1. Introduction and overview DOJO Antwerp 8th Apr 2013 Vincent Van der Kussen @vincentvdk - #vincent_vdk
2. DOJO Why this talk? Why this talk? • Initial oVirt relaeses based on Fedora Initial oVirt relaeses based on Fedora • Now being build for .el6 by oVirt project Now being build for .el6 by oVirt project • Goal : Testing CentOS builds Goal : Testing CentOS builds You can help!
3. DOJO CentOS repo CentOS repo [ovirt_test] name=CentOS-$releasever - oVirt-Test baseurl=http://dev.centos.org/centos/6/ovirt/x86_64/ gpgcheck=1 Priority=1 enabled=1 gpgkey=http://mirror.centos.org/centos/RPM-GPG-KEY- CentOS-Testing-6
4. DOJO What is oVirt What is oVirt (10.000 feet view) (10.000 feet view) * Can be part of a cloud setup • NACP - Not Another Cloud Platform* NACP - Not Another Cloud Platform* • Virtualization management platform. Virtualization management platform. • KVM KVM • Key components : Key components : – oVirt Engine oVirt Engine (management) (management) – oVirt Node oVirt Node (hypervisor) (hypervisor)
5. DOJO Some features Some features • Live migration Live migration • Load balancing Load balancing • Hot Plug Hot Plug disks and NICs disks and NICs • ISCSI, FC, NFS, Gluster ISCSI, FC, NFS, Gluster • Snapshots Snapshots • WebUI, API, shell WebUI, API, shell • VLANs, Bonds VLANs, Bonds • Quota Quota – Limit users or groups to a certain amount of resources Limit users or groups to a certain amount of resources
6. DOJO Architecture Architecture
7. DOJO ovirt-engine ovirt-engine • Java app running on JBoss Java app running on JBoss • Provides Provides – Web based interface Web based interface – API API • Authentication / Authorization Authentication / Authorization – Currently only FreeIPA / AD / IBM Currently only FreeIPA / AD / IBM – 1 local admin account 1 local admin account • Stores VM info in DB Stores VM info in DB
8. DOJO # yum install ovirt-engine # engine-setup
9. DOJO Installing: Creating JBoss Profile... [ DONE ] Creating CA... [ DONE ] Setting Database Security... [ DONE ] Creating Database... [ DONE ] Updating the Default Data Center Storage Type... [ DONE ] Editing JBoss Configuration... [ DONE ] Editing oVirt Engine Configuration... [ DONE ] Configuring the Default ISO Domain... [ DONE ] Starting JBoss Service... [ DONE ] Configuring Firewall (iptables)... [ DONE ] **** Installation completed successfully *****
10. DOJO oVirt Node oVirt Node • Hypervisor host Hypervisor host • 2 ways to install 2 ways to install – ISO ISO (jeos) (jeos) • PXE PXE • USB USB • Needs approval in ovirt-engine Needs approval in ovirt-engine – Existing/new CentOS install Existing/new CentOS install • Install triggered from the ovirt-engine Install triggered from the ovirt-engine
11. DOJO Terminologie Terminologie • DATACENTER(S) DATACENTER(S) • That contains That contains CLUSTER(S) CLUSTER(S) • That contains That contains HOSTS,NETWORKS HOSTS,NETWORKS • That contains That contains VMs VMs
12. DOJO
13. DOJO Datacenter Datacenter • Does not mean a physical DC :-) Does not mean a physical DC :-) • Logical container of resources. Logical container of resources. – Hosts, networks, storage, .... Hosts, networks, storage, .... • Can have max. 200 hosts (=physical) Can have max. 200 hosts (=physical) • SPM (Storage Pool Manager) SPM (Storage Pool Manager) – Runs on Runs on one host one host in the datacenter in the datacenter
14. DOJO Cluster Cluster • Logical group of hosts. Logical group of hosts. • Enable Gluster / Virt service Enable Gluster / Virt service • Cluster policy Cluster policy – Power saving Power saving – Even distribution Even distribution • Resilience policy Resilience policy – Set whether VMs can migrate in the cluster. Set whether VMs can migrate in the cluster.
15. DOJO Hosts Hosts • They run VMs. Yeay! They run VMs. Yeay! • SPM priority SPM priority • Connect to storage Connect to storage • Runs the VDSM daemon Runs the VDSM daemon • .... that's it .... that's it
16. DOJO VDSM VDSM • V Virtual irtual D Desktop and esktop and S Server erver M Manager anager • Runs on the hypervisor node Runs on the hypervisor node • Tracks memory and network resources Tracks memory and network resources • Manages vm creation, log collection, shared Manages vm creation, log collection, shared storage, .. storage, .. • Communicates with Communicates with – Libvirt for VM lifecycle Libvirt for VM lifecycle – oVirt-agent (runs on VM) oVirt-agent (runs on VM)
17. DOJO VDSM Hooks VDSM Hooks • Use new Libvirt/KVM Use new Libvirt/KVM feature. feature. • Can be initiated at Can be initiated at the Vms lifecycle the Vms lifecycle
18. DOJO STORAGE
19. DOJO Storage Storage • File based File based – NFS NFS – POSIX POSIX – Gluster Gluster • QCOW2 and RAW QCOW2 and RAW • Block based Block based – FC FC – iSCSI iSCSI • LUN LUN • Direct LUN Direct LUN
20. DOJO Storage Pool Manager Storage Pool Manager • One One SPM in each Datacenter SPM in each Datacenter • Can write storage domain metadata Can write storage domain metadata – Other hosts read from here Other hosts read from here • SPM role is selected by the ovirt-engine SPM role is selected by the ovirt-engine
21. DOJO Storage Domains Storage Domains • ISO domain ISO domain – NFS share NFS share – Holds the ISOs of a Datacenter Holds the ISOs of a Datacenter • EXPORT domain EXPORT domain – NFS NFS – Export / Import VMs Export / Import VMs • DATA domain DATA domain – Holds the VM disks Holds the VM disks
22. DOJO Storage Domains Storage Domains (block based!) (block based!) • Storage Domain = Volume Group Storage Domain = Volume Group [root@node-05 ~]# vgs VG #PV #LV #SN Attr VSize VFree 9d1a1691-9d36-49b7-bc8a-aac13175689a 1 15 0 wz--n- 1.82t 1.72t vg_node05 1 3 0 wz--n- 465.27g 0 [root@node-05 ~]#
23. DOJO [oVirt shell (connected)]# list storagedomains id : 9d1a1691-9d36-49b7-bc8a-aac13175689a name : DATA1 id : 88ead5c8-6747-4378-8529-4638524cef09 name : ISO [oVirt shell (connected)]# VG maps to the Storage Domain's Id
24. DOJO [oVirt shell (connected)]# list disks --vm-identifier centos_srv02 id : a0807542-d2e4-41d4-8873-4afe52285992 name : centos_srv01_Disk1 [oVirt shell (connected)]# So disks are LVs then? Could it be? Let's find out....
25. DOJO [oVirt shell (connected)]# show disk --id a0807542-d2e4-41d4-8873- 4afe52285992 id : a0807542-d2e4-41d4-8873-4afe52285992 name : centos_srv01_Disk1 actual_size : 1073741824 alias : centos_srv01_Disk1 bootable : True format : cow image_id : e070da65-5ff1-4248-bee5-42e6dbeaa627 interface : virtio propagate_errors : False provisioned_size : 21474836480 quota-id : 00000000-0000-0000-0000-000000000000 shareable : False size : 21474836480 sparse : True status-state : ok storage_domains-storage_domain-id: 9d1a1691-9d36-49b7-bc8a-aac13175689a wipe_after_delete : False [oVirt shell (connected)]# Volume Group
26. DOJO [root@node-05 ~]# lvs LV VG Attr LSize Pool Origin Data% Move Log Cpy%Sync Convert 0cda4fd9-5cc6-43ae-b5fe-4900e9184cc5 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-ao--- 1.00g 2393c936-4e77-41e1-aa16-8a2fd122eca9 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-ao--- 2.00g 4239e2b1-60cf-4f5c-a362-aefe12519810 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-ao--- 20.00g 709f5ab6-9b96-461e-b3c9-b078c7fcc898 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-a---- 20.00g b5aa7025-cb68-4a87-9fcb-2536ca6fb93b 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-ao--- 5.00g b85450b0-f068-4938-a827-55fe8c1339e6 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-ao--- 20.00g e070da65-5ff1-4248-bee5-42e6dbeaa627 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-a---- 1.00g f3797b3c-c9d7-4e6b-a20f-bbcabecd59df 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi------ 10.00g fd45936b-5bfa-4d39-b0c7-0f2558c33260 9d1a1691-9d36-49b7-bc8a-aac13175689a -wi-ao--- 20.00g
27. DOJO Storage Allocation Storage Allocation • Preallocated Preallocated – Better performance Better performance – Typically for machines with high IO Typically for machines with high IO • Sparsely allocated Sparsely allocated – Test machines, desktops Test machines, desktops – Grows with 1GB chunks Grows with 1GB chunks
28. DOJO Storage features Storage features • Live Snapshots Live Snapshots • Live storage migration Live storage migration • Clone from snapshots Clone from snapshots
29. DOJO Network
30. DOJO Networks Networks • Logical networks Logical networks – ovirtmgm ovirtmgm is defined by default is defined by default – Group network traffic. Ex : storage network, vlan Group network traffic. Ex : storage network, vlan – Defined at the Defined at the datacenter level datacenter level – Can be made required at the cluster level Can be made required at the cluster level – It's actually a Bridge It's actually a Bridge
31. DOJO Networks Networks [root@node-05 ~]# brctl show bridge name bridge id STP enabled interfaces ;vdsmdummy; 8000.000000000000 no deathstar 8000.002590374880 no eth0.2 dojo_net 8000.002590374880 no eth0.1 ovirtmgmt 8000.002590374881 no eth1
32. DOJO Networks Networks • vNICS are connected to the logical network = vNICS are connected to the logical network = bridge bridge
33. DOJO Networks Networks Combinations Combinations • NICS + BRIDGE NICS + BRIDGE • BONDS + BRIDGE BONDS + BRIDGE • NIC + VLANs + Multiple Bridges NIC + VLANs + Multiple Bridges • BOND + VLANs + Multiple Bridges BOND + VLANs + Multiple Bridges
34. DOJO Networks Networks BOND + VLANs + Multiple Bridges
35. Management
36. DOJO • Web interface Web interface – Administrator Administrator – User portal User portal • CLI CLI • SDK SDK – Python Python – Java Java
37. DOJO
38. DOJO ovirt-shell ovirt-shell • Manage oVirt from the CLI Manage oVirt from the CLI • Has tab completion Has tab completion • Wrapper for REST API Wrapper for REST API • Same functionality than the web interface Same functionality than the web interface
39. DOJO # yum install ovirt-engine-cli On Fedora / CentOS Or from PyPi pip-python install ovirt-shell
40. DOJO Copy the certificate # scp root@ovirt-engine:/etc/pki/ovirt-engine/ca.pem \ ovirt-engine.pem
41. DOJO Connect to the ovirt-shell # ovirt-shell -c -l https://ovirt-engine.test.btr.local/api -u \ admin@internal -A ovirt-engine.pem
42. DOJO Demo
43. DOJO [oVirt shell (connected)]# ping success: oVirt manager could be reached OK. [oVirt shell (connected)]# Test Connection
44. DOJO [oVirt shell (connected)]# list vms |grep name name : centos_srv01 name : centos_srv02 name : centos-srv03 name : clone_from_snap name : serverfromcli name : testfrom-cli [oVirt shell (connected)]# Pipe output
45. DOJO list vms --query status=down Run queries Start / stop a VM action vm centos_srv02 start action vm centos_srv02 stop
46. DOJO add host --address node-10.test.btr.local --root_password centosdojo --cluster-name ninja_team --name node- 10.test.btr.local Add a hypervisor host add vm --name serverfromcli --cluster-name ninja_team --memory 1073741824 --cpu-topology-cores 2 --cpu- topology-sockets 1 --template-name Blank --type server Add a VM
47. DOJO add disk --size 10737418240 --format raw --interface virtio --storage_domains-storage_domain "storage_domain.name=DATA1" --sparse fal Add a disk to a storage domain list vms --kwargs placement_policy affinity=user_migratable Show a lists of VMs that are user migrateable
48. DOJO SDK
49. DOJO • Bindings Bindings – Python Python – Java Java – Ruby (rbovirt) Ruby (rbovirt) • Integrate with your infrastructure. Integrate with your infrastructure. • Used scripts Used scripts – https://github.com/vincentvdk/ovirt-scripts https://github.com/vincentvdk/ovirt-scripts
50. DOJO # yum install ovirt-engine-sdk
51. DOJO Demo
52. DOJO Extendable Extendable • Foreman integration Foreman integration • Monitoring Monitoring • Offloading thin provisioning to the SAN box Offloading thin provisioning to the SAN box (NetApp) (NetApp) • Aeolusproject Aeolusproject • Quantum Quantum
53. DOJO Future ? Future ? • Openstack integration Openstack integration – https://blueprints.launchpad.net/nova/+spec/rhev- https://blueprints.launchpad.net/nova/+spec/rhev- m-ovirt-clusters-as-compute-resources m-ovirt-clusters-as-compute-resources The proposal is to have a nova compute proxy connects to a RHEV-M/oVirt through oVirt Rest APIs and expose configured clusters as a compute hosts.
54. DOJO Not so great stuff (imho) Not so great stuff (imho) • VM poweroff to remove snapshot VM poweroff to remove snapshot • Storage can be weird Storage can be weird • Engine Engine (out of the box) (out of the box) = SPOF = SPOF • No ldap (other than FreeIPA/RHDS / No ldap (other than FreeIPA/RHDS / • No local users other than admin@internal No local users other than admin@internal
55. DOJO More information More information • CentOS wiki CentOS wiki – http://wiki.centos.org/HowTos/oVirt?highlight=%28ovirt%29 http://wiki.centos.org/HowTos/oVirt?highlight=%28ovirt%29 • oVirt website oVirt website – http://www.ovirt.org http://www.ovirt.org • #ovirt on OFC #ovirt on OFC • Jason Brooks' blog Jason Brooks' blog – http://blog.jebpages.com/ http://blog.jebpages.com/ • Scripts using rest api Scripts using rest api – https://github.com/dougsland/ovirt-restapi-scripts https://github.com/dougsland/ovirt-restapi-scripts
56. DOJO Thank you! @vincentvdk #vincent_vdk vincent@vanderkussen.org http://blog.vanderkussen.org
