May the force be with your Java applications - they can start more rapidly and run faster! [Devoxx Morocco 2023]

"May the force be with your Java Applications"
- they can start more rapidly and run faster! -

These slide decks were used at Devoxx Morocco 2023.

Transcript

1. May the force be with your Java applications - they can start more rapidly and run faster! NISHIKAWA, Akihiro (@logico_jp) Cloud Solution Architect Microsoft
2. Who am I? { "name": "Akihiro Nishikawa", "country": "Japan", "favourites": [ "JVM", "GraalVM", "Azure" ], "expertise": [ "Application integration", "Container and Serverless" ] }
3. Agenda  Why startup gets important  Startup procedure of Java Applications  Options to improve startup time  Future
4. Why startup gets important
5. Performance... Startup CPU Usage Throughput Latency Size Memory footprint
6. Situation changed I understand all aspects are important, of course  Startup Latency Throughput Footprint Java applications (Run on App Servers)) △ ◎ ◎ ◦ Serverless applications and autoscaling containers ◎ ◎ ◎ ◎
7. Serverless adoption Source : The Future of Java by Mark Little – YouTube [Devoxx UK 2022] 1. Node.js (62.9%) 2. Python (20.8%) 3. Go (6.4%) 4. Java (6.1%) 5. C# (3.8%)
8. Startup procedure
9. Startup What happens in starting Java applications? JVM • Load and Initialize • Generate bytecode templates JVM • Load application classes • Initialize application classes • Application specific initialization JVM • Compile/deoptimize/recompile Application • Process specific workloads JVM Startup Application Startup Application Warmup Fast Quick Long time
10. Life cycle (image) CL: class loading JIT: JIT compilation GC: garbage collection
11. Tiered compilation C1 (a.k.a. client compiler)  Shorter time to compile  Not so highly optimized  Not so better throughput C2 (a.k.a. server compiler)  Longer time to compile  Highly optimized  Better throughput
12. Compilation Level C1 full optimization (no profiling) C1 with invocation and back-edge counters C1 full profiling (level2 + MDO: MethodDataOop) 0 1 2 3 4 C1 Interpreter C2
13. Compilation Level 0 1 2 3 4 Normal path Delayed due to C2 capacity C1 Interpreter C2 0 1 2 3 4 Deoptimization
14. Method compilation life cycle Run Interpreter C1 C2 Code cache Save C1 compiled code(s) Save C2 compiled code(s) Profiling Profiling Deoptimization Deoptimize compiled code Interpret and profile
15. Thresholds static bool apply_scaled(const methodHandle& method, CompLevel cur_level, int i, int b, double scale) { double threshold_scaling; if (CompilerOracle::has_option_value(method, CompileCommand::CompileThresholdScaling, threshold_scaling)) { scale *= threshold_scaling; } switch(cur_level) { case CompLevel_none: case CompLevel_limited_profile: return (i >= Tier3InvocationThreshold * scale) || (i >= Tier3MinInvocationThreshold * scale && i + b >= Tier3CompileThreshold * scale); case CompLevel_full_profile: return (i >= Tier4InvocationThreshold * scale) || (i >= Tier4MinInvocationThreshold * scale && i + b >= Tier4CompileThreshold * scale); default: return true; } } jdk/src/hotspot/share/compiler/compilationPolicy.cpp at jdk-21+35 · openjdk/jdk (github.com)
16. Thresholds static bool apply_scaled(const methodHandle& method, CompLevel cur_level, int i, int b, double scale) { double threshold_scaling; if (CompilerOracle::has_option_value(method, CompileCommand::CompileThresholdScaling, threshold_scaling)) { scale *= threshold_scaling; } switch(cur_level) { case CompLevel_none: case CompLevel_limited_profile: return (i >= Tier3InvocationThreshold * scale) || (i >= Tier3MinInvocationThreshold * scale && i + b >= Tier3CompileThreshold * scale); case CompLevel_full_profile: return (i >= Tier4InvocationThreshold * scale) || (i >= Tier4MinInvocationThreshold * scale && i + b >= Tier4CompileThreshold * scale); default: return true; } } jdk/src/hotspot/share/compiler/compilationPolicy.cpp at jdk-21+35 · openjdk/jdk (github.com) case CompLevel_limited_profile: return (i >= Tier3InvocationThreshold * scale) || (i >= Tier3MinInvocationThreshold * scale && i + b >= Tier3CompileThreshold * scale); case CompLevel_full_profile: return (i >= Tier4InvocationThreshold * scale) || (i >= Tier4MinInvocationThreshold * scale && i + b >= Tier4CompileThreshold * scale);
17. Thresholds # of Executions > TierXInvocationThreshold * Scale # of Executions > TierXMinInvocationThreshold * Scale AND # of Executions + # of Iterations > TierXCompileThreshold * Scale OR Level 3 Level 4 TierXInvocationThreshold 200 5_000 TierXMinInvocationThreshold 100 600 TierXCompileThreshold 2_000 15_000
18. $ java -XX:+PrintFlagsFinal \ –version | grep Threshold
19. $ java -XX:+PrintFlagsFinal -version | grep Threshold intx CompileThreshold = 10000 {pd product} {default} double CompileThresholdScaling = 1.000000 {product} {default} double G1PeriodicGCSystemLoadThreshold = 0.000000 {manageable} {default} uintx G1SATBBufferEnqueueingThresholdPercent = 60 {product} {default} uintx IncreaseFirstTierCompileThresholdAt = 50 {product} {default} uintx InitialTenuringThreshold = 7 {product} {default} size_t LargePageHeapSizeThreshold = 134217728 {product} {default} uintx MaxTenuringThreshold = 15 {product} {default} size_t PretenureSizeThreshold = 0 {product} {default} uint StringDeduplicationAgeThreshold = 3 {product} {default} double SweeperThreshold = 15.000000 {product} {default} uintx ThresholdTolerance = 10 {product} {default} intx Tier2BackEdgeThreshold = 0 {product} {default} intx Tier2CompileThreshold = 0 {product} {default} intx Tier3BackEdgeThreshold = 60000 {product} {default} intx Tier3CompileThreshold = 2000 {product} {default} intx Tier3InvocationThreshold = 200 {product} {default} intx Tier3MinInvocationThreshold = 100 {product} {default} intx Tier4BackEdgeThreshold = 40000 {product} {default} intx Tier4CompileThreshold = 15000 {product} {default} intx Tier4InvocationThreshold = 5000 {product} {default} intx Tier4MinInvocationThreshold = 600 {product} {default} openjdk version "21" 2023-09-19 OpenJDK Runtime Environment (build 21+35-2513) OpenJDK 64-Bit Server VM (build 21+35-2513, mixed mode, sharing)
20. Startup time and performance - Fibonacci numbers // java Fib.java 45 --> 45th number is 1_134_903_170 // -XX:+UseG1GC -Xmx2g -Xms2g -XX:+UseStringDeduplication public class Fib { public static void main(String... args) { long num = 0; if(args.length != 1) return; num = Long.valueOf(args[0]); System.out.printf("%d(st/nd/rd/th) >> %d\n", num, fib(num)); } static long fib(long n) { if(n < 2) return n; return fib(n - 2) + fib(n - 1); } }
21. Results (seconds) AMD 3rd EPYCTM 7763v (8 vcpus, 32 GiB memory) Java 17.0.8 Java 21 GraalVM 23.1 (Java 21) Compile Run Compile Run Compile Run Interpreter only N/A 250.315 N/A 143.185 N/A 143.750 C1 Only (no profiling in Interpreter) 0.390 4.597 0.381 5.183 0.163 4.945 C2 Only (no profiling in C1) 3.961 7.803 5.585 10.117 3.655 6.941 Tiered compilation (Interpreter  C1) 0.009 4.141 0.012 4.717 0.022 4.758 Tiered compilation (Interpreter  C1  C2) C1: 0.009 C2: 0.002 3.542 C1: 0.011 C2: 0.005 4.094 C1: 0.052 C2*: 0.053 3.254 (*) Regarding GraalVM, not C2 but JVMCI-native compiler is used.
22. Options to improve startup time
23. Custom JRE C1 only AOT compilation Warm up in advance Code cache Checkpoint CDS Archive JIT Centralization
24. 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined C1 Native CRaC Startup time ratio (Base=100, smaller is better) 99P 95P 90P 50P Average
25. Benchmark environment Allocation per container vCore: 2 RAM: 4GiB JDK 17 (17.0.8.1) GC : G1 Max heap : 75% allocation Application framework Micronaut 4.1.3 Option +UseStringDeduplication Other options might be specified in each case. Measurement Run 1000 times Average / Percentile (50, 90, 95, 99)
26. Baseline java -XX:+UseG1GC \ -XX:MaxRAMPercentage=75 \ -XX:InitialRAMPercentage=75 \ -XX:+UseStringDeduplication \ -jar App.jar
27. Improve class loading Custom JRE CDS Archive
28. Custom JRE Reduce the number of classes to be loaded. jdeps jdeps –R \ -cp "target/lib/*" \ --print-module-deps \ --ignore-missing-deps \ --multi-release 17 \ target/App.jar # java.base,java.compiler, # java.desktop,java.management, # java.naming,java.sql,java.xml, # jdk.unsupported jlink jlink --compress=2 \ --module-path $JAVA_HOME/jmods \ --add-modules \ java.base, java.compiler,\ java.desktop, java.management,\ java.naming, java.sql, \ java.xml, jdk.unsupported \ --no-header-files \ --no-man-pages \ --output linked Custom JRE
29. Result 99% 100% 101% Base jlink 99P 95P 90P 50P Average Custom JRE
30. Benefits and cautions Benefits  Startup time and memory footprint are improved since the number of classes to be loaded is decreased. Cautions  A little bit efforts are required to create custom JRE (e.g., Multi-stage build to create container image).  Note that jdeps sometimes does not find dependency modules like jdk.crypto.ec. Custom JRE
31. CDS Archive Change the way to load classes  App CDS (JEP 310 / JDK 10)  Application Class Data Sharing (AppCDS) stores classes used by your applications in an archive file. (The java Command (oracle.com))  Default CDS (JEP 341 / JDK 12)  Created at the JDK build time by running -Xshare:dump, using G1 GC and 128M Java heap (Oracle JDK / Class Data Sharing (oracle.com))  Dynamic CDS (JEP 350 / JDK 13)  Dynamic CDS archive extends application class-data sharing (AppCDS) to allow dynamic archiving of classes when a Java application exits. (Class Data Sharing (oracle.com)) CDS Archive
32. # Create Static CDS archive $java -Xshare:off \ -XX:DumpLoadedClassList=<ClassFileList> -jar app.jar $java -Xshare:dump -XX:SharedArchiveFile=<Archive> \ -XX:SharedClassListFile=<ClassFileList> # Create Dynamic CDS archive at exiting application $ java -XX:ArchiveClassesAtExit=<Archive> -jar app.jar # Use the CDS archive with application $ java -XX:SharedArchiveFile=<Archive> -jar app.jar # Create CDS Archive automatically (since JDK 19) $ java -XX:+AutoCreateSharedArchive \ –XX:SharedArchiveFile=<Archive> -jar app.jar CDS Archive Other options are found in The java Command (oracle.com)
33. Result (Static CDS only) 75% 80% 85% 90% 95% 100% 105% Base jlink CDS 99P 95P 90P 50P Average CDS Archive
34. Result (Static & Dynamic CDS w/ training) 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined 99P 95P 90P 50P Average CDS Archive
35. Benefits and cautions Benefits  Improve time to load classes.  Available in any platforms  Can coexist Dynamic CDS and static CDS.  Can use CDS archives with custom JRE. Cautions  As applications are updated, we have to recreate CDS archive. CDS Archive
36. Note  Neither -Xverify:none nor –noverify is used  Deprecated since JDK 13 and will be removed in the future release. [JDK-8218003] Release Note: Deprecated Java Options -Xverify:none and -noverify - Java Bug System (openjdk.org)  For users who need to run without startup verification  AppCDS allows us to archive their classes. The classes are verified during archiving and avoid verification at runtime.
37. Use only C1 without profiling -XX:TieredStopAtLevel=1  JVM selects C2 by default when CPU on the platform is multi-core processors or using 64-bit VMs.  If using only C1,  There is no profiling overhead.  You will get better performance than when profiling is enabled. C1 only
38. Result 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined C1 99P 95P 90P 50P Average C1 only
39. Benefits and cautions Benefits  Short-live applications can gain benefits.  As no profiling occurs, startup time will be reduced.  Custom JRE, CDS archive, and this can be used together. Cautions  This setting is not useful for long running applications, since such applications should leverage code generated by C2, which is highly optimized. C1 only
40. Offloading JIT compilation AOT compilation JIT Centralization
41. AOT (Ahead of time) compilation  Resolve dependencies and compile codes at build time.  JDK 9-17: experimental (deprecated and removed)  JDK Support  GraalVM (Native Image)  Azul Zulu  OpenJ9, etc.  Development framework support  Micronaut  Spring Boot AOT compilation
42. Generic Micronaut Spring Boot $ mvn -Pnative spring-boot:build-image $ gradle bootBuildImage # Using Native Build Tools $ mvn -Pnative native:compile $ gradle nativeCompile $ native-image App.class $ native-image -jar App.jar $ mvn package -Dpackaging=native-image $ gradle nativeCompile
43. Result GraalVM Native Image 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined C1 Native 99P 95P 90P 50P Average AOT compilation
44. Result GraalVM Native Image 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined C1 Native 99P 95P 90P 50P Average AOT compilation 1.50% 1.55% 1.60% 1.65%
45. Result AOT enabled Framework 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base Base+framework AOT support jlink CDS CDS Combined C1 Native Native+ framework AOT support 99P 95P 90P 50P Average AOT compilation
46. Result AOT enabled Framework (Base) 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base Base+framework AOT support jlink CDS CDS Combined C1 Native Native+ framework AOT support 99P 95P 90P 50P Average AOT compilation 99.0% 99.2% 99.4% 99.6% 99.8% 100.0% 100.2% Base Base+framework AOT support
47. Result AOT enabled Framework (Native) 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base Base+framework AOT support jlink CDS CDS Combined C1 Native Native+ framework AOT support 99P 95P 90P 50P Average AOT compilation 1.35% 1.40% 1.45% 1.50% 1.55% 1.60% 1.65% 1.70% Native Native+ framework AOT support
48. Benefits and cautions Benefits  Applications can start rapidly.  Lower memory footprint and other advantages Cautions  AOT compilation support  Neither all application development frameworks nor all distributions support AOT.  Especially GraalVM Native Image,  Hardware/Platform (CPU/OS) specific  Long build time  As of now, generated executables are not suitable for long running.  A little bit effort is required for reflection support. AOT compilation
49. 2) Centralized JIT  Offloading JIT compilation to other environment, which returns compiled codes to runtime environment (e.g., containers), to improve startup time of applications.  OpenJ9 JITServer (Eclipse OpenJ9)  JITServer technology - (eclipse.dev)  Azul Cloud Native Compiler  Java Compilation in the Cloud | Cloud Native Compiler (azul.com) JIT Centralization
50. Concept  Ordinally JIT compilation runs in each JVM. VM or Containers VM or Containers VM or Containers VM or Containers VM or Containers VMs or Containers Java Application JVM JIT Compilation JIT Centralization
51. Concept  JIT compilation runs in dedicated JVM instance.  Each JVM instance communicates with the JIT JVM instance. VM or Containers VM or Containers VM or Containers VM or Containers VM or Containers VMs or Containers Java Application JVM JIT Compilation Dedicated JVM instance(s) for JIT compilation JIT Compilation Request compilation   Return generated codes JIT Centralization
52. Benefits and cautions Benefits  Java applications could run on smaller resources.  Especially useful for apps running on containers.  Might allocate smaller CPU core and memory to each container  With caching compiled code in the dedicated JIT server instance, JIT compilation might be faster. Cautions  Network latency (recommends to use along with Kubernetes)  Might not be suitable for super short-live applications  Not all distributions are supported. JIT Centralization
53. Short-cut to reach peak performance Warm up in advance Code cache Checkpoint
54. Use profiled data to warmup applications  JWarmup (Alibaba Dragonwell) JEP draft: JWarmup precompile java hot methods at application startup (openjdk.org)  Azul ReadyNow! (Azul) ReadyNow!® - Azul | Better Java Performance, Superior Java Support Train applications
55. Benefits and cautions Benefits  No code change is required since characteristics of Java JIT compiler are leveraged to increase startup time. Cautions  Not all distributions are supported.  Depending upon distributions, how to provide/collect profile log/data is different. [ReadyNow!]  -XX:ProfileLogIn=<file>  -XX:ProfileLogOut=<file> [JWarmup]  -XX:CompilationWarmUpLogFile=<file> Train applications
56. Use code cache  Compile Stashing (Azul) Using Compile Stashing (azul.com)  Dynamic AOT and Shared Class Cache (OpenJ9) AOT Compiler - (eclipse.dev) Introduction - (eclipse.dev) Use code cache
57. Benefits and cautions Benefits  Reduce startup time, especially compilation time.  Code cache along with warm up feature might allow us to run applications faster and gain optimized codes. Cautions  Not all distributions are supported. Use code cache
58. Use checkpoints  CRIU (Checpoint/Restore in Userspace) CRIU support - (eclipse.dev)  CRaC (Coordinate Restore at Checkpoint) Java on CRaC - Optimize JVM Start-Up | Azul Use checkpoint
59. CRaC (Coordinate Restore at Checkpoint) Bypassed Application start point
60. Please note that... "CRaC implementation creates the checkpoint only if the whole Java instance state can be stored in the image. Resources like open files or sockets are cannot, so it is required to release them when checkpoint is made. CRaC emits notifications for an application to prepare for the checkpoint and return to operating state after restore." https://github.com/CRaC/docs Use checkpoint
61. CRaC # 1. Start an application in the checkpoint mode. $JAVA_HOME/bin/java \ -XX:CRaCCheckpointTo=<CheckPointFileDir> -jar App.jar # 2. After warm up, Request checkpoint jcmd App.jar JDK.checkpoint # 3. Restore the snapshot $JAVA_HOME/bin/java -XX:CRaCRestoreFrom=<CheckPointFileDir> Use checkpoint
62. Result 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined C1 Native CRaC 99P 95P 90P 50P Average Use checkpoint
63. Result 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS C1 CRaC Native 99P 95P 90P 50P Average Use checkpoint 0.00% 2.00% 4.00% 6.00% 8.00% Native CRaC
64. Benefits and cautions Benefits  Work well for containers.  Startup time is quite short. Cautions  Strictly same dependencies and environment between executions is required.  Project is undergoing.  Privilege operation is required.  Some efforts to capture checkpoint (Automation is a key...) Use checkpoint
65. 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 110% Base jlink CDS CDS Combined C1 Native CRaC Startup time ratio (Base=100, smaller is better) 99P 95P 90P 50P Average
66. Future
67. Project Leyden openjdk.org/projects/leyden  Goal  Improve the startup time, time to peak performance, and footprint of Java programs.  Focus  Standardize AOT for Hotspot JVM  Start native, but support and optimize dynamic stuff later  Resources  Project Leyden - Capturing Lightning in a Bottle - YouTube  202308-Leyden-JVMLS.pdf (openjdk.org)  leyden-premain-petclinic-2023-09-12.pdf (openjdk.org)  Project Leyden By Brian Goetz - YouTube
68. Concept: Shifting computation Using both the existing features and newly added ones Dynamic CDS Archive Cached Code Archive classes and heap snapshot Static CDS Archive training data pre-compiled machine code We can use these techniques now!
69. Takeaways
70. Takeaways  We have several options to improve startup time.  Updating Java version is also another option.  Several projects to improve startup time are now on-going.  It is the most important to choose the most suitable technique based on characteristics and requirements of applications.
