About us Celsus is analyzing medical images in order to
1) automate part of the radiology workflow to support faster decisions 2) reduce the risk of the errors Our team • Backend/frontend • Sales & Marketing • Data Team • ML team (11 ML engineers) -
Example - Mammography datasets © 2020, ООО “Медицинские скрининг системы”
4 Dataset 1 Classes: • Mass (malignant & benign) • Calcifications (malignant & benign) 1878 patients from 1 medical organization 1 annotator per image, non-verified Dataset 2 Classes: • Malignant mass • Benign mass • Malignant calcification • Benign calcification • Skin thickening 200 patients from 1 medical organization 3 annotators per image, verified Dataset 3 Patient-level annotations (benign/malignant) 5720 patients from ~30 medical organizations Unknown annotators -
Example - Mammography datasets © 2020, ООО “Медицинские скрининг системы”
5 Dataset 1 Classes: • Mass (malignant & benign) • Calcifications (malignant & benign) 1878 patients from 1 medical organization 1 annotator per image, non-verified Dataset 2 Classes: • Malignant mass • Benign mass • Malignant calcification • Benign calcification • Skin thickening 200 patients from 1 medical organization 3 annotators per image, verified Dataset 3 Patient-level annotations (benign/malignant) 5720 patients from ~30 medical organizations Unknown annotators -
Example - Mammography datasets © 2020, ООО “Медицинские скрининг системы”
6 Dataset 1 Classes: • Mass (malignant & benign) • Calcifications (malignant & benign) 1878 patients from 1 medical organization 1 annotator per image, non-verified Dataset 2 Classes: • Malignant mass • Benign mass • Malignant calcification • Benign calcification • Skin thickening 200 patients from 1 medical organization 3 annotators per image, verified Dataset 3 Patient-level annotations (benign/malignant) 5720 patients from ~30 medical organizations Unknown annotators -
Example - Mammography datasets © 2020, ООО “Медицинские скрининг системы”
7 Dataset 1 Classes: • Mass (malignant & benign) • Calcifications (malignant & benign) 1878 patients from 1 medical organization 1 annotator per image, non-verified Dataset 2 Classes: • Malignant mass • Benign mass • Malignant calcification • Benign calcification • Skin thickening 200 patients from 1 medical organization 3 annotators per image, verified Dataset 3 Patient-level annotations (benign/malignant) 5720 patients from ~30 medical organizations Unknown annotators -
Terminology © 2020, ООО “Медицинские скрининг системы” • X -
input image or a series of images • y - target variable ◦ classification - normal/pathological ◦ sorting - risk score ◦ detection - bounding boxes ◦ segmentation - per-pixel masks -
Problem sources 1) X a) Different scanners b) Different image
acquisition protocols c) Human errors 2) Noisy y a) Inter-observer annotation variability b) Intra-observer annotation variability c) Unreliable data sources 3) Different label sets of y a) Different classes in the different datasets -
Problem sources #2 4) Weak y a) Image-, volume-, patient-level
annotations are cheaper and easier to acquire 5) Scarce y a) Annotation of medical images is expensive b) Some conditions are naturally rare -
Types of solutions • Prevention • Data-centric solutions • Architectural
modifications • Training process modifications • ... -
Our solution Universal image preprocessor • Artifact removal • Contrast/brightness
normalization • Correct color inversion & flip • Crop by the region of the interest • Unifying digitized film scans and digital scans • …. -
Out-of-Distribution in Production? • Classic CV methods • Unsupervised feature-based
methods • Image quality branch • Confidence branch -
Ambiguous “background” category © 2020, ООО “Медицинские скрининг системы” 22
Dataset 1 Bounding boxes: • Malignant mass • Benign mass • Malignant calcification • Benign calcification • Skin thickening Dataset 2 Bounding boxes: • Malignant mass • Benign mass We will penalize network for proposing non-annotated regions in Dataset 2 that contain objects! -
Reducing annotator variability • Prevention ◦ Creating and updating labeling
guides ◦ Exams for annotators • Post factum ◦ Automatic resolution of minor conflicts ◦ Additional expert opinion on major conflicts -
Dealing with noisy annotations during training • Dropping or re-weighting
noisy examples ◦ Usually doesn’t work well in the medical domain • Label smoothing ◦ Soft labels ◦ Smoothing for mask boundaries • Online noise correction ◦ Bounding box correction ◦ Mask refinement -
MIL upgrades • Other pooling techniques (LSEPooling) • Attention mechanisms
• Aggregating bags of local instances -
Training meta-models 1. Training detector/segmentator with existing small annotated datasets
2. Generating features for large weakly labeled dataset 3. Training simple meta-model to predict final target -
Gold standard datasets It is absolutely necessary to create and
update gold standard datasets: • Consensus labeling by at least 3 annotators • Preferably clinically verified • It must include all conditions that your system is supposed to detect But remember - every time you test your experiment on this dataset - you are one step closer to overfitting -
Main takeaways • You need to stay strong if you
want to work with the medical data -
Main takeaways • You need to stay strong if you
want to work with the medical data • It is both challenging and rewarding -
Main takeaways • You need to stay strong if you
want to work with the medical data • It is both challenging and rewarding • Read literature, but stay creative - every problem is unique -
Main takeaways • You need to stay strong if you
want to work with the medical data • It is both challenging and rewarding • Read literature, but stay creative - every problem is unique • Invest time and money into creating gold standard dataset for pre-release testing of all your crazy ideas
