Building Multi-Page {shiny} apps with {brochure}

NHS-R / 2022-02-16

Transcript

1. BUILDING MULTI-PAGE {SHINY} APPS WITH
   {BROCHURE}
   NHS-R / 2022-02-16
   COLIN FAY


   View Slide

2. > whoami
   Colin FAY - Data Science Engineering & R-Hacker at
   ThinkR.
   Hyperactive open source developer, lead developer of
   the {golem} project, author of the Engineering
   Production Grade Shiny Apps book.
   https://rtask.thinkr.fr
   https://twitter.com/_colinfay
   https://github.com/colinfay
   https://colinfay.me
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 2 / 23


   View Slide

3. Data Science
   engineering, focused on
   R
    Training
    Software Engineering
    R in production
    Consulting
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 3 / 23


   View Slide

4. BUILDING MULTI-PAGE {SHINY} APPS WITH
   {BROCHURE}


   View Slide

5. Multiple Page Shiny Apps with
   {brochure}
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 5 / 23


   View Slide

6. I know what you're thinking
   🤔
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 6 / 23


   View Slide

7. YASE (Yet Another Shiny
   Extension)
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 7 / 23


   View Slide

8. Ok let me explain
   🗣
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 8 / 23


   View Slide

9. (Because yes, there's a rational
   explaination)
   Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 9 / 23


   View Slide

10. 10(*) types of webapps
    Multi-page apps
    The "traditionnal" way of building content on the web.
    Each time you move from one page to another, the whole content is reloaded.
    This is how most websites work.
    Single page apps
    More "modern" way to build apps.
    The HTML/CSS/JS is uploaded one time, and its content is updated via JavaScript requests
    to the server.
    This is how {shiny} works.
    (*) Sorry for everyone not getting the joke, I just read a book about binary numbers and wanted to
    sound smart.
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 10 / 23


    View Slide

11. What's wrong with the way
    {shiny} works?
    Nothing, but let's take a step back
    What do I need when I build a web app?
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 11 / 23


    View Slide

12. What do I need when building a
    web app ?
     Multiple paths (real ones): /, /analysis, /results, /contact...
     Not load the whole app everytime
     Cookies
     Healtcheck
     HTTP method support (POST, PUT, DELETE, etc.)
     HTTP code support (200, 300, 400...)
     Tweak http requests and responses
    And many others things
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 12 / 23


    View Slide

13. But why would I want that?
    Serving static, pure HTML landing pages
    Being able to point to specific part of the app (not 'open the app, click there and there
    and see')
    Lower the load on the server by serving static HTML elements
    Monitor your app via healthcheck
    Identify the user when they come back to the app
    POST elements to the server
    Add a 404 page for unreachable pages
    Redirect pages to others
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 13 / 23


    View Slide

14. HERE COMES {BROCHURE}!


    View Slide

15. Previous works
    {blaze} https://github.com/nteetor/blaze
    {shiny.router} https://github.com/Appsilon/shiny.router
    => Not really multi-page, but "hack" your browser path by using URL fragments
    A Fragment URL Specifies A Location Within A Page
    Url fragments create history in your browser but don't reload the full page
    Are not sent as part of the http request (so it can be harder to log what's happening in
    the app)
    => Don't have all the features from the last slide
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 15 / 23


    View Slide

16. Basic brochure
    library(shiny)

    library(brochure)

    brochureApp(

    page(

    href = "/",

    ui = fluidPage(

    plotOutput("plot")

    ),

    server = function(input, output, session) {

    output$plot <- renderPlot({

    plot(iris)

    })

    }

    ),

    page(

    href = "/page2",

    ui = fluidPage(

    h1("This is my second page")

    )

    )

    )
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 16 / 23


    View Slide

17. About HTTP


    View Slide

18. log_where <- function(req) {

    cli::cat_rule(

    sprintf(

    "%s - %s",

    Sys.time(),

    req$PATH_INFO

    )

    )

    req

    }

    brochureApp(

    req_handlers = list(

    log_where

    )

    )
    Cookies, request and response
    handlers
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 18 / 23


    View Slide

19. Cookies, request and response
    handlers
    login <- function() {

    page(

    href = "/login",

    ui = tagList(

    h1("You've just logged!")

    ),

    server = function(input, output, session) {

    },

    res_handlers = list(

    ~ set_cookie(.x, "BROCHURECOOKIE", 12)

    )

    )

    }
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 19 / 23


    View Slide

20. brochureApp(

    # Pages

    page_1(),

    page_2(),

    page_contact(),

    page(

    href = "/check",

    ui = tagList(),

    # This req_handler will returns

    # an httpResponse, it will be

    # returned directly to the browser

    req_handlers = list(

    # Exported since shiny 1.6.0

    ~ shiny::httpResponse(

    200,

    content = "OK"

    )

    )

    )

    )
    > httr::GET('http://url/check')
    Response [http://url/check]
    Date: 2022-02-16 12:19
    Status: 200
    Content-Type: text/html;
    charset=UTF-8
    Size: 2 B
    Simple healthcheck
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 20 / 23


    View Slide

21. Demo time
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 21 / 23


    View Slide

22. 📖 engineering-shiny.org/
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 22 / 23


    View Slide

23. Thx! Questions?
    Find me Online
    colin@thinkr.fr
    https://twitter.com/_colinfay
    https://twitter.com/thinkr_fr
    https://github.com/ColinFay
    https://thinkr.fr/
    https://rtask.thinkr.fr/
    https://colinfay.me/
    Colin FAY (@_ColinFay) - https://rtask.thinkr.fr 23 / 23


    View Slide
