Location-Based Navigation: QRCode Positioning and Navigation Integration

Rex Cammack and Paul Hunt
University of Nebraska Omaha
#nacis2015

Transcript

1. Loca%on-­‐Based  Naviga%on:    QRCode
   Posi%oning  and  Naviga%on
   Integra%on

   Rex  Cammack  and  Paul  Hunt
   University  of  Nebraska  Omaha


   View Slide

2. View Slide

3. Path
   •  Why  QRcodes
   •  Rendering  QRCodes
   •  Reading  QRCodes
   •  Naviga%on  System  Integra%on
   •  Current  State
   •  Future  Deployment


   View Slide

4. Why  QRcodes
   •  Flexibility
   •  Ease  of  Construc%on
   •  Scalability
   •  Data  types
   •  Low  Cost
   •  Thema%c
   •  Accepted
   •  Technology  Integra%on


   View Slide

5. Rendering  QRCodes
   •  Online  –  services
   – Free
   – Pay
   •  Types  of  code  make  a  different
   –  Color
   –  Themes
   •  Coding
   – Many  Libraries  in  many  Languages


   View Slide

6. Reading  QRCodes
   •  Camera  base
   –  Web  Apps  –  Mobile  Phone,  Web  Cam    or  Scanner
   –  Data  types    (hSp://goqr.me/)
   •  URL
   •  Text
   •  Vcard
   •  SMS
   •  Call
   •  Geolocate
   •  Event
   •  Email
   •  Wifi
   •  Really  any  type  of  text  based  data  you  want



   View Slide

7. Reading  QRCodes
   •  To  read  the  Graphic
   – A  Program  will  use  a  camera/scanner
   – The  program  processes  the  data
   •  Passes  the  data  through  an  open  access  image
   interpreter
   –  Local  or  outside
   •  Uses  it
   •  Passes  the  data  on  to  another  program


   View Slide

8. Naviga%on  System  Integra%on
   •  The  main  goal  for  this  research  and
   development  is  to  create  a  low  cost  solu%on
   to  posi%ons  inside  of  building  for  route
   naviga%on
   •  Class  Research  Project
   – Five  Students
   •  Sarah  Polachek,  Chris%na  Lee,  Laura  PickeS,  Travis
   Husman,  Stephen  Krupa


   View Slide

9. Naviga%on  System  Integra%on
   •  System  -­‐    a  PC  virtual  machine  lab  where
   students  have  a  computer  that  is  Virtualized
   with  their  own  web  server  and  ArcGIS  servers
   so^ware  configura%on.
   •  ArcSDE  to  connect  to  a  Enterprise  database


   View Slide

10. Naviga%on  System  Integra%on
    •  Build  Mapping  Services
    – WMS  WMTS  Cached    WFS  and  others
    •  Web  Applica%on  development
    – JavaScript  based  Dojo,  ArcGIS  API  for  Javascript
    and  others
    – Aptana,  WebStorm,  and  NotePad++
    •  ArcGIS  Server  is  installed  and  connected  to  IIS


    View Slide

11. Naviga%on  System  Integra%on
    •  System  Development
    •  Service  Design
    •  Service  Choices
    •  Web  applica%on  Development
    •  App  Development


    View Slide

12. Current  State
    – Students  have  design  abstract  campus  base  map  -­‐
    WMTS
    – Created  content  layers    -­‐  WMS
    •  They  are  also  looking  at  reflec%ve  Map  Design
    – Web  Development
    – A  Big  Issue  is  figuring  out  all  the  Client  and  Server
    side  func%ons  of  the  project
    – Tested  QRcode  reader  for  JavaScript:
    – Students  will  begin  crea%ng  encoded  QRcodes  for
    feature  .


    View Slide

13. Future  Deployment
    – Comple%ng  Web  App  and  Services    for  Project
    – Deploying  Web  App  for  Mobile  Phones
    – Conver%ng  WEB  App  to  App  for  Mobile  Phones



    View Slide

14. Thank  you  for  your  %me


    View Slide

15. Map  Year
    hSp://mapyear.org/
    ICA  -­‐Commission  on  Maps  and  Internet
    We  will  help
