PyCon Ireland 2013 Saturday Morning Keynote - Stephan Gorget (Facebook)

(via http://python.ie/pycon/2013/talks/datacenter_and_cluster_management__facebook/)
Datacenter and Cluster Management @ Facebook

Facebook is a company that moves fast, this means our infrastructure has to evolve quickly and adapt to the needs. We add, drain, put back to production and decommission datacenters and clusters almost on a daily basis. As the size of Facebook is increasing, it's becoming more and more complex to manage all those moving pieces. Facebook addresses the issue by writing a software that automates all those steps that compose the lifecycle of a cluster.

This talk will be about the journey of Facebook in that automation process and how python is used to build such a flexible tool.

Transcript

2. Data Center and Cluster Management at Facebook Stéphan Gorget
4. Servers Software Data Centers Network
5. The Site
6. Let’s talk about clusters
11. Cluster roles ? Service Cluster Back-End Cluster Front-End Cluster Web Ads Multifeed Other Services Cache Services
12. Tools for cluster management • Provisioning (Kobold) • Automatic remediation (FBAR) • Configuration (Configerator) • Monitoring (VipMonitor and others)
13. Going to automation
14. How was provisioning ? (2010) • One person knows it all ! • So we decided to write it down • No formal testing • and extremely manual
15. 2010 - Manual configuration
16. 2011 - And then Kobold
17. What does Kobold do ?
18. What is Kobold ? • Components are Python Objects • Support multiple operations • Populate directory service • Define cluster-level processes • Anything you can code !
19. What is Kobold ? • With those components, you create services : • Set up core services • Load balancer configuration • Memcache clusters • Configurable scope • World, Region, Datacenter, Cluster, POP
20. Where ?
21. Show me the code !
22. class Test(Service): requires = ['Init', 'Test2'] def __init__(self, options): Service.__init__(self, options) self.config = ComponentList() self.config += [ RandomComponent( name='my_random_component', targets=all_cluster_types, args={'foo': 'test.{c}'}, ) ] class RandomComponent(Component): def check(self, foo): value = int(random.random()*10) if (value % 2): self.err("Magic 8-ball says no.") return False else: self.ok("Magic 8-ball says yay!") return True def turnup(self, foo): self.ok("I just turned up '%s'." % foo) return True def drain(self, foo): self.ok("I just drained '%s'." % foo) return True
23. ➜ $ kobold check dc1c01 test [dc1c01] 1 service(s) lined-up: test. [dc1c01] Running 'check' for service 'test'... ! [dc1c01/check/test/my_random_component] Magic 8-ball says no. ! [dc1c01] Some components failed. Service 'test' failed. [dc1c01] 1 service(s) failed: test.
24. ➜ $ kobold turnup dc1c01 test [dc1c01] 1 service(s) lined-up: test. Ready to rock and roll? [yn] y [dc1c01] Running 'turnup' for service 'test'... ! [dc1c01/turnup/test/my_random_component] Magic 8-ball says no. * [dc1c01/turnup/test/my_random_component] I just turned up 'test.prn1c01'. [dc1c01] Service 'test' passed! [dc1c01] 1 service(s) passed: test.
25. ➜ $ kobold turnup dc1c01 test [dc1c01] 1 service(s) lined-up: test. Ready to rock and roll? [yn] y [dc1c01] Running 'turnup' for service 'test'... * [dc1c01/turnup/test/my_random_component] Magic 8-ball says yay! [dc1c01] Service 'test' passed! [dc1c01] 1 service(s) passed: test.
26. Did you say audit ?
27. Kobold UI
28. How bold is kobold ?
29. Results • Turn-up phases reduced • LBs configured in < 10 mins vs multiple days • Cluster turn up • From 7~8 Weeks in 2010 to < few days
30. Results • Service dependencies checked in seconds, instead of human iterating on data • No longer rely on tribal knowledge • Code as documentation • Some numbers : • 20k lines of code • 75+ components • 90+ services
31. More Automation
32. SSH in a FOR Loop for i in $webserver_list do ssh $i /etc/init.d/webserver restart done
33. Server Break/Fix • Deploy updated app versions • Restart services • Check for hardware failures • Swap systems • Clean up log spew
34. FBAR Retrieve Alerts Insert Jobs into Queue Calculate Jobs
35. FBAR Remediation Plugins FBAR API Repair API HW API Config API Mon API
36. FBAR Plugin1 Plugin2 Repair Resolve Escalate
37. Keys for automation
38. Automation • Use mental model -> translate to code • Humans are bad at repetitive work • They forget • They need sleep or • Don’t sleep at all and make mistakes • Machines don’t need hugs or feeding
39. Abstractions for automation • Build abstractions for human work • Extensible libraries breed bigger tools • Knobs & levers • Turn individual systems on & off • Shed load • Test things in production or in a subset of systems
40. Automation Pitfalls • Can mask systemic problems • Cascading failures • Unknown actors • Cultural fear
41. Conclusion • Automate as much as you can • Write code that is an abstraction • Test your code • Create libraries and APIs to control everything
42. Thank you for your attention
