greenDAO2ObjectBox

Links
Sample code
- https://github.com/kaelaela/greenDAO2ObjectBox

ObjectBox press release
- http://greenrobot.org/announcement/introducing-objectbox-beta/

ObjectBox repo
- https://github.com/greenrobot/ObjectBox

Transcript

1. greenDao2ObjectBox
   @kaelaela(Yuichi Maekawa)
   Work @ CyberAgent
   Twitter : kaelaela31
   Github : kaelaela


   View Slide

2. Agenda
   ● What is greenDAO and ObjectBox
   ● How to convert greenDAO to ObjectBox


   View Slide

3. What is greenDAO and ObjectBox
   ● Made by greenrobot
   ● SQLite database
   ● ORM
   ● Based on code generation


   View Slide

4. ● Since 2011
   ● ~ v2 :Need to make yourself DAOgenerator
   ● v3 ~ : Enable annotation
   ● Latest version is v3.2.1


   View Slide

5. ● Two Important concept
   ○ Schema: create db and make all tables and entities
   ○ Entity: add properties and relations to POJO
   ● Daos and entiries are generated by DaoGenerator


   View Slide

6. v2 architecture
   DaoGenerator: generated class. Do not white code.
   DaoMaster: generated class. Use to get settion.
   DaoSession: generated class. Use to get dao.
   EntityDao: generated class. CRUD from database.
   Entity: generated entity(It has getter/setter. Editable)


   View Slide

7. v3 architecture
   DaoGenerator: generated class. Do not white code.
   DaoMaster: generated class. Use to get settion.
   DaoSession: generated class. Use to get dao.
   EntityDao: generated class. CRUD from database.
   Entity: your entity. Annotate this. And generate code into this.


   View Slide

8. ● A new database based on greenDAO
   ● Do not use SQLite
   ● Pretty fast
   ● Latest version is v0.9.7(beta)


   View Slide

9. ObjectBox
   ● Important concept
   ○ Object(POJO)
   ○ Box
   ○ BoxStore(like db)
   Memo Box
   Memo
   object


   View Slide

10. ObjectBox
    ● Important concept
    ○ Object(POJO)
    ○ Box
    ○ BoxStore(like db)
    Memo Box


    View Slide

11. ObjectBox
    ● Important concept
    ○ Object(POJO)
    ○ Box
    ○ BoxStore(like db) Memo Box some Box
    some Box
    some Box
    BoxStore


    View Slide

12. v0.9.7(beta) architecture
    ● MyObjectBox: build BoxStore
    ● BoxStore: provide box for your object. Likes database.
    ● default.json: crucial ids here. Do not touch.
    ● Memo: your entity. Generated CRUD methods into this.
    ● Memo_: Property class. It is used to access member
    (ex. Memo_.id)


    View Slide

13. interface
    box.put(memo); //insert, update
    box.remove(memo);
    box.getAll();
    box.query().equal(Memo_.content, "test").build().find();


    View Slide

14. Convert to ObjectBox(from v3)
    http://greenrobot.org/objectbox/documentation/introduction/
    > Have an app with greenDAO? DaoCompat is for you!
    DaoCompat is an compatibility layer that gives you an greenDAO like API for
    ObjectBox.
    http://greenrobot.org/news/objectbox-presentation-thank-you/
    > For existing apps using greenDAO
    Easy switch to ObjectBox


    View Slide

15. Convert to ObjectBox(from v3)
    http://greenrobot.org/objectbox/documentation/introduction/
    > Have an app with greenDAO? DaoCompat is for you!
    DaoCompat is an compatibility layer that gives you an greenDAO like API for
    ObjectBox.
    http://greenrobot.org/news/objectbox-presentation-thank-you/
    > For existing apps using greenDAO
    Easy switch to ObjectBox


    View Slide

16. Good news. Let’s try it.


    View Slide

17. Build setting
    buildscript {
    repositories {
    maven { url "http://objectbox.net/beta-repo/" }
    }
    }
    dependencies {
    classpath 'io.objectbox:objectbox-gradle-plugin:0.9.7'
    }
    allprojects {
    repositories {
    maven { url "http://objectbox.net/beta-repo/" }
    }
    }


    View Slide

18. Build setting
    apply plugin: 'io.objectbox'
    dependencies {
    compile 'org.greenrobot:greendao:3.2.0'
    compile 'io.objectbox:objectbox-android:0.9.7'
    compile 'io.objectbox:objectbox-daocompat:0.9.7'
    }
    objectbox {
    daoCompat true
    }


    View Slide

19. Replace annotations
    ● File paths are chended
    org.greenrobot.greendao.annotation
    > io.objectbox.annotation
    ● Relpace @ToOne @ToMany annotations with @Relation


    View Slide

20. Initialize MyObjectBox in Application
    @Override public void onCreate() {
    super.onCreate();
    boxStore = MyObjectBox.builder().androidContext(this).build();
    //use to old interface
    daoSession = new DaoSession(boxStore);
    }
    public BoxStore getBoxStore() {
    return boxStore;
    }
    public BoxStore getDaoSession() {
    return daoSession;
    }


    View Slide

21. That’s all.
    Let’s build!!


    View Slide

22. View Slide

23. It is not work yet well.
    And source code is not public
    Wait for v1.


    View Slide

24. Sample code
    https://github.com/kaelaela/greenDAO2ObjectBox


    View Slide

25. See you next version released!


    View Slide
