Transcript
MuleSoft 2017
Hoje vamos falar de mock dados usando o Set
payload
Vamos criar um fluxo com da seguinte forma (Poll, set
Payload, Transform Message, log)
Mude a execução do Poll para minutos para não executa
a cada um segundo
Nosso transform espera receber uma lista de json com (Nome,
Descricao e Valor) então preciso passa essa estrutura com valores para testar.
Estrutura json [ { "Nome":"pao", "Descricao":"pao de queijo", "Valor":"1"
}, { "Nome":"queijo", "Descricao":"queijo coalho", "Valor":"2" } ]
No Set Payload no quadro value você tem que preenche
com o json semelhante com a esperada
Json setado no set payload e type MIME e Encoging
Rodando o projeto em modo Debug com break no Set
payload Payload vázio
Depois do set Payload o valor do set payload foi
atribuído ao payload
Resultado depois do transform uma lista conforme a saída setado
no transform
<?xml version="1.0" encoding="UTF-8"?> <mule xmlns:dw="http://www.mulesoft.org/schema/mule/ee/dw" xmlns:metadata="http://www.mulesoft.org/schema/mule/metadata" xmlns="http://www.mulesoft.org/schema/mule/core" xmlns:doc="http://www.mulesoft.org/schema/mule/documentation"
xmlns:spring="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring- beans-current.xsd http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd http://www.mulesoft.org/schema/mule/ee/dw http://www.mulesoft.org/schema/mule/ee/dw/current/dw.xsd"> <flow name="mock-set-payloadFlow"> <poll doc:name="Poll"> <fixed-frequency-scheduler frequency="1000" timeUnit="MINUTES"/> <logger message="====Start=====" level="INFO" doc:name="Logger"/> </poll> <set-payload value="[ { "Nome":"pao", "Descricao":"pao de queijo", "Valor":"1" },
{ "Nome":"queijo", "Descricao":"queijo coalho", "Valor":"2"
} ]" encoding="UTF-8" mimeType="application/json" doc:name="Set Payload"/> <dw:transform-message metadata:id="a1c6eb81-1b6a-4655-b17f-2ee3d5afb0e0" doc:name="Transform Message"> <dw:input-payload doc:sample="input.json" mimeType="application/json"/> <dw:set-payload><![CDATA[%dw 1.0 %output application/java --- payload map ((payload01 , indexOfPayload01) -> { name: payload01.Nome, description: payload01.Descricao, value: payload01.Valor })]]></dw:set-payload> </dw:transform-message> <logger message="=====resultado======#[message.payloadAs(java.lang.String)]" level="INFO" doc:name="Logger"/> </flow> </mule>
FIM
