Introduction to Google App Engine

An introduction to Google App Engine. Presented @ Google Developer Group North East.

https://www.eventbrite.co.uk/e/introduction-to-google-app-engine-tickets-26308106254

Transcript

1. View Slide

2. View Slide

3. View Slide

4. View Slide

5. View Slide

6. View Slide

7. flickr photos shared under a Creative Commons (BY) license


   View Slide

8. View Slide

9. Operating System
   Configurations
   Hardening
   Security Patches
   Tunning
   Scalability
   Maintenance
   Hardware Failures
   Applications
   Sharding
   Replication
   Indexes


   View Slide

10. View Slide

11. View Slide

12. We’re sorry
    Our servers are over capacity and certain pages may be temporarily
    unavailable. We’re working quickly to resolve the issue.


    View Slide

13. View Slide

14. View Slide

15. ○
    ○
    ○
    ○
    ○
    ○


    View Slide

16. View Slide

17. View Slide

18. View Slide

19. Java PHP Go
    Python


    View Slide

20. View Slide

21. Key id firstName lastName dateOfBirth age
    Person:1219989 1219989 John Smith 10/07/1976 40
    Person:1529889 1529889 Jane Doe 23/01/1985
    Person Kind vs. Table
    Indexed Property vs. Column
    Key vs.
    Primary key
    Entity vs. Row
    namespace:Kind:ancestor_path:id


    View Slide

22. Ancestor path
    [Person:GreatGrandpa, Person:Grandpa, Person:Dad, Person:Me]


    View Slide

23. View Slide

24. View Slide

25. View Slide

26. View Slide

27. View Slide

28. View Slide

29. Image Service
    Users Service
    Memcache Task Queues


    View Slide

30. View Slide

31. ○
    ○
    ○
    ○
    http://my-app.appspot.com
    http://admin.my-app.appspot.com
    http://v1.admin.my-app.appspot.com
    http://v2.admin.my-app.appspot.com


    View Slide

32. ○
    ○
    ○
    ○
    ○
    ○
    ○


    View Slide

33. View Slide

34. PaaS
    IaaS
    Flexibility Agility
    Your
    code
    Your
    code


    View Slide

35. View Slide

36. App Engine App Engine Flexible What VM means for customers
    Execution Environment
    Where the code runs
    Optimised Sandbox
    Secured
    0 to N scaling
    GA
    GCE VM-Based
    Docker containers based
    in Beta
    Flexibility
    Any language, framework, or library
    Performance
    Up to 32 vCPUS or 208 GB of mem
    Networking stack Custom Cloud Platform networking
    stack
    One network
    ● VPN, direct, carrier connection options
    ● Connect App Engine instances to Compute Engine on
    private network
    Load balancer
    Autoscaler
    Custom Cloud Load Balancer
    Cloud Autoscaler
    More control
    Configure lower-level infrastructure services as necessary
    NoSQL
    Tasks & cron
    Integrated Decoupled More control
    ● Access NoSQL Datastore from any compute product
    ● Utilize Task Queues or Pub/Sub to facilitate
    intra-project communication
    Managed runtime
    support
    constrained Fully open-source
    compliant
    New runtimes
    Managed Node.js, Python 3, Java 8, PHP, Go


    View Slide

37. • Docker images hosted on gcr.io
    • Pure openjdk8: deploy a jar
    • Springboot, Vertx, SparkJava, etc…
    • Simple app.yaml
    • Pure Servlet 3.1: deploy a war
    • Jetty9, collaboration with the Jetty project
    • Simple app.yaml
    • For GAE Standard Apps: Jetty9 +Sandbox compatibility layer
    • Run Standard apps as is,
    • needs appengine-web.xml


    View Slide

38. The Java 8 Runtime Dockerfile FROM gcr.io/google_appengine/openjdk8
    ADD myspringbootapp.jar /app
    app.yaml runtime: custom / java
    vm: true
    api_version: 1
    runtime_config:
    jdk: openjdk8
    The Java 8 / Jetty 9.3 Runtime Dockerfile FROM gcr.io/google_appengine/jetty9
    ADD root.war $JETTY_BASE/webapps/
    app.yaml runtime: custom / java
    vm: true
    api_version: 1
    runtime_config:
    jdk: openjdk8
    server: jetty9
    The Java 8 / Jetty 9.3 Compact
    Runtime Dockerfile FROM gcr.io/google_appengine/jetty9-compat
    ADD . /app/
    appengine-web.xml true


    View Slide

39. app.yaml now controls Java runtimes
    (The compat runtime
    still needs
    appengine-web.xml)
    runtime: java
    vm: true
    api_version: 1
    handlers:
    - url: .*
    script: dynamic
    resources:
    cpu: .5
    memory_gb: 1.3
    disk_size_gb: 10
    automatic_scaling:
    min_num_instances: 1
    max_num_instances: 20
    cool_down_period_sec: 60
    cpu_utilization:
    target_utilization: 0.5
    env_variables:
    OAUTH2_CALLBACK: http://your-project-id.appspot.com/oauth2callback
    LOG_PATH: /var/log/app_engine/custom_logs


    View Slide

40. New tooling
    • Cloud SDK
    • fingerprinting
    • deploy app.yaml configurations
    • Maven Plugin for Cloud SDK
    • Automatic staging phase for GAE sandbox compat applications
    • or put app.yaml and Dockerfile in src/main/appengine directory

    com.google.appengine
    gcloud-maven-plugin
    2.0.9.111.v20160527

    purejetty9vmtrue



    com.google.cloud.tools
    appengine-maven-plugin
    0.1.1-beta





    View Slide

41. View Slide

42. View Slide

43. ○
    ○
    ○
    ○
    ○
    ○
    ○
    ○
    ○
    ○


    View Slide

44. View Slide

45. View Slide

46. ○
    ○


    View Slide

47. View Slide

48. View Slide

49. git clone https://github.com/omerio/spring-boot-container-demo.git
    cd spring-boot-container-demo/
    mvn clean package
    mvn docker:build
    mvn exec:java
    mvn gcloud:deploy -Dgcloud.project=gde-demos -Dapp.version=v2


    View Slide

50. View Slide

51. View Slide

52. View Slide
