GCP GIS Quickstart

Sergei Kozyrenko
CTO, Parknav

Transcript

1. GCP GIS Quickstart Sergei Kozyrenko CTO, Parknav sergei@parknav.com
2. Parknav See Street Parking Availability in US and Germany
3. Managed Everything Cloud SQL, Memorystore, Kubernetes • High Availability • Failover • Patches • Monitoring • Logs
4. Cloud SQL • Postgres 9.6, PostGIS 2.3 • Enable PostGIS: create extension postgis; • https://cloud.google.com/sql/docs/postgres/extensions
5. Cloud SQL The bigger the disk space/machine size, the higher the throughput
6. Demo: RideAustin data https://data.world/ride-austin/ride-austin-june-6-april-13
7. Demo: app that queries and shows RideAustin data on the map https://github.com/kozyr/gis-java-sql
8. PostGIS - Geometry columns Add geometry columns for faster queries SELECT AddGeometryColumn ('public','ride','end_geom',3857,'POINT',2); update ride set end_geom=ST_Transform(ST_SetSRID(ST_Point(end_location_long,end_location_lat),4326),3857); CREATE INDEX idx_ride_end_geom ON ride USING gist(end_geom);
9. Geometry Columns vs Geography https://medium.com/coord/postgis-performance-showdown-geometry-vs-ge ography-ec99967da4f0
10. Geometry vs Geography speedup
11. Demo: Geometry columns, GeoJSON
12. Java and GIS Lots of libraries: • hibernate-spatial (part of hibernate core as of hibernate 5) • JTS • GeoTools
13. Java Topology Suite (JTS) https://github.com/locationtech/jts • Classes for representing geometries on a plane - Points, Polygons, LineStrings, etc. • Area and distance calculation, buffer computation, geometric simplification, spatial index with quadtree and STR-tree, convex hull, spatial graphs, WKT/WKB/GML support and many more features • GEOS, a port of JTS into C/C++, is widely used and is present in QGIS, PostGIS, R, GeoDjango etc.
14. hibernate-spatial Works with JPA, Spring Data and JTS to make storing/retrieving geometry columns easy
15. hibernate-spatial and spring-data-jpa
16. GeoTools http://geotools.org/ Builds on JTS, adds support for converting between different coordinate systems - see TransformHelper in the demo app
17. Kubernetes Great way to run arbitrary Java apps on GCP
18. Cloud SQL and Kubernetes https://cloud.google.com/sql/docs/postgres/connect-kubernetes-engine Cloud SQL Proxy as sidecar service
19. Cloud SQL and k8s CronJobs Cloud SQL Proxy does not terminate by itself when cron job is done Solution: kill the proxy manually - name: cloudsql-proxy image: gcr.io/cloudsql-docker/gce-proxy:1.11 command: ["sh", "-c"] args: - /cloud_sql_proxy -instances=... -credential_file=... & pid=$! && (sleep 30 && kill -9 $pid 2>/dev/null)
20. Cloud Memorystore Redis 3.2.11, GA from Sep 19, 2018 Supports spatial operations via geohash
21. Redis: Demo MSET 592590 json1 592617 json2 GEOADD ride 30.272 -97.726 592590 GEOADD ride 30.291 -97.741 592617 keys = GEORADIUS ride 15 30.272 -97.726 m WITHDIST MGET key1 key2
22. Thanks!
