  1. Revealing BlueStore Corruption Bugs
    in Containerized Ceph Clusters
    Nov. 11st, 2022
    Cybozu, Inc.
    Satoru Takeuchi
    1

    View Slide

  2. Table of Contents
    2
    ▌Cybozu and our infrastructure
    ▌What kind of bugs we have revealed
    ▌Why we hit these bugs
    ▌Proposals to improve the official QA process
    ▌Conclusion

    View Slide

  3. Table of Contents
    3
    ▌Cybozu and our infrastructure
    ▌What kind of bugs we have revealed
    ▌Why we hit these bugs
    ▌Proposals to improve the official QA process
    ▌Conclusion

    View Slide

  4. What is Cybozu
    ▌A leading cloud service provider in
    Japan
    ▌Providing software that supports
    teamwork
    4

    View Slide

  5. Cybozu’s infrastructure
    ▌The current infrastructure is a
    traditional VM-based system
    ▌Developing a new modern
    containerized infrastructure
    ⚫Using Kubernetes
    ⚫Using Rook/Ceph as storage
    5

    View Slide

  6. The characteristics of modern
    containerized systems
    ▌Easy to deploy/manage than traditional
    systems
    ▌Restart both nodes and containers
    frequently
    ▌Usually run integration tests per PR
    ⚫Create/restart containers during tests
    6

    View Slide

  7. The characteristics of the
    development of our infrastructure
    ▌Create Ceph clusters frequently
    ▌Create and restart OSDs frequently
    7

    View Slide

  8. Development strategy
    1. Every change (PR) to our infrastructure kicks
    integration tests in VM-based test environments
    ⚫Each test environment emulates the whole data center
    having two Rook/Ceph clusters
    2. If this test passed, apply changes to the on-
    premise staging system
    3. If the staging system works fine, apply changes
    to the on-premise production system
    8

    View Slide

  9. When we create/restart OSDs
    ▌For each integration test
    ⚫Creates two Rook/Ceph clusters (totally > 10 OSDs)
    ⚫Restarts all nodes (it implies all OSDs)
    ⚫This test runs > 10 times a day
    ▌Restart all nodes of the staging environment once
    per week
    ⚫To verify our infrastructure’s availability and update
    firmware
    ⚫The staging environment has about 100 OSDs
    9

    View Slide

  10. # of OSD creation/restart
    ▌Estimated values from test/operation logs
    ⚫3000/month for both creating/restarting OSD
    ▌I believe that it’s a far larger number than
    traditional non-containerized Ceph clusters
    10

    View Slide

  11. Table of Contents
    11
    ▌Cybozu and our infrastructure
    ▌What kind of bugs we have revealed
    ▌Why we hit these bugs
    ▌Proposals to improve the official QA process
    ▌Conclusion

    View Slide

  12. The bugs we have revealed
    ▌3 bugs: failed to create a new OSD
    ▌2 bugs: bluefs corruption just after
    restarting an OSD
    12

    View Slide

  13. List of bugs (1/5)
    ▌osd: failed to initialize OSD in Rook
    ⚫https://tracker.ceph.com/issues/51034
    ▌Failed to prepare a new OSD
    ▌Due to the inconsistency of write I/O
    ▌Fixed by
    ⚫ https://github.com/ceph/ceph/pull/42424
    13

    View Slide

  14. List of bugs (2/5)
    ▌OSD::mkfs: ObjectStore::mkfs failed
    with error (5) Input/output error
    ⚫https://tracker.ceph.com/issues/54019
    ▌Failed to prepare a new OSD
    ▌Not fixed yet
    14

    View Slide

  15. List of bugs (3/5)
    ▌failed to start new osd due to SIGSEGV
    in BlueStore::read()
    ⚫https://tracker.ceph.com/issues/53184
    ▌Succeeded to prepare a new OSD
    but failed to start this OSD
    ▌Not fixed yet
    15

    View Slide

  16. List of bugs (4/5)
    ▌rocksdb crushed due to checksum mismatch
    ⚫https://tracker.ceph.com/issues/57507
    ▌Bluefs corruption just after restarting an OSD
    ▌Due to collision between BlueFS and BlueStore
    deferred write
    ▌Probably fixed by
    ⚫https://github.com/ceph/ceph/pull/46890
    16

    View Slide

  17. List of bugs (5/5)
    ▌bluefs corrupted in a OSD
    ⚫https://tracker.ceph.com/issues/48036
    ▌bluefs corruption just after restarting an OSD
    ▌Due to the lack of mutual exclusion in
    Rook
    ▌Fixed by
    ⚫https://github.com/rook/rook/pull/6793
    17

    View Slide

  18. Additional information
    ▌We hit many of these bugs for the first
    time
    ▌Most bugs were detected in OSD on HDD
    ⚫HDD seems to be good for detecting these
    kinds of bugs
    ▌All bugs can be reproduced by stress tests
    ⚫Creating/restarting OSDs continuously
    18

    View Slide

  19. Table of Contents
    19
    ▌Cybozu and our infrastructure
    ▌What kind of bugs we have revealed
    ▌Why we hit these bugs
    ▌Proposals to improve the official QA process
    ▌Conclusion

    View Slide

  20. Questions
    ▌Why Cybozu hit these bugs for the first
    time?
    ▌Why Ceph’s official QA process hasn’t
    detected these bugs?
    20

    View Slide

  21. My hypotheses
    ▌The number of OSD creation/restart in
    Cybozu is far larger than the official QA
    ▌The official QA hasn’t used HDD for
    OSD
    21

    View Slide

  22. # of OSD creation/restart in the
    official QA
    ▌Original data
    ⚫The records of “pulpito.ceph.com” during Sep. 2022
    ▌OSD creation: > 120000/month
    ⚫~30000 jobs * ~4 OSDs per tests
    ▌OSD restart: < 500/month
    ⚫Only happen in upgrade tests
    ⚫# of upgrade test cases is small
    ⚫Usually only runs before the new releases
    22

    View Slide

  23. Comparing the numbers
    23
    ▌My hypotheses were…
    ⚫not correct about OSD creation
    ⚫correct about OSD restart
    Cybozu The Official QA
    # of OSD creation/month > 3000 > 120000
    # of OSD restart/month > 3000 < 500

    View Slide

  24. Does official QA use HDD?
    ▌Many machines in Sepia Lab have both HDD
    and NVMe SSD
    ⚫https://wiki.sepia.ceph.com/doku.php?id=hardw
    are:infrastructure
    ▌I couldn’t find whether the official QA uses
    HDD for OSD or not
    ⚫Please let me know if you know anything about it
    24

    View Slide

  25. Table of Contents
    25
    ▌Cybozu and our infrastructure
    ▌What kind of bugs we have revealed
    ▌Why we hit these bugs
    ▌Proposals to improve the official QA process
    ▌Conclusion

    View Slide

  26. Proposal(1/2)
    ▌Adding the stress tests about restarting OSD
    ▌It would be nice to detect bluefs corruption
    bugs just after restarting OSD
    ▌If we use 10 OSDs and restarting one OSD
    takes 3 minutes, # of restarting OSD is ~5000
    per day
    ⚫Ref. 3000/month(Cybozu) and 500/month(the
    Official QA)
    26

    View Slide

  27. Proposal(2/2)
    ▌If the official QA hasn’t used HDD for
    OSD, using them would improves the
    official QA
    ▌It also makes the stress test of
    restarting OSD better
    27

    View Slide

  28. Table of Contents
    28
    ▌Cybozu and our infrastructure
    ▌What kind of bugs we have revealed
    ▌Why we hit these bugs
    ▌Proposals to improve the official QA process
    ▌Conclusion

    View Slide

  29. Conclusion
    ▌The development of Cybozu’s modern containerized
    Ceph clusters revealed many bluefs corruption bugs
    ▌The key factors
    ⚫The frequency of creating/restarting OSDs
    ⚫OSD on HDD
    ▌The official QA would be better if
    ⚫Adding the stress test of restarting OSD
    ⚫Use HDD for OSD (if it hasn’t been used)
    29

    View Slide

  30. Thank you!
    30
