡
    Time taken to adapt to common data model
    and/or software stack
    ¡
    Difficult to arrive at consensus with diverse group

    View Slide

  22. Acknowledgments
    • InterMine Team
    ¡
    Gos Micklem
    ¡
    Julie Sullivan
    ¡
    Alex Kalderimis
    ¡
    Richard Smith
    ¡
    Sergio Contrino
    ¡
    Josh Heimbach
    ¡
    et al.
    • Araport Team
    ¡
    Chris Town
    ¡
    Jason Miller
    ¡
    Matt Vaughn
    ¡
    Maria Kim
    ¡
    Svetlana
    Karamycheva
    ¡
    Erik Ferlanti
    ¡
    Chia-Yi Cheng
    ¡
    Benjamin Rosen
    ¡
    Irina Belyaeva
