  1. White Paper
    Foundstone Services
    TeslaCrypt Uncovered
    By Thomas Roccia

    View Slide

  2. White Paper
    2
    TeslaCrypt Uncovered – Thomas Roccia
    Table of Contents
    Introduction ............................................................................................................................................................................................................................ 3
    Teslacrypt Presentation .................................................................................................................................................................................................... 3
    Teslacrypt Protection ......................................................................................................................................................................................................... 4
    A brief overview of TeslaCrypt capabilities ........................................................................................................................................................... 11
    Conclusion ............................................................................................................................................................................................................................. 16
    Table of Figures
    Figure 1. CreateProcess in packed TeslaCrypt .................................................................................................................... 5
    Figure 2. GetThreadContext in packed TeslaCrypt .............................................................................................................. 5
    Figure 3. GetThreadContext in packed TeslaCrypt .............................................................................................................. 6
    Figure 4. VirtualAlloc in packed TeslaCrypt ........................................................................................................................ 7
    Figure 5. Breakpoint at VirtualAlloc .................................................................................................................................... 7
    Figure 6. Follow in dump the allocation of the PE ............................................................................................................... 8
    Figure 7. Breakpoint on memory space .............................................................................................................................. 8
    Figure 8. PE on memory space ............................................................................................................................................ 9
    Figure 9. Save memory data to file ..................................................................................................................................... 9
    Figure 10. PE in Buffer in WriteProcessMemory ............................................................................................................... 10
    Figure 11. PE unpacked File header .................................................................................................................................. 11
    Figure 12. PE packed File header ....................................................................................................................................... 11
    Figure 13. SeDebugPrivilege ............................................................................................................................................. 12
    Figure 14. IsDebuggerPresent ........................................................................................................................................... 13
    Figure 15. FindFirstFile ...................................................................................................................................................... 14
    Figure 16. FindNextFile ..................................................................................................................................................... 14
    Figure 17. HttpSendRequest ............................................................................................................................................. 15

    View Slide

  3. White Paper
    3
    TeslaCrypt Uncovered – Thomas Roccia
    Introduction
    Cybercrime and malware are becoming more and more complex to steal more money. We recently saw
    an increase of ransomware cases. Ransomware is a malware that hijacks your data in exchange of a
    ransom. At the beginning ransomware were not sophisticated and did not use encryption. The access
    to the computer was only blocked but data could be recovered, we talked about “Locker Ransomware”.
    Then attackers improve their techniques with the use of encryption, “Crypto Ransomware”. These kind
    of ransomware targets specific valuable data stored on the computer and encrypt data with strong
    encryption algorithm. Making thereof unusable without the decryption key.
    Ransomware attack is a very successful attack, and allows attackers to steal lot of money with a minimal
    risk. Coupled with the development of anti-analysis technique, the complexity of this malware is still
    growing.
    This paper talk about a short analysis of TeslaCrypt v4, the last release of infamous ransomware.
    Teslacrypt Presentation
    TeslaCrypt is a ransomware released for the first time in February 2015. It finds and encrypt your data
    then print a message to inform you that your data has been encrypted and is unusable unless you pay
    to get the decryption key.
    The first releases of TeslaCrypt were not properly built. As the encryption algorithm was not correctly
    implemented security researchers were able to create decryption tools.
    In November 2015, the TeslaCrypt version 2 had also some issues, attackers released the version 3 in
    January 2016 to correct these issues. With this version, the data was not recoverable.
    Then in March 2016, the last version released: the version 4. With this version the encryption files keep
    their original extension and a new name is implemented to the recover files.
    This latest version don’t allow to decrypt files. TeslaCrypt is now stronger than ever.

    View Slide

  4. White Paper
    4
    TeslaCrypt Uncovered – Thomas Roccia
    Teslacrypt Protection
    Lot of malwares use protection tricks to trap the analyst and make difficult the reverse engineering
    and the detection. We will see in this section how to recover the original sample file.
    The packing technique is commonly used to protect itself the sample. Common packer could be easily
    to detect and to use to get the original file. However in many case attackers uses custom packer to
    avoid recovery.
    In this case, a custom packer is used with multiple decryption and the use of process hollowing
    technique. Process hollowing is a common technique that inject a malicious code in a suspended
    process.
    So to use process hollowing, attackers uses the following Api:
    x CreateProcess: in a suspended mode with the CreationFlag at 0x0000 0004.
    x GetThreadContext: retrieves the context of the specified thread.
    x ZwUnmapViewOfSection: Unmaps a view of a section from the virtual address space of a
    subject process.
    x VirtualAllocEx: allocates memory within the suspended process’s address space.
    x WriteProcessMemory: writes data of the PE file into the memory just allocated within the
    suspended process.
    x SetThreadContext: sets the EAX register to the entry point of the executable written.
    x ResumeThread: resumes the thread of the suspended process.

    View Slide

  5. White Paper
    5
    TeslaCrypt Uncovered – Thomas Roccia
    We can find these functions in the packed TeslaCrypt:
    Figure 1. CreateProcess in packed TeslaCrypt
    Figure 2. GetThreadContext in packed TeslaCrypt

    View Slide

  6. White Paper
    6
    TeslaCrypt Uncovered – Thomas Roccia
    The prototype is:
    BOOL WINAPI GetThreadContext(
    _In_ HANDLE hThread,
    _Inout_ LPCONTEXT lpContext
    );
    Then we can see the call of ZwUnmapViewOfSection:
    Figure 3. GetThreadContext in packed TeslaCrypt
    The prototype is:
    NTSTATUS ZwUnmapViewOfSection(
    _In_ HANDLE ProcessHandle,
    _In_opt_ PVOID BaseAddress
    );

    View Slide

  7. White Paper
    7
    TeslaCrypt Uncovered – Thomas Roccia
    Then the VirtualAlloc function:
    Figure 4. VirtualAlloc in packed TeslaCrypt
    LPVOID WINAPI VirtualAlloc(
    _In_opt_ LPVOID lpAddress,
    _In_ SIZE_T dwSize,
    _In_ DWORD flAllocationType,
    _In_ DWORD flProtect
    );
    We can here dump the unpacked file loaded in the memory after the 4th hit of VirtualAlloc.
    We can see the VirtualAlloc API by hit CTRL+G and enter “VirtualAlloc”:
    Figure 5. Breakpoint at VirtualAlloc

    View Slide

  8. White Paper
    8
    TeslaCrypt Uncovered – Thomas Roccia
    By pressing F9 we hit the breakpoint, then we return to usercode, and follow the register EAX in memory.
    Figure 6. Follow in dump the allocation of the PE
    We have now in memory pan an empty space which will be fill by the function. We can setup a hardware
    breakpoint to see what’s happened.
    Figure 7. Breakpoint on memory space

    View Slide

  9. White Paper
    9
    TeslaCrypt Uncovered – Thomas Roccia
    Then we press F9 to check the file dropped in the memory space. Here we see the memory during
    each hit of VirtualAlloc. The sample unpacked is the last one.
    Figure 8. PE on memory space
    We can dump this one for analysis with “save data to file”.
    Figure 9. Save memory data to file
    Invalid PE Valid PE
    but still packed
    Valid PE
    unpacked

    View Slide

  10. White Paper
    10
    TeslaCrypt Uncovered – Thomas Roccia
    At this point we have a valid unprotected PE.
    The other way to dump quickly the PE without hit each VirtualAlloc is to setup a breakpoint at
    WriteProcessMemory API and follow in memory the buffer.
    Figure 10. PE in Buffer in WriteProcessMemory
    BOOL WINAPI WriteProcessMemory(
    _In_ HANDLE hProcess,
    _In_ LPVOID lpBaseAddress,
    _In_ LPCVOID lpBuffer,
    _In_ SIZE_T nSize,
    _Out_ SIZE_T *lpNumberOfBytesWritten
    );
    With the valid unprotected PE we can now analysis it to better understand his behavior.

    View Slide

  11. White Paper
    11
    TeslaCrypt Uncovered – Thomas Roccia
    A brief overview of TeslaCrypt capabilities
    After unpacked the file we can find more interesting information.
    The original date of compilation can be found the March 18 2016 at 09:37:49 UTC.
    Figure 11. PE unpacked File header
    The date before the unpacking was the February 22 2007 at 5:38:20 UTC.
    Figure 12. PE packed File header
    Metadata:
    File Name unpackTesla.mem
    File Size 249856 bytes
    File Type PE32 executable (GUI) Intel 80386, for MS Windows
    Md5 ea3ccdd7c69b5e1a18c473d937c68c37
    Ssdeep 6144:NSMPQFF58b1H2towR74r7kLeY4U3HUck:NSJFF41H2to07475A0

    View Slide

  12. White Paper
    12
    TeslaCrypt Uncovered – Thomas Roccia
    Malware uses some trick to elevate their privilege one of this trick is to use the SeDebugPrivilege, which
    attribute the System privilege to the malware. The following screenshot shows how it’s working.
    Figure 13. SeDebugPrivilege
    When the sample is running, it enables the SeDebugPrivilege by setting an access token right. An access
    token is an object containing the security descriptor of a process. The sample uses the functions
    OpenProcessToken and LookupPrivilegeValue to get the LUID (Local Unique Identifier) and check the
    privilege SeDebugPrivilege.
    Then the sample used the function AdjustTokenPrivilege for setting the token. The SeDebugPrivilege
    is normally used for system level debugging but it is also a trick used by malware coder to gain access
    to system level process.

    View Slide

  13. White Paper
    13
    TeslaCrypt Uncovered – Thomas Roccia
    The malware also uses some anti-debugging technique; we can find the API IsDebuggerPresent that
    check if the process is being debugged or not.
    Figure 14. IsDebuggerPresent
    If the debugger is detected the sample terminate the process, and never call the rest of the code.
    Debugger detection
    Rest of the code
    Terminate process if
    debugger is detected

    View Slide

  14. White Paper
    14
    TeslaCrypt Uncovered – Thomas Roccia
    To browse the disk and find all the file to encrypt, the sample use both API, FindFirstFile and FindNextFile.
    Figure 15. FindFirstFile
    Figure 16. FindNextFile

    View Slide

  15. White Paper
    15
    TeslaCrypt Uncovered – Thomas Roccia
    To connect with the remote IP and register the infected machine, the function HttpSendRequest is used.
    Figure 17. HttpSendRequest
    The sample try to connect to the following IP.
    Domain Ip
    resumosdenovela.net 108.167.185.237
    classemgmt.testbada.com 115.94.157.252
    shampooherbal.com 104.128.239.91
    exaltation.info 46.235.47.104
    commonsenseprotection.com 50.116.109.230
    ebookstoreforyou.com 87.229.77.69

    View Slide

  16. White Paper
    16
    TeslaCrypt Uncovered – Thomas Roccia
    During the analysis we found some part of code referring to a Bitcoin foundation github project (secp256k1).
    (https://github.com/bitcoin/secp256k1)
    The Secp256k1 is used in Bitcoin and defined in Standards for Efficient Cryptography.
    (https://en.bitcoin.it/wiki/Secp256k1)
    We can find the code above at this address:
    https://github.com/bitcoin/secp256k1/blob/master/src/secp256k1.c
    Conclusion
    This short paper briefly presents some functionalities of TeslaCrypt and brings an overview of its capacities.
    With the increasing development of cybercrime, ransomware gain in strength and become more complex
    and powerful. As we know TeslaCrypt is still active and developers continue to improve their code in order
    to gain more money.
    The best way to avoid infection is still to educate users but also to do regular backups.
    To be continued…
